Eurotech TRV602 NF Technical manual

Dear User,
we are sincerely grateful to you for purchasing one of our products.
We are sure that the appliance modern, functional and easy to use, built with the finest materials
and components will satisfy all your needs.
We would ask that you read the instructions within this booklet very carefully so as to enable you
to obtain quality results from the outsets.
The appliance must be installed only by a qualified electrician in compliance with the
instructions provided. The manufacturer declines all responsability for improper installation.
USE, INSTALLATI N AND MAINTENANCE
INSTRUCTI NS F R ELECTRICAL
BUILT-IN H T PLATES
The manufacturer is not responsible for any transcription errors or misprints contained in this handbook
and, furthermore, reserves the right to make any modification on the products, which might be deemed
necessary or usefull, this being in the user’s interest, without altering their basic operating or safety
features.This cook top was designed to be used exclusively as a cooking appliance: any other use
(such as heating rooms) is to be considered improper and dangerous.
COD. 04074EUR - 21.06.2012
M DELS: TRV602 NF

DESCRIPTI N
2
1 Radiant electric heating element Hi-light Ø 140 mm of 1200 W
2 Radiant electric heating element concentric Hi-light Ø 180/120 mm of 1700/700 W
3 Knob for electric element 1
4 Knob for electric element 2
TYPE: PCZ VTC 30

3
USE
FIG. 1
1) ELECTRIC H B
The hot plates are equipped with radiant heating
elements with different powers and diameters.
Cooking zones are aesily identifiables thanks to the
circles (see illustration in description) on the top;
relative powers are listed in the scheme n. 1.
On the frontal panel, close to each knob, has been
silk-screened a scheme where is indicated to which
cooking zone the knob refers (fig. 1).
In some particular models the scheme annexes a
light indicator that turns on when the cooking zone
temperature is above 60 °C.
The indicator will turn off only when the temperature
of the cooking zone will be below the value: this is
the reason why we call it residual heat indicator.
Some other models they have only one indicator
(see description paragraph).
Connection of electric heating elements
Heating elements are controlled by energy
regulators with 12 positions that permit to obtain a
big range of different temperatures.
In Scheme 1, by way of information, we give
instructions to obtain different cooking levels.
To connect the heating elements is necessary to
turn clockwise or anticlockwise the relative knob.
How to use the cooking zones
Heating takes place only in the inside part of the
circles drawn on the special glass. The circles have
to be wholly covered by the pots.

USE
4
SCHEME 1
Power and dimensions
of the cooking zones
Position for regulation
of the knobs
Possible cooking
processes
Zone
no° Diameter
in mm
Heating
element
Power
W
1 140 Hi-light 1200 1
2 180/120 Hi-light 1700/700 1 - 4
To dissolve butter, chocolate,
etc... To heat small amounts
of liquid.
4 - 8
To heat larger amounts of
liquid. To prepare cremes
and suces requiring long slow
cooking times.
5 - 6
To heat foods to boiling point.
To brown delicate meats and
fish.
8 - 10
To thaw frozen foods and
prepare stews, heat to boiling
point or simmer.
10 - 12
For escalopes and steaks.
To simmer large amounts
of food.
12
To bring large amounts of
liquid to the boil.
For frying.

5
WARNINGS:
for a correct use, please look at fig. 2 and remind:
- switch on the electricity only after having placed
the pot on the cooking zone.
- Use pots and pans with flat solid bottoms.
- Use pots with the same diameter of the cooking
zones.
- Dry the bottom of the pot before put in on the
cooking zones.
- Do not scrape the pot against the glass so to
not damage it.
- During the use of the cooking zones, please,
keep the children away from the hot plates.
ake sure that the handles of the pots are
placed in the right way towards the interior.
Be aware that overheated fats and oils may
become inflamed.
- Cooking zones after using remain warm; don’t
leave objects, don’t lean your hands so to avoid
burns, till the indicator light is off.
- If the glass cracks, please, disconnect the
appliance.
- Don’t use plastic pots or alluminium sheets.
- Don’t use hob as a supplementary surface.
- Containers wider than the unit are not
recommended.
USE
FIG. 2

6
WARNING FOR USE:
►the appliance is built to perform the following function: cooking and heating food.
Every other use must be considered improper:
►never use this appliance to heat the environment;
►do not attempt to change the technical characteristics of the product because it
can be dangerous.
►
If you should not to use this appliance any more (or replace an old model), before disposing
of it, make it inoperative in conformity with current law on the protection of health and the
prevention of environmental pollution by making its dangerous parts harmless, especially
for children who might play on an abandoned appliance;
► do not touch the appliance with wet or damp hands or feet;
►do not use the appliance barefoot;
►the manufacturer will not be liable for any damage resulting from improper, incorrect or
unreasonable use;
►during, and immediately after operation, some parts of the cook top are very hot: avoid
touching them;
►if the ceramic glass hob is not cleaned immediately, there is a risk of residues becoming so
encrusted that they will be impossible to remove after the hob has cooled;
The hob instructions must state that the appliance is not destined for use
with an external timer or a separate remote control system.
The appliance is not destined for use by people (including children)
with physical, sensorial or mental impairments, unless they are supervised
or instructed in the use of the appliance by a person responsible for their safety.
Children must be supervised to make sure that they do not play with
the appliance.
USE

