EST CM1 User manual

Network Controllers
Installation Manual
P/N 270239
Revised 14JUL97
firealarmresources.com

DEVELOPED BY Edwards Systems Technology
6411 Parkland Drive
Sarasota, FL 34243
[phone]
COPYRIGHT NOTICE Copyright © 1997 Edwards Systems Technology, Inc.
This manual and the products it describes are copyrighted by
Edwards Systems Technology, Inc. (EST). You may not reproduce,
translate, transcribe, or transmit any part of this manual without
express, written permission from EST.
This manual contains proprietary information intended for distribution
to authorized persons or companies for the sole purpose of
conducting business with Edwards Systems Technology, Inc. If you
distribute any information contained in this manual to unauthorized
persons, you have violated all distributor agreements and we may
take legal action.
CREDITS This manual was designed and written by the EST Technical
Services - Documentation Department, Sarasota.
firealarmresources.com

Network Controllers Manual i
Content
CM1 Master Control Module 1
Applicable Modules and Options1
Description 1
Application 2
Specifications 2
Installation 3
Indicators 4
Controls 6
CM1 System Configuration 7
CM1N and RMDP-1N Master Control Modules 8
Applicable Modules And Options 8
Description 8
Application 10
Specifications 10
Installation 11
Indicators 12
Controls 14
System Configuration 14
CM2 Secondary Control Module 16
Applicable Modules and Options16
Description 16
Application 17
Specifications 17
Installation 17
System Configuration 19
CM2N Secondary Control Module 20
Applicable Modules and Options20
Description 20
Application 21
Specifications 21
Installation 22
Indicators 24
Controls 24
System Configuration 24
Troubleshooting 25
CM2ND Secondary Control Module With Display 28
Applicable Modules and Options28
Description 28
Application 29
Specifications 30
Installation 30
Indicators 32
Controls 33
Operation 33
Configuration 33
firealarmresources.com

ii Network Controllers Manual
Troubleshooting 35
CPU-3/1N and CPU-3/2N Control Module Cards 36
Description 36
Application 36
Specifications 36
Installation 37
Troubleshooting 37
COMM-3 Communications Card 38
Description 38
Application 38
Specifications 39
Installation 39
Indicators 40
Programming Notes 40
Application Drawings 41
COMM-3S Serial Communications Card 43
Description 43
Application 43
Specifications 44
Installation 44
Indicators 44
Programming Notes 44
SO-20 Serial Option to 20mA Loop Module 45
Description 45
Application 45
Specifications 46
Installation 46
Indicators 47
Theory Of Operation 48
Application Drawings 49
SO-20D Dual Serial Option to 20mA Loop Module 54
Description 54
Specifications 55
Installation 55
Indicators 56
Application Drawings 57
FIB-20 Serial Option 20mA Loop Card, SO-FIB Option Fiber
Optics Interface Module 59
Description 59
Application 60
Specifications 61
Installation 61
Indicators 64
Application Drawings 65
firealarmresources.com

Network Controllers Manual iii
Important information
Limitation of liability
The content of this manual is proprietary in nature and is intended
solely for distribution to authorized persons, companies, distributors
and/or others for the sole purpose of conducting business associated
with Edwards Systems Technology, Inc. The distribution of
information contained within this manual to unauthorized persons shall
constitute a violation of any distributor agreements and may result in
implementation of legal proceedings.
This product has been designed to meet the requirements of NFPA
Standard 72, 1996 Edition; Underwriters Laboratories, Inc., Standard
864, 7th Edition; and Underwriters Laboratories of Canada, Inc.,
Standard ULC S527. Installation in accordance with this manual,
applicable codes, and the instructions of the Authority Having
Jurisdiction is mandatory. EST, Inc. shall not under any circumstances
be liable for any incidental or consequential damages arising from loss
of property or other damages or losses owing to the failure of EST, Inc.
products beyond the cost of repair or replacement of any defective
products. EST, Inc. reserves the right to make product improvements
and change product specifications at any time.
While every precaution has been taken during the preparation of this
manual to ensure the accuracy of its contents, EST assumes no
responsibility for errors or omissions.
FCC warning
This equipment can generate and radiate radio frequency energy. If this
equipment is not installed in accordance with this manual, it may cause
interference to radio communications. This equipment has been tested
and found to comply within the limits for Class A computing devices
pursuant to Subpart B of Part 15 of the FCC Rules. These rules are
designed to provide reasonable protection against such interference
when this equipment is operated in a commercial environment.
Operation of this equipment is likely to cause interference, in which
case the user at his own expense, is required to take whatever measures
may be required to correct the interference.
firealarmresources.com

