Eteros Mobius User manual

USER GUIDE
©2020 ETEROS TECHNOLOGIES INC. ALL RIGHTS RESERVED. | UG2008TBW

CONTENTS

SAFETY INSTRUCTIONS
SERVICE & REPAIRS
SPECIFICATIONS
5
5
6
SAFETY 4
WHAT’S IN THE BOX 8
INITIAL SETUP 7
OPERATION PREP
CONTROL PANEL OVERVIEW
COMPONENT INSTALLATION AND REMOVAL
GENERAL OPERATION
10
10
10
12
OPERATION 9
CLEANING
MAINTENANCE
LIFTING AND MOVING
WARRANTY
TROUBLESHOOTING
15
15
15
16
16
CLEANING & MAINTENANCE 14

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
4
SAFETY

5
MOBIUSTRIMMER.COM
SAFETY INSTRUCTIONS
This document refers to Eteros Technologies’ specialized component washing machine as the Mobius
Automatic Tumbler & Brush Washer or the MTB Washer. This machine is not to be used for any purpose
other than those expressly stated in the User Guide, advertising literature or other Eteros Technologies
written material pertaining to the Mobius Automatic Tumbler & Brush Washer.
To avoid possible damage to the machine and risk of injury to the operator, consult with an Eteros
Technologies representative to answer any questions. Operators are encouraged to use caution and
best judgment when using equipment. Equipment should be serviced when required.
All operators must read and understand this User Guide and be trained in safe operation and use of
the Mobius Automatic Tumbler & Brush Washer. We recommend the owner of this equipment develop
a standard operating procedure specic to each worksite to address any local hazards or other
conditions not outlined in this User Guide.
Disconnect power to the washer before servicing and when adjusting or removing the components
being cleaned. The MTB Washer must be inspected regularly for damage, component failure, and
wear. Results of inspection activity should be documented.
Eteros Technologies makes every effort to ensure the MTB Washer is compliant with all current safety
standards. It is the responsibility of the owner to ensure all municipal, provincial, state, county, territo-
rial, and federal codes, regulations and standards have been met in each working location, including
disposal of wastewater from the machine.
Do not lend or rent your machine without providing the User Guide. A rst-time operator should receive
practical instruction before using the machine.
SERVICE & REPAIRS
Repairs may only be carried out by Eteros Technologies or a designated authorized agent (service
technician).
Should the need arise, please notify:
ETEROS TECHNOLOGIES
502-130 INDUSTRIAL AVE.
CARLETON PLACE, ONTARIO, CANADA
K7C 3T2
www.ETEROS.com
Improper interfacing, improper repair, or unauthorized modication could result in void warranty claims.

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
6
SPECIFICATIONS
Construction 304 / 316 SS, HDPE, Delrin (Black Acetyl)
Speed Adjustments N/A
Drive Motor 1/8 HP (90W)
Power Requirements 110/115VAC, 60Hz, 1.51/1.54A
Tool-less Use Yes
Tool-less Disassembly No
Fits Through Door Yes
Width 32.25”
Length 62.5”
Height 43.5”
Weight 270lbs
Warranty 1 year
Machine Certications None
Motor Certications UL / CSA / CCC / EN / CE
Accessories None

7
MOBIUSTRIMMER.COM
INITIAL SETUP

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
8
WHAT’S IN THE BOX
Your MOBIUS AUTOMATIC TUMBLER AND BRUSH WASHER comes fully assembled, tested, and ready
for operation. It includes the following removable parts:
• INTERNAL ROTATIONAL SPREADER
• DRAINAGE HOSE
spilCgnivieceRhsurB
B
ELACS 1:1
LIATED
spilCgnivieceRhsurB
ksiDgnikcoL
ksiDevirD
r
el
p
u
o
C
e
vir
D
es
o
h
e
g
a
ni
ar
D
evlaveganiarD
teltuoeganiarD
esoHeganiarD
evlaVeganiarD
ksiDgnikcoL
ksiDevirD
redaerpS
nottuBpotS/tratS
n
o
t
t
u
B
p
ot
S
-
E
niPhctiwStimiL
B
E
:DEIFICEPSESIWREHTOSSELNU
1
F
O
1
T
E
E
HS
02:1:ELACS :THGIEW
VER
.ON.GWDEZIS
:ELTIT
GNIWARDELACSTONOD
NOITACILPPA
NO
DE
S
U
YSSATXEN
1
EDIUGRESUROFSEGAMI
LAITNEDIFNOCDNAYRATEIRPORP
HSINIF
LAIRETAM
CIRTEMOEGTERPRETNI
:REPGNICNARELOT
SIHTNIDENIATNOCNOITAMROFNIEHT
FOYTREPORPELOSEHTSIGNIWARD
YNA.>EREHEMANYNAPMOCTRESNI<
ELOHWASAROTRAPNINOITCUDORPER
FONOISSIMREPNETTIRWEHTTUOHTIW
SI>EREHEMANYNAPMOCTRESNI<
.DETIBIHORP
EMANETAD
:STNEMMOC
.A.Q
.RPPAGFM
.RPPAGNE
DEKCEHC
NWARD
SEHCNINIERASNOISNEMID
:SECNARELOT
LANOITCARF
HCAM:RALUGNA DNEB
LAMICEDECALPOWT
LAMIC
EDECALPEERHT
AA
BB
CC
DD
EE
FF
GG
HH
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1