Before any cleaning operation, disconnect the
appliance from the electric circuit.
2) ELECTRIC H B
If you want to preserve the surface clean and bright,
we recommend you to use a silicone conditioner.
The use of this conditioners, prior to jam-making,
helps to protect the surface of the hob. This
protective film is not durable, so it is advisable to
repeat the application of the product frequently.
It is very important to clean the surface soon after
every use, when the glass is still tepid.
Do not use metallic sponges, powder abrasives or
corrosive sprays.
Depending on the dirty level we recommend:
- slights stains: it is enought the use of a moist clean
rag.
- Burnt or soiling may be removed with a special
razor scraper (fig. 3); be aware that the razor
can cause wounds.
- Marks of liquid, overflowed from the pot, can be
removed using vinegar or lemon.
-Pay attention to not let fall sugar or element with
sugar. In this case turn the switch off and clean
the surface with hot water and the razor blade
scraper.
- After a period of time may appear metal reflex and
scratches (fig. 4) due to the wrong cleaning and
the wrong use of the pots. The scratches are
difficultly removable, but they do not compromise
the good working of the hob.
- Don’t use steam jets for the equipment cleaning.
FIG. 3 FIG. 4
CLEANING
7

TECHNICAL INSTRUCTIONS
FOR THE INSTALLER
Installation, transformations and maintenances
below listed, may only be carried out by a
competent technician.
The appliance must be correctly installed in
conformity with current law and the
manufacturer's instructions.
A wrong installation may provoke damages to
persons, animals or things, for which the builder
can not be responsible.
Throughout the life of the system, the devices
for the safety and automatic regulation of the
appliances must only be modified by the
manufacturer or the duly authorised supplier.
3) INSERTING
After having cleared out all the packing components,
make sure of the integrity of the appliance.
If you are in any doubt, do not use the appliance
and contact qualified personnel.
The packing elements (cardboard, bags,
polystyrene, nails...) must not be left within the
reach of children as they are potential sources
of danger.
Make a cutout in the worktop, according to the
dimensions indicated in fig. 5; make sure that will be
respected the critical dimensions of the space in
which the appliance has to be installed (fig. 5 - 6).
In order to avoid accidental contact with the surface
of the box of the overheated hob during use, it is
necessary to install a wooden divider at a minimum
distance of 120 mm from the top, fastening it in
place with screws (fig. 5).
CO PLY WITH THE DI ENSIONS (mm)
FIG. 5 FIG. 6
INSTALLATI N
A B C D E
2 EL. 282 482 59 59 60 min.
8
CAUTION:
do not place the glass directly on the unit.
The bottom of the hob must rest on the unit.

INSTALLATI N
9
FIG. 7 FIG. 8
4) FIXING
A special sealing strip underneath the hob for
damage. Make sure it is correctly positioned with no
gaps; it avoids any water infiltration. To fix in the right
way the putty , please, respect the following
instructions:
- remove all the mobile parts of the hob.
- Cut the putty into 4 strips of the lengths suitable to
fit it along the 4 sides of the glass.
- Overturn the hob, take the putty strips off from their
support, having care that the transparent protection
remains attached to the putty . Correctly place the
putty "E" (fig. 7) under the hob edge, so that the
external side of the putty fits together with the
external perimentrical edge of the hob. The ends of
the putty must fit together without overlapping.
- Stick the putty to the hotplate uniformly, pressing it
with fingers.
- Position the hob in the hole in the unit and fasten it in
place using the appropriate screws “F” of the
fastening hooks “G” (see fig. 8).
- In order to avoid accidental contact with the
surface of the box of the overheated hob during
use, it is necessary to install a wooden divider at a
minimum distance of 120 mm from the top,
fastening it in place with screws (fig. 5).
- To fasten this product to the supporting structure,
we advise you not to use mechanical or electrical
screwdrivers and to exercise moderate pressure
by hand on the fastening hooks.
WARNINGS:
be aware that the glue that join the laminated
plastic to the furniture, has to resist to
temperature not below 150 °C, to avoid the
unstuck of the panelling.
The rear wall, adjacent and surrounding surfaces
must therefore be able to withstand an
overtemperature of 65 K.
P SITI N H KS N THE B TT M

