Eusso UNC7825 Series User manual

Indoor/Outdoor Dual-Codec
CCD IP Speed Dome Camera
UNC7825-Series User’s Manual
Version: 1.4
Date: 03/26/2008
Copyright EUSSO Technologies, Inc. All rights reserved
1

Content
INTRODUCTION...................................................................................................................................................................- 4 -
WHAT IS NETWORK DOME CAMERA?......................................................................................................... - 4-
FEATURES...................................................................................................................................................................... - 5-
1PHYSICALCONNECTIONS...........................................................................................................................................- 7 -
1.1 STRUCTURAL ELEMENT................................................................................................................................................. - 7-
1.2 CONNECTION JACK AND CABLE REQUIREMENT............................................................................................................. - 8-
1.3 DIPSWITCH SETTING.................................................................................................................................................. - 10 -
1.4 NDC IDADDRESS SETTING REFER CHART...................................................................................................................- 11 -
2INSTALLATION..............................................................................................................................................................- 12 -
2.1 INSTALLATION PREVIEW .............................................................................................................................................. - 12 -
2.2 HARDWARE INSTALLATION.......................................................................................................................................... - 13 -
2.3 SOFTWARE INSTALLATION ........................................................................................................................................... - 25 -
2.4 NETWORK CONFIGURATION......................................................................................................................................... - 26 -
3USAGE OFWEB-BASED USER INTERFACE...........................................................................................................- 30 -
3.1 BROWSE LIVE VIDEO................................................................................................................................................... - 30 -
3.2 VIDEO AND AUDIO RECORDING................................................................................................................................... - 33 -
3.3 VIDEO CONFERENCE.................................................................................................................................................... - 34 -
4CONFIGURATION OFWEB-BASED USER INTERFACE ......................................................................................- 37 -
4.1 CONFIGURATION PREVIEW........................................................................................................................................... - 37 -
4.2 CONFIGURATION OF A/V SETTING ............................................................................................................................... -38 -
4.3 SETTING EXTERNAL SOURCES ..................................................................................................................................... - 42 -
4.4 PTZ SETTINGS............................................................................................................................................................. - 43 -
4.5 ON SCREEN DISPLAY ................................................................................................................................................... - 48 -
4.6 CONFIGURATION OF NETWORK SETTING ..................................................................................................................... - 49 -
4.7 CONFIGURATION OF SYSTEM ....................................................................................................................................... - 53 -
4.8 CONFIGURATION OF EVENT ......................................................................................................................................... - 57 -
5ADVANCED SETTINGS FOR UNC7825-O.................................................................................................................- 60 -
5.1 CALL OUT THE OSD SETUP MENU .............................................................................................................................. - 60 -
5.2 SET UP FUNCTIONS...................................................................................................................................................... - 61 -
6ADVANCED SETTINGS FOR UNC7825-OW.............................................................................................................- 70 -
6.1 CALL OUT THE OSD SETUP MENU .............................................................................................................................. - 70 -
6.2 SPECIAL FUNCTIONS.................................................................................................................................................... - 71 -
6.3 CAMERA SETTINGS...................................................................................................................................................... - 74 -
6.4 LENS CONTROL ........................................................................................................................................................... - 86 -
7ADVANCED SETTINGS FOR UNC7825-OT ..............................................................................................................- 88 -
- 1 -

7.1 CALL OUT THE OSD SETUP MENU .............................................................................................................................. - 88 -
7.2 SETUP FUNCTIONS ....................................................................................................................................................... - 90 -
8SURVEILLANCE SYSTEM CONFIGURATION .....................................................................................................- 101 -
8.1 NDCAND KEYBOARD ............................................................................................................................................... - 101 -
8.2 INITIAL POWER UP INSPECTION ................................................................................................................................. - 103 -
8.3 OPERATING NDCWITH KEYBOARD........................................................................................................................... - 103 -
9SPECIFICATIONS........................................................................................................................................................ - 113 -
APPENDIX A. UPGRADING THE SOFTWARE............................................................................................................ - 118 -
APPENDIX B. UPGRADE CUSTOM WEB PAGES ......................................................................................................- 121 -
APPENDIX C. EMERGENCY FACTORY DEFAULT...................................................................................................- 123 -
APPENDIX D. QUICK REFERENCE TABLE FOR KEYBOARD CONTROL.........................................................- 124 -
APPENDIX E. TROUBLE SHOOTING...........................................................................................................................- 126 -
- 2 -

