EUTECH INSTRUMENTS CYBERSCAN PC 510 PHCONDUCTIVITY METER User manual

Instruction Manual
PC 510
Bench pH/Conductivity Meter
Technolo
g
y
M
ade
E
a
s
y
.
.
.
68X090816
Rev. 3 12/03

Preface
Thank you for choosing the PC 510 pH and Conductivity bench meter series.
This manual serves to explain the use of the PC 510 bench meter. The manual functions as a step-by-
step operational guide to help you familiarise with the meter’s features and as a handy reference
guide.
This instruction manual is written to cover as many anticipated applications and uses of the PC 510
bench meter as possible. If there are doubts in the use of the meter, please do not hesitate to contact
the nearest Authorised Distributors.
Eutech Instruments/ Oakton Instruments cannot accept any responsibility for damage or malfunction
to the meter caused by improper use of the instrument.
The information presented in this manual is subject to change without notice as improvements are
made, and does not represent a commitment on the part of Eutech Instruments Pte Ltd/ Oakton
Instruments.
Note: Eutech Instruments Pte Ltd/ Oakton Instruments reserves the right to make
improvements in design, construction, and appearance of our products without notice.
Copyright © 2001 All rights reserved.
Eutech Instruments Pte Ltd
Oakton Instruments
Rev. 3 12/03

TABLE OF CONTENTS
1INTRODUCTION 1
2METER INFORMATION 1
2.1 Meter parts 1
2.2 Customised LCD 1
2.3 Slide-out card 1
2.4 Rear instrument panel 1
2.5 AC/DC adapter 2
2.6 Electrodes 2
2.7 Electrode holder 2
3KEYPAD FUNCTIONS 2
3.1 Keypad 2
3.2 Display 4
4PREPARATION 5
4.1 Connecting the Sensor Electrode 5
4.1.1 To connect the pH electrode: 5
4.1.2 To connect the conductivity/temperature probe: 5
4.2 Connecting the A.C. Adapter 5
5CALIBRATION 6
5.1 Important information on meter calibration 6
5.2 Preparing the meter for calibration 6
5.3 pH calibration 7
5.3.1 Preparing for pH calibration 7
5.3.2 Before starting 7
5.3.3 To calibrate pH 7
5.4 Conductivity/TDS calibration 9
5.4.1 Preparing for conductivity/TDS calibration 9
5.5 TDS Calibration 11
5.5.1 Calibrating for TDS directly 11
5.6 Calibration with Conductivity Standard and TDS factor 11
5.6 Calibration with Conductivity Standard and TDS factor 12
5.7 Temperature Calibration 13
6MEASUREMENT 14
6.1 Taking pH Measurements 14
6.1.1 Automatic Temperature Compensation 14
6.1.2 Manual Temperature Compensation (pH) 14
6.1.3 Taking pH Measurements 15
6.2 Taking Conductivity or TDS Measurement 15
6.2.1 Automatic Temperature Compensation 15
6.2.2 Manual Temperature Compensation 16
6.2.3 Setting a manual temperature compensation value 17
6.2.4 Taking Measurements (Conductivity or TDS) 17
6.2.5 Using Auto and Manual Ranging Function (for conductivity & TDS) 18
7HOLD FUNCTION 20
8ADVANCED SETUP FUNCTIONS 20
8.1 Advanced SETUP mode Overview 22
8.2 P1.0: Viewing previous pH calibration data 25
8.3 P2.0: Viewing pH electrode data 26
8.4 P3.0: pH Measurement configuration 27
8.4.1 P3.1: READY Indicator and auto endpoint function 28
8.4.2 P3.2: Selecting number of pH calibration points 29
8.4.3 P3.3 Selecting USA or NIST buffer 29
8.4.4 P3.4 Selecting °C or °F 30
8.5 P4.0: Resetting to factory default settings (pH) 31
8.6 P5.0: Viewing previous conductivity calibration data 32
8.7 P6.0: Viewing conductivity probe data 33
8.8 P7.0: Conductivity or TDS measurement configuration 34
8.8.1 P7.1: READY indicator and auto endpoint function 34
8.8.2 P7.2: Selecting °C or °F 35
8.8.3 P7.3: Selecting Automatic or Manual Temperature Compensation 35
8.8.4 P7.4: Setting the TDS factor 36
8.9 P8.0: Temperature 37
8.9.1 P8.1: Selecting the temperature coefficient 37
8.9.2 P8.2: Adjusting the normalisation temperature 38
8.9.3 P9.0: Resetting to factory default settings (conductivity) 38

