EuropAce ESB 7310W User manual

MULTI-FUNCTION HOTPOT | ESB 7310W
Multi-Function Hotpot.
| 使用说明书
1
POWER OFF MAX

Product Features
产品特点 1
产品的技术参数
Technical Parameters 1
Product Part Lists
产品结构图 1
电路图
Circuit Diagram 2
使用方法
Operating Instructions 2
Safety Instructions
注意事项 3
Safety and Precaution
产品安全及注意事项 5
Care and Maintenance
保养方式 6
7
Hazardous Substances List
有害物质表
Content 目录

Grill
Handle
Aluminium pot
煎盘
Heating Base
Power Light
1
1. Combined with Eastern and Western cuisine culture in design.
在设计和造型方面，融合中西饮食文化的精华。
2. One switch temperature control for easy use.
通过调节杆滑动，易于使用。
3. Removable construcon for easy cleaning.
分体式结构，方便清洗。
Product Features 产品特点
Technical Parameters 产品的技术参数
Power Cord
锅盖
Glass lid
Heating Plate
Clasp hands
Control rod
Product Part Lists 产品结构图
ESB 7310W 220-240V ~ 50Hz 1000W 3.0L
Model No.
型号
Rated Voltage
额定电压
Rated Power
额定功率
Capacity
额定容量
手柄
发热盘
扣手
调节杆
指示灯
底座
电源线
铝锅
电源 关高

Circuit Diagram 电路图
2
L
E
N
电阻
发热体
电阻
可调温控器
Thermostat
Resistant
Diode
Fuse
Heater Resistant
发光二极管
Diode
发光二极管
热熔断器
Operating Instructions 使用方法
For Cooking Pot 铝锅使用方法
1. Before each operaon,check if there are any arcles on the surface of the heang plate;
remove it if there is any. Ensure the surface of the heang plate clean and dry.
使用前，请检查底座的发热盘表面，如有异物应予以清除。
2. To avoid the poor contact, first dry the water stain on the bottom of the pan filled with
soup or water, then put it on the hot plate.
装有汤料（清水）的铝锅，先把锅底部的水渍擦干，再放于发热盘上，避免发热盘与锅之间
有异物，从而导致接触不良，加热不均匀。
3. Switch the knob to the “OFF” posion and insert the plug into the socket.
将调节杆滑至“关”的位置，然后将电源线一端插入底座品字插内，另一端插头插入电源插
座，电源指示灯亮。
4. Switch the knob to the “HIGH” posion (the highest working temperature) and the
indicang light turns on, indicang working.
将调节杆滑至“高”的位置（最高工作温度位置），此时加热指示灯亮，表示正在加热。
N.B. During the heang process, you can move the lever towards the OFF posion and
the power can be minimized from high to low.
（注：在使用过程中，若觉得温度过高，可将调节杆滑向关的方向，即可实现断续加热，达到所需的温度.）
5. And food to the cooking pot when the water or soup start to boil.
当水沸腾后，就可以开始煮食物。
6. Aer using, move the lever to the OFF posion and take off the plug from the socket.
使用完毕，将调节杆滑至“关”的位置，然后将电源线插头拔下。