iv Network Controllers Manual
Document history
Network Controllers Installation Manual P/N 270239
Revision Status
Revision Date Reason For Change
1.0 September 1995 Initial Release.
1.5 July 1997 Layout and content revisions.
firealarmresources.com

Network Controllers Manual 1
CM1 Master Control Module
Applicable Modules and Options
This manual covers the following modules/options:
CM1 - (P/N 240102) CM1-SO - (P/N - 240185)
CM1-SG - (P/N 240525) CM1-SO-SG - (P/N 240547)
CM1-RM - (P/N 240359) CM1-SO-RM - (P/N 240350)
Description
The CM1 is the master controller for a 576 point non-networked
system. This controller contains all the circuitry, memory, instructions,
and controls to define a system. The CM1 incorporates a 2 line, 40
character alpha-numeric LCD display, a keypad for manual control,
LED status indicators, and panel control switches.
OPERATING INSTRUCTIONS
NORMAL
NORMAL
ALARM
ALARM
SUPERVISORY
SUPERVISORY
TROUBLE
TROUBLE
TROUBLE
SILENCE
TROUBLE
SILENCE
MODEL CM1
MODEL CM1
CONTROL MODULE
CONTROL MODULE
BACK
BACK
TEST/PRGM
TEST/PRGM
RESET
RESET
ALARM
SILENCE
ALARM
SILENCE
STATUS AND PROGRAM DISPLAY
STATUS AND PROGRAM DISPLAY
NEXT/ACK
NEXT/ACK
DRILL/
ALL CALL
DRILL/
ALL CALL
NEXT/ACK-Acknowledges
currently displayed
off-normal condition,
then displays next
off-normal condition.
BACK- Reviews previously
acknowledged off-normal
condition.
LAMP TEST- Press ALARM
SILENCE and TROUBLE
SILENCE switches at
the same time.
Keypad under cover
(shown with keypad protective cover installed)
(
shownwithke
y
pad p
r
otective cove
r
r
emoved
)
[NWC-001.CDR]
Model CM1
firealarmresources.com

2 Network Controllers Manual
The system data base is stored in non-volatile Electrically Erasable
Programmable Read Only Memory (EEPROM). Information is entered
and/or modified with an IBM compatible personal computer.
The CM1 is comprised of a control module motherboard, a display panel,
and the following plug in cards:
A. The CPU card which contains the controller microprocessor, system
firmware, RAM and EEPROM memory.
B. The communications card. Options include class A (style 7) or B
(style 4) RS-485 or serial loop system data lines. Serial data lines
are available in 20 mA loop or fiber optic format. An RS-232
printer/program port is also provided on each communications card.
C. Option Cards. A selection of system input and output cards are
available in a number of configurations.
The CM1 circuitry is housed in a protective cover, which contains the
basic system operating instructions.
Application
The CM1 is designed to provide the master control function for a system
of up to 576 points. Each system must have a CM1 which provides 32
panel addresses. A variety of system communication formats are
available.
A variety of option modules are available to customize the function of
each CM1. Available modules include:
• System Communications Cards
• Intelligent Analog Sensor and control cards
• Supervised Input Cards
• Supervised Audio, Control, and Signal Circuits
Additional space for option cards may be added to the system by adding
CM2 series.
Note: There is no survivability if communications is lost to the CM2.
Specifications
Specifications
Standby Current 190 mA
Data Line Formats, Class A or B RS-485, 9600 Baud, 5VDC max,
30 mA max
20 mA loop using an SO-20
Fiber optic loop using SO-FIB
Printer Port
Max. Voltage
Max. Current
RS-232, 300-4800 baud
+/- 12
25 mA
firealarmresources.com