WARNING and PRECAUTIONS
Please read the manual before attempting installation or operation.
Please be aware of the following:
1. Don't use any chemical detergent to clean the machine surface, use a damp cotton cloth only. Regularly clean the dome
cover to ensure more accurate focusing.
2. Please install the Network Dome Camera in a dry area; water and high humidity may cause damage on internal parts.
External housing should be used for outdoor installations.
3. Please use parts supplied by the manufacturer only, any unqualified part using in the equipment may violate the warranty.
4. Avoid installing the equipment in an unstable surface. Ensure that the equipment is attached to something that is fixed
solidly in place. Falling equipment may injure personnel and damage the equipment.
5. Do not install the equipment near any flammable materials as they may cause a fire or personal injury.
6. Avoid running video cable and signal cable through or passing interference sources such as video waves, broadcast
stations, power generators, elevator motors or high voltage areas, etc. as they may cause interference.
7. Ensure the power cable is properly attached. Improperly attached cables may cause a serious short circuit or fire.
8. Correct cable connection is important. Do not place any object on the connection cable and change the cable if there is
damage on cable. Violation may cause short circuit, fire and injury.
9. Make sure ground is well connected to avoid damage caused by lightning.
10. Do not put any foreign objects inside the equipment and do not spray any liquid on equipment. This will avoid short circuit
damage.
11. Do not touch power connection with wet hands to avoid short circuit or electricity shock.
12. Do not apply smash-force on the equipment. Violation may cause damage.
13. Do not install the equipment in a location that may expose the equipment directly to sunlight. Violation may cause color
fading or damage.
14. Do not install the equipment in high temperature or low temperature environment to avoid damage. The normal
operational temperature is between -5oC ~ +50oC.
15. The Network Dome Camera contains high sensitive electric parts inside. Do not try to repair them without qualified
personnel.
16. Turn off the power immediately and contact the technician when the following occurs:
A. Damage on power cable or plug.
B. Water leak into the equipment.
C. The Network Dome Camera can not be operated normally.
D. Equipment falling on ground or damage on external case.
E. Unusual occurrence.
17. Warning: Do not try to repair the equipment. Only a qualified technician may disassemble and repair the equipment. Shut
off the power before disassemble the equipment and don't put power on unless the case is completely assembled.
- 3 -

Introduction
What is Network Dome Camera?
The Network Dome Camera (“NDC” here and after) is an Internet-based digital Network Speed Dome Camera, it has
built in Pan/Tilt/Zoom and CCD module to distribute the compressed live video into Intranet/Internet through Ethernet
connection.
NDC can move (Pan/Tilt/Zoom) the view point to get the best monitoring angle easily via standard browser such as
Internet ExplorerTM or NetscapeTM.
NDC is self-contained Web Server. Users could access the Network Dome Camera just like browsing website over
Internet using standard browser such as Internet ExplorerTM or NetscapeTM , and do all the management, configuration,
and monitoring easily.
NDC contains an MPEG-4 image compression chipset capable of delivering streaming, constant or variable bit rate
MPEG-4 video over the network in real-time.
- 4 -

Features
There are 3 types of the Network Dome Camera – UNC7825-O (25X Optical Lens) and UNC7825-OW (Wide Dynamic
Range / 25X Optical Lens) UNC7825-OT (Tracking / 25X Optical Lens). The specifications and functions will be
different between these types.
Common Features
z360ocontinuous rotation
zHigh speed rotation and tilt, speed range varies from 0.18°/sec ~ 360°/sec
zUp to 128 programmable preset positions
zPreset positions auto scanning
z6 alarm inputs, 1 alarm output can be set as NO (normally open) or NC (normally close) for each NDC
zTwo types of alarm response mode: Lock Mode, Release Mode
z180° Horizontal Instant Flip
zBuilt-in 1/4” Interline Transfer CCD
zAutomatic / Manual Focus
zAutomatic / Manual Iris Control
zAuto Gain Control (Sensitivity adjustable)
zWhite Balance Control (Auto, Indoor, Outdoor)
zBack Light Compensation
zRS-485 control interface
zUp to 64 NDC configuration
zCompatible with PC control (protocol required)
z12V DC voltage input (power supply options: AC 90~260V or AC 24V)
zFlexible Mounting: Indoor-embedded and attached types; Outdoor-with weather resistant housing
UNC7825-O & UNC7825-OW Common Features
zAuto Focus Lens: built-in 25X optical zoom lens with focal length 3.8 ~ 95.0mm
zTrue Day & Night Camera: Color / Mono Switch (IR Cut Filter)
z570 TV Lines Mono Resolution, 480 TV Lines Color Resolution
z0.01 Lux Sensitivity (Mono), 0.1 Lux Sensitivity (Color)
zAuto Focus Modes Selectable
zManual Iris Speeds Selectable
zBack Light Compensation Zone Selectable
zGamma Adjustment
zOn-Screen Setup Menu
- 5 -

UNC7825-OT
zAuto tracking movement.
UNC7825-O
zAperture Correction Adjustment
UNC7825-OW
z2.56X Digital Zoom: For a total of 64X combined digital and optical zoom.
zWide Dynamic Range: Uses two Shutter Speeds in alternative video fields and combines two fields into one
progressive scan frame. As a result, combined field yield a frame of high-quality image.
zDynamic Privacy Zone: With this function, unwanted or prohibited areas within an image can be masked
appropriately.
zPreset Scene File: Preset setting such as BLC, AE mode, Shutter speed and AF mode can be saved as Scene
File and apply to other presets with similar circumstances to improve efficiency.
zSlow-speed Shutter
zImage Memory Function: Horizontal/Vertical Flip, 180oImage Rotation, Field Image Capture.
- 6 -