Safety Instructions 注意事项
1. Before connecng to power, please ensure the local voltage fit to the appliance and the
socket must be grounded and installed as required.
在接通电源之前，请确认当地电压与产品工作电压相符，电源插座必须接地极，并按要求安装。
2. Operate the appliance on a flat, venlated, dry and heat-proof place.
使用时应将产品放置于水平、通风、干燥的地方。
3. Before use, please do make sure the heang plate and the bottom of the cooking pot/ grill
are clean and ensure the cooking pot or grill well connect with the heang plate.
使用前必须清除发热盘表面和铝锅底部的杂物，使发热盘与铝锅良好接触。
4. Before turn on the appliance, add water to the cooking pot first. Never turn on the appliance
with an empty pot for dry burning as this may result in serious damage to the appliance.
产品工作时，铝锅内先加水，后通电，请勿通电干烧，否则容易烧坏产品。
5. During use, the temperature is very high on the surface of the product and vapor is
exhausted from the vented hole. Please do not approach or touch the surface in
case of getng burnt.
使用过程中，产品表面温度较高，排气孔有蒸汽排出，请勿靠近或触摸，以免烫伤。
6. The cooking pot/grill and heang base remains hot aer use when the hotpot or grill
removed. Please do not approach or touch the heang base to avoid getng burnt.
使用完毕，铝锅/煎盘，发热盘温度仍较高，请勿靠近或触摸，以免烫伤。
3
For Grill 煎盘使用方法
1. Place the grill onto the heang and slightly adjust it to fit with the heang plate.
将煎盘放于热源座上，确保煎盘与发热盘表面接合。
2. To avoid the poor contact, first dry the water stain on the bottom of the pan filled with
soup or water, then put it on the hot plate.
将调节杆滑至“关”的位置，然后将电源线一端插入底座品字插内，另一端插头插入电源插座，
电源指示灯亮。
3. Switch the knob to the “OFF” posion and insert the plug into the socket.
将调节杆滑至“高”的位置（最高工作温度位置），此时加热指示灯亮，表示正在加热。
4. Add food into the grill when the grill is hot.
待煎盘热后，再加入煎烤的食物。
N.B. During the grill process, please pay attenon the color change of the food and turn the
food regularly to prevent burn or rare food.
（注：煎烤过程，请注意食物的变化并且需要翻动食物，以免烤焦或烤不熟等现象）
5. Aer using, move the lever to the OFF posion and take off the plug from the socket.
使用完毕，将调节杆滑至“关”的位置，然后将电源线插头拔下。

7. To prevent leakage or short circuit, do not put the heang base into water or exposed in
dampness.
请勿将底座浸入水中，否则会导致电器部分受潮，直接影响到电器部分的绝缘性能，从而造
成漏电或短路，容易发生触电危险。
8. Never heat the hotpot or the grill on other heang sources.
请勿将铝锅/煎盘置放于其他炉具上加热。
9. During first use, some slight smoke and smell may be emitted from the appliance, which
is a normal phenomenon as it is from the protecng oil on the heang plate. This will
disappear aer a few mes of use and will not do harm to human health. Please open
your windows for better air venlaon and quicker dispersal.
第一次使用时，如闻到异味、青烟，不必担心，这属于正常现象，是产品的保护油散发出来
的气味，使用后会消除，不会对人体造成伤害，可开窗通风，快速驱散异味。
10. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
如果电源软线损坏，为避免危险，必须由厂家或厂家授权的专业人员来更换。
11. This appliance is not intended for use by persons (including children) with reduced
physical, sensory of mental capabilies, or lack of experience and knowledge, unless they
have been given supervision or instrucon concerning the use of the appliance by a
person responsible for their safety.
本器具不预备给体能弱、反应迟缓或有精神障碍的人（包括儿童）使用，除非在对其负有安全
责任的人员指导或帮助下安全使用。
12. Close supervision is necessary when the appliance is used by or near children.
Never leave the appliance unattended in case children shall play with the appliance.
Children should be supervised to ensure that they do not play with the appliance.
儿童应该被监督，以保证他们不玩耍器具，以免发生意外。
13. Appliances are not intended to be operated by means of an external mer or separate
remote-control system.
本产品不能在外接定时器或独立的遥控控制系统的方式下运行。
4

5
请勿用抹布或其它物品
覆盖蒸汽口，以免影响
机器运作。
如果电源软线损坏，必须用
专用软线或从其制造厂
或维修部买到的专用
组件来更换。
请不要用水直接冲洗
淋湿机体，以免机件
损坏或漏电。 远离高温发热器具或
灶头，避免环境温度
过高，影响机器运作。
请勿自行拆卸、修理或改装
此产品，以免日后使用
时发生危险。
请不要使用额定电压
以外的电源插座。
此产品运作时，请勿
靠近接触蒸汽口，
以免烫伤。
请勿于湿手时接触电源
插座或电源线以免
发生危险。
如长时间不使用本产品，
请拨下电源插头。 请勿于运作中移动
此产品，必须先关
机及拨出电源线，
以免危险。
请勿将任何异物插/放
入机体内，以免机件
故障。
请勿让儿童操作此产品，
并放置于婴儿不能
触及的地方。
Please do not directly wash the appliance in
case of malfuncon or electric shock.
Never leave the appliance near the gas cooker
or other heang sources to avoid
being affected by high
temperature.
Get the power cord replaced by the
manufacturer or its service facility or similar
professionals when it malfuncons.
Do not self-disassemble, self-repair or
self-alter the appliance for the sake of safety.
Do not approach or touch the vented hole
of the glass lid in case of
getng burnt.
Please unplug when the appliance is not in
use for a certain period.
Please do not attempt to reach inside the
appliance with metal objects as it may
lead to electric shock or malfuncon.
Children are not allowed to operate on the
appliance. And never leaver the appliance
in the place where children
could reach.
Do not move the appliance when it’s working.
Turn off power and unplug from the socket if
you have to move the appliance.
Do not connect the power plug to the socket
with wet hand in case of electric shock.
Do not use the socket that’s not complied
with the rated voltage.
Safety and Precaution 产品安全及注意事项
Ensure proper operaon of the appliance, do
not cover the vented hole with mop or other
arcles.