Network Controllers Manual 3
Max. Current (riser current) 3.5 Amps DC
250 W @ 70 VRMS
250 W @ 25 VRMS
Max. Wire Size 14 AWG
Mounting One module footprint
CM1 firmware revision level may be determined by looking at the label
on the EPROM chip U3 on the CPU card.
Installation
Caution: Disconnect power before removing or installing modules.
The CM1 master control module requires one standard module
footprint and mounts directly below the PS4/8B power supply, using
#6 screws.
Plug Connections
P1 Connect a power supply cable assembly from connector P1 of
associated PS4B/8B power supply.
Cable assembly, 1 control module P/N 250057.
Cable assembly, 2 control modules P/N 250058.
Cable assembly, 3 control modules P/N 250059.
P2 Connect ribbon cable to P2 of associated PS4B/8B. Ribbon
cable assembly P/N 250054.
P3 Communications card, COMM-3 (P/N 130080) or COMM-3S
(P/N 130144)
P4 CPU card P/N 130073/1. Provides control functions for the
system. Verify firmware level required.
P5 First option card.
P6 Second option card. P5 MUST be utilized before using P6.
P7 Used to connect the LCD (CM1) display to the motherboard.
Jumpers J3 and J4 are to provide continuity when an associated
slot is not used and MUST be removed when the associated slot
has an option card installed.
firealarmresources.com

4 Network Controllers Manual
OPTION CARD SLOT
OPTION CARD SLOT
CONTROL PANEL
MOTHER BOARD CM1(N) or CM2(N)
P5
P6
TB4
TB2
A
B
B
A
OPTION CARD TERMINALS
FOR OPTION
CARD SLOT P5
FOR OPTION
CARD SLOT P6
FOR OPTION
CARD SLOT P5 & P
6
OPTION CARD TERMINALS
TB3
TB1
SUPV
TO PS4B OR PS8B
RS-232
PRINTER/
PROGRAM
PORT
DATA
LINES
COMM
RXD
TXD
SHLD
SHLD
2(-)
2(+)
1(+)
1(-)
1
4
4
8
8
10
10
1
1
5
5
3
3
7
7
9
9
2
2
6
6
1
9
9
5
5
13
13
3
3
11
11
7
7
15
15
2
2
10
10
6
6
14
14
4
4
12
12
8
8
16
16
J4
J3
P1
POWER
DATA
RISERS
CLASS A
CLASS B
P2
P3 P4
P7
C
[NWC-002.CDR]
Network Controller Motherboard
Field Wiring
TB1 Refer to COMM-3 or COMM-3S section for instructions.
TB2 Refer to the section of the module installed in slot P5 for
instructions.
TB3 Terminals 1-6, refer to section of module installed in
connector P5 for instructions.
TB3 Terminals 5-10, refer to section of module installed in
connector P6 for instructions.
TB4 Refer to the section of the module installed in slot P6 for
instructions.
Jumper Setup
Jumper Setup
Motherboard
Jumper Name
Jumper State Condition
J3 IN No option card installed in P5
J3 OUT Option card installed in P5
J4 IN No option card installed in P6
J4 OUT Option card installed in P6
Indicators
LEDs
Normal - Green LED, flashing indicates system operating normally.
firealarmresources.com

Network Controllers Manual 5
Alarm - Red LED, flashing indicates an alarm condition.
Supervisory - Yellow LED, flashing indicates a short on a supervisory
zone.
Trouble - Yellow LED, flashing indicates a trouble condition.
Test/Prgm - Yellow LED, flashing indicates system in test or program
mode.
Alarm Silence (integrated into alarm silence switch) - Yellow LED,
indicates alarm silence (action 9004) has been activated.
Trouble Silence (integrated into trouble silence switch)-Yellow LED,
indicates trouble silence.
Drill/All Call (integrated into drill/all call switch) - Yellow LED,
indicates drill/all (action 9003) has been activated.
CM1 CPU status is indicated by the CPU Fail LED on the associated
power supply.
CM1 communication status is indicated by LEDs on the
communications cards. Refer to the COMM-3/COMM-3S data sheet.
Alphanumeric Display
A 40 character 2 line liquid crystal display provides system status and
program information.
08:53:18 AP 0000 DP 0000
PRESENTTIME
ACTIVE POINTS
DISABLED POINT
S
40 CHARACTER CUSTOM MESSAGE
[NWC-003.CDR]
CM1 Display
Status Codes
Fuz = Fuse
Gnd = Ground Fault
Acp = AC Voltage
Vlt = DC Voltage
Bat = Battery
Ext = Trouble
Int = Internal Fault (ZAS Card/Continuity Jumper, Display,
COMM Card, CPU Card)
Prn = Printer
1 = OK
0 = Fault
firealarmresources.com

