ETAS ES4435.1 User manual

ES4435.1 Current Source Load Board
User’s Guide

2
Copyright
The data in this document may not be altered or amended without special noti-
fication from ETAS GmbH. ETAS GmbH undertakes no further obligation in rela-
tion to this document. The software described in it can only be used if the
customer is in possession of a general license agreement or single license. Using
and copying is only allowed in concurrence with the specifications stipulated in
the contract.
Under no circumstances may any part of this document be copied, reproduced,
transmitted, stored in a retrieval system or translated into another language
without the express written permission of ETAS GmbH.
© Copyright 2012 - 2018 ETAS GmbH, Stuttgart
The names and designations used in this document are trademarks or brands
belonging to the respective owners.
V1.0.0 R03 EN - 08.2018

ES4435.1 Current Source Load Board - User’s Guide 3
Contents
ETAS Contents
1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Basic Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.1 Correct Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.2 Labeling of Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 Identifications on the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.1 KC Mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Current Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.1 Currents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.2 Switched Battery Voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.3 Calibrating the Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Configuration in LABCAR-RTC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3 Assigning “Load in Slot x” to Connector “Load n” . . . . . . . . . . . . . . . . . . 13
2.4 The Load Signals at the Backplane Connectors . . . . . . . . . . . . . . . . . . . . . . 14
3Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4ETAS Contact Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

ES4435.1 Current Source Load Board - User’s Guide4
Contents ETAS

ES4435.1 Current Source Load Board - User’s Guide 5
ETAS Introduction
1 Introduction
This User’s Guide describes the ES4435.1 Current Source Load Board.
It consists of the following chapters:
• "Introduction" on page 5
This chapter – here you will find general information on the ES4435.1
Current Source Load Board.
• "Hardware" on page 11
This chapter describes the individual function units of the ES4435.1 Cur-
rent Source Load Board in more detail.
• "Technical Data" on page 15
This section contains the technical data of the ES4435.1 Current Source
Load Board
CAUTION!
Some components of the ES4435.1 Current Source Load Board may
be damaged or even destroyed by static discharge. Leave the board in
its transport package until you want to install it.
The ES4435.1 Current Source Load Board should only be taken from
its package, configured and installed at a working place that is pro-
tected against static discharge.
WARNING!
The components, connectors and conductors of the ES4435.1 Cur-
rent Source Load Board may carry dangerous voltages. These voltages
may even exist if the ES4435.1 is not installed in the ES4408.1 Load
Chassis or the ES4408.1 Load Chassis is powered off.
Make sure the ES4435.1 is protected against contact during opera-
tion.
CAUTION!
If cards are unlocked (e.g. during setup or calibration) but not com-
pletely removed from the housing, they nevertheless have to be
pulled out of the housing so that the distance between the card and
the backplane of the housing is at least 1 cm! Otherwise there could
be contacts between the cards which could then be destroyed as a
result.

ES4435.1 Current Source Load Board - User’s Guide6
Introduction ETAS
1.1 Features
The ES4435.1 Current Source Load Board is a 3 U plug-in board for the ES4408.1
Load Chassis and is used to simulate low current loads up to 150 mA.
A total of seven boards of the type ES4434.1 Configurable Load Board and
ES4435.1 Current Source Load Board can be installed in the ES4408.1 Load
Chassis.
The ES4435.1 Current Source Load Board has the following features:
• 24 current sources
• Current direction can be set for every current source in LABCAR-RTC
• Every current source can drive currents of 5...150 mA (at 6 V...20 V bat-
tery voltage)
• Power limitation 3 W/current source – with higher battery voltages (up to
60 V max.) the maximum permissible current will be limited accordingly
• Current sources are enabled/disabled depending on the status of a spe-
cific battery node – sources are also assigned to battery nodes in LABCAR-
RTC.
This makes the ES4435.1 Current Source Load Board suitable for projects in
which frequent reconfigurations are necessary – for rare changes, we would rec-
ommend the ES4434.1 Configurable Load Board which can accommodate 24
manually configurable loads.

ES4435.1 Current Source Load Board - User’s Guide 7
ETAS Introduction
Fig. 1-1 shows the block diagram of the ES4435.1 Current Source Load Board.
Fig. 1-1 Block Diagram of the ES4435.1 Current Source Load Board
FPGA
Status BN[0...5]
SPI
JTAG
12
12
12
12
Current Source10
Current Source 1
Current Source 2
Current Source 3
Current Source 4
Current Source 5
Current Source 6
Current Source 7
Current Source 8
Current Source 9
Current Source 11
Current Source 12
Current Source 22
Current Source 13
Current Source 14
Current Source 15
Current Source 16
Current Source 17
Current Source 18
Current Source 19
Current Source 20
Current Source 21
Current Source 23
24
Current Source 0

ES4435.1 Current Source Load Board - User’s Guide8
Introduction ETAS
1.2 Basic Safety Instructions
Please adhere to the safety instructions in this manuals to avoid injury to yourself and
others as well as damage to the device.
1.2.1 Correct Use
ETAS GmbH cannot be made liable for damage which is caused by incorrect use and not
adhering to the safety instructions.
1.2.2 Labeling of Safety Instructions
The safety instructions contained in this manual are shown with the standard danger sym-
bol shown below:
The following safety instructions are used. They provide extremely important information.
Please read this information carefully.
CAUTION!
indicates a low-risk danger which could result in minor or less serious injury
or damage if not avoided.
WARNING!
indicates a possible medium-risk danger which could lead to serious or even
fatal injuries if not avoided.
DANGER!
indicates a high-risk, immediate danger which could lead to serious or even
fatal injuries if not avoided.