9PROBE CARE AND MAINTENANCE 39
9.1 pH Electrode care 39
9.2 Conductivity electrode 40
10 TROUBLE SHOOTING GUIDE 41
11 ERROR MESSAGES 42
12 SPECIFICATIONS 43
13 ACCESSORIES 44
14 ADDENDUM 2: CALCULATING TDS CONVERSION FACTORS 48
15 ADDENDUM 3: STANDARD pH BUFFERS 48
16 ADDENDUM 4: CALCULATING TEMPERATURE COEFFICIENTS 49
17 ADDENDUM 5: METER FACTORY DEFAULT SETTINGS 50
18 WARRANTY 51
19 RETURN OF ITEMS 51

Instruction Manual PC 510
1
1 INTRODUCTION
Thank you for selecting the PC 510 pH and Conductivity bench meter. This step-by-step instruction
manual gives you a detailed description on the use and operation of features on the meter. This PC
510 pH and Conductivity bench meter is designed to be user-friendly while providing unprecedented
levels of accuracy, repeatability and reliability.
The PC 510 is an advanced microprocessor-based (ASIC - Application Specific Integrated Circuit)
ideal for routine measurement that best meets discerning user’s individual needs. This multi-parameter
meter reads pH, mV, Conductivity, Total Dissolved Solids (TDS) and temperature (°C or °F). It has
splash-proof keypad, simultaneous pH/mV/Conductivity/TDS and temperature display on a large
angled custom LCD. This instruction manual is illustrated with useful hints and diagrams that show
which specific key-presses to access for each function.
2 METER INFORMATION
The PC 510 meter is packaged in a corrugated box that is made of environment-friendly materials and
can be re-cycled.
2.1 Meter parts
The instrument is designed to give an aesthetic look as well as ergonomic functionality. A large
custom dual LCD is provided at an angle for optimum viewing. A splash-proof keypad with audible
tactile response gives you a good feel of the instrument. A slide-out instruction card offers a handy
reference. Listed below are the major components of the meter.
2.2 Customised LCD
The PC 510 bench meter is characterised by large dual custom LCD (Liquid Crystal Display). The
display has also mode annunciators for pH, temperature, mV, conductivity and TDS readings. The
secondary (lower) display shows the temperature readings simultaneously with the primary (upper)
display of measured mode. Special annunciators such as graphical symbols, error messages,
measurement units and modes of operation are arranged around the primary and secondary displays
to give a comprehensive display. The integration of graphics and error messages into the LCD
provides you a higher level of user-friendliness and easy readability.
2.3 Slide-out card
A plastic slide-out card is provided at the bottom of the PC 510 bench meter. The function of this card
is to provide a quick guide to the functions of the individual keys as well as to provide a useful
troubleshooting reference.
2.4 Rear instrument panel
The PC 510 bench meter provides three connectors at the rear of the meters. These connectors are
labeled CON/TEMP, pH and DC.
CON/TEMP pH DC
Figure 1 : View of meter rear panel

Instruction Manual PC 510
2
Connector Function
CON/TEMP For connecting 6-pins conductivity/TDS sensor with built-in temperature sensor to the
meter or optional temperature probe for use with pH electrode (when applicable).
Always make sure that the connector is clean and dry.
pH For connecting pH sensor with a BNC connector to the meter. Always make sure that
the connector is clean and dry.
DC For connection to the AC power source to the power jack (DC).
2.5 AC/DC adapter
The AC/DC adapter converts the power mains voltage 120/220 VAC to low DC voltage for the PC 510
bench meter operation. Two basic models of adapters are available depending upon power supply
specification of each country.
Description Order Code Voltage
AC Adapter 120 V EC-120-ADA / 35615-07 110-120 V, 50-60 Hz
AC Adapter 220 V EC-220-ADA / 35615-08 220-240 V, 50-60 Hz
2.6 Electrodes
Your meter includes two probes:
•pH electrode with BNC connector
•conductivity probe with built-in temperature sensor with a notched 6-pin connector
The temperature sensor built into the conductivity probe will also compensate for pH readings as long
as both probes are in your solution at the same time.
If you want to use a “3-in-1” pH probe with a built-in temperature sensor, or if you want to use a
separate temperature probe, you will need to disconnect the conductivity probe to allow for connection
of the separate temperature sensor.
2.7 Electrode holder
The integral electrode holder serves as a handy holder for mounting
the pH and conductivity/temperature probes during measurement or
when idle.
The bench meter’s base plate has a side metal bar to which you
can attach an integral swivel electrode holder. You can mount the
electrode holder on either right or left side of the meter.
To position the electrode arm:
holder.
3 KEYPAD FUNCTIONS
3.1 Keypad
The PC 510 is equipped with large tactile response keypad for
ease of use. All keys have primary function with some keys having
secondary functions.
Use a Philips screwdriver to remove the screw holding the
electrode holder. Slide the side metal bar until the second screw
slot lines up with the original screw hole. Use the screw removed
earlier to secure the electrode holder into position. Note the side
metal bar is reversible. If desired, remove screw holding electrode
holder base and slide out of brackets. Slide base into brackets on
opposite side and tighten screws. See Figure 2.
To install electrode arm to the meter:
To mount the electrode arm into the metal rod on the side bar,
align the slot with the metal rod and base of electrode arm. Push
it downwards until it fully sits into position. Avoid using excessive
force when fixing or removing. The electrode arm is ready for use.
NOTE: Move the base of electrode holder if you wish to swing the
electrode holder about. To prevent the meter form toppling over
causing accidental spills, DO NOT swing the body of the
electrode holder.
Figure 2: To position electrode arm
Figure 3: Installing the
electrode arm
Base of
Electrode
Holder
Body of Electrode
Holder
Side Metal Bar