6 Network Controllers Manual
Communications Failures:
ComP = Primary Communications
ComS = Secondary Communications
ComE = External Command
NG = No Good
EN = Enabled
Status Codes w/ZAS-2
Com = Communications between ZAS-2 & CPU
Res = ZAS-2 Device Reset
ZAS = ZAS-2 Card Restsrt
Mpg = Mapping
Mpe = ZAS-2 Card Programming
Gnd = ZAS-2 Card Ground Fault
Lin = Class A Fault on ZAS-2 Circuit
Map = Map Fault
1 = OK (completed)
0 = Fault (in progress)
Controls
Switches
Reset - Returns system to normal state after all inputs have been
restored. Calls action 9002.
Alarm Silence - Silences audible devices. Calls predetermined action
9004. Pressing Alarm Silence twice initiates drill/all call.
Trouble Silence - Silences local PS4/8B trouble buzzer.
Drill/All Call - Generates general activation on all audible circuits per
action 9003.
Back - Reviews previously displayed information and provides a
backspace function during keypad entry.
Next/Ack - scrolls display to next screen; acknowledges receipt of
alarm and trouble conditions.
Keypad
The keypad is used to perform advanced system functions, not required
during basic fire alarm system operation. The keypad is normally covered
with removable panel, which contains the basic system operating
instructions.
Buzzer
The system buzzer sounds during system trouble and pulses on
unacknowledged messages. Located on power supply PS4B or PS8B.
firealarmresources.com

Network Controllers Manual 7
CM1 System Configuration
CM1 configuration is dependent upon system requirements and design.
All CM1s have a CM1 CPU card (P/N 130073/1) installed in connector
P4.
CM1 system communication specifications govern the type of
communications card installed in connector P3 of the CM1. Wiring to
CM1 terminal strip TB1 is dependent on the type of communications card
installed, and may be found on the COMM-3 RS-485/RS-232C
communications card (P/N 130080) or the COMM-3S serial
communications card (P/N 130144).
Two option cards may be installed in the CM1 in connectors P5 and P6.
Details on option card programming and termination’s of CM1 terminal
strips TB2, TB3, and TB4 may be found on each modules technical data
sheet.
Programming Notes
The CM1 panel configuration menu (menu selection “3”) in the data
entry program should be set as “supervised” power supply. Additional
CM2(N) motherboards should be set as “unsupervised” power supply
when connected to the same power supply as the CM1.
Jumper Connections:
Pins 6, 8, and 20
Pins 4 and 5
Jumper Connections:
Pins 1, 4, and 6
Pins 7 and 8
TB1-2
TB1-2
TB1-3
TB1-3
TB1-4
TB1-4
[NWC-004.CDR]
DB25 FEMALE or DB9 FEMALE
Download Cable
T
O
P
C
S
ERIAL P
O
RT
PIN 1
PIN 14
PIN 13
PIN 25
PIN 1
PIN 9
23 7
OR
23 5
CONTROL PANEL
MOTHER BOARD CM1(N) or CM2(N
)
TB1
4
8
10
1
5
3
7
9
2
6
P1
P2
P3 P4
P7
Programming Connections
firealarmresources.com

