Estella 236ECEG26 User manual

02/2020
236ECEG26
ESPRESSO GRINDER
USER MANUAL

1
Installation .............................................. 2
Operation ............................................... 2
Cleaning ................................................ 2
Adjustments ............................................. 3
Safety .................................................. 3
Electrical Diagram ........................................ 3
Specifications............................................ 4
Warranty................................................ 5
INDEX
NOTE: Save these instructions for future reference.

2
INSTALLATION
OPERATION
CLEANING
• Make sure grinder is sitting on a flat surface.
• Before plugging in the grinder, make sure the voltage of the electric supply match
machine ratings
Wall receptacle must be grounded.
Do not use extension cords or wall adapters.
1. Ensure that the hopper is securely fitted to the top of the grinder
2. Close the slide underneath the hopper
3. Fill the hopper with espresso beans and secure the lid
4. Open the slide to allow beans to fall into the grinder
5. Turn the power switch to the on position to begin grinding. Grounds will begin
to fill the doser.
6. Turn off the power switch in order to stop grinding.
7. Put the portafilter below the doser
8. Pull the lever to dispense grounds into the portafilter. Be sure to pull forward
until click is heard then allow the lever to return to its original position to ensure
consistent dosing
If grounds are not dispensing ensure that properly dried espresso beans are being used.
Make sure to pull dispensing lever entire way forward and then allow to release back to
its original position.
Use included brush to sweep out excess grounds. Hopper may be removed to be
cleaned. Use only nonabrasive chemicals and water to clean hopper. Ensure that
hopper and machine are completely dry before using.

3
SAFETY
ELECTRICAL DIAGRAM
• This machine should only be used by qualified personnel
• Do not allow anyone under the age of 18 to use this machine
• Do not unplug the grinder by pulling on the cord
• Unplug the grinder before reaching in for any reason.
• Beware that grinder may continue to spin for a short period of time after
turning off the machine
• Do not operate with wet hands
• Do not allow liquid to come into contact with the grinder
• Only put espresso beans into hopper
ADJUSTMENTS
To adjust coarseness of grounds thread the adjustment handle into the grind
selector and rotate to desired position.
POWER SWITCH
MOTOR START
CAPACITOR
POWER SWITCH FAILURE
GROUNDING LINE
POWER
PLUG

4
SPECIFICATIONS
1Grind Adjustment Spring
2Grinding Machine
3Gear Plate Group
4M4 Screw
5
Grinding Machine
Anchor Screw
6M4 Screw
7
Cone-Shape Coffee Beans
Pouring Trough
8Grinder Selector
9Adjustment Stick
10
Grind Adjustment Abut
Screw (M4 Screw)
11 Funnel
12
Funnel Lip
13 Portion Control Stick
14
Lead Screw
15
Powder Stirring Device
16
Quantity Control Spring
17
Portion Adjustment Group
18
Powder Blade
19
Steel Wire for Sweeping Powder
20
Device for Keeping High
Degree of Portion
21
M5 Screw
22
Lid of Quantity Control Device
23
Cooling Fan
24 Foundation Lid
25 Foot Pad
26 Handle Frame
27 Electric Power Switch
28
Automatic Power Failure Installment
28
26
15
14
16
1
2
4
6
9
10
8
7
5
317
19
20
20
22
11
12
27
25
24
23
13

5
EQUIPMENT
LIMITED WARRANTY
TO MAKE A WARRANTY CLAIM:
For Warranty Inquiries contact the locaon where you purchased the product:
• WebstaurantStore.com: Contact [e-mail]. Please have your order number ready.
• The Restaurant Store: If you purchased this unit from your local store, please contact your store directly.
• TheRestaurantStore.com: Online purchases, call 717-392-7261. Please have your order number ready.
Failure to contact the designated locaon prior to obtaining equipment service may void your warranty.
Estella makes no other warranes, express or implied, statutory or otherwise, and HEREBY DISCLAIMS ALL
IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS
FOR A PARTICULAR PURPOSE.
This Limited Warranty does not cover:
• Equipment sold or used outside the Connental United States
• Use of unltered water
• Estella has the sole discreon on wearable parts not covered under warranty
• Equipment not purchased directly from an authorized dealer
• Equipment used for residenal or other non-commercial purposes
• Equipment that has been altered, modied, or repaired by anyone other than an authorized service agency
• Equipment where the serial number plate has been removed or altered.
• Damage or failure due to improper installaon, improper ulity connecon or supply, and issues resulng from
improper venlaon or airow.
• Defects and damage due to improper maintenance, wear and tear, misuse, abuse, vandalism, or Act of God.
Warranty Claims can be rejected if it is found the cause is poor water condions.
Poor water condions meet the following criteria:
• Total Dissolved Solids: Minimum 50 PPM, Maximum 125 PPM
• Total Hardness: Minimum 3 GPG, Maximum 5 GPG
• pH: Minimum 6.5, Maximum 7.5
• Free Chlorine: Maximum 0.5 PPM
• Total Chlorine: Maximum 1 PPM
Any acon for breach of this warranty must be commenced within 1 year of the date on which the breach occurred.
No modicaon of this warranty, or waiver of its terms, shall be eecve unless approved in a wring signed by the
pares. The laws of the Commonwealth of Pennsylvania shall govern this warranty and the pares’ rights and dues
under it. Estella shall not under any circumstances be liable for incidental or consequenal damages of any kind,
including but not limited to loss of prots.
Estella warrants its equipment to be free from defects in material and workmanship for a period of 1 year. This is the
sole and exclusive warranty made by Estella covering your Estella brand equipment. A claim under this warranty must
be made within 1 year from the date of purchase of the equipment. Only the equipment’s original purchaser may
make a claim under this warranty. Estella reserves the right to approve or deny the repair or replacement of any part
or repair request. The warranty is not transferable. Estella Equipment installed in/on a food truck or trailer will be
limited to a period of 30 days from the original date of purchase.
