Elcometer 2250 User manual

en
Elcometer 2250
Krebs Viscometer
Operating Instructions

R
en
This product meets the Electromagnetic Compatibility Directive and the Low Voltage
Directive.
The product is Class B, Group 1 ISM equipment according to CISPR 11.
Group 1 ISM product: A product in which there is intentionally generated and/or used conductively
coupled radio-frequency energy which is necessary for the internal functioning of the equipment
itself.
Class B product are suitable for use in domestic establishments and in establishments directly
connected to a low voltage power supply network which supplies buildings used for domestic
purposes
, is a registered trademark of Elcometer Limited.
All other trademarks acknowledged.
© Copyright Elcometer Limited, 2010 - 2012.
All rights reserved. No part of this Document may be reproduced, transmitted, transcribed, stored
(in a retrieval system or otherwise) or translated into any language, in any form or by any means
(electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission
of Elcometer Limited.
A copy of this Instruction Manual is available for download on our Website via www.elcometer.com.
Doc.No. TMA-0475 Issue 03
Text with Cover No: 21806
R

3
R
en
CONTENTS
Section Page
1 About your Viscometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 What the box contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Krebs units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 The parts of the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Rear connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Installing the Viscometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4 Fitting the spindle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.5 Fitting a sample container support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.6 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 The sample. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 Sample quantity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.2 Sample temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Configuring your Viscometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 Taking a measurement in automatic mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Taking a measurement in manual mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8.1 Security stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8.2 Unstable readings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8.3 Instrument does not zero. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
10 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10.1 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10.2 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
11 Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
12 Spare parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
13 Related equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4
R
en
Thank you for purchasing this Elcometer Krebs Viscometer. Welcome to Elcometer.
Elcometer are world leaders in the design, manufacture and supply of inspection equipment for
coatings and concrete. Our products cover all aspects of coating inspection, from development
through application to post application inspection.
The Elcometer Krebs Viscometer is a world beating product. With the purchase of this product you
now have access to the worldwide service and support network of Elcometer. For more information
visit our website at www.elcometer.com
1 ABOUT YOUR VISCOMETER
The Elcometer Krebs Viscometer measures the viscosity of paints, varnishes, adhesives, pastes
and liquid inks in accordance with ASTM D 562 and other standards.
This simple-to-use instrument consists of a paddle mounted on the end of a rotating spindle. The
paddle is immersed in the sample and rotated at a constant speed of 200 revolutions per minute.
The viscometer automatically calculates the viscosity value from the power required to maintain the
speed of rotation of the spindle.
A digital display shows the viscosity of the sample in Krebs units, centipoise or grams.
The Elcometer Krebs Viscometer features manual or automatic operation. In automatic mode, at
the press of a button:
• the spindle lowers into the sample to a pre-set depth
• the instrument waits to allow turbulence in the sample to subside (the wait time is adjustable)
• the spindle rotates and the measurement is taken (the measurement rotation time is
adjustable)
• the spindle rises out of the sample.
The operation of the Elcometer Krebs Viscometer is based on the Stormer mechanical system. In
this system a blade rotates at a constant angular velocity and the variation of viscosity between
products is determined by modifying theweight (ingrams) neededto maintainthis constantvelocity.
1.1 What the box contains
Note: When removing the viscometer from the packaging box, hold the viscometer by the
base and the column - do not lift it by the head.
•Viscometer
• Drive coupling protection cap, plastic
• Krebs spindle
• Sample container support, large, for 600 ml glass beaker and 1 pint (USA) can
• Sample container support, small, for ½ pint (USA) can
• Locating plug for sample container support
• Sample container, 600 ml, glass
• Hexagonal wrench, 1.5 mm
• Power supply cable
• Calibration certificate
• Operating instructions

