Treasure Garden AD45 Cantilever Installation instructions

AD45
11’
OC /10’ SQ /8’ SQ
Cantilever
Assembly and Operation Guide
www.treasuregarden.com
©2013 Treasure Garden, nc. - All Rights Reserved. Rev. 3/13

E
O
A
D
B
C
H
I
J
M
L
K
N
F
G
A- Cross Bars (2) F- Gasket K- Canopy Support Beam
B- Foot Pedal G- Knob L- Finial
C- Rotating Hub Cover H- Crank Handle M- Canopy
D- Rotating Hub I- Main Frame N- Ribs
E- Main Frame Support Tube J- Main Frame Grip O- Vega™Light Adapter
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 1 year from the date of purchase.
f a defect in the original material or
workmanship appears during the warranty
period; Treasure Garden will (at its option)
repair or replace the product without
charge. Limited warranty against fabric
fading, based on fabric grade.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
n many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
n the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the first
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
Thank you for your purchase of Treasure Garden’s AD45 Cantilever Umbrella.
Please remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your AD45, read and follow this
assembly and operation guide We recommend a two-person team for assembly and
disassembly. Save information for future reference.
S A F E T Y P R E C A U T O N S :
• Close the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Do not leave open umbrella unattended. f damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
C A R E A N D M A N T E N A N C E :
• When not in use, close and cover umbrella with a protective cover (sold separately).
• Allow a wet canopy to dry opened up.
• f necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry, protective place.
• Any visible defects must be repaired by a professional.
After the Winter:
• Areas subject to turning and sliding can be treated with a non-staining lubricant spray
(silicone-based).
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
101
AD45 CHECKLIST

To ATTACH Umbrella Li ht:
Loosen the light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 25). After loosening, pull down light adapter post (Fig. 26) to attach the
umbrella light (Fig. 27 and 28) (sold separately).
To REMOVE Umbrella Li ht and CLOSE adapter:
Remove umbrella light, and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 25).
(Fig. 25) (Fig. 26)
(Fig. 27) (Fig. 28)
AD45 Features
AD45 PART LIST
Part Description Qty.
1 Cross Bars 2
2 Main Frame with Canopy 1
3 Support Stem 1
4 Main Frame Support Tube 1
5 Gasket 1
6 Rotating Hub Cover 1
7 Rotating Hub 1
8 Foot Pedal 1
9 Knob 1
10 Crank Handle 1
11 Large Bolts 4
12 Medium Bolts 4
13 Small Screw 1
14 Washers 8
15 Wrench 1
REQUIRED FOR ASSEMBLY:
• One (1) Phillips Screwdriver
• Four (4) 40 lb. weights - square stones or concrete weights. (160 lb. total weight
needed for support - weights not included) Stones & weights, standard sizes
can be used up to 20" L x 20" W x 1.5" H.
NOTE: Using the cross bar stand without weights will damage your umbrella
and may cause in ury.
2
9

(Fig. 1)
S T E P 1 Assemble Cross Bar Stand
Select area to set AD45 base and place in desired location. Set cross bars in a cross position
(Fig. 1). Secure stand with (4) square stones or concrete weights (weights not
included).
IMPORTANT: Cross bar stand will not support umbrella without proper weights.
Using the stand without weights will damage your umbrella.
S T E P 8 Closin AD45
To close umbrella, squeeze main frame grip handle (Fig. 21) and slide grip handle down to
closed position (Fig. 22). Turn crank handle counter-clockwise (Fig. 23) until
umbrella is closed (Fig. 24). Use ties to secure canopy to the main frame when umbrella is
not in use.
(Fig. 21)
(Fig. 23) (Fig. 24)
38
S T E P 2Assemble AD45 Rotatin Hub to Cross Bar Stand
Attach foot pedal to rotating hub (Fig. 2). Turn rotating hub on side and secure foot
pedal with small screw underneath foot pedal by tightening with phillips screwdriver
(Fig. 3). Turn rotating hub upright and set onto cross bar stand (Fig. 4). By lining up
holes, attach rotating hub to cross bar stand with 4 supplied large bolts and washers.
Tighten with supplied wrench (Fig. 5).
(Fig. 4)
(Fig. 3)
(Fig. 5)
(Fig. 2)
(Fig. 22)
S T E P 7 Rotatin AD45 360°
Place your foot on the foot pedal of the rotating hub and place hands on the main frame
(Fig. 19). Swivel the umbrella frame in either direction until desired position is reached.
There are 12 locking positions for the AD45 to rotate 360° (Fig. 20). Step off the foot
pedal to engage rotating lock. Your umbrella will now be locked into desired location.
(Fig. 19) (Fig. 20)

