EtroVISION EV6150A User manual

Model
• EV6150A
Before Using the EV6150A
Check the PC requirements
Review the OS platform requirements
Read an special and import precautionary information
Having basic knowledge of network setup and conguration will be helpful
Important Announcements
NOTE: This icon represents a tip for operation.
CAUTION: This icon stands for an action that could affect an operation or
mildly impair the system.
WARNING: This icon indicates an action that will likely impair the system.
About This Guide
Disclaimer
© 2007 Etrovision Technology. All rights reserved.
EtroLink™ & AnyUSB™ are trademarks of Etrovision Technology; other product or
service names mentioned herein are the trademarks of their respective owners.
Information contained in this document may be superseded by updates. No
representation or warranty is given and no liability is assumed by Etrovision
Technology with respect to the accuracy or use of the information, or infringement
of patents or other intellectual property rights. No licenses are conveyed, implicitly
or otherwise, under any intellectual property rights.

1 PRODUCT OVERVIEW...........................................................................................................1
1.1 Product Specications.........................................................................................................1
1.2 Dual Streaming Capabilities..............................................................................................2
1.3 Resolution................................................................................................................................2
1.4 Package Checklist..................................................................................................................2
1.5 Product CD...............................................................................................................................3
1.6 Language Support................................................................................................................3
1.7 Front Camera View...............................................................................................................3
1.8 Rear Camera View ................................................................................................................3
1.9 Physical Connections...........................................................................................................4
2 USING THE EV6150A FOR THE FIRST TIME....................................................................5
2.1 Initial Requirements.............................................................................................................5
Software Requirements..................................................................................................................5
Install EtroScan™................................................................................................................................5
2.2 Physical IP Camera Connections......................................................................................6
Connect to the Network..................................................................................................................6
Connect Digital I/O............................................................................................................................6
Connect Audio In...............................................................................................................................6
Power on IP Camera..........................................................................................................................6
2.3 Initial Network Conguration...........................................................................................6
Factory IP Address.............................................................................................................................6
Using EtroScan™.................................................................................................................................7
Change Network Setting via EtroScan™....................................................................................8
2.4 Access the IP Camera Web Interface............................................................................10
3 ETROLINK™ CONFIGURATION PORT.............................................................................13
3.1 OS Requirements................................................................................................................13
3.2 Setup Using the EtroLink™ Cong Port.......................................................................13
Connecting the IP camera to the PC........................................................................................13
Quick Cong Login.........................................................................................................................14
Quick Wizard - Network.................................................................................................................15
Manually Starting the Quick Cong Wizard...........................................................................17
TABLE OF CONTENTS

TABLE OF CONTENTS
3.3 Factory Default....................................................................................................................18
3.4 Missing root Password......................................................................................................19
4 CAMERA LED INDICATORS...............................................................................................21
5 ADDITIONAL INFORMATION...........................................................................................22