Instruction Manual PC 510
3
SET
MODE
HOLD
ON/OFF
ENTER
RANGE
CAL
MEAS
Figure 4: Keypad
ON/OFF Powers the meter on or off. When meter is switched on, it starts in the mode the meter
was last in when powered off.
SET Enters advanced setup mode. SETUP mode lets you customise meter preferences and
defaults, and view calibration and probe data.
MODE Measurement: Press MODE to toggle between pH, mV, conductivity and TDS.
Calibration: In calibration mode, press MODE to access temperature calibration.
HOLD
Freezes the measured reading. To activate, press HOLD while in measurement mode. To
release, press HOLD again.
Note: When auto endpoint feature is switched on, meter automatically holds reading after
5 seconds of stability. The HOLD indicator appears on the display. Press HOLD to release
auto endpoint feature.
CAL/MEAS
Toggles between Calibration and Measurement mode. Example: If you are in pH
measurement mode, press CAL/MEAS to enter pH calibration mode.
Note: Temperature calibration is available from pH, TDS or Conductivity calibration mode.
In Setup mode: Press CAL/MEAS to return to main menu from sub menus. Press
CAL/MEAS again to return to measurement mode from main menu.
ENTER/RANGE ENTER: Press to confirm values in Calibration mode and to confirm selections in Setup
mode.
RANGE: Press to switch to manual ranging in Conductivity or TDS mode.
 Press in Setup mode to scroll up through subgroups. Also lets you increase the values
in the conductivity, TDS and temperature calibration modes.
 Press in Setup mode to scroll down through subgroups. Also lets you decrease the
values in the conductivity, TDS and temperature calibration modes.

Instruction Manual PC 510
4
3.2 Display
The PC 510 features a large dual display that shows the measured parameter in the primary display,
plus temperature in °C or °F in the secondary display. It also features mode annunciators that describe
the meter’s functions.
SETUP MEAS CAL
Primary Display
Secondary Display
ERR
ATC
°C °F
READY
HOLD
ON
OFF
-8.8.8.8
-1.8.8.8
123
5
4
6
7
8
9
10
11
12
1314
15
16
17
18
19
20 mS
ppt
ppm
pH
mV
%
pH
µ S
K =
Figure 5: Full LCD Screen
1. SETUP mode indicator
2. MEASurement mode indicator
3. CALibration indicator
4. mV indicator
5. % indicator
6. pH measurement indicator
7. milli-Siemens indicator
8. micro-Siemens indicator
9. parts per thousand indicator
10. parts per million indicator
11. temperature indicator
12. pH indicator
13. Automatic Temperature
Compensation (ATC) indicator
14. ERRor indicator
15. probe indicator
16. calibration solution indicator
17. cell constant indicator
18. ON/OFF indicator
19. HOLD indicator
20. READY indicator