5
R
en
Your Elcometer Krebs Viscometer is packed in a cardboard and foam package. Please ensure that
this packaging is disposed of in an environmentally sensitive manner. Consult your local
Environmental Authority for further guidance.
1.2 Standards
Your Viscometer can be used in accordance with the following National and International
Standards:
• AS/NZS 1580.214.1
• ASTM D 562
• ASTM D 1084-C
1.3 Krebs units
The Elcometer Krebs Viscometer is suitable for measuring in Krebs units (KU) the viscosity of
paints, varnishes, adhesives, pastes, liquid inks and other similar substances.
The Krebs unit scale is commonly used to refer to viscosity or consistency of paints that are applied
by brush or roller.
The Krebs unit is defined by following equation:
• For viscosity in the range from 200 cP to 2100 cP
KU = 1.1187 + 0.8542 ln ( 0.1938 v + 36 ) - 0.0443 [ ln ( 0.1938 v + 36 ) ] 2
• For viscosity in the range from 2100 cP to 5000 cP
KU = 1.8118 + 0.596 ln ( 0.1938 v + 36 ) - 0.0206 [ ln ( 0.1938 v + 36 ) ] 2
where:
• KU is viscosity in Krebs units
• v is viscosity in centipoise (cP)
Note: The equivalent viscosity in cP given by the instrument should only be used for comparison
between one sample and another; it must never be used for quantitative measurement of viscosity.
To maximise the benefits of your new Elcometer Krebs Viscometer please take some time to
read these Operating Instructions. Do not hesitate to contact Elcometer or your Elcometer
supplier if you have any questions.
2 CAUTION
The Elcometer Krebs Viscometer has been manufactured with your safety in mind.
However, improper use can result in damage to the machine.
Please observe the precautions discussed in these operating instructions.
• To reduce the risk of electric shock, do not open the Viscometer. There are no
user-serviceable parts inside.
• To reduce the risk of fire or electric shock, do not expose the Viscometer to rain or excess
moisture.
• The mains plug on your Viscometer may be fitted with a fuse. When replacing this fuse, ensure
a fuse of the correct rating is used.
• Do not use the Elcometer Krebs Viscometer in hazardous environments.

6
R
en
3 GETTING STARTED
3.1 The parts of the instrument
Viscometer head with
display and control
panel
Spindle
Base
Column
Sample container
support for
beaker/can

7
R
en
3.2 Rear connections
3.3 Installing the Viscometer
To install your Viscometer:
1. Place the base on a stable and flat
surface.
2. Rotate the adjustable feet under the
base until the instrument is level; use a
bubble level placed on the base of the
instrument as a guide.
3. Remove the plastic drive coupling
protection cap from the bottom of the
Viscometer; pull the cap vertically
down until it is well clear of the drive
coupling and then remove to one side.
Do not dispose of the protection
cap. To prevent accidental damage
to the drive coupling, always replace
the cap when the instrument is not
in use.
4. Connect the instrument to the mains.
Power supply socket
RS 232 interface
Power on/off switch
Drive
coupling
protection
cap

8
R
en
3.4 Fitting the spindle
Note: This operation must be done very
carefully to ensure that the spindle is not
bent and the motor drive coupling or internal
components are not damaged.
1. Check that the connecting surfaces of
the spindle and the motor drive
coupling are clean.
2. Insert the spindle as far as it will go up
into the motor drive coupling.
3. Using the hexagonal wrench supplied,
rotate the retaining screw until it just
makes contact with the spindle.
4. Pull down on the spindle until its
movement is stopped by the retaining
screw.
5. Tighten the retaining screw.
3.5 Fitting a sample container
support
During a test, the sample container (glass
beaker or can) is held in position at the
correct height by the sample container
support. Two supports are supplied with the
instrument - a large one and a smaller one.
Which support you use depends upon the
size of the sample container.
The sample container support is held in
position on the base by the locating plug.
To fit the sample container support:
When using the glass beaker supplied
with the instrument, or a 1 pint (USA)
can
1. Place the locating plug into the recess
on the base of the instrument.
2. Place the large sample container
support onto the locating plug.
When using a ½ pint (USA) can
1. Place the locating plug into the recess on the base of the instrument.
2. Place the large sample container support onto the locating plug.
3. Place the smaller sample container support into the recess on the top of the large sample
container support.
Spindle
Drive
coupling
Smaller
support
Large
support
Locating
plug

9
R
en
3.6 Control panel
Your Viscometer is controlled using the five buttons on the control panel on the front of the
Viscometer head.
4 THE SAMPLE
4.1 Sample quantity
To maximise the accuracy and consistency of test results, always use the same quantity of sample
for each test.
To determine the correct quantity of sample, do the following:
1. Place the sample container on the sample container support.
2. Attach the spindle to the drive head (see “Fitting the spindle” on page 8).
3. Switch on the instrument and select manual mode (see “Taking a measurement in manual
mode” on page 14).
4. Press [DOWN] until the spindle reaches the lowest position (the instrument will sound an
audible beep when the spindle reaches the lowest position).
5. Pour the sample into the container. Stop pouring when the surface of the sample reaches the
notch on the spindle shaft. If using the 600 ml glass beaker supplied with the instrument,
450 ml to 460 ml of sample will be required to reach this level.
6. Make a record of the quantity of sample used.
Whenever you conduct a test, always use this same quantity of sample. By doing this, you will be
able to perform different measurements with the same working conditions, therefore permitting
reliable comparisons between test results to be made.
4.2 Sample temperature
The temperature of the sample has a significant effect upon its viscosity. Always check the
temperature of the sample before conducting a test. The temperature of the sample must be stable
and at the value specified in the test standard.
Raise and lower
spindle (manual
mode)
Scroll in menus
Start test
(automatic mode)
Stop test
Start test (manual mode)
Confirm menu selection