1.1 Product Specifications
Model EV6150A-BI EV6150A-CI
Image Sensor 1/3" Superior Image Quality CCD 1/3" SONY CCD
Lens CS Mount Type, Lens Changeable
Minimum Illumination 0.1 Lux at F2.0, 5~10 Lux
B/W Mode Auto Switch 0.012 Lux at F1.2, 0.0014 Lux at F1.2 B/W Mode
1/60 ~ 1/110,000 sec. (NTSC) 1/60 ~ 1/120,000 sec. (NTSC)
Shutter Time 1/50 ~ 1/110,000 sec. (PAL)1/50 ~ 1/120,000 sec. (PAL)
510 x 492 (NTSC) 811 x 508 (NTSC)
Number of Effective Pixels
(HxV) 512 x 582 (PAL) 795 x 596 (PAL)
Auto Iris DC Drive
Sync System Internal Lock / Line Lock
Resolution 520 TVL 600 TVL
Camera
S/N Ratio More than 50dB
Video Compression M-JPEG, MPEG-4,H.264 Format Selectable
NTSC: D1(720x480), CIF(352x240), QCIF(176x120)
Resolutions PAL: D1 (720x576), CIF(352x288), QCIF(176x144)
Frame Rate Up to 30fps (NTSC) / 25fps (PAL) @ D1 Resolution
Video Streaming Simultaneous Dual Streams Controllable Frame Rate and Bandwidth
Image Settings Compression, Brightness, Contrast,
Mirror Compression, Brightness, Contrast, White Balance , Mirror
Bit Rate M-JPEG: 5 Video Quality Level Selectable; MPEG-4/H.264 : 64K~4Mbps
Video Output1CH NTSC/PAL, BNC Connector, 1.0Vp-p with 75 ΩLoading
Video / Audio
AudioAudio In/Out ADPCM
Security Password Protection, IP Address Filtering, User Access Privelge
Network Supported Protocols TCP/IP, DHCP, PPPoE, HTTP, DDNS, NTP, FTP, SMTP, UDP, RTP,
RTSP,
3GPP, UPnP
Application Programming
InterfaceEtroSDK™ 3.0
Intelligent Video Video Motion Detection
Alarm Events Intelligent Video, File Upload via FTP and E-mail, Notification via E-mail,
External Output Activation, File Recording to Local SD Card
Video Buffer Pre-and Post Alarm Buffer up to 10-sec
Configuration EtroScan™ Utility
System
Integration &
Maintanance
Web Browser Microsoft Internet Explorer 6.0, or Above
CasingMetal (Aluminium)
Dimension 76(W) X 58(H)X 109(D) mm
Processor and Memory ARM9 Base SoC, 128MB RAM, 16MB Flash
Power 12V DC / 1A, PoE
Connectors RJ-45 for 10BASE-T/100 BASE-TX,DC Jack ,EtroLink™, BNC,
Iris Control Adaptor, Mini Din (DI/DO/RS485), USB A-Type Female ,
SD/SDHC Card Slot, Auido In, Audio Out
CPU Pentinum 4, 2.4GHz and Above
Hard Disk 40 GB or Above
Memory 512 MB or Above
Operating System Windows XP with SP2 or Above / Windows 2000 with SP4 or Above
Video Resolution SVGA or XGA with 1024x768 Resolution
General
Software DirectX 9.0C or Above
The EV6156A Box IP Camera comes equipped with a WDR CCD sensor and
Day/Night mode sensor to overcome challenging lighting conditions. The sensor
has a variety of settings to ne tune the camera to suit your needs. With H.264
compression technology, the EV6156A delivers superior image quality while
minimizing bandwidth requirements.
1 PRODUCT OVERVIEW

1 PRODUCT OVERVIEW
Temperature: 0 ºC ~ 40 ºC (32 ºF ~ 104 ºF)
Operating Conditions Humidity: 20% ~ 80% RH
Power over Ethernet Yes
Approvals CE, FCC, RoHS
Weight 390g
Included AccessoriesPower Adapter, USB Cable, CD-ROM (User Manual, Free Bundle NVR),
Mini Din Cable
1.2 Dual Streaming Capabilities
The EV6150A Series supports dual streams simultaneously.
Combination options include:
Stream 1 Stream 2
H.264 M-JPEG
H.264 MPEG-4
H.264 H.264
M-JPEG MPEG-4
M-JPEG H.264
M-JPEG M-JPEG
MPEG-4 H.264
MPEG-4 M-JPEG
MPEG-4 MPEG-4
If users assign the same stream format for both Stream1 and 2, the image
may be unable to achieve real-time performance. This is a system limitation.
1.3 Resolution Resolution CIF QCIF D1
NTSC 352X240 176X120 720X480
PAL 352X288 176X144 720X576
1.4 Package Checklist
The EV6150A packaging will include the following materials.
• EV6150A IP Camera x 1
• Power Adapter x 1

1 PRODUCT OVERVIEW
• USB Cable x 1
• Mini DIN Cable x 1
• Product CD x 1
1.5 Product CD
The product CD contains
• EtroStation™3.0 NVR management software
• 16CH Live View/Recording/4CH Playback
• User’s Manual
1.6 Language Support
• English
1.7 Front Camera View
1.8 Rear Camera View