Instruction Manual PC 510
5
4 PREPARATION
4.1 Connecting the Sensor Electrode
4.1.1 To connect the pH electrode:
1. Slide the BNC connector of the probe over the BNC connector socket on the meter. Make sure the
slots of the connector are in line with the posts of the socket. Rotate and push the connector
clockwise until it locks.
2. To remove electrode, push and rotate the connector anti-clockwise. While holding onto the metal
part of connector, pull it away from the meter
NOTE: Keep connector dry and clean. Do not touch connector with soiled hands.
CAUTION:Do not pull the probe cord or the probe wires might disconnect.
4.1.2 To connect the conductivity/temperature probe:
1. Line up the notch and 6-pins on the probe connector with the holes in the connector located on the
top of the meter. Push down and screw the metal sleeve to lock the probe connector into place.
See Figure 1 on page 1 for the meter rear panel view.
2. To remove probe, unscrew the metal sleeve and slide up the probe connector. While holding onto
the metal sleeve, pull probe away from the meter.
NOTE:Follow the same directions to connect an optional separate temperature element.
Keep connector dry and clean. Do not touch connector with soiled hands.
CAUTION:Do not pull on the probe cord or the probe wires might disconnect.
4.2 Connecting the A.C. Adapter
1. Before plugging in the A.C. adapter, switch off the meter and the power source of the A.C.
adapter. This is a safety precaution that should be adhered to safeguard your meter.
2. The A.C. adapter should have the following settings:
Output voltage: 9 V D.C.
Current: 500 mA
NOTE:Ensure that the input mains voltage (110/220/240 V) matches your adapter requirements.
3. Insert the D.C. jack into the socket at rear panel of the meter as shown in Figure 1on page 1.
4. Switch on the power to the adapter, followed by the meter.

Instruction Manual PC 510
6
5 CALIBRATION
5.1 Important information on meter calibration
When you calibrate your meter, old calibration points are replaced on a “point by point” basis in pH,
and on a “range by range” basis in conductivity or TDS.
For example:
•pH:if you previously calibrated your meter at pH 4.01, 7.00 and 10.01, and you recalibrate at pH
7.00, the meter retains the old calibration data at pH 4.01 and pH 10.01.
•Conductivity:if you previously calibrated your meter at 1413 µS in the 0 to 1999 µS range and
you recalibrate at 1500 µS (which is also in the 0 to 1999µS range), the meter will replace the old
calibration data (1413 µS) in that range. The meter will retain all calibration data in other ranges.
•TDS:If you previously calibrated your conductivity meter at 300 ppm in the 0 to 999 ppm range
and you re-calibrate at 500 ppm (which is also in the 0 to 999 ppm), the meter will replace the old
calibration data (300 ppm) in that range. The meter will retain all calibration data in other ranges.
To view current calibration points:
•pH:Program P1.0 in the SETUP section 8.2 page 38.
•Conductivity & TDS:Program P5.0 in the SETUP section, page 32.
To completely recalibrate your meter, or when you use a replacement probe, it is best to clear old
calibration data by resetting the meter.
To reset the meter to its factory defaults:
•pH: Program P4.0 in the SETUP section, page 32.
•Conductivity & TDS: Program P9.0 in the SETUP section, page 38.
NOTE:Resetting the meter will set meter to factory defaults. Conductivity and pH must be reset
separately.
For directions on how to calibrate your meter:
•See section 5.3 on page 7 for pH calibration
•See section 5.4 on pages 9 for conductivity calibration
•See section 5.5 on page 11 for TDS calibration
5.2 Preparing the meter for calibration
Before starting calibration, make sure you are in the correct measurement mode. When you switch on
the meter, the meter starts up in the measurement mode you shut it off in. For example, if you shut the
meter off in pH measurement mode, the meter will be in the pH measurement mode when you switch
the meter on.
Do not re-use calibration solutions after calibration. Contaminants in the solution can affect the
calibration, and eventually the accuracy of the measurements. See section 13 on “Accessories” on
page 44 for information on our high quality calibration solutions.