10
R
en
5 CONFIGURING YOUR VISCOMETER
To configure your Elcometer Krebs Viscometer ready to take measurements, do the following:
1. Switch on the Viscometer (use the power on/off switch at rear of head).
The instrument displays:
2. While the welcome message is displayed (5 seconds), press [START] and then [ENTER].
The instrument displays the viscosity units selection screen:
3. If necessary, press [UP] or [DOWN] to select the working units: Ku (Krebs units),
cP (Centipoise) or g (grams).
4. Press [ENTER] to confirm your selection.
The instrument displays the SWT (sample wait time) selection screen:
5. If necessary, press [UP] or [DOWN] to select the sample wait time: minimum = 1 second,
maximum = 99 seconds, default = 1 second.
6. Press [ENTER] to confirm your selection.
The instrument displays the SMT (sample measure time) selection screen:
7. If necessary, press [UP] or [DOWN] to select the sample measure time: minimum = 5 seconds,
maximum = 99 seconds, default = 10 seconds.
2250 KV 1.1
Viscosity Units
Ku
SWT: 01
Sample Wait Time
SMT: 10
Sample Measure Time

11
R
en
8. Press [ENTER] to confirm your selection.
The instrument displays the time/date setup screen:
9. If necessary, press [UP] or [DOWN] to select the time/date mode: EU mode (European mode:
day-month-year) or US mode (month-day-year).
10. Press [ENTER] to confirm your selection.
The instrument displays the set clock screen:
The day of the week flashes.
11. If necessary, press [UP] or [DOWN] to change the day of the week.
12. Press [ENTER] to confirm your selection.
The first digit of the date flashes.
13. If necessary, press [UP] or [DOWN] to change the digit.
14. Press [ENTER] to confirm your selection.
15. Continue adjusting values and confirming with [ENTER] until all date and time values are
correct.
The instrument displays the welcome message again and immediately afterwards the working
mode selection screen:
Your Elcometer Krebs Viscometer is now configured and ready to take measurements in automatic
mode (page 12) or in manual mode (page 14).
TIME/DATE
EU mode
Set Clock EU mode
Tuesday (day)
15-11-05 (ddmmyy)
11:14:05 (hhmmss)
2250 KV 1.1
<START> automatic
<ENTER> manual
XX:XX:XX

12
R
en
6 TAKING A MEASUREMENT IN AUTOMATIC MODE
Use the automatic mode of your Elcometer Krebs Viscometer for your standard testing - it will help
you to conduct tests easily, rapidly and consistently.
Note: Do not select automatic mode when using a ½ pint (USA) can - the neck of this can
is too narrow to allow the spindle blades to pass through without manual intervention;
always select manual mode when using a ½ pint (USA) can (see “Taking a measurement
in manual mode” on page 14).
1. Attach the spindle to the drive head (see “Fitting the spindle” on page 8).
2. Fit the large sample container support onto the locating plug on the base of the instrument.
Check that the sample container fits into the recess in the top of the sample container support.
3. Pour the correct amount of sample to be tested into the sample container (see “Sample
quantity” on page 9).
4. Place the sample container onto the sample container support.
5. Switch on the Viscometer (use the power on/off switch at rear of head).
The instrument displays:
After 5 seconds, the instrument displays the working mode selection screen:
6. Press [START] to select automatic mode.
The instrument displays:
7. If necessary, press [ENTER] to adjust the values of SWT, SMT or the working units:
Use the [UP] and [DOWN] buttons to select the value of the parameter and then press
[ENTER] to confirm your selection.
8. Press [START] to start the measurement.
(If necessary, to stop the automatic process at any time, press [STOP])
2250 KV 1.1
2250 KV 1.1
<START> automatic
<ENTER> manual
XX:XX:XX
automatic process
SWT: 05s. SMT: 10s
Ku: 000.0
Press <START>