5) ELECTRICAL C NNECTI N
The electrical connection has to be done in
accordance with all electrical and installation
requirements of the regulation.
Before proceeding with the connection, please,
verify that:
- the voltage matches the value shown on the
specification plate and the section of the wires of
the electrical system can support the load, which
is also indicated on the specification plate.
- The power of the electrical system and the power
of the outlets is adequate to the maximum power
of the appliance (see the identification label in the
lower part of the body).
- The outelets and all the electrical system has an
efficient connection to the "earth" according with
the Regulation. We disclaim all responsabilities
for not observing such points.
- If the appliance is not equipped with an input
cable, connect to the clump with an adequate
section cable (see scheme paragraph 7) keeping
the "earth" conductor longer than "live" ones,
following the scheme of fig. 9, 10, and 11.
When the connection to the input system has
been done through a outlet:
- apply to the input cable "C", if unprovided, a
normalized plug adequate to the load indicated in
the identification label. Connect the cables
according to the scheme of fig. 9, 10, and 11,
making sure to respect the undermentioned
respondences:
Letter L (Live) = cable brown colour;
Letter N (Neutral) = cable blue colour;
Symbol (Earth) = cable green - yellow colour.
- The input cable has to be located so that never
reach the over temperature of 75 K.
- Please do not use in the connection any
reduction, adaptation that may provoke a false
contact with following dangerous overheatings.
- The outlet must be accessible after the built-in.
When the connection has been done directly to
the input system:
- interpose between the appliance and the system
an onnipolar switch, in compliance with current
installation regulations, with a minimum aperture
between contacts of 3 mm.
- Keep in mind that the "earth" cable does not have
to be interrupted by the switch.
- Alternatively, the electrical connection can also be
protected by a differential switch with high
sensitivity.
We recommend to fix the earth coloured cable to
an appropriate earth installation.
Before performing any service on the electrical
part of the appliance, it must absolutely be
disconnected from the electrical network.
WARNINGS:
all our products are projected and built
according with the European Norms
EN 60 335-1, EN 60 335-2-6 and relative
amendments.
The appliance has been produced according
with the European Directives:
- CEE 2004/108/CE concerning the compatibility
electromagnetic.
- CEE 2006/ 95 concern i ng the elect rical
security.
INSTALLATI N
10
I PORTANT: the appliance must be installed
following the manufacturer's instructions.
The manufacturer will not be liable for injury
to persons or animals or property damage
caused by an incorrect installation.
If the installation requires modifications to
the home's electrical system or if the socket
is incompatible with the appliance's plug,
have changes or replacements performed by
professionally-qualified person. In particular,
this person must also make sure that the
section of the wires of the socket is suitable
for the power absorbed by the appliance.

11
INSTALLATI N
FIG. 11
FIG. 9 FIG. 10
PCZ VTC 30

SERVICING
Always disconnect the appliance from the
electricity main before proceeding with any
servicing operation.
6) REPLACING THE ELECTRICAL
C MP NENTS
For access to the various parts, remove the hotplate
from the top of the cabinet. Then overturn it, unscrew
screw and remove under the bottom.
After these actions is possible to work on the
plates, commutators, clamps and input cable.
N.B. In case of substitution of the input cable,
the installer must keep the “earth” conductor
longer than “live” ones, and must respect the
cautions in paragraph “Electrical connection”.
To reassemble the appliance repeat the inverse
process.
7) TECHNICAL CHARACTERISTICS F
THE ELECTRICAL C MP NENTS
To facilitate the job of the installer we present a sche-
me with the characteristics of the components.
P WER F ELECTRICAL C MP NENTS
Description W
Heating element hi-light Ø 140 mm 1200
Heating element concentric hi-light Ø 180/120 mm 1700/700
12
WARNING:
AINTENANCE UST ONLY BE
PERFOR ED BY AUTHORISED PERSONS.
TYPE AND SECTI N F THE P WER CABLES (F R 2 HEATING ELEMENTS)
Cable type Single phase power
230 - 240 V ~
Rubber H05 RR-F 3 x 1.5 mm2

13
TECHNICAL DATA
M DEL 2 HEATING ELEMENTS (30)
(1 HI-LIGHT + 1 HI-LIGHT WITH C NC. D UBLE Z NE)
Voltage 230 - 240/400 - 415 V 3 ~
Frequency 50/60 Hz
Tot. rating 2900 W

14
TECHNICAL ASSISTANCE AND SPARE PARTS
This appliance, before leaving the factory, has been carefully tested and regulated by expert and
specialized personnel in order to guarantee the best performances.
Any repairs or adjustments which may be subsequently required may only be carried out by qualified
personnel with the utmost care and attention.
For this reason, always contact your Dealer or your nearest After Sales Centre whenever repairs or
adjustments are required, specifying the type of fault and the model of appliance in your possession.
Please also note that genuine spare parts are only available from our After Sales Service Centres and
authorized retail outlets.
The above data are printed on the data label put on the inferior part of the appliance and on the packing
label.
The above informations give to the technical assistant the possibility to get fit spare parts and a heaven-
sent intervention. We suggest to fill the table below.
ARK: ................................................
ODEL: .............................................
SERIES: .............................................

15

16
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
This guideline is the frame of a European-wide validity of return and recycling on Waste Electrical and
Electronic Equipment.