Instruction Manual PC 510
7
5.3 pH calibration
NOTE:We recommend that you perform at least a 2-point calibration using standard buffers that
bracket (one above and one below) the expected sample range.
5.3.1 Preparing for pH calibration
This meter is capable of up to 5-point pH calibration to ensure accuracy across the entire pH range of
the meter. Select from the following buffer options:
•USA: pH 1.68, 4.01, 7.00, 10.01 and 12.45
•NIST: pH 1.68, 4.01, 6.86, 9.18 and 12.45
The meter automatically recognises and calibrates to these standard buffer values, which makes pH
calibration faster and easier.
NOTE: Selection of USA or NIST buffer standards must be done prior to calibration. Refer to Section
8.4 on P3.3 on page 29.
5.3.2 Before starting
Be sure to remove the protective electrode storage bottle or rubber cap
of the probe before calibration or measurement. If the electrode has
been stored dry, hydrate the probe in tap water for 10 minutes before
calibrating or taking readings to saturate the pH electrode surface and
minimise drift.
Wash your probe in de-ionised water after use, and store in electrode
storage solution. If storage solution is not available, use pH 4.01 or
7.00 buffer for short term storage. DO NOT store electrode in distilled
or de-ionised water.
5.3.3 To calibrate pH
1. If necessary, press the MODE key to select pH mode. The pH
indicator appears in the upper right hand corner of the display.
2. Rinse the probe thoroughly with de-ionised water or rinse solution.
Do not wipe the probe as this causes a build-up of electrostatic
charge on the glass surface.
3. Dip the probe into the standard calibration buffer. The end of the
probe must be completely immersed into the sample. Stir the probe
gently to create a homogeneous sample.
NOTE:The temperature element is in the conductivity cell. For
temperature compensated readings, dip the conductivity cell or ATC
probe into the calibration buffer as well.
4. Press CAL/MEAS to enter pH calibration mode. The CAL indicator
will be shown. The primary display will show the measured reading
while the smaller secondary display will indicate the pH standard
buffer solution.
5. Wait for the measured pH value to stabilise. If the READY indicator
has been activated through the Setup, the READY appears when
the reading is stable.
6. Press ENTER to confirm calibration. The meter is now calibrated to
the current buffer. The lower display automatically scrolls through
the remaining buffer options.
•If you are performing multi-point calibration, go to step 7.
MEAS
pH
ATC
°C
7.16
22.3
CAL
pH
pH
7.16
7.00
CAL
MEAS
CAL
pH
pH
READY
7.16
7.00
CAL
pH
pH
READY
7.00
7.00
ENTER
RANGE
Figure 6: pH calibration

Instruction Manual PC 510
8
•If you are performing one-point calibration, go to step 9.
7. Rinse the electrode with de-ionised water or rinse solution, and
place it in the next pH buffer.
8. Follow steps 5 to 7 for additional calibration points.
9. When calibration is complete, press CAL/MEAS to return to pH
measurement mode.
NOTE: To exit from pH calibration mode without confirming calibration,
DO NOT press ENTER in step 6. Press CAL/MEAS instead.
If the selected buffer value is not within ±1.0 pH from the measured pH
value: the electrode and buffer icon blink and the ERR annunciator
appears in the lower left corner of the display.
To limit the number of pH buffer values available during calibration,
see section 8.4 Setup P3.2 on page 29.
Figure 7: Next point calibration
for pH 4.01
CAL
pH
pH
READY
4.15
4.01
CAL
pH
pH
READY
4.01
4.01
ENTER
RANGE
Figure 8: Err message and
electrode icon will appear if
in
co
rr
ect
bu
ff
e
r i
s
used
CAL
pH
pH
ERR
0.64
1.68

Instruction Manual PC 510
9
5.4 Conductivity/TDS calibration
The PC 510 has 5 measuring ranges. You can calibrate 1 point each of the measuring ranges (up to 5
points). If you are measuring values in more than 1 range, make sure to calibrate each of the ranges
you are measuring. All new calibration data will over-ride existing stored calibration data for each
measuring range you calibrate.
•If you are measuring in ranges near to or greater than 20 mS (10 ppt), or near to or lower than 100
µS (50 ppm), calibrate the meter at least once a week to get specified ±1% Full Scale accuracy.
•If you are measuring in the mid-ranges and you washed the probe in de-ionised water and stored
it dry, calibrate the meter at least once a month.
•If you take measurements at extreme temperatures, calibrate the meter at least once a week.
5.4.1 Preparing for conductivity/TDS calibration
For best results, select a standard value close to the sample value you are measuring. Alternatively,
use a calibration solution value that is approximately 2/3 the Full-Scale value of the measurement
range you plan to use. For example, in the 0 to 1999 µS conductivity range, a 1413 µS solution is a
good solution for calibration.
See the table below for recommended calibration solution ranges.
Range
Indicator Conductivity Range Recommended Calibration Solution Range TDS Range Recommended Calibration
Solution Range
r 1 0.00 to 19.99 µS 6.00 to 17.00 µS 0.00 to 9.99 ppm 3.00 to 8.50 ppm
r 2 0.0 to 199.9 µS 60.0 to 170.0 µS 10.0 99.9 ppm 30.0 to 85.0 ppm
r 3 0 to 1999 µS 600 to 1700 µS 100 to 999 ppm 300 to 850 ppm
r 4 0.00 to 19.99 mS 6.00 to 17.00 mS 1.00 to 9.99 ppt 3.00 to 8.50 ppt
r 5 0.0 to 199.9 mS 60.0 to 170.0 mS 10.0 to 200 ppt 30.0 to 170.0 ppt
Calibration Solution Ranges
Temperature Coefficient: These meters are factory set to a temperature coefficient of 2.1 % per °C.
For most applications this will provide good results. See Program P8.1 on page 37 to set the
temperature coefficient to different value. See Addendum 2, “Calculating Temperature Coefficients” to
determine the appropriate temperature coefficient for your solution.
Normalisation Temperature: The factory default value for normalisation temperature is 25 °C. If you
need to normalise to a value other than 25 °C, see Program P8.2 on page 38.
Do not reuse calibration solutions after calibration. Contaminants in the solution can affect the
calibration, and eventually the accuracy of the measurements. Use fresh calibration solution each time
you calibrate your meter.
All new calibration data will over-ride existing stored calibration data for each measuring range
calibrated.