47
S T E P 3 Assemble AD45 Support Stem to Rotatin Hub
Slide support stem over rotating hub (Fig. 6) and line up holes. Tighten with 4
supplied medium bolts and washers. Tighten with supplied wrench (Fig. 7). Slide
rotating hub cover over rotating hub (Fig. 8).
(Fig. 7)
(Fig. 8)
(Fig. 6)
Tilt Positions (Fig. 18)
S T E P 6 Tiltin AD45
To tilt umbrella, squeeze the main frame grip handle (Fig. 17) and slide handle to desired tilt
position (Fig. 18). Release main frame grip handle to lock into tilt position.
(Fig. 17)
Tilt Position #5 Hole
Tilt Position #4 Hole
Tilt Position #3 Hole
Tilt Position #2 Hole
Tilt Position #1 Hole
Tilt Position #6/Closed
Horizontal Position Hole
Tilt Position #1 Tilt Position #2
Tilt Position #3 Tilt Position #4 Tilt Position #5
Horizontal Position
Tilt Position
#6/Closed

S T E P 5 Openin AD45
Attach crank handle to crank mechanism (Fig. 13). From closed position, turn the crank
clockwise (Fig. 14) until the umbrella is fully opened (Fig. 15) and the hub is at the
top most position (Fig. 16). Tilt umbrella to desired position. See Step 6 for tilt operation.
NOTE: When cranking umbrella open, if you feel resistance and the umbrella is not opening,
do not force the crank. Gently spread umbrella ribs with hands, then continue to crank open.
65
(Fig. 13) (Fig. 14)
(Fig. 12)
(Fig. 16)
S T E P 4 Assemble AD45 Main Frame to Base
Slide main frame support tube over support stem (Fig. 9). Slide gasket over support
stem and snap onto main frame support tube (Fig. 10). Slide main frame over
support stem (Fig. 11). NOTE: Make sure back side of main frame is on the same
side as hole located on support stem. Once main frame is set in place on support
stem, secure together with knob. Tighten knob by turning clockwise (Fig. 12),
without over tightening.
(Fig. 15)
Hub
(Fig. 11)
(Fig. 9)
(Fig. 10)

S T E P 5 Openin AD45
Attach crank handle to crank mechanism (Fig. 13). From closed position, turn the crank
clockwise (Fig. 14) until the umbrella is fully opened (Fig. 15) and the hub is at the
top most position (Fig. 16). Tilt umbrella to desired position. See Step 6 for tilt operation.
NOTE: When cranking umbrella open, if you feel resistance and the umbrella is not opening,
do not force the crank. Gently spread umbrella ribs with hands, then continue to crank open.
65
(Fig. 13) (Fig. 14)
(Fig. 12)
(Fig. 16)
S T E P 4 Assemble AD45 Main Frame to Base
Slide main frame support tube over support stem (Fig. 9). Slide gasket over support
stem and snap onto main frame support tube (Fig. 10). Slide main frame over
support stem (Fig. 11). NOTE: Make sure back side of main frame is on the same
side as hole located on support stem. Once main frame is set in place on support
stem, secure together with knob. Tighten knob by turning clockwise (Fig. 12),
without over tightening.
(Fig. 15)
Hub
(Fig. 11)
(Fig. 9)
(Fig. 10)

47
S T E P 3 Assemble AD45 Support Stem to Rotatin Hub
Slide support stem over rotating hub (Fig. 6) and line up holes. Tighten with 4
supplied medium bolts and washers. Tighten with supplied wrench (Fig. 7). Slide
rotating hub cover over rotating hub (Fig. 8).
(Fig. 7)
(Fig. 8)
(Fig. 6)
Tilt Positions (Fig. 18)
S T E P 6 Tiltin AD45
To tilt umbrella, squeeze the main frame grip handle (Fig. 17) and slide handle to desired tilt
position (Fig. 18). Release main frame grip handle to lock into tilt position.
(Fig. 17)
Tilt Position #5 Hole
Tilt Position #4 Hole
Tilt Position #3 Hole
Tilt Position #2 Hole
Tilt Position #1 Hole
Tilt Position #6/Closed
Horizontal Position Hole
Tilt Position #1 Tilt Position #2
Tilt Position #3 Tilt Position #4 Tilt Position #5
Horizontal Position
Tilt Position
#6/Closed