8 Network Controllers Manual
CM1N and RMDP-1N Master Control Modules
Applicable Modules And Options
This covers the following module/options:
CM1N - (P/N 240100) CM1N-RM - (P/N 240235)
CM1N-SG-L CM1N-SO-RM - (P/N 240236)
CM1N-SG-RM-L CM1N-X-RM - (P/N 240281)
CM1N-SO (P/N 240186) CM1N-X-SO-RM - (P/N 240282)
CM1N-X-SO - (P/N 240212) CM1N-SG-SO - (P/N 240527)
CM1N-X - (P/N 240211) CM1N-SG-RM - (P/N 240529)
CM1N-SG - (P/N 240526) CM1N-SG SO-RM - (P/N 240531)
CM1N-SG-X - (P/N 240528) CM1N-SG-X-SO-RM - (P/N 240533)
CM1N-SG-SO-X - (P/N 240530) RMDP-1N-SO - (P/N 240187)
CM1N-SG-X-RM - (P/N 240532) RMDP-1N-X - (P/N 240213)
RMDP-1N - (P/N 240132) RMDP-1N-SG-SO - (P/N 240544)
RMDP-1N-SO-X - (P/N 240214) RMDP-1N-SG-SO-X - (P/N 240546)
RMDP-1N-SG - (P/N 240543) RMDP-1N-SG-X - (P/N 240545)
Description
The CM1N(RMDP-1N) is the master controller for single line network
systems. The CM1N(RMDP-1N) incorporates a 2 line, 40 character
alphanumeric LCD display, a keypad for manual control, LED status
indicators and panel control switch's. The LCD display on the CM1N-
RM rack mount version is backlit. The CM1N mounts in a standard
module space. The CM1N-RM installs in an RMOF chasis which mounts
in a CAB 17, 31, or 45 enclosure.
The CM1N-L is a limited address control module. The CM1N-L only
allows 14 addresses for control modules. The additional addresses are
available for annunciators.
The system data base which defines and configure each system is stored
in non-volatile Electrically Erasable Programmable Read Only Memory.
(EEPROM). Information is entered and/or modified with an IBM
compatible personal computer.
The CM1N(RMDP-1N) is comprised of a control module motherboard, a
display panel, and the following plug in cards:
A. The CPU card which contains the controller microprocessor, system
firmware, RAM and EEPROM memory.
B. The communications card. Options include class A (style 7) or B
(style 4) RS-485 or serial loop network data lines. Serial data lines
are available in 20 mA loop or fiber optic format. An RS-232
printer/program port is also provided on each communications card.
C. Option Cards. A selection of system input and output cards are
available in a number of configurations.
When supplied as a CM1N, the above circuitry is housed in a protective
cover, which contains the basic system operating instructions. The
RMDP-1N is the 19" rack mounted panel display version of the master
firealarmresources.com

Network Controllers Manual 9
control module, which also provides basic system operating instructions
on its front panel.
OPERATING INSTRUCTIONS
NORMAL
NORMAL
ALARM
ALARM
SUPERVISORY
SUPERVISORY
TROUBLE
TROUBLE
TROUBLE
SILENCE
TROUBLE
SILENCE
MODEL CM1N
MODEL CM1N
CONTROL MODULE
CONTROL MODULE
BACK
BACK
TEST/PRGM
TEST/PRGM
RESET
RESET
ALARM
SILENCE
ALARM
SILENCE
STATUS AND PROGRAM DISPLAY
STATUS AND PROGRAM DISPLAY
NEXT/ACK
NEXT/ACK
DRILL/
ALL CALL
DRILL/
ALL CALL
NEXT/ACK-Acknowledges
currently displayed
off-normal condition,
then displays next
off-normal condition.
BACK- Reviews previously
acknowledged off-normal
condition.
LAMP TEST- Press ALARM
SILENCE and TROUBLE
SILENCE switches at
the same time.
Keypad under cover
(shown with keypad protective cover installed)
(
shownwithke
y
pad p
r
otective cove
r
r
emoved
)
[NWC-005.CDR]
Model CM1N
NORMAL
ALARM
SUPERVISORY
TROUBLE
TROUBLE
SILENCE
MODEL RMDP-1N
CONTROL MODULE
BACK
TEST/PRGM
RESET
ALARM
SILENCE
STATUS AND PROGRAM DISPLAY
NEXT/ACK
DRILL/
ALL CALL
NEXT/ACK-Acknowledges currently displayed off-normal condition,
then displays next off-normal condition.
BACK- Reviews previously acknowledged off-normal condition.
LAMP TEST- Press ALARM SILENCE and TROUBLE SILENCE switches at
the same time.
OPERATING INSTRUCTIONS
[NWC-006.CDR]
Model RMDP-1N
firealarmresources.com