9
MOBIUSTRIMMER.COM
OPERATION

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
10
OPERATIONAL PREP
CONTROL PANEL OVERVIEW
COMPONENT INSTALLATION AND
REMOVAL
Please take the following steps to conrm the MTB Washer is ready to operate:
• Complete a thorough inspection of the equipment to ensure there is no damage and that all
components are in place.
• Conrm the power cord is in good condition.
• Ensure the lid is properly installed with the limit switch pin in place
• Ensure that the equipment is in a clear and tidy workspace and that all controls are accessible
• Connect the drainage hose to the drainage outlet on the MTB Washer basin and ensure that
the valve on the outlet is closed.
E-STOP - Prevents accidental start-up, used for
servicing and removing components.
START –Starts motor rotation
STOP – Stops motor rotation
LIGHT - Green when powered on (running)
Remove the spreader
assembly from the washer
and place the drive (left)
end on the ground
START
STOP E-STOP
INDICATOR LIGHT

11
MOBIUSTRIMMER.COM
Remove the locking disk
from the main shaft of the
spreader.
Slide the tumbler over the
main shaft of the spreader
and replace the locking
disk on the shaft. Don’t
tighten yet!
Slide the tumbler end
cap at the bottom into
the matching prole at
the base of the spreader.
Rotate clockwise to lock in
place.
Lift opposite tumbler end
cap up and interlock with
matching features on the
locking disk.
Holding the tumbler end
cap on the bottom end to
keep locked into place,
rotate the knob on the
locking disk clockwise to
tension the tumbler. The
wires should be taut for
cleaning.
To remove, rotate the knob counter-clockwise to de-tension the tumbler, then rotate the tumbler end
caps to disengage the tabs at both ends, remove the locking disk and remove the tumbler from the
spreader.

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
12
Begin by lling washer basin approximately half full with warm or
hot water. The ll slots on the motor mount plate will prevent you
from over-lling the basin. It is recommended that water tempera-
ture not exceed 65°C (150°F).
Add a degreasing solution of your choice to the basin. The
amount to be added should be based on the manufacturer’s
recommended dilution ratio. Note, cleaning agents should be
added after lling the basin with water to avoid excessive foaming.
Install the soiled M108S brush into washer by clicking each end of
the brush into the receiving clips on the lid. These work the same
way that they do in the M108S lid.
Lift the spreader at each end and lower it into the basin, resting
the knob-end on the plastic support on the right-hand side.
Lift the left end cap and slide
it towards the motor to align
the drive cone. Rotate the
assembly to align the drive
pin with one of the holes in
the spreader plate. As you
do so, the shaft at the knob
side should fall down into
place on the plastic support.
GENERAL OPERATION
MACHINE START UP SEQUENCE
Rotate the spreader once by hand to ensure the system will rotate freely.
Close the lid. This will bring the limit switch pin into position and allow the machine to start. It will not
operate with the lid open.
OPERATING
Release the e-stop by rotating it clockwise.
Press the start button to begin rotation and cleaning.
Set a timer (not included) for 5 minutes to start. The length of time can be adjusted to suit the soil level
of your tumbler and brush, but this is a good place to start.

13
MOBIUSTRIMMER.COM
MACHINE STOP & SHUTDOWN SEQUENCE
Remove the brush by
grasping it at both ends and
pulling gently to release
it from the clips. Rinse off
and set aside to dry. We
recommend using the end
bearings as support during
drying so that the bristles
do not dry at.
Remove the spreader from
the basin by lifting the right
hand side and sliding to the
right to disengage drive pin
before lifting the assembly
fully out of the basin. Set
the assembly down and
rinse off. Remove tumbler
from spreader.
Rinse tub and spreader to remove any debris and clean as required. Avoid spraying water directly onto
electrical panel or surrounding area.
Reassemble spreader and re-install in tub for storage until next use.
Repeat as many cycles as required. At the end of the cleaning
session, push the e-stop and unplug the machine.
Drain cleaning solution from the washer basin and dispose of as
required by site or municipal regulations.
Press the stop button to stop rotation.
Open the lid and visually inspect the tumbler and brush.
If not sufcient, restart
the wash cycle until
desired cleanliness is
achieved.
If sufciently washed,
press the e-stop to
lockout the machine
before proceeding.

