ETEKCITY A41-C User manual

Alluma LED Desk Lamp
Model No.: A41-C
Questions or Concerns?
[phone]
[e-mail]

Thank you for purchasing the Alluma LED Desk Lamp
(A41-C) by Etekcity. This high power, eco-friendly lamp
enables users to adjust lighting brightness and color
temperature according to the appropriate application.
Whether used to read, study, or relax, this lamp is
automatically set to the best lighting conditions for
each use without the hassle of eye strain or exhaustion
while charging nearly any device with the included USB
charging port, enhancing the efficiency in your work or
study space.
We’re constantly working at building better living with
the products and services we create. Should you ever
experience any issues with your new product, feel free
to contact our helpful customer service team toll-free at
[phone] or by e-mail at [e-mail].
2

Safety Information
IMPORTANT: Please read and comply with all of the
instructions and warnings provided in this manual before
using the product. Failure to comply with the instructions
and warnings provided herein may result in inaccurate
results and/or damage to the product itself.
• DO NOT attempt to repair, disassemble or modify
under any circumstances.
• DO NOT look directly into the LED light.
• DO NOT place near any heat source or in direct
sunlight.
• Place on a flat, secure surface.
• Only use the supplied AC power adapter to operate the
lamp.
• DO NOT use the lamp of the electrical power cord is
frayed or damaged.
• DO NOT touch any electrical appliances with wet
hands or near liquid.
• Keep the light and power cord dry and clean at all
times.
• DO NOT operate this lamp in damp or moist
environments.
• In order to avoid an overload, do not plug a USB
charging port extender to the lamp. Only charge one
device at a time when using the desk lamp.
• Unplug the adapter when the light is not in use for an
extended period of time.
• DO NOT attempt to repair or disassemble the device.
Doing so may void any warranty.
• Never overload electrical circuits as it may cause an
electrical shock or hazardous fire.
• In order to maintain normal operation, use only the
included power cable with the desk lamp.
3

Main Functions
Function Diagram
1. Lamp base
2. Touch control
3. USB charging port
4. Lamp neck
5. LED light
6. Power input
7. Power cable
1
5
2
4
37
4
6
55°
135°
180°

Button Functions
Button Symbol Color Temperature Function
Power Turn the lamp power on and off.
Read Mode 4500k - 5200k Stimulates concentration and reduces eye
strain with mid-range color temperature.
Study Mode 5400k - 6100k Increases attention and concentration
with high-range color temperature.
Relax Mode 3400k - 4100k Increases relaxation and improves mood
with low-range color temperature.
Sleep Mode 2700k - 3400k Stimulates a deep sleep with the comfort
of soft light.
Timer Automatically shuts off light after 1 hour
of operation in any brightness mode.
Increase Brightness Increase light brightness.
Decrease Brightness Decrease light brightness.
5

Set-Up
Plug the included power cable into the lamp’s DC power
input, then plug the adapter into a powered outlet.
Operation
1. Press the ‘ ’ button to turn on the lamp.
2. To change the color mode, press the desired mode
according to its symbol.
3. Press the ‘+’ button repeatedly to increase the lamp’s
brightness. There are up to 5 available levels of
brightness.
4. Press the ‘-’ button repeatedly to decrease the lamp’s
brightness. There are up to 5 available levels of
brightness.
NOTE: Each mode’s default brightness level is Level 3.
The lamp will remember the last mode and brightness
level when turned on and off; however, this memory
function will not work if the power source is interrupted.
5. Press the ‘ ’ button to set a 60 minute auto-off
timer for the lamp’s light.
NOTE: The ‘ ’ button will begin flashing to indicate
that the timer has been set.
6

Cleaning & Maintenance
Charging Devices
To charge a device, plug the device to a USB cable and
plug the cable into the desk lamp’s USB charging port.
The device will begin to automatically charge.
NOTE: To charge a device, you must have a compatible
USB charging cable. The USB output is DC 5V./1.5A. If the
charging current is greater than 1.5A (i.e. iPad, tablets,
etc.), then the charging speed will be affected.The lamp’s
light does not need to remain on in order to charge a
device.
Cleaning
Unplug any connected device and disconnect the lamp.
Use a slightly damp soft cloth to clean the surface of the
lamp. Wipe dry with a soft cloth.
Disassembly
For easy storage, unscrew the plastic cap located on the
bottom of the desk lamp, rotating counter clockwise.
Remove the cap to detach the lamp neck from the lamp
base.
7

Specifications
Modes: Reading / Study / Relax / Sleep
Brightness Levels: 5
LED Power: 6 - 11W
Lumen: 530 LM
Max Illumination: > 2000 lux
Color Temperature: 2700 - 6100K
Power Input: AC 100-240V 50/60Hz
USB Output: DC 5V / 1.5A
Operating Voltage: DC 12 / 1.5A
Package Contents
1 x Alluma LED Desk Lamp
1 x User Manual
Customer Support
Should you encounter any issues or have any questions
regarding your new product, feel free to contact our
helpful Customer Support Team. Your satisfaction is ours!
Etekcity Corporation
1202 N Miller Street, Suite A
Anaheim, CA 92806
Toll-Free: [phone]
Fax: [phone]
Local: [phone]
Email: [e-mail]
Live Chat: www.etekcity.com
Support Hours
Monday - Friday: 9:00am - 5:00pm PST
*Please have your order number ready before contacting
customer support.
8

Warranty Information
Terms & Policy
Etekcity warrants all products to be of the highest quality in material,
craftsmanship and service for a minimum of 1 year, effective from the date
of purchase. Warranty lengths may vary between product categories. For
specific warranty terms, please refer to your product listing page or product
operation manual.
Under the limited warranty, Etekcity will replace or refund any product
found to be defective due to manufacturer flaws based on eligibility. This
warranty extends only to personal use and does not extend to any product
that has been used for commercial use, rental use, or any other use in which
the product is not intended for. There are no warranties other than that
expressly set forth with each product.
This warranty is non-transferrable. Etekcity is not responsible in any way for
any damages, losses or inconveniences caused by equipment failure or by
user negligence, abuse, or use noncompliant with the user manual or any
additional safety, use, or warnings included in the product packaging and
manual.
Etekcity and its subsidiaries assume no liability for damage caused by the
use of the product other than for its intended use or as instructed above and
within the user manual. Some states do not allow this exclusion or limitation
of incidental or consequential losses so the foregoing disclaimer may not
apply to you. This warranty gives you specific legal rights and you may also
have other rights which may vary from state to state.
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY
OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.
Should your product prove defective within the specified warranty period,
please return the defective unit in its original packaging with (1) an original
copy of invoice, (2) your warranty ID number, (3) and your order number.
Exceptions & Exclusions
• Damage due to abuse, accident, alteration, misuse, tampering or
vandalism.
• Improper or inadequate maintenance.
• Damage in return transit.
• Unsupervised use by children under 18 years of age.
9

Date of Purchase: ______________________
Place of Purchase: ______________________
Order ID: ______________________
Warranty ID: ______________________
To receive a valid warranty ID number, sign into your
Etekcity customer account at www.etekcity.com. At the
top of the warranty page, type in your order number
located in your order invoice to retrieve your warranty
ID number. Your warranty ID number will then be sent to
your email for your records. If deemed defective, your
product will be replaced or refunded at no charge to you,
based on eligibility.
To register your warranty or to make a claim, please
contact our helpful customer support team at
[phone] or email [e-mail].
*Please have your order ID number ready before
contacting customer support.
10