13
R
en
The instrument displays “Going DOWN” and the head moves down until the spindle reaches
its lowest position.
When the spindle reaches its lowest position, the sample wait timer starts to count down.
When the sample wait timer reaches zero, the spindle starts rotating and the sample
measurement timer starts to count down. While the spindle rotates, the instrument displays the
viscosity reading:
When the sample measurement timer reaches zero, the spindle stops rotating, the head
moves up and the instrument displays the final viscosity reading and the option to print the
results or quit:
9. If necessary, press [ENTER] to print the results. If
your Viscometer is connected to a suitable printer,
this provides a quick and easy way to save and
document individual test results. See “Spare parts
and accessories” on page 17.
The results from the test are output via the RS232
connection at the rear of the Viscometer head.
10. When you have finished taking the measurement,
press [STOP].
11. After use, clean the instrument and spindle - see
“Cleaning” on page 16.
automatic process
SWT: 05s. SMT: 10s
Ku: 000.0
Going DOWN
automatic process
SWT: 05s. SMT: 10s
Ku: 121
<STOP> quit
automatic process
SWT: 05s. SMT: 10s
Ku: 121
<ENT> print <STP> quit

14
R
en
7 TAKING A MEASUREMENT IN MANUAL MODE
If you need to work with a ½ pint (USA) can or alternative containers and sample volumes, the
spindle must be positioned manually in order to immerse it in the sample at the correct level. To do
this, use your Elcometer Krebs Viscometer in manual mode.
1. Attach the spindle to the drive head (see “Fitting the spindle” on page 8).
2. Fit the appropriate sample container support onto the locating plug on the base of the
instrument (see page 8). Check that the sample container fits into the recess in the top of the
sample container support.
3. Pour the sample to be tested into the sample container.
4. Place the sample container onto the sample container support.
5. Switch on the Viscometer (use the power on/off switch at rear of head).
The instrument displays:
After 5 seconds, the instrument displays the working mode selection screen:
6. Press [ENTER] to select manual mode.
The instrument displays:
7. Press [DOWN] to move the spindle down into the sample.
Note: If using a ½ pint (USA) can, the neck of this can is too narrow to allow the spindle blades
to pass through. Tilt the can slightly to allow the spindle blades to pass through the neck of the
can.
8. Use the [UP] and [DOWN] buttons to adjust the position of the spindle until the notch on the
spindle shaft is level with the surface of the sample.
9. Press [START] to start the spindle rotating.
The value of viscosity is shown on the display.
10. When you are satisfied with the result, press [STOP] to stop the spindle rotating.
11. Press [UP] to move the spindle up out of the sample.
2250 KV 1.1
2250 KV 1.1
<START> automatic
<ENTER> manual
XX:XX:XX
<UP/DOWN> spindle
<START/STOP> measure
Ku: 000.0
<ENTER> print

15
R
en
12. If necessary, press [ENTER] to send the results to a printer (see page 13 for details).
13. When you have finished taking the measurement, press [STOP].
14. After use, clean the instrument and spindle - see “Cleaning” on page 16.
8 TROUBLESHOOTING
8.1 Security stop
If an obstruction causes the up or down movement of the head to be impeded, or in the unlikely
event of a malfunction, an audible alarm sounds, the movement is stopped and the instrument
displays the following message:
1. Press [STOP] to switch off the alarm.
2. If appropriate, switch off the instrument, remove the obstruction and then restart the test.
3. If the malfunction persists, contact Elcometer or your local supplier.
8.2 Unstable readings
Unstable viscosity readings may be caused by changes in the temperature of the sample or by the
behaviour of the product itself.
Check that the instrument is level. If the readings obtained remain unstable, the temperature of the
sample should be controlled and stabilised. If the readings remain unstable the instability is due to
the interaction between the product sample and the movement of the spindle.
In this instance, the product is called ‘Non-Newtonian’ and the behaviour of the product can be
described as thixotropic, rheoplexic, dilatant, pseudoplastic, etc. The same settings (SWT, SMT
and temperature) should always be used to test this type of product.
8.3 Instrument does not zero
When the spindle is rotating in free air (not immersed in a sample), the viscosity reading should be
zero. If it is not zero, please contact Elcometer or your local Elcometer supplier.
9 CALIBRATION
Your Viscometer was calibrated at the factory before shipment and a calibration certificate was
included in the box. Additional calibration checks at regular intervals over the life of the Viscometer
are a requirement of quality management procedures, e.g. ISO 9000, and other similar standards.
Calibration checks may be carried out by the user of the Viscometer (see instructions below),
however if the calibration of the Viscometer is found to need adjustment, please contact Elcometer
or your local Elcometer supplier.
SECURITY STOP
mechanical
malfunction