10 Network Controllers Manual
Application
The CM1N(RMDP-1N) is designed to provide the master control
function for single line IRC-3 network systems of up to 3,072 points.
Each single line network must have a CM1N(RMDP-1N). The
CM1N(RMDP-1N) provides 32 panel addresses; 56 addresses with “X”
option, and 16 addresses with the “L” option. A variety of network
communication formats are available to meet many applications. The
system provides true networked operation, with copies of system
definitions and operating instructions located at strategic locations
throughout the network.
A variety of option modules are available to customize the function of
each CM1(N). Available modules include:
• Network Communications Cards
• Intelligent Analog Sensor and control cards
• Supervised Input Cards
• Supervised Audio, Control and Signal Circuits
Additional space for option cards may be added to the network by adding
CM2(N) series.
Specifications
Specifications
Standby Current 190 mA
Data Line Formats, Class A or B RS-485, 9600 Baud, 5VDC max,
30 mA max
20 mA loop using an SO-20
Fiber optic loop using SO-FIB
Printer Port
Max. Voltage
Max. Current
RS-232, 300-4800 baud
+/- 12
25 mA
Max. Current (riser curret) 3.5 Amps DC
250 W @ 70 VRMS
250 W @ 25 VRMS
Max. Wire Size 14 AWG
Mounting
CM1N
RMDP-1N
One module footprint
5 1/4” of rack space and one
module footprint
CM1N(RMDP-1N) firmware revision level may be determined by
looking at the label on the EPROM chip U3 on the CPU card.
firealarmresources.com

Network Controllers Manual 11
Installation
Caution: Disconnect power before removing or installing modules.
The CM1N master control module requires one standard module
footprint and mounts directly below the PS4B/8B power supply, using #6
screws.
Plug Connections
P1 Connect a power supply cable assembly from connector P1 of
associated PS4B/8B power supply.
Cable assembly, 1 control module P/N 250057.
Cable assembly, 2 control modules P/N 250058.
Cable assembly, 3 control modules P/N 250059.
P2 Connect ribbon cable to P2 of associated PS4B/8B. Ribbon
cable assembly P/N 250054.
P3 Communications card, COMM-3 (P/N 130080) or COMM-3S
(P/N 130144)
P4 CPU card P/N 130073/1. Provides control functions for the
system Verify firmware level required.
P5 First option card.
P6 Second option card. P5 MUST be utilized before using P6.
P7 Used to connect the LCD (CM1N or RMDP-1N) display to
the motherboard.
Jumpers J3 and J4 provide continuity when an associated slot is not used
and MUST be removed when the associated slot has an option card
installed.
OPTION CARD SLOT
OPTION CARD SLOT
CONTROL PANEL
MOTHER BOARD CM1(N) or CM2(N)
P5
P6
TB4
TB2
A
B
B
A
OPTION CARD TERMINALS
FOR OPTION
CARD SLOT P5
FOR OPTION
CARD SLOT P6
FOR OPTION
CARD SLOT P5 & P
6
OPTION CARD TERMINALS
TB3
TB1
SUPV
TO PS4B OR PS8B
RS-232
PRINTER/
PROGRAM
PORT
DATA
LINES
COMM
RXD
TXD
SHLD
SHLD
2(-)
2(+)
1(+)
1(-)
1
4
4
8
8
10
10
1
1
5
5
3
3
7
7
9
9
2
2
6
6
1
9
9
5
5
13
13
3
3
11
11
7
7
15
15
2
2
10
10
6
6
14
14
4
4
12
12
8
8
16
16
J4
J3
P1
POWER
DATA
RISERS
CLASS A
CLASS B
P2
P3 P4
P7
C
[NWC-002.CDR]
Network Controller Motherboard
firealarmresources.com