Care and Maintenance 保养方式
1 Cook with 10% of white vinegar to disinfect the cooking pot by boiling for 10 minutes in
inial use.
2. The aluminum cooking pot may fur up aer a few mes' use which is a normal
phenomenon that generated by a calcium and magnesium ions in water. It can be
removed by boiling with white vinegar and tea.
铝锅水垢为正常现象，是由于水中钙镁离子于发热盘反应生成。使用白醋，茶叶（绿茶）煮
沸，可以有效清除水垢。
3. Pay attenon to proper operaon when using to prevent the soup from overflowing.
使用时注意正确操作，防止汤汁外溢。
4. Please pour enough water into the cooking pot before use and mely add with addional
amount of water when water's reduced to avoid dry-burning.
使用时应在铝锅内必须放入适量水，水量过少时应及时添加，防止干烧。
5. If soup needs removed from the pot, please first turn off power and allow the pot to
cool down to avoid burns as the heang plate remains hot.
当需要清除锅中汤水时，应先断电冷却后再倒出，此时发热盘温度较高，以免烫伤。
6. No separaon between the aluminum pot and heang plate when in use. DO NOT put
the aluminum pot on fire heang directly.
产品使用时铝锅和发热盘间不能有任何物品隔开。请勿将铝锅放在明火上加热。
7. Wash with a mild detergent and dry with a dry cloth aer each use. DO NOT use the
corrosive cleaning detergent for cleaning.
用中性清洗剂清洗，每次使用后应清洗并用干布擦干水份。需要特别注意的是，不可用腐蚀
性强的清洗剂清洗产品。
8. The plug should be wiped frequently to keep the product clean. Or the dust will gradually
accumulate at the two poles of the plug to increase the contact resistance of the socket
and the plug, resulng in poor contact and heat.
插头应经常擦试，保持产品清洁，否则会在插头两极逐渐积灰尘产生铜绿增加插座与插头的
接触电阻，导致接触不良、发热等问题。
9. Pay attenon to the shape of the bottom of the pot to prevent collision deformaon,
affecng thermal efficiency and service life, if the bottom of the pot is deformed, stop
using it and replace the aluminum pan.
注意保持锅底的形状，防止碰撞变形，影响热效率和使用寿命，如果锅体底部变形，应停止
使用并更换铝锅。
10. Clean the grill aer itcools down with so cotton orsponge damped inmild
detergent. Never scrub the grill with abrasive cloth ormetallic ball. Please soak the
grill for about 10 minutes before cleaning if the stains are hard toclean.
.
铝锅初次加热可倒入十比一左右的白醋煮沸10分钟，进行消毒。
6

7
煎盘使用后，等煎盘自然冷却，用柔软的棉纱团或海绵加上中性的清洗剂来清洗，切勿以粗
糙的砂布或金属球大力洗擦。如果遇到难洗的顽固污渍，用清水浸泡十分钟左右再用柔软的
棉纱团或海绵进行清洗。
Hazar dous Substances List 有害物质表