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
14
CLEANING
& MAINTENANCE

15
MOBIUSTRIMMER.COM
CLEANING
With the exception of the electrical enclosure, the MOBIUS AUTOMATIC TUMBLER AND BRUSH WASHER
can be washed, cleaned, and wiped down with normal detergents, degreasers, and disinfectants.
The lid and facias can be removed to facilitate cleaning. The inside of the MTB WASHER can be washed
and wiped as needed.
The exterior of the MTB WASHER can be hosed or sprayed, except in the control panel area. Evidence
of water near the electrical panel could void the machine warranty.
The machine is easily moved and rolled on level surfaces. The machine includes four locking swivel
casters that are installed at the factory. The machine is designed to be operated on smooth and level
oors.
If lifting is required, the MOBIUS AUTOMATIC TUMBLER AND BRUSH WASHER must be lifted using a forklift
on the lower surface of the body. Ensure that the forks are fully spread to avoid overturning or ipping
off the forks.
DO NOT LIFT FROM THE STRUTS AT THE BOTTOM OF THE MACHINE.
The MOBIUS AUTOMATIC TUMBLER AND BRUSH WASHER is largely maintenance-free.
The components that support the spreader shaft are the only parts that may experience wear. The
condition of these surfaces should be inspected before each use. If you begin to notice galling on
the stainless-steel surface or signicant wear of the plastic surfaces, contact ETEROS TECHNOLOGIES to
obtain a replacement component.
This User Guide does not include instructions for machine repair. For your safety, repairs must be
completed by ETEROS TECHNOLOGIES or an authorized agent (service technician).
Should repairs be required, please contact:
ETEROS TECHNOLOGIES
502-130 INDUSTRIAL AVE.
CARLETON PLACE, ONTARIO, CANADA
K7C 3T2
www.ETEROS.com
Improper interfacing, improper repair, or unauthorized modication could result in void warranty claims.
MAINTENANCE
LIFTING AND MOVING
ENSURE THAT THE MOBIUS AUTOMATIC TUMBLER AND BRUSH WASHER
IS LOCKED OUT BEFORE PERFORMING ANY SETUP OR MAINTENANCE.

MOBIUS TUMBLER AND BRUSH WASHER USER GUIDE
16
WARRANTY
For a period of one (1) year after equipment shipment, ETEROS TECHNOLOGIES (“Seller”) warrants the
MOBIUS AUTOMATIC TUMBLER AND BRUSH WASHER shall be free from defects in material and workman-
ship.
In the event of an issue covered under warranty, the original owner/purchaser of the of the MOBIUS
AUTOMATIC TUMBLER AND BRUSH WASHER must contact ETEROS TECHNOLOGIES to le a claim.
Prolonged operation of a damaged machine may cause additional damage and/or wear not
covered by warranty.
ETEROS TECHNOLOGIES
502-130 INDUSTRIAL AVE.
CARLETON PLACE, ONTARIO, CANADA
K7C 3T2
www.eteros.com
The seller understands the cost of downtime and will make every reasonable effort to process approved
warranty claims and repairs as quickly as possible. In some instances, the owner/purchaser may need
to ship the equipment to the Seller’s manufacturing facility to complete the repairs. The repairs will
come at no cost to the owner.
TROUBLESHOOTING
WILL NOT START • Ensure the machine is plugged in
• Ensure the e-stop is disengaged (twist to
release)
• Ensure the limit switch pin is present and the lid
closes properly
• Ensure motor and spreader are not jammed /
lodged
DEVICE IS ABNORMALLY NOISY • Ensure that the spreader assembly is installed
correctly
• Ensure that the drive pin is properly engaged
• Check for wear on components that support
rotating assembly
TUMBLER / BRUSH IS NOT CLEAN
ENOUGH
• Ensure correct cleaning solution, concentra-
tion and water temperature are used
• Adjust time of cleaning to ensure enough
scrubbing exposure time
• Check for debris and buildup in cleaning
solution. Fresh cleaning solution may be
required.

Eteros Technologies West
202-17665 66A Ave.
Surrey, BC
V3S 2A7
Eteros Technologies East
502-130 Industrial Ave.
Carleton Place, ON
K7C 3T2
1-866-874-6244
[email protected]
MOBIUSTRIMMER.COM