ES4435.1 Current Source Load Board - User’s Guide 9
ETAS Introduction
1.3 Identifications on the Product
The following Symbols are Used for Product Labeling:
1.3.1 KC Mark
With the KC mark attached to the product and its packaging, ETAS confirms that
the product has been registered in accordance with the product-specific KCC
guidelines of the Republic of Korea.
Symbol Description
Marking for KCC conformity
(see "KC Mark" on page 9)
Marking for conformity with WEEE directive
(see "Taking the Product Back and Recycling" on page 10)

ES4435.1 Current Source Load Board - User’s Guide10
Introduction ETAS
1.4 Taking the Product Back and Recycling
The European Union has passed a directive called Waste Electrical and Electronic
Equipment, or WEEE for short, to ensure that systems are setup throughout the
EU for the collection, treating and recycling of electronic waste.
This ensures that the devices are recycled in a resource-saving way representing
no danger to health or the environment.
Fig. 1-2 WEEE Symbol
The WEEE symbol on the product or its packaging shows that the product must
not be disposed of as residual garbage.
The user is obliged to collect the old devices separately and return them to the
WEEE take-back system for recycling.
The WEEE directive concerns all ETAS devices but not external cables or batteries.
For more information on the ETAS GmbH Recycling Program, contact the ETAS
sales and service locations (see "ETAS Contact Addresses" on page 17).

ES4435.1 Current Source Load Board - User’s Guide 11
ETAS Hardware
2 Hardware
This chapter describes the individual function units of the ES4435.1 Current
Source Load Board in more detail.
These are:
• "Current Sources" on page 11
• "Configuration in LABCAR-RTC" on page 12
• "Assigning “Load in Slot x” to Connector “Load n”" on page 13
• "The Load Signals at the Backplane Connectors" on page 14
2.1 Current Sources
The current sources of the ES4435.1 Current Source Load Board are controlled
MOSFET current sources for regulating current – the input operational amplifier
is addressed via a 10-bit D/A converter with a serial input.
Mechanical relays control the pull functionality.
Operation Modes “Pull-Up” and “Pull-Down”
In the operation mode “pull-up”, the current source is switched internally
against the positive potential of the selected battery node. A current flows from
the source when the load is connected to an ECU pin with lower potential (e.g.
-UBatt).
In the operation mode “pull-down”, the current source is switched internally
against the negative potential (-UBatt). A current flows into the source when the
load is connected to an ECU pin with higher potential.
2.1.1 Currents
The maximum power of the current sources is 3 W. For the maximum current
rating of the current sources, this means:
• 150 mA (pull-up/pull-down) with a battery voltage of 6..20 V
• 70 mA with a battery voltage of 20..42 V
• 50 mA with a battery voltage of 42..60 V
with an accuracy of 3 mA.
2.1.2 Switched Battery Voltages
All current sources must refer to switched battery voltages in their pull-up func-
tion, i.e. the corresponding current source only becomes active when the corre-
sponding battery node is activated.
The battery node control signals are TTL signals which are applied from the
ES4408CON.1 Communication Interface to the backplane of the ES4408.1 Load
Chassis.
Note
The ES4435.1 Current Source Load Board can only be operated in connection
with LABCAR-RTC! Otherwise, leakage currents of the MOSFETs can lead to
signal problems as the relevant source is disabled but configured as pull-down.
If the ES4435.1 is disabled in LABCAR-RTC, these problems do not occur.

ES4435.1 Current Source Load Board - User’s Guide12
Hardware ETAS
2.1.3 Calibrating the Circuit
The current sources can be calibrated by ETAS. The order data is shown below:
2.2 Configuration in LABCAR-RTC
To configure the individual current sources of the ES4435.1 Current Source Load
Boards used:
• Open your hardware configuration in LABCAR-RTC.
• Select the “ES4435-Current-Sources” device.
• Select the “Signals” tab.
To see the operation mode
• Select the channel to be configured (the relevant
current source 0...23)
• Select the operation mode in the “Operation
Mode” column
To select the battery node
• Select the relevant battery node (from the “Battery
Node” column) against which the current source is
to be configured.
Order Name Short Name Order Number
Calibration Service for ES4435 K_ES4435 F-00K-106-387

