Valor LX1 Series User manual

June 2019
Framing - Wood
LX1 1/2
10-1/4”
[261 mm]
15”
[381 mm]
8”
[204 mm]
11-1/4”
[286 mm]
46-1/2” [1181 mm]
18-1/2”
[470 mm]
Combustible wall nish zone
Non-combustible wall nish zone
Combustible framing
material.
1/2” [13 mm] non-
combustible cement
board required in this
zone. May be covered
with max. 3/4” [19 mm]
combustible nish.
Combustible projec-
tions must otherwise
conform to allowable
clearances. See “Clear-
ances to Combustibles”
in Installer’s Manual.
Max 1-1/4” [32 mm]
thickness combustible
wall nish allowed, if
within 4” of opening.
Combustible framing
material allowed.
Zero clearance stand-
os (2 front, 2 rear).
HeatShift pipes (4)
5” Ø connect to
plenum or termina-
tion plates above,
see “Appendix D” of
Installer’s Manual.
HeatShift plenum or duct plates framing
required (top, front, or sides).
WARNING
Ensure weight of wall above is
NOT carried by the appliance.
46-3/4” [1187 mm]
From wall
2”
[51 mm]
Requires steel stud
under outlet open-
ing when using LDK4
plenum.
WARNING
There are restrictions for where drilling and
screwing may take place. See Installer’s Manual.

Valor Fireplaces • 190—2255 Dollarton Highway • North Vancouver, BC • V7H 3B1
Tel: [phone] or 1.800.468.2567 • Fax: [phone] or 1.800.268.0333
www.valorreplaces.com
Framing - Steel
10-1/4”
[261 mm]
2”
[51 mm]
15”
[381 mm]
8”
[204 mm]
11-1/4”
[286 mm]
(non-combus-
tible clear-
ance)
46-3/4” [1187 mm]
From wall
18-1/2”
[470 mm]
1/2” [13 mm] non-com-
bustible cement board
required in this zone. May
be covered with max.
3/4” [19 mm] combus-
tible nish. Combustible
projections must other-
wise conform to allowable
clearances. See “Clear-
ances to Combustibles” in
Installer’s Manual.
Max 1-1/4” [32 mm] thick-
ness combustible wall
nish allowed if within 4”
of opening.
Combustible nishing
material allowed.
HeatShift plenum or duct plates
framing required (top, front, or rear).
WARNING
Ensure weight of wall above is
NOT carried by the appliance.
9-5/8”
[245 mm]
Combustible studs (2)
proud of wall surface re-
quired to mount framing
kit. Requires solid con-
nection to studs behind
wall.
Combustible wall nish zone
Min 1/4” [6 mm] gap
between sections
Min 1/4” [6 mm] gap
between sections
30”
[762 mm]
11-5/8”
[295 mm]
Use self-drilling screws
when applying wall n-
ishes (up to 2 layers).
Non-combustible wall nish zone
HeatShift pipes (4) 5”
Ø connect to plenum
or termination plates
above, see “Appendix D “
of Installer’s Manual.
WARNING
There are restrictions for where drilling and
screwing may take place.
