European Home Scaffold Designer Surround 95 User manual

1
Element4 Modore Fireplaces EuropeanHome.com
Scaffold
Designer Surround
Installation Guide
May 2019
Exclusively designed to fit these
Element4 Fireplaces:
Modore 140 Modore 185Modore 95

2
Element4 Modore Fireplaces EuropeanHome.com
TABLE OF CONTENTS
Important Information 3
Specications and Dimensions 5
Pre-Installation Planning 6
Installation 7
Maintenance 12
Warranty 13

3
IMPORTANT INFORMATION
Element4 Modore Fireplaces EuropeanHome.com
PRODUCT INSTALLATION RECORD
Installer: Please complete this form. Customer: Please retain this information.
Purchased From
Date of Purchase
Installed By
Date of Installation
Surround Serial Number
Thank you for your purchase of a Designer Surround for Element4!
Since your Designer Surround for Element4 is designed to install, and perform, like ceramic tile, it should be
installed by a professional.
Please refer to your dealer for additional information for professional installers .

Element4 Modore Fireplaces EuropeanHome.com
SCAFFOLD SURROUND PANELS
4
52” Metal 63” Metal 84” Metal
95 Scaold - 2 -
140 Scaold - - 2
185 Scaold 4 - -
52”
63”
84”
Each surround contains Metal and Tile Panels according to the chart, above.
All surround panels are 7/16”thick
6”
6”
6”
12”
16 3/4” 12”
17 1/8”
12” 16 13/16”
24”
16 3/4” 24”
17 1/8”
24” 16 13/16”
12"x 16 13/16"
tile
12"x 16 3/4"
tile
12"x 17 1/8"
tile
24"x 16 13/16"
tile
24"x 16 3/4"
tile
24"x 17 1/8"
tile
95 Scaold 1 - - 1 - -
140 Scaold - 1 - - 1 -
185 Scaold - - 1 - - 1

SPECIFICATIONS and DIMENSIONS
5
Element4 Modore Fireplaces EuropeanHome.com
SPECIFICATIONS and DIMENSIONS
5
140
185
91 1/8”
109”
28 3/4”
29 1/8”
95
73 1/2”
29”
Tile Tile
Tile Tile
Tile Tile
63”
63”
84”
84”
52”52”
52” 52”

Element4 Modore Fireplaces EuropeanHome.com
6
PRE-INSTALLATION PLANNING
BEFORE YOU BEGIN
These surrounds are intended to be installed in the same manor you would use a french cleat system.
(See image below)
Please read these instructions thoroughly before proceeding. There is information which is important for safe
and eective installation.
Please inspect your shipment for completeness and any damage. Contact your retailer if any damage is found.
Do not install your surround with any damaged or substituted parts.
For the best nished results, please consider hiring a professional Carpenter or Contractor to install these
surround panels. You can also refer to your dealer.
Before you begin your installation you should have the following tools and supplies:
• Gloves
• Pencil
• Impact Gun
• Drill
• Level
• Tape Measure and Framing Square
• Lint-free Cloth
• Stud-nder
• #8 Screws (Bugle Head)
Included with the Surround Panels:
• Various sized Z-Clips
Wall
Surround
Detail of French Cleat Operation

Element4 Modore Fireplaces EuropeanHome.com
INSTALLATION
7
LAYING OUT THE PANELS
The panels of the Designer Surround for Element4 are made to t against the replace opening and each other.
First, hold a metal panel up to the lower edge of the replace and mark the wall with a light pencil line along
the lower edge of the metal panel(s). Then draw a straight line parallel to the right edge of the replace
opening at the distance shown below as appropriate for your surround model. The intersection of these two
lines is the starting point for the installation.
Layout Lines for the Scaold 95
(not to scale)
7 1/2” right of
replace opening
Layout Lines for the Scaold 140
(not to scale)
8 1/4” right of
replace opening
Layout Lines for the Scaold 185
(not to scale)
9” right of
replace opening
Starting
Point
Starting
Point
Starting
Point
6” down from replace
6” down from replace
6” down from replace