16
R
en
Checking Viscometer calibration
It is recommended that calibrated Krebs viscosity oil is used for checking calibration - see “Spare
parts and accessories” on page 17. Use calibration oil with a Krebs value close to that of the
samples you regularly test.
1. Pour the correct amount of calibration oil into the sample container.
2. Check the temperature of the calibration oil; it must be stable and at the value specified in the
test standard.
3. Conduct an automatic test of the calibration oil using the values for SWT and SMT specified in
the test standard.
4. Once the test has been completed, check the viscosity reading on the display. If the reading is
identical to the nominal viscosity of the Krebs calibration oil, your Viscometer is calibrated
correctly.
10 MAINTENANCE
The Elcometer Krebs Viscometer is designed to give many years reliable service under normal
operating and storage conditions.
10.1 Cleaning
Always clean the instrument and spindle after use.
Always remove the spindle from the instrument before cleaning. The spindle or motor
coupling will almost certainly be damaged if attempts are made to clean the spindle while it
is still attached to the instrument.
Do not use very aggressive solvents or wire brushes, metal scrapers, metal files or other metallic
tools. Do not use excessive force which might otherwise bend delicate spindles.
Clean the spindle and other parts using a suitable solvent only.
After cleaning and before storing the instrument ensure that all materials are removed and that the
instrument is dry.
10.2 Service
The Elcometer Krebs Viscometer does not contain any internal user-serviceable components. In
the unlikely event of a fault, the instrument should be returned to your local Elcometer supplier or
directly to Elcometer. The warranty will be invalidated if the instrument has been opened.
Details of Elcometer offices around the world are given on the outside cover of these Operating
Instructions. Alternatively visit the Elcometer website, www.elcometer.com

17
R
en
11 TECHNICAL SPECIFICATION
Room temperature: 10°C to 40°C (50°F to 104°F)
Relative humidity: < 80%
Speed: 200 rpm
Accuracy (speed): ± 1 rpm
Measurements, KU: range 40.2 KU to 141 KU, resolution 0.1 KU
g: range 32 g to 1099 g, resolution 1 g
cP: range 27 cP to 5274 cP, resolution 5 cP
Accuracy (measurement): ± 1% of full scale
Repeatability: ± 0.5%
Maximum altitude: 2 000 m (6 500 ft) above sea level
Ingress protection: Level 2
Operating voltage: UK, 240 V AC 50 Hz
EUR, 220 V AC 50 Hz
US, 110 V AC 60 Hz
Overvoltage category: Class II (domestic/light industry)
Power consumption: 0.2 A
Dimensions: 500 mm x 325 mm x 190 mm
(19.7" x 12.8" x 7.5")
Weight: 8.5 kg (18.7 lb)
12 SPARE PARTS AND ACCESSORIES
The following spare parts and accessories for your Elcometer Krebs Viscometer are available from
your local supplier or direct from Elcometer:
Spindle, Krebs, standard KT00225021791
Special Paste Spindle KT00225022906
Sample container, 600 ml, glass KT00225021796
Sample container support, for 600 ml glass beaker and 1 pint (USA) can KT00225021794
Sample container support, for ½ pint (USA) can KT00225021795
Locating plug for sample container support KT00225021793
Hexagonal wrench, 1.5 mm T9992596-
Power supply cable, European KT009999P001
Power supply cable, UK KTUK9999P001
Power supply cable, US KTUS9999P001

18
R
en
Thermal Printer, 220 V Euro KT00999920178
Thermal Printer, 240 V UK KT00999920179
Thermal Printer, 110 V US KT00999920180
Viscosity oil, Krebs, 64 KT002250N001
Viscosity oil, Krebs, 79 KT002250N002
Viscosity oil, Krebs, 84 KT002250N003
Viscosity oil, Krebs, 95 KT002250N004
Viscosity oil, Krebs, 115 KT002250N005
13 RELATED EQUIPMENT
In addition to the Elcometer Krebs Viscometer, Elcometer produces a wide range of other
equipment for determining the physical characteristics of surface coatings.
Users of the Elcometer 2250 may also benefit from the following Elcometer products:
• Elcometer 2300 Rotational Viscometer
• Elcometer 2000 Muller Laboratory Grinder
• Elcometer Fineness of Grind Gauges
• Elcometer Viscosity Cups
• Elcometer Film Applicators
For further information contact Elcometer, your local Elcometer supplier or visit www.elcometer.com
or www.elcoship.com.