(Fig. 1)
S T E P 1 Assemble Cross Bar Stand
Select area to set AD45 base and place in desired location. Set cross bars in a cross position
(Fig. 1). Secure stand with (4) square stones or concrete weights (weights not
included).
IMPORTANT: Cross bar stand will not support umbrella without proper weights.
Using the stand without weights will damage your umbrella.
S T E P 8 Closin AD45
To close umbrella, squeeze main frame grip handle (Fig. 21) and slide grip handle down to
closed position (Fig. 22). Turn crank handle counter-clockwise (Fig. 23) until
umbrella is closed (Fig. 24). Use ties to secure canopy to the main frame when umbrella is
not in use.
(Fig. 21)
(Fig. 23) (Fig. 24)
38
S T E P 2Assemble AD45 Rotatin Hub to Cross Bar Stand
Attach foot pedal to rotating hub (Fig. 2). Turn rotating hub on side and secure foot
pedal with small screw underneath foot pedal by tightening with phillips screwdriver
(Fig. 3). Turn rotating hub upright and set onto cross bar stand (Fig. 4). By lining up
holes, attach rotating hub to cross bar stand with 4 supplied large bolts and washers.
Tighten with supplied wrench (Fig. 5).
(Fig. 4)
(Fig. 3)
(Fig. 5)
(Fig. 2)
(Fig. 22)
S T E P 7 Rotatin AD45 360°
Place your foot on the foot pedal of the rotating hub and place hands on the main frame
(Fig. 19). Swivel the umbrella frame in either direction until desired position is reached.
There are 12 locking positions for the AD45 to rotate 360° (Fig. 20). Step off the foot
pedal to engage rotating lock. Your umbrella will now be locked into desired location.
(Fig. 19) (Fig. 20)

To ATTACH Umbrella Li ht:
Loosen the light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 25). After loosening, pull down light adapter post (Fig. 26) to attach the
umbrella light (Fig. 27 and 28) (sold separately).
To REMOVE Umbrella Li ht and CLOSE adapter:
Remove umbrella light, and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 25).
(Fig. 25) (Fig. 26)
(Fig. 27) (Fig. 28)
AD45 Features
AD45 PART LIST
Part Description Qty.
1 Cross Bars 2
2 Main Frame with Canopy 1
3 Support Stem 1
4 Main Frame Support Tube 1
5 Gasket 1
6 Rotating Hub Cover 1
7 Rotating Hub 1
8 Foot Pedal 1
9 Knob 1
10 Crank Handle 1
11 Large Bolts 4
12 Medium Bolts 4
13 Small Screw 1
14 Washers 8
15 Wrench 1
REQUIRED FOR ASSEMBLY:
• One (1) Phillips Screwdriver
• Four (4) 40 lb. weights - square stones or concrete weights. (160 lb. total weight
needed for support - weights not included) Stones & weights, standard sizes
can be used up to 20" L x 20" W x 1.5" H.
NOTE: Using the cross bar stand without weights will damage your umbrella
and may cause in ury.
2
9

E
O
A
D
B
C
H
I
J
M
L
K
N
F
G
A- Cross Bars (2) F- Gasket K- Canopy Support Beam
B- Foot Pedal G- Knob L- Finial
C- Rotating Hub Cover H- Crank Handle M- Canopy
D- Rotating Hub I- Main Frame N- Ribs
E- Main Frame Support Tube J- Main Frame Grip O- Vega™Light Adapter
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 1 year from the date of purchase.
f a defect in the original material or
workmanship appears during the warranty
period; Treasure Garden will (at its option)
repair or replace the product without
charge. Limited warranty against fabric
fading, based on fabric grade.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
n many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
n the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the first
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
Thank you for your purchase of Treasure Garden’s AD45 Cantilever Umbrella.
Please remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your AD45, read and follow this
assembly and operation guide We recommend a two-person team for assembly and
disassembly. Save information for future reference.
S A F E T Y P R E C A U T O N S :
• Close the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Do not leave open umbrella unattended. f damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
C A R E A N D M A N T E N A N C E :
• When not in use, close and cover umbrella with a protective cover (sold separately).
• Allow a wet canopy to dry opened up.
• f necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry, protective place.
• Any visible defects must be repaired by a professional.
After the Winter:
• Areas subject to turning and sliding can be treated with a non-staining lubricant spray
(silicone-based).
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
101
AD45 CHECKLIST

AD45
11’
OC /10’ SQ /8’ SQ
Cantilever
Assembly and Operation Guide
www.treasuregarden.com
©2013 Treasure Garden, nc. - All Rights Reserved. Rev. 3/13