Instruction Manual PC 510
10
Calibrating for Conductivity:
1. If necessary, press the MODE key to select conductivity mode.
2. Rinse the probe thoroughly with de-ionised water or a rinse
solution, then rinse with a small amount of calibration standard.
3. If necessary, ensure that the probe’s yellow probe guard is
attached. Dip the probe into the calibration standard. Immerse the
probe tip beyond the upper steel band. Stir the probe gently to
create a homogeneous sample.
4. Wait for the measured conductivity value to stabilise. If the READY
indicator has been activated (SETUP program P7.1 – see page
31), the READY annunciator lights when the reading is stable.
5. Press CAL/MEAS to enter conductivity or TDS calibration mode.
The CAL indicator will appear in the upper right corner of the
display.
6. Press the  or key to change the value on the primary display
to match the value of the calibration standard.
7. Press ENTER to confirm calibration value. The meter returns to the
MEAS (measurement) mode.
8. Repeat steps 1 to 7 for other measuring ranges.
NOTES: When entering calibration mode, the meter will display the
factory default value. If the meter was previously calibrated, the display
may “jump” to the factory default / uncalibrated value when switching
from measurement to calibration mode.
To exit from Conductivity calibration mode confirming calibration,
DO NOT press the ENTER key in step 7. Press CAL/MEAS instead.
This will retain the meter’s old calibration data in the measuring range
of the calibration.
You can offset the conductivity reading up to ±40% from default
setting. If your measured value differs by more than ±40% clean or
replace probe as needed, or use a calibration standard with a higher
value as required.
A wide selection of high-quality calibration standards is available. See page 44 for more information.
Figure 9: Conductivity
calibration
MEAS
1409
µ S
ATC
°C
22.3
1413
µ S
ATC
°C
22.3
MEAS
READY
ENTER
RANGE
1409
µ S
ATC
°C
22.3
CAL
CAL
MEAS
1413
µ S
1409
CAL
READY

Instruction Manual PC 510
11
5.5 TDS Calibration
5.5.1 Calibrating for TDS directly
The factory default setting for TDS conversion factor is 0.5. If your
solution has a different TDS factor, you can improve calibration
accuracy by setting the TDS factor prior to calibration. See Program
P7.4 on page 36 for directions.
1. If necessary, press the MODE key to select TDS mode.
2. Rinse the probe thoroughly with de-ionised water or a rinse
solution, then rinse with a small amount of calibration standard.
3. If necessary, ensure that the probe’s yellow probe guard is
attached. Dip the probe into the calibration standard. Immerse the
probe tip beyond the upper steel band. Stir the probe gently to
create a homogeneous sample. Allow time for the reading to
stabilise.
4. Press the CAL/MEAS to enter TDS calibration mode. The CAL
indicator will appear in the upper right corner of the display.
5. Press the  or key to change the value on the primary display
to match the value of the calibration standard.
6. Press ENTER to confirm the calibration value. The meter returns
to the MEAS (measurement) mode. See Figure 10.
7. Repeat steps 1 to 6 for other measuring ranges.
NOTES:
To exit from TDS Calibration mode without confirming calibration, DO
NOT press ENTER key in step 6. Press CAL/MEAS instead. This will
retain the meter’s old calibration data in the measuring range of the
calibration. You can offset the TDS reading up to ±40% from the
default setting. If your measured value differs by more than ±40%,
clean or replace probe as needed, or use a calibration standard with a
higher value as required.
MEAS
265
ppm
ATC
°C
25.8
300
ppm
ATC
°C
25.8
MEAS
READY
ENTER
RANGE
265
ppm
ATC
°C
25.8
CAL
CAL
MEAS
300
ppm
265
CAL
READY
Figure 10: TDS calibration