ES4435.1 Current Source Load Board - User’s Guide 13
ETAS Hardware
To set the current
• Enter the required current in the “Current” column.
The LABCAR-RTC User’s Guide contains more details on the configuration of
LABCAR-RTC.
2.3 Assigning “Load in Slot x” to Connector “Load n”
The loads in the various slots are routed to the connectors “Load n” as follows.
Tab. 2-1 Slot:Load →Connector:Pin
Tab. 2-2 Assignment: Slot x →Connector “Load n”
Slot:Load Connector:Pin Slot:Load Connector:Pin
Slot x:load 1 Load n:1 Slot x:load 13 Load n:13
Slot x:load 2 Load n:2 Slot x:load 14 Load n:14
Slot x:load 3 Load n:3 Slot x:load 15 Load n:15
Slot x:load 4 Load n:4 Slot x:load 16 Load n:16
Slot x:load 5 Load n:5 Slot x:load 17 Load n:17
Slot x:load 6 Load n:6 Slot x:load 18 Load n:18
Slot x:load 7 Load n:7 Slot x:load 19 Load n:19
Slot x:load 8 Load n:8 Slot x:load 20 Load n:20
Slot x:load 9 Load n:9 Slot x:load 21 Load n:21
Slot x:load 10 Load n:10 Slot x:load 22 Load n:22
Slot x:load 11 Load n:11 Slot x:load 23 Load n:23
Slot x:load 12 Load n:12 Slot x:load 24 Load n:24
Note
Please note that the connector numbering does not correspond to the slot
numbering (see the following table)!
Slot 6 7 8 9 10 11 12
Connector Load 15 Load 14 Load 13 Load 12 Load 11 Load 10 Load 9

ES4435.1 Current Source Load Board - User’s Guide14
Hardware ETAS
2.4 The Load Signals at the Backplane Connectors
The following table shows how the load signals are routed from the connector
on the rear of the ES4408.1 Load Chassis to the backplane connectors.
Tab. 2-3 Load Signals and Backplane Connectors
Slot:
Signal
Slot:
Backplane
Connector
Slot:
Signal
Slot:
Backplane
Connector
Slot n:load 1 Slot n:a11 Slot n:load 14 Slot n:b15
Slot n:load 2 Slot n:b11 Slot n:load 15 Slot n:c15
Slot n:load 3 Slot n:c11 Slot n:load 16 Slot n:a16
Slot n:load 4 Slot n:a12 Slot n:load 17 Slot n:b16
Slot n:load 5 Slot n:b12 Slot n:load 18 Slot n:c16
Slot n:load 6 Slot n:c12 Slot n:load 19 Slot n:c17
Slot n:load 7 Slot n:a13 Slot n:load 20 Slot n:c17
Slot n:load 8 Slot n:b13 Slot n:load 21 Slot n:c17
Slot n:load 9 Slot n:c13 Slot n:load 22 Slot n:a18
Slot n:load 10 Slot n:a14 Slot n:load 23 Slot n:b18
Slot n:load 11 Slot n:b14 Slot n:load 24 Slot n:c18
Slot n:load 12 Slot n:c14 GND board Slot n:c10
Slot n:load 13 Slot n:a15

ES4435.1 Current Source Load Board - User’s Guide 15
ETAS Technical Data
3 Technical Data
This section contains the technical data of the ES4435.1 Current Source Load
Board
Current Sources
Environmental Conditions
Power Supply
Dimensions
No. of channels 24
Maximum output current 150 mA ±3 mA
Overvoltage protection to 60 V
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Relative humidity 0 to 95% (non-condensing)
Current consumption + 3.3 V: 100 mA
+ 5 V: 700 mA
+12 V: 20 mA
-12 V: 20 mA
Height 3 U
Width 4 HP
Length 340 mm

ES4435.1 Current Source Load Board - User’s Guide16
Technical Data ETAS

ES4435.1 Current Source Load Board - User’s Guide 17
ETAS ETAS Contact Addresses
4 ETAS Contact Addresses
ETAS HQ
ETAS GmbH
ETAS Subsidiaries and Technical Support
For details of your local sales office as well as your local technical support team
and product hotlines, take a look at the ETAS website:
Borsigstraße 24 Phone: [phone]
70469 Stuttgart Fax: [phone]
Germany WWW: www.etas.com
ETAS subsidiaries WWW: www.etas.com/en/contact.php
ETAS technical support WWW: www.etas.com/en/hotlines.php

ES4435.1 Current Source Load Board - User’s Guide18
ETAS Contact Addresses ETAS

ES4435.1 Current Source Load Board - User’s Guide 19
ETAS Index
Index
A
Applications 5
B
Battery node
select 12
Block diagram 7
C
Configuration
in LABCAR-RTC 12
Current
set 13
Current intensities 11
Current sources 11
E
ETAS Contact Addresses 17
F
Features 6
O
Operation mode
set 12
P
Product Back 10
Pull-Down 11
Pull-Up 11
R
Recycling 10
S
Safety instructions, basic 8
Safety instructions, labeling 8
T
Technical data 15
U
Use, correct 8
W
Waste Electrical and Electronic Equip-
ment 10
WEEE take-back system 10

ES4435.1 Current Source Load Board - User’s Guide20
Index ETAS