Product Warranty
The Warranty Card is not provided in the product packaging. You can register the product
warranty online at our website https://www.europace.com.sg/ewarranty/ within 7 (seven)
days from the date of purchase. You will enjoy an additional 3 months of the product
standard warranty when you register online. Please produce your E-warranty registration
when requesting for repair and service at our Service Centres nearest to you.
In the event, if you are unable to register the product warranty online you must produce your
purchase receipt/tax invoice and such other documentary proof of purchase of the appliance
when requesting for repair and service.
Product Warranty Coverage
You may nd out your product warranty coverage at the link below before calling our Cus-
tomer Service Hotline [phone] or visiting our Service Centre.
http://europace.com.sg/ewarranty/src/cupload/settings_pd-
f/1/1-1-2c899-1563960978-WARRANTY-COVERAGE-19_0221.pdf
TERMS & CONDITIONS OF WARRANTY (THIS WARRANTY IS VALID IN SINGAPORE ONLY)
Your appliance is warranted against faulty design, workmanship or materials for a period of
12 months unless otherwise stated from the date of purchase, subject to the following terms
& conditions herein below:-
1) That the owner shall register the product warranty online at our website www.eu-
ropace.com.sg within 7 (seven) days from the date of purchase.
2) That the appliance shall be used solely for domestic purposes and not for commercial
purposes or any other purposes whatsoever and used strictly under the instruction for
operation as provided by the manufacturers or the appliance.
3) That if any time during the warranty period any part or parts of this appliance is removed,
tampered, modied, adjusted, altered, handled or repaired in any way whatsoever by any
persons other than those authorized by Strategic Marketing (S) Pte Ltd, this warranty shall
immediately cease to be valid and become void.
4) That the owner shall produce the E-warranty registration or tax invoice/receipt and such
other documentary proof of purchase of the appliance to our satisfaction as we may deem
necessary when requesting for repair and service.
5) That our decision on all queries relating to complaints as to defects either of workmanship
or of materials shall be conclusive and the owner shall agree to abide by such a decision. Any
appliance or defective part which has been replaced shall become our property.
6) The terms and conditions of this warranty shall be contained exclusively in this document
and no other presentation of provision, either written or otherwise, regardless of the origin of
the same, shall be accepted as either adding or removing from these terms and conditions.
7) That this warranty shall cease to be valid and void if the appliance is exported or
relocated from Singapore.
8) That there shall be no removal, alteration, defacement, or made illegible/tampered or any
kind of the serial number on the appliance.
9) That the owner shall be fully responsible for the due delivery and collection of the appli-
ance for any work done according to this warranty. Transportation expenses incurred for
delivery or handling the appliance are chargeable to the owner.
10) Transportation and labour charges apply after the full parts warranty expires. Refer to
https://www.europace.com.sg/ewarranty/ for more information.

In addition to the above, this warranty shall be subjected to the following limitations and
exclusions:-
a)The appliance shall be warranted by STRATEGIC MARKETING (S) PTE. LTD. from date of
purchase only for a period of:-
10 years - Heating Element warranty applies to selected models of Storage Water Heaters.
- Tank Leakage warranty applies to selected models of Storage Water Heaters.
8 years - Motor warranty applies only to selected models of Stand Fans (Walk-in warranty).
10 years - Compressor warranty applies to selected models of Refrigerators.
6 years - Motor warranty applies only to selected models of Stand Fans (Walk-in warranty).
- Compressor warranty applies only to selected models of System Air Conditioners
and Portable Air Conditioners.
5 years - Compressor warranty applies to Refrigerators, Freezers, Wine Coolers, Portable
Air Conditioners & Casement Air Conditioners (Outdoor warranty). Transportation is
chargeable from the 2nd year to 5th year.
- Compressor warranty applies to Dehumidiers (Walk-in warranty)
- Motor warranty applies only to selected models of Stand Fans (Walk-in warranty).
3 years - Full parts warranty applies only to selected models of Air Puriers & selected
models of Dehumidiers (Walk-in warranty).
- Heating Element warranty applies only to selected models of Garment Steamers
(Walk-in warranty).
- Motor warranty applies only to selected models of Jet Turbine Fans & selected
models of Air Coolers (Walk-in warranty).
2 years - Motor and internal parts warranty applies only to selected models of Stand Fans,
selected models of Oscillation Power Fans & selected models of Air Puriers
(Walk-in warranty).
- Heating Element warranty applies to selected models of Electric Ovens &
selected models of Kettle Jugs. (Walk-in warranty)
- Motor warranty applies only to selected models of Jet Turbine Fans
(Walk-in warranty).
- Full parts warranty applies only to Wine Coolers of 34 Bottles & above.
1 year - Full parts warranty applies to *Lifestyle Products (cash & carry items), Small
Kitchen Appliances, Fans, Air Coolers, Wine Coolers of 20 Bottles & below, Mini
Bar Fridge (Walk-in warranty)
- Full parts warranty apply to Refrigerators, Air Conditioners & Freezers
(Outdoor warranty).
Check out the warranty coverage of your appliance at www.europace.com.sg
b) The owner waives all or any claims to compensation monetary or otherwise which
he/she may be entitled to and shall agree to accept any compensation whatsoever by
way of additional repairs or otherwise which we in our absolute discretion may deem t
to oer. The giving of compensation shall be subjected to the other provisions of the
warranty.
c) This warranty shall not be transferable, negotiable or assignable to any third party.
d) The warranty does not include transport delivery or handling charges incurred in the
transportation of the appliance to and from Strategic Marketing (S) Pte Ltd.
e) Damage caused during transit where the appliance is transported for servicing, repair,
or in relation thereof or connection therewith.
f) In respect of refrigerator and air conditioner only, upon the expiry of 12 months from
the date of purchase, this warranty will not cover transport, refrigerant and labour to
install a new compressor.