Instruction Manual PC 510
12
5.6 Calibration with Conductivity Standard and TDS factor
The concentration of salts dissolved in solution increases the conductivity of that solution. This
relationship varies from salt to salt and is roughly linear over a given range for a given salt.
The TDS conversion factor is the number used by the meter to convert from conductivity to TDS.
Instead of calibrating for TDS directly (described above), you can calibrate the PC 510 bench meter
by:
1. Calibrating to conductivity standards (as described above) and then
2. Entering the appropriate TDS conversion factor into the meter.
To determine the conductivity to TDS conversion factor for your solution:
•Addendum 1 on page 47 lists some commonly used conversion factors.
•Addendum 2 on page 48 describes how to calculate the TDS conversion factor for other
solutions.
Enter the TDS conversion factor into your meter as described under Section 8.8, in Program P7.4,
Setting the TDS Factor on page 36.

Instruction Manual PC 510
13
5.7 Temperature Calibration
The conductivity electrode (EC-CONSEN91W / 35608-50) supplied has a
built-in temperature sensor. Alternatively, a separate temperature sensing
element can be used (such as temperature probe EC-WPPHTEM-01W /
35618-05), or a “3-in-1” pH/Temperature combination electrode with ATC
connection.
The conductivity probe is factory calibrated. Temperature calibration is
recommended only if you suspect temperature errors may have occurred
over a long period of time, or if you have a replacement probe.
Temperature calibration is accessible during pH, conductivity or TDS
calibration.
Temperature Calibration
1. Make sure the conductivity electrode, or temperature probe, or “3-in-1”
electrode is attached to the 6-pin connector.
2. Switch the meter on.
3. Press the CAL/MEAS key to enter calibration mode (either from pH or
conductivity mode). The CAL indicator will appear above the primary
display.
4. While in pH (or conductivity or TDS) calibration mode, press the MODE
key to enter temperature calibration mode. The primary display shows
the last set temperature value and the secondary display shows the
temperature reading with zero offset.
5. Dip the ATC probe into a solution of known temperature (i.e. a
temperature bath). Allow time for the temperature probe to stabilise.
6. Scroll with the  or key to set the correct temperature value (i.e. the
temperature of the temperature bath). You can adjust the reading by 0.1
°C or °F increments.
7. Once you have selected the correct temperature press the ENTER key.
The meter automatically returns to measurement mode.
NOTES:
•You can offset the temperature reading up to ±5°from default reading.
•To exit this program without confirming the temperature calibration value, DO NOT press ENTER,
press CAL/MEAS in step 7 instead.
Figure 12: Temperature calibration
in pH mode
MEAS
pH
ATC
°C
7.16
22.3
MEAS
pH
ATC
°C
7.16
22.0
CAL
pH
pH
7.16
7.00
CAL
A
TC
°C
22.3
22.3
ATC
°C
22.0
22.3
CAL
READY
MODE
ENTER
RANGE
CAL
MEAS

Instruction Manual PC 510
14
6 MEASUREMENT
6.1 Taking pH Measurements
6.1.1 Automatic Temperature Compensation
Automatic Temperature Compensation only occurs when a temperature sensing element is plugged
into the meter.
Temperature sensing element refers to the following probes made specifically for this meter. See
accessories for ordering information
•The conductivity electrode with a built-in temperature
sensor
•Temperature probe; or
•The 3-in-1 pH/Temperature combination electrode.
If there is no temperature sensor plugged into the meter, the default
manual temperature setting is automatically 25 °C. You can manually
set the temperature to match your working conditions using a separate
thermometer.
For automatic temperature compensation (ATC) simply plug the temperature probe into the meter (see
page 5 for directions). The ATC indicator will light up on the LCD. See Figure 13.
NOTE: The temperature sensing element must be submersed in the liquid you are measuring.
6.1.2 Manual Temperature Compensation (pH)
IMPORTANT: For manual compensation, you must disconnect the
temperature probe (see page 5 for instructions).
1. Switch the meter on. Press MODE key to select pH mode.
2. Press the CAL/MEAS key to enter pH calibration mode. The CAL
indicator will appear above the primary display.
3. While in pH calibration mode, press the MODE key to enter
temperature calibration mode. The primary and secondary displays
show the last set temperature value.
4. Check the temperature of your sample using an accurate
thermometer.
5. Press the  or key to set the temperature to the measured
value from step 4.
6. Press ENTER to confirm the selected temperature and to return to
the pH measurement mode.
See Figure 14.
The meter will now compensate pH readings for the manually set
temperature.
NOTES: To exit this program without confirming the manual
temperature compensation value, DO NOT press ENTER in step 6.
Press CAL/MEAS instead.
Figure 13: ATC annunciator will
light up when connected to
temperature probe
Figure 14: Manual temperature
compensation
MEAS
ATC
pH
°C
7.05
24.5
READY
CAL
°C
25.0
25.0
MEAS
°C
7.05
30.0
READY
pH
ENTER
RANGE
°C
30.0
25.0
CAL

