EUPRY ESU-1 User manual
User Guide
April 2018
Eupry Connection Status Unit
(ESU-1)
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018
Eupry ApS |Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
Contents
1 Introduction 3
1.1 Intended Purpose 3
1.2 Package Contents 3
1.3 The Front Panel 4
1.4 The Rear Panel 5
1.5 Technical Specifications 6
2 Support 7
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018 Page 2 of 7
Eupry ApS | Dortheavej 59, 3rd Floor | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
1 Introduction
1.1 Intended Purpose
The Eupry Connection Status Unit is a WiFi device that functions as a ‘connection status’ or ‘heartbeat’ unit. This
means that it monitors your internet connection to ensure that you are always connected. This is necessary because
if your internet is down for whatever reason, the Data Loggers would be unable to provide you with any alarms.
Therefore this unitv will alert you if the internet is down.
1.2 Package Contents
The package includes following:
1 x 1 Ethernet Cable
1 x 2 Power Supply
1 x 3 Eupry 3G Connection Status Unit
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018 Page 3 of 7
Eupry ApS | Dortheavej 59, 3rd Floor | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
1.3 The Front Panel
Name
Status
Indication
Power
Off
Power is off.
On
The router is on.
WLAN
Off
The wireless function is disabled.
Flashing
There is data being transferred through wireless.
On
The wireless function is enabled.
LAN
Off
There is no device linked to the ethernet port.
On
There is a device linked to the ethernetport.
Flashing
Data is transmitting from the ethernetport.
INTERNET
Off
There is no device linked to the port.
Flashing
The ethernet port is transferring data.
On
A device is connected to the port but there is no data activity.
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018 Page 4 of 7
Eupry ApS | Dortheavej 59, 3rd Floor | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
1.4 The Rear Panel
The following parts are located on the rear panel:
1. MODE SWITCH: This button is used to switch the working mode of the router.
2. RJ45 Ethernet Port: This port can be LAN or WAN port depending on the working mode.
3. Mini USB Port: This port is used to connect the provided power adapter.
4. 3G/4G USB Port: This port should not be used.
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018 Page 5 of 7
Eupry ApS | Dortheavej 59, 3rd Floor | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
1.5 Technical Specifications
General
Standards
IEEE 802.3, 802.3u, 802.11b, 802.11g and 802.11n
Protocols
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100M Auto-Negotiation LAN/WAN RJ45 port
LEDs
PWR, Internet, WLAN, Ethernet, WPS
Safety & Emissions
FCC, CE
Wireless
Frequency Band
2.4~2.4835GHz
Radio Data Rate
11n：up to 150Mbps（Automatic）
11g：54/48/36/24/18/12/9/6M（Automatic）
11b：11/5.5/2/1M（Automatic）
Frequency Expansion
DSSS (Direct Sequence Spread Spectrum)
Modulation
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Security
WEP/WPA/WPA2/WPA2-PSK/WPA-PSK
Sensitivity @PER
130M: -68dBm@10% PER 108M: -68dBm@10% PER; 54M: -68dBm@10% PER
11M: -85dBm@8% PER; 6M: -88dBm@10% PER 1M: -90dBm@8% PER
Antenna Gain
5dBi
Environmental and Physical
Temperature
Operating : 0℃~40℃ (32~104℃℃)
Humidity
Operating: 10% ~ 90% RH, Non-condensing
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018 Page 6 of 7
Eupry ApS | Dortheavej 59, 3rd Floor | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
2 Support
If you have any problems with setting up the device, please visit support.eupry.com (accessible if you are logged in
to the Eupry Logger).
Alternatively, please call us at: +45 53 51 77 00 - and we will do our best to help.
User Guide: Eupry Connection Status Unit
Rev. 1.1 - April 2018 Page 7 of 7
Eupry ApS | Dortheavej 59, 3rd Floor | 2400 Copenhagen NV | www.eupry.com | +45 53 51 77 00