g) This warranty will not cover chemical cleaning, maintenance service, general service and
overhaul, which if conrm is chargeable.
h) Defects or fault in the appliance which has been used for commercial purposes or which
have been rented/leased or which have been otherwise subject to other than household
use.
i) Claims for damaged/missing parts after 3 days from the original date of goods received
will not be valid.
j) This warranty and the Replacement Scheme does not particularly cover damages and/or
defects arising from
• Usage of wrong electrical supply/voltage.
• Usage not according to the Instruction Manual provided by the manufacturers.
• Misuse, accidents, negligence, abuse, improper installation, or any manner of tampering.
• Normal wear and tear.
• Corrosions rusting or stains.
• Scratches, dents on the unit body, casing or paintwork of the appliance.
• Act of God, re, ood and civil unrest.
• We shall not under any obligation, legal or otherwise to repair this appliance or one to one
exchange if the same shall be required as a result of losses, damages, and malfunctions
arising from any of the causes mentioned in the paragraph.
k) All accessories, external parts and extruded parts such as front panel, casing, door, glass
cover, glass door, cable/cord assembly, batteries, adaptor, plug, remote control, control
knob, buttons, lter, UV lamp, oven tray, wooden rack, exhaust hose, xtures, panels, cover,
lid and lever, plastic parts, fan blades, blade guard, inner pots, brushes, water tanks, attach-
ments made of glass, plastic and/or porcelain, detachable parts, and other option items are
excluded from this warranty.
All services provided after the warranty period will be chargeable at standard rates deter-
mined by STRATEGIC MARKETING (S) PTE. LTD.
The terms and conditions of this warranty shall be varied except with the written and
express consent or agreement of Strategic Marketing (S) Pte. Ltd. While Strategic Marketing
(S) Pte. Ltd. endeavours to repair any defects after the warranty period, it is subject to avail-
ability.
It is hereby expressly provided that any liability of Strategic Marketing (S) Pte. Ltd. for any
loss or damage whatsoever arising from, relating to or in connection with the purchase of
the appliance shall not exceed the purchase price (excluding installation costs) of the appli-
ance. Similarly, Strategic Marketing (S) Pte. Ltd.’s liability for any breach of this warranty shall
be limited to the purchase price (excluding installation costs) of the appliance.
* Lifestyle Products - Garment Steamer, Humidier, Dehumidier, Air Purier, Mini
Bar-Fridge.
* Walk-in warranty - Customers are obliged to bring the warranted products to Strategic
Marketing (S) Pte. Ltd. Service Centre for repair/service during the warranty period.
Ver. 20 _0312
Scan QR Code for
the online Warranty
Registration

System Split Aircons | Tel: [phone]| Email: [e-mail] (Twin City)
Portable & Casement Aircons | Tel: [phone] | Email: [e-mail] (Jia Yue)
Refrigerators, Washing machines, Cookers & other major appliances |
Tel: [phone] | Email: [email protected]om.sg (TnG)
RELATED PRODUCTS & MAIN CONTACT HOTLINE
Ver. 20 _0312