Instruction Manual PC 510
15
6.1.3 Taking pH Measurements
Be sure to remove the electrode storage bottle or protective rubber cap
on the electrode before measurement.
To take readings:
1. Rinse the pH electrode with de-ionised or distilled water before use
to remove any impurities adhering to the probe body. If the pH
electrode has dehydrated, soak it for 30 minutes in electrode
storage solution or 2M – 4 M KCL solution (sold separately).
2. Press ON to switch meter on.
3. Press the MODE key to select pH measurement mode. The MEAS annunciator appears on the
top center of the LCD. The ATC indicator appears in the lower right-hand corner to indicate
Automatic Temperature Compensation.
NOTE:For pH manual temperature compensation, you must disconnect the conductivity cell from the
6-pin connector. The ATC indicator will disappear form the display. You also need to set a manual
temperature compensation value. See Section 6.2.2: Manual Temperature Compensation on page 16.
4. Dip the probe into the sample. Since the conductivity cell contains the temperature sensor, make
sure it is also immersed in your solution.
When dipping the probe into the sample, the sensor or the glass bulb of the electrode must be
completely immersed into the sample. Stir the probe gently in the sample to create a homogeneous
sample.
5. Allow time for the reading to stabilise. Note the reading on the display. If the READY indicator is
selected on, it will appear when the reading is stable. See below for more information.
Taking measurements with READY indicator selected on
If the READY indicator has been activated, the READY annunciator lights when the reading is stable *.
Switch the READY indicator on or off in SETUP program P3.1. See page 28 for directions.
* The READY indicator appears and the reading holds until the measured value exceeds the tolerance
(±0.02 pH; +0.8 mV < 400; ±1.2 mV > 400). Then READY annunciator turns off.
Taking measurements with the auto endpoint feature selected on
When a reading is stable for more than 5 seconds, the auto endpoint feature will automatically “HOLD”
the reading. The “HOLD” indicator appears on the left side of the display. Press the HOLD key to
release the reading. Switch the Auto endpoint feature on or off in SETUP program P3.1, see page 28
for instructions.
6.2 Taking Conductivity or TDS Measurement
6.2.1 Automatic Temperature Compensation
For automatic temperature compensation (ATC), simply plug the
conductivity probe into the meter (see page 5 for directions). The ATC
indicator will light on the LCD.
NOTE:If the ATC indicator does not light, manual temperature
compensation may be selected in the meter’s SETUP mode. See
Program P7.3 on page 35 for directions on selecting Automatic
Temperature Compensation.
Figure 15: Measurement mode
Figure 16: ATC annunciator will
light up when connected to
temperature probe
MEAS
pH
ATC
°C
8.23
21.3
MEAS
READY
ATC
°C
1402
24.5
µ S

Instruction Manual PC 510
16
6.2.2 Manual Temperature Compensation
IMPORTANT: For manual compensation, you must deactivate the
temperature probe.
Selecting Manual Temperature Compensation for conductivity
Selecting between Automatic Temperature Compensation (ATC) and
Manual Temperature Compensation in the SETUP program P7.3 on
page 35. Meter default is ATC on.
From Conductivity or TDS measurement mode
1. Press SETUP key to enter Setup mode.
2. Press the  or key to scroll through subgroups until you view
parameter P7.0. See Figure 17.
3. Press ENTER key three times to select parameter 7.3. The upper
display shows “ATC” and the lower display shows “P7.3”.
4. Press ENTER key again. The upper display shows “ATC” and the
lower display shows “YES” or “NO”.
5. Press the  or key to select the Automatic Temperature
Compensation feature on (ATC) or off (ATC off). See Figure 14.
6. Press ENTER key to confirm selection and to return to the
subgroup menu. Press the CAL/MEAS key to return to
measurement mode.
Note that the ATC indicator no longer appears on the display.
Proceed to the next section to select a manual temperature
compensation value.
Figure 17: P7.0 configuration
setup for conductivity & TDS
SETUP
COF
P7.0
mS
S
ppt
ppm
µ
Figure 18: Turning ATC
feature ON or OFF
SETUP
p7.3
°C
ATC
ENTER
RANGE
SETUP
YES
°C
ATC
ENTER
RANGE
SETUP
°C