Element4 Modore Fireplaces EuropeanHome.com
INSTALLATION
8
The metal panels and tile panels should be applied to the wall in the order shown below. They will be hung on
the wall using z-clips by the system described on page 6,9,10 and 11.
140 Fireplace
185 Fireplace
95 Fireplace
2 (Tile) 3 (Tile)
4 (Metal)
1 (Metal)
4 (Metal)
1 (Metal)
2 (Tile) 3 (Tile)
Scaold 95
Scaold 140
Scaold 185
5 (Metal)
1 (Metal)
3 (Tile) 4 (Tile)
INSTALLATION: WALL LAYOUT
2 (Metal)
6 (Metal)

Element4 Modore Fireplaces EuropeanHome.com
INSTALLATION: WALL LAYOUT + Z-CLIPS
9
NOTE ABOUT ZCLIPS
Z-clips installed on the wall should have the interlocking side facing up. The slotted side of the clips face
the wall. The length of the clips is to account for contact with the existing wall stud behind the wall sheet-
ing. Mount the Z-clips to studs only.
ZCLIP INSTALLATION PREP  REFER TO GRAPHICS ON PAGES 1011
• Use a stud-nder to mark the stud locations above, below, and anking the replace within the relevant
area you will be installing the surround. Screw into these locations for structural integrity. Note, you can
drill into the replace cabinet using 3/4” self tapping screws.
• The included z-clips should exceed 16”slightly. Holes are predrilled to 16” to line up with the rule of 16”
on center. There should be center drilled holes as well.
• Before sinking the second screw, make sure you level the clip o along the guideline.
Ideal Stud Framing Example

Element4 Modore Fireplaces EuropeanHome.com
INSTALLATION
10
Using the starting point and the edges of the replace, mark lines on the wall using the measurements
appropriate to your model, below.
Red lines Represent guidelines for Z-clip; draw these in as guides for mounting.
Layout Lines for the Scaold 95
(not to scale)
Layout Lines for the Scaold 140
(not to scale)
Layout Lines for the Scaold 185
(not to scale)
6”
6”
24” 12”
2 5/16”
2 5/16”
2 3/16”
6”
6”
24” 12”
2 5/16”
2 5/16”
2 3/16”
6”
6”
24” 12”
2 5/16”
2 5/16”
2 3/16”
INSTALLATION: WALL LAYOUT

Element4 Modore Fireplaces EuropeanHome.com
INSTALLATION
11
The areas in gray, below, show where the Z-clips is to be applied to the wall.
Align Z-Clips to Red Lines
(140 - not to scale)
Align Z-Clips to Red Lines
(185- not to scale)
Align Z-Clips to Red Lines
(95- not to scale)
6”
6”
24” 12”
2 5/16”
2 5/16”
2 3/16”
6”
6”
24” 12”
2 5/16”
2 5/16”
2 3/16”
6”
6”
24” 12”
2 5/16”
2 5/16”
2 3/16”

MAINTENANCE
12
Element4 Modore Fireplaces EuropeanHome.com
SURROUND MAINTENANCE
Weekly Cleaning
Both the metal and tile panels should be wiped with a lint free cloth to remove any dust then wiped with a
damp cloth.

WARRANTY
13
Element4 Modore Fireplaces EuropeanHome.com
WARRANTY
13
European Home Warranty
Designer Surround for Element4
European Home warrants this product against defects in materials and workmanship for a period of TWO (2)
YEARS from the date of original retail purchase.
If a defect exists, European Home will, at its option, either (1) provide needed components using new or
refurbished replacement parts or (2) exchange the product with one which is new or which has been manu-
factured from new or serviceable used parts and is at least functionally equivalent to the original product. A
replacement product/part assumes the remaining warranty of the original product or ninety (90) days from
the date of replacement or repair, whichever provides longer coverage for you. When a product or part is
exchanged, any replacement item becomes your property and the replaced item becomes the property of
European Home. All warranty claims must be submitted through the dealer from which you purchased the
product. Check with your dealer in advance for any costs to you when arranging a warranty call. Shipping
and/or delivery charges for parts are not covered by this warranty.
Nothing in the above shall be deemed to imply that this warranty shall apply to work which has been
abused or neglected or shows evidence of changes or modications by others with or without permit, dam-
ages caused by the acts of God, building settlement or moving, re or vandalism. In addition, installation of
this product that varies from the requirements stated in the instruction manual will void the warranty.

14
Element4 Modore Fireplaces EuropeanHome.com
EUROPEAN HOME
a division of Europa Ja, Inc.
30 Log Bridge Road
Building 300 - Suite 303
Middleton, MA 01949
www.europeanhome.com