12 Network Controllers Manual
Field Wiring
TB1 Refer to COMM-3 or COMM-3S section for instructions.
TB2 Refer to the section of the module installed in slot P5 for
instructions.
TB3 Terminals 1-6, refer to section of module installed in
connector P5 for instructions.
TB3 Terminals 5-10, refer to section of module installed in
connector P6 for instructions.
TB4 Refer to the section of the module installed in slot P6 for
instructions.
Jumper Setup
Jumper Setup
Jumper Name Jumper State Condition
J3 IN No option card installed in P5
J3 OUT Option card installed in P5
J4 IN No option card installed in P6
J4 OUT Option card installed in P6
Indicators
LEDs
Normal - Green LED, flashing indicates system operating normally.
Alarm - Red LED, flashing indicates an alarm condition.
Supervisory - Yellow LED, flashing indicates a short on a supervisory
zone.
Trouble - Yellow LED, flashing indicates a trouble condition.
Test/Prgm - Yellow LED, flashing indicates system in test or program
mode.
Alarm Silence (integrated into alarm silence switch) - Yellow LED,
indicates alarm silence (action 9004) has been activated.
Trouble Silence (integrated into trouble silence switch)-Yellow LED,
indicates trouble silence.
Drill/All Call (integrated into drill/all call switch) - Yellow LED,
indicates drill/all (action 9003) has been activated.
CM1N/RMDP-1N CPU status is indicated by the CPU Fail LED on the
associated power supply.
CM1N/RMDP-1N communication status is indicated by LED's on the
communications cards. Refer to the COMM-3/COMM-3S data sheet.
firealarmresources.com

Network Controllers Manual 13
Alphanumeric Display
A 40 character 2 line liquid crystal display provides system status and
program information.
08:53:18 AP 0000 DP 0000
PRESENTTIME
ACTIVE POINTS
DISABLED POINT
S
40 CHARACTER CUSTOM MESSAGE
[NWC-003.CDR]
CM1N Display
Status Codes
Fuz = Fuse
Gnd = Ground Fault
Acp = AC Voltage
Vlt = DC Voltage
Bat = Battery
Ext = Trouble
Int = Internal Fault (ZAS Card/Continuity Jumper, Display,
COMM Card, CPU Card)
Prn = Printer
1 = OK
0 = Fault
Communications Failures:
ComP = Primary Communications
ComS = Secondary Communications
ComE = External Command
NG = No Good
EN = Enabled
Status Codes w/ZAS-2
Com = Communications between ZAS-2 and CPU
Res = ZAS-2 Device Reset
ZAS = ZAS-2 Card Restsrt
Mpg = Mapping
Mpe = ZAS-2 Card Programming
Gnd = ZAS-2 Card Ground Fault
Lin = Class A Fault on ZAS-2 Circuit
Map = Map Fault
1 = OK (completed)
0 = Fault (in progress)
firealarmresources.com

14 Network Controllers Manual
Controls
Switches
Reset - Returns system to normal state after all inputs have been
restored. Calls action 9002.
Alarm Silence - Silences audible devices. Calls predetermined action
9004. Pressing Alarm Silence twice initiates drill/all call.
Trouble Silence - Silences local PS4/8B trouble buzzer.
Drill/All Call - Generates general activation on all audible circuits per
action 9003.
Back - Reviews previously displayed information and provides a
backspace function during keypad entry.
Next/Ack - Scrolls display to next screen; acknowledges receipt of
alarm and trouble conditions.
Keypad
The keypad is used to perform advanced system functions, not required
during basic fire alarm system operation. The keypad is normally covered
with removable panel, which contains the basic system operating
instructions.
Buzzer
The system buzzer sounds during system trouble and pulses on
unacknowledged messages. Located on power supply PS4B or PS8B.
System Configuration
CM1N (RMDP-1N) configuration is dependent upon system
requirements and design. All CM1N (RMDP-1N)’s have a CM1N
(RMDP-1N) CPU card (P/N 130073/1) installed in connector P4.
CM1N (RMDP-1N) system communication specifications govern the
type of communications card installed in connector P3 of the CM1N
(RMDP-1N). Wiring to CM1N (RMDP-1N) terminal strip TB1 is
dependent on the type of communications card installed, and may be
found on the COMM-3 RS-485/RS-232C communications card (P/N
130080) or the COMM-3S serial communications card (P/N 130144).
Two option cards may be installed in the CM1N (RMDP-1N) in
connectors P5 and P6. Details on option card programming and
termination’s of CM1N (RMDP-1N) terminal strips TB2, TB3, and TB4
may be found on each modules technical data sheet.
Programming Notes
The CM1N (RMDP-1N) panel configuration menu (menu selection “3”)
in the data entry program should be set as “supervised” power supply.
Additional control modules should be set as “unsupervised” power supply
when connected to the same power supply as the CM1N (RMDP-1N).
firealarmresources.com