1 Physical Connections
1.1 Structural Element
9
8
7
5
6
4
10
3
2
1
1. Dome Cover 6. Video In /Out Jack
2. Camera Case 7. Power In Jack
3. Ethernet Port 8. Alarm In/Out Jack
4. Power / Network Status LED 9. RS-485 In/Out Jack
5. Audio Line In Jack 10. Camera Base
- 7 -

1.2 Connection Jack and Cable Requirement
Power In Jack
zDC12V Input Voltage, Power Consumption 1.2Adc, Center Pin 2.0mm
zRequire Cable: 18 AWG x 2C
Video Out BNC Jack
zVideo Signal Output CVBS 1.0Vpp 75ΩBNC
zRecommend Data Cable:5C2V
Alarm In/Out Jack
zEach NDC contains 6 alarm inputs and 1 alarm output
zAlarm Input Voltage 5.6V max, Output 0.5A 120Vac/ 1A 24Vdc
zRecommend Data Cable: UL 26 AWG 80 C 300V UL 24 AWG 80 C 300V
- 8 -

RS-485 In/ Out Jack
zRS-485 Input (TXDI+, TXDI-) to receiver signal from keyboard, matrix, DVR or multiplexer through twisted pair
cable.
zRS-485 Output (TXDO+, TXDO-) sending out signal to next NDC through twisted pair cable.
zRecommend Data Cable: 2547 VW-ISC UL 24 AWG x 2C
zTransmission Distance: Max. 1 Kilometer
* When 24VAC PSU is used, the recommend cables are:
zUL SPT-1 VW-1 18AWG x 2C
zUL SPT-2 VW-1 18AWG x 2C
zUL SUT 105C VW-1 18AWG x 3C
The distance between 24Vac PSU and fast dome cannot exceed 200 meters.
Ethernet
zStandard IEEE 802.3 10 /100 Base-T port
Power/Status LED
zPower On: constant red.
zEmergency factory default (appendix C): Blinking orange (i.e. red mix with green).
Network LED
zNetwork Link (connected): Constant red.
zNetworks have activities: Blink red.
zData sent out from server: Blink green.
zNetwork disconnected: Constant slow blinking green.
zUpgrading software (appendix A): Constant slow to fast blinking of orange.
- 9 -

1.3 DIP Switch Setting
Fan Power Switch
Turn the number 2 switch to ON position to activate the internal fan. This will maintain the temperature inside and
make electric parts life.
Alarm Mode Switch
Alarm Mode can be set as Lock or Release mode. Turn number 1 switch to ON position to choose Release mode.
Turn number 1 switch to OFF position to choose Lock mode. The NDC has 6 alarm inputs and 1 output, which
can be set either NC (normally close) or NO (normally open) mode. Turn number 2 switch to NO position to
choose NC mode. Turn number 2 switch to OFF position to choose NO mode.
Camera Function Switch
For UNC7825-O, UNC7825-OW (25X optical lens model) and UNC7825-O T, please refer to “5. Advanced Settings for
UNC7825-O”, “6. Advanced Settings for UNC7825-OW” and “7. Advance Settings for UNC7825-OT” for details.
- 10 -

1.4 NDC ID Address Setting Refer Chart
Up to 64 NDC can be serial linking in one system. Therefore each dome is addressing by ID switch located at the base
of the NDC. Below is the address setting for camera 1~64:
- 11 -

2 Installation
2.1 Installation Preview
There are 3 mains steps required to perform a successful installation:
zHardware installation
zSoftware installation
zNetwork configuration
Hardware installation consists of connecting cables to the NDC including network, video, and power cables.
Software installation consists of the installation of software that is necessary to properly view the video from the NDC
or to configure the NDC itself. The software includes:
zIP Installer -- a utility for locating devices and configuring network settings on a LAN.
zComponent Installer -- installs all ActiveX components used by the device for things such as video display and
configuration.
zMacromedia Flash Player -- necessary for displaying some components of the Web UI.
The following are not necessary, but may be used for convenience:
zRecording Software -- displaying and recording up to 16 channels simultaneously. Both the MPEG-4 and MJPEG
devices are supported.
zXvid -- a MPEG-4 codec. If no other MPEG-4 codecs (ie. DivX, 3ivX, ffdshow, etc.) are installed on your computer,
the Component installer will install this for you.
zQuickTime or VLC -- though not necessary, this can be used for viewing the MPEG-4 stream without a Web
browser.
Network configuration consists of modifying the network settings for the NDC in order to successfully connect to the
device.
- 12 -

2.2 Hardware Installation
– Indoor Installation Structural Drawing
- 13 -

– Outdoor Installation Structural Drawing (Pendant Mounting)
- 14 -

– Embedded Mounting (False Ceiling)
- 15 -

- 16 -

Note: After dome cover is attached, use glass-cleaning cloth to clean dome cover. Unclean dome cover may
affect camera performance.
- 17 -

– Attached Mounting (Fixed Ceiling)
- 18 -

Note: After dome cover is attached, use glass-cleaning cloth to clean dome cover. Unclean dome cover may
affect camera performance.
- 19 -