1 PRODUCT OVERVIEW
1.9 Physical Connections
1. ICR Control (EV6150A-CI Only)
2. Auto Iris Control Adaptor
3. EtroLink™ USB Cong Port
4. 12V DC Power Input
5. mini DIN I/O Socket
6. SD Card Slot
7. Wi USB Dongle port
8. Audio In/Out
9. BNC Video Out Connector
10. RJ-45 Ethernet Port
11. Power LED

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
2.1 Initial Requirements
Software Requirements
Installation and conguration require the following:
• Microsoft Windows 2000 or XP Operating System
• Microsoft Internet Explorer version 6 or higher
Other browsers (i.e. Mozilla Firefox) are not currently supported.
Install EtroScan™
EtroScan™ is a utility is used to congure network settings for IP cameras and other
devices (i.e. NVR). EtroScan™ is available via two methods.
Install EtroStation™ 3.0
EtroStation™ 3.0 includes the EtroScan™ utility. EtroStation™ is on the product CD
that accompanies the EV6150A. Please refer to the EtroStation™ documentation for
installation instructions.
Download from Etrovision’s Website
EtroScan™ can also be downloaded from Etrovision’s website. It is available in the
Software Tools section of the Download area, http://www.etrovision.com/
Download_list.aspx?no=5.
After downloading the archived le, extract the contents and run Setup.exe to
install EtroScan.

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
2.2 Physical IP Camera Connections
Connect to the Network
Connect the EV6150A to network hub/switch via a standard CAT5 Ethernet cable
with an RJ-45 connector. Please note that the PC must be on the same network
domain as the IP camera.
Connect Digital I/O
For digital I/O functionality, connect the corresponding devices with the IP camera
via the digital I/O terminal.
Properly align the wiring and terminals when connecting; an
improper connection can damage the camera.
Connect Audio In
For audio functionality, connect the audio input cable.
Video icker may occur when enabling/disenabling audio.
This situation normally only lasts for a second.
Power on IP Camera
Connect the power adapter to the power connector. The adapter should be
connected to 110v~22OV AC socket. There is no power button on the camera, so
connecting/disconnecting the power adapter will start/shutdown the IP camera.
2.3 Initial Network Conguration
To congure the IP camera’s network settings use the EtroScan™ utility.
Factory IP Address
Below are the initial factory IP address settings for the IP camera:
IP Address 192.168.1.2
Subnet Mask 255.255.255.0
Gateway 192.168.1.1

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
Using EtroScan™
EtroScan™ allows users to easily nd an IP camera and congure the settings.
Select EtroScan™ from the start menu to start.
Press the Scan button to list the IP and MAC address list for IP cameras on the
network.
A new IP camera will display the factory IP address, 192.168.1.2. However, if
multiple new devices are present on the network, then multiple instances of
192.168.1.2 will be listed.

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
To identify a specic IP camera, use the MAC address which is located on the
bottom of the camera. Below is an example of the label displaying the MAC
address.
Change Network Setting via EtroScan™
There are two ways to modify the network settings.

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
1. Double click on a specic IP address; the setting page will be displayed.
2. Click Change Setting… button at the bottom of the screen.
Either method will display the network settings conguration.
After altering the IP camera network settings, click Apply.
A prompt for the administrator authentication will be displayed:

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
The default password for the administrator account (root) is pass. Enter the default
password and click OK to conrm the changes.
After applying the new network settings, the IP camera will reboot; this process
takes about 45 seconds. The IP camera’s Power LED light will blink during the
reboot process; the light will become stable once reboot is complete.
Exit the “Setting Page” by clicking Close, and wait for the reboot to complete.
After rebooting, press Scan to verify the new IP address. If using DHCP, then the
MAC address may be necessary to accurately identify a specic camera.
Press Exit to quit EtroScan™.
2.4 Access the IP Camera Web Interface
MS Internet Explorer is used to access and congure the IP camera. When
accessing an IP camera using the web interface for the rst time, some
conguration for ActiveX controls may be required.
1. Open the IE browser
2. Type in the IP address of the IP camera
3. Enter the administrator username and password:
User name: root
Default password: pass
Press OK button to access to the Live View web page.
Usernames and passwords are case sensitive.
The administrator password should be changed after installation is
complete. Please refer to the User Manual for more information.

