Essential Garden C-160-2GGZ User manual

1
owner’s
manual
Date of purchase: _____/ _____/ _____
Product code: 0-01288493-8
UPC code: 769455755438
Vendor Item: C-160-2GGZ
Dunes Gazebo Canopy Replacement

PARTS
Read through all the instructions before beginning assembly. Unpack and identify all the parts.
Place them on a flat, non-abrasive surface. Assembly by six people is recommended.
ACCESSORIES
#1 (6)
Crossbar
#2 (12)
Top Crossbar
#4 (12 + 1 spare)
Bolt
#7 (1)
Assembly
Instructions Sheet
2
#8 (1)
Allen Wrench
#6 (1)
New Canopy
#5 (12 + 1 spare)
Nut
#9 (1)
Open Hex Wrench
#3 (1)
Finial Top
Use the follwing parts from your orignal gazebo Use the follwing parts from the hardware
1
owner’s
manual
Dateof purchase: _____/ _____/ _____
Productcode: 8-5001288493-8
UPCcode: 769455755438
VendorItem: C-160-2GGZ
DunesGazebo Canopy Replacement
Special Warning
Assemble your gazebo on a soft, non-abrasive surface to avoid damage. The gazebo is heavy. Use care when handing.
Assembly by four adults is recommended. The gazebo is not intended to be a permanent structure. Take it down during
high winds or it may be damaged.
KEEP ALL FLAME AND HEAT SOURCES AWAY FROM CANOPY FABRIC
The canopy is made with flame-resistant fabric which meets CPAI-84 specifications. It is not fireproof. The canopy fabric
will burn if left in continuous contact with flame source. The application of any foreign substance to the canopy fabric
may render the flame-resistant properties ineffective.

3
ASSEMBLY INSTRUCTIONS
1
2
PROCESS OF REMOVING GAZEBO CANOPY
Remove the tips of top crossbars (#2) from the
pocket of old large canopy. See Fig. 1A. Then
remove bolts (#4) and nuts (#5) which attached
on the crossbars (#1) and top crossbars (#2).
See Fig. 1B.
Remove the finial top (#3) from the top of
canopy frame. See Fig. 2A. Then remove the
top crossbars (#2) from the old large canopy.
See Fig. 2B.
Fig. 1B
Fig. 1A
52
146
2
33
2
6
Fig. 2A
Fig. 2B

CARE INSTRUCTIONS
Wash with a mild solution of soap and water; rinse thoroughly. Dry completely. Do not use bleach or solvents.
Cover furniture with outdoor furniture covers when not in use.
4
Attach the new canopy (#6) to top crossbars (#2)
by inserting the top crossbars into the holes of
the canopy. See Fig. 3A. Tighten the finial top (#3)
onto the top of the canopy. See Fig. 3B.
Attach the assembled canopy top onto the
crossbars (#1), using bolts (#4), nuts (#5).
(Make sure the valances locate outside of the
crossbars (#1)), See Fig. 4A. Pull down the
edge of the canopy (#6) and slide each tip end
of the canopy frame bar (#2) into the corner
pocket of the canopy. See Fig. 4B.
Your gazebo with new canopy is now ready for use. Enjoy!
3
4
PROCESS OF REPLACING NEW GAZEBO CANOPY
Fig. 3B
Fig. 3A
6
33
6
2
Fig. 4A
Fig. 4B
52
4
16
2
Made in CHINA for Kmart Corporation, Hoffman Estates, IL 60179
SHOP kmart.com
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
For questions or comments about product:
Call toll-free: 800-457-4652
Please refer to part numbers when reordering