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
Upon login, the error “ActiveX control failed to load (OCX)” may be encountered.
The error indicates the browser requires adding certain ActiveX controls for the
viewer to work.
Near the top of the browser page is a message regarding an add-on to run.
The request is highlighted below in blue.
Clicking on the add-on message will bring up options; choose Run Add-on to add.
A conrmation message box will be displayed; choose Run.

2 USING THE EV6150A FOR THE FIRST TIME
2 USING THE EV6150A FOR THE FIRST TIME
Wait for the add-on to complete and the page to attempt reloading.
Most likely other ActiveX controls will be required. Repeat the above procedure of
adding ActiveX controls until the no other add-on requests are displayed and the
Live View page loads without error.

3 ETROLINK™ CONFIGURATION PORT
The EtroLink™ USB Conguration Port provides an alternate method of
conguration.
The EtroLink™ USB Conguration allows conguration using a Quick Cong
Wizard which requires no software installation.
3.1 OS Requirements
The PC which will access the IP camera using the EtroLink™ USB port requires the
following to run the EtroLink™ Quick Cong Wizard:
• Windows XP (all editions)
• Windows 2000 (all editions)
• Windows 98 (SE)
Windows XP should run the wizard automatically.
Windows 2000 and 98(SE) require manually running the EtroLink™ Quick Cong
Wizard.
3.2 Setup Using the EtroLink™ Cong Port
The following discusses using the EtroLink™ Cong Port using Windows XP.
With the exception of the automatic execution of the Quick Cong Wizard, the
process is the same among all the Microsoft versions noted above.
A demonstration of how to manually start the Quick Cong Wizard will be
provided at the end of this section.
Connecting the IP camera to the PC
1. Unplug the IP camera’s power cable and network cable
2. Connect EtroLink™ and PC via the mini USB cable.
3. Once the PC detects the IP camera, wait for a pop-up dialog prompting the user
for a program choice.
4. “Cong Wizard” should already be highlighted; click OK.

3 ETROLINK™ CONFIGURATION PORT
The Quick Cong login screen will be displayed.
Quick Cong Login
Unless the password has already been modied, use the default administrator
login is:
ID: root
Password: pass
NOTE: restoring factory settings will restore default login password.
Click the Login button; the Status page will then be available.

3 ETROLINK™ CONFIGURATION PORT
Quick Wizard - Network
The Quick Wizard button is used to congure network and DDNS settings. Clicking
Quick Wizard will display Step 1.
Step 1
The network conguration options include “Static IP”, “DHCP”, and “PPPoE”.
Select an option and click Next.
Step 2
Selecting “Static IP” and clicking Next:

3 ETROLINK™ CONFIGURATION PORT
Selecting “DHCP” and Next:
Selecting “PPPoE” and Next:
Enter all the relevant network settings, and click Next.
Step 3
Regardless of network connection type, step 3 and 4 are the same.
Change the port information if applicable, and then click Next. First a conrmation
dialogue will be displayed.

3 ETROLINK™ CONFIGURATION PORT
Click OK to proceed to Step 4.
Select Setup DDNS to congure DDNS or Finish to exit the Quick Cong Wizard.
Manually Starting the Quick Cong Wizard
When using Windows 2000 or 98, the EtroLink™ Quick Cong Wizard will not be
automatically started after connecting the IP camera and PC. To start it manually:.
1. Connect the IP camera and PC using the mini USB cable.
2. Wait a moment for the PC to recognize the IP camera as a new drive.
3. Using Windows Explorer, nd the IP camera represented as a new drive.
The Etrovision logo should help identify the specic drive.
