Evco Syncro Series User manual

Syncro series inverter
Inverter for high power synchronous motors
WARNING
Make sure you read and fully
understand the user manual
before using this device.
Non-observance of these
instructions will result in death
or serious injury.
114EIXKE4.00 - 02/2022
Hardware Manual

114EIXKE4.00 ·Syncro series inverter
CONTENTS
02/2022
| 2 |
IMPORTANT INFORMATION.............................................................................................................. 4
IMPORTANT SAFETY INFORMATION................................................................................................ 5
SAFETY INFORMATION RELATING TO THE PRODUCT..................................................................... 6
1. INTRODUCTION .............................................................................................................................. 8
1.1 Description ............................................................................................................................................. 8
1.2 Product overview................................................................................................................................... 8
1.3 Features .................................................................................................................................................. 8
1.4 General Compliance............................................................................................................................... 8
2. PURCHASING CODES...................................................................................................................... 9
2.1 Purchasing codes table ......................................................................................................................... 9
3. RECEIVING THE PRODUCT ........................................................................................................... 10
2.2 Checking the packaging.......................................................................................................................10
2.2.1 Opening the packaging..............................................................................................................................10
2.2.2 Checking the packaging contents............................................................................................................10
4. TECHNICAL DATA.......................................................................................................................... 11
4.1 Technical specications......................................................................................................................11
4.2 Other technical information................................................................................................................11
5. MECHANICAL ASSEMBLY............................................................................................................ 12
5.1 Introduction to installation.................................................................................................................12
5.2 Permitted installation positioning ......................................................................................................13
5.3 Minimum installation distances..........................................................................................................13
5.4 Installation method..............................................................................................................................15
5.5 Dimensions and weight........................................................................................................................16
6. ELECTRICAL CONNECTIONS........................................................................................................ 17
6.1 Connection best practice ....................................................................................................................17
6.1.1 Wiring best practices................................................................................................................................18
6.1.2 Sizing safety interlocks.............................................................................................................................18
6.2 Wiring diagram.....................................................................................................................................19
6.2.1 Safety digital input STO wiring diagram..................................................................................................20
7. REGULATORS ................................................................................................................................. 21
7.1 Control types ........................................................................................................................................21
7.2 Protection .............................................................................................................................................21
7.3 LED interface ........................................................................................................................................21
7.4 Operation ..............................................................................................................................................22
7.4.1 Rotation direction reversal......................................................................................................................22
7.4.2 Compressor heating .................................................................................................................................22
7.4.3 Motor control at start-up .........................................................................................................................22
7.4.4 Motor pole pairings...................................................................................................................................22

114EIXKE4.00 ·Syncro series inverter
CONTENTS
02/2022
| 3 |
7.4.5 Speed jump.................................................................................................................................................23
7.4.6 Speed prole..............................................................................................................................................23
7.4.7 Reducing the PWM carrier frequency and/or speed............................................................................24
7.4.8 Motor phase loss alarm sensitivity .........................................................................................................24
7.4.9 Motor stall alarm sensitivity ....................................................................................................................25
8. MANUAL TUNING MODE / AUTOTUNING.................................................................................... 26
8.1 Manual tuning mode ............................................................................................................................26
8.2 Autotuning mode ..................................................................................................................................27
8.2.1 Autotuning procedure ..............................................................................................................................27
9. CONFIGURATIONS........................................................................................................................ 29
9.1 Control via analogue and digital input ...............................................................................................29
9.1.1 Wiring diagram ..........................................................................................................................................29
9.1.2 Parameter conguration..........................................................................................................................29
9.2 Control via Slave Serial port ...............................................................................................................30
9.2.1 Wiring diagram ..........................................................................................................................................30
9.2.2 Parameter conguration..........................................................................................................................30
10. PARAMETERS.............................................................................................................................. 31
10.1 Table of conguration parameters ..................................................................................................31
10.2 Table of Modbus commands .............................................................................................................34
10.3 Serial communication settings.........................................................................................................34
10.4 Table of Modbus variables................................................................................................................34
10.5 Table of monitor data.........................................................................................................................36
11. ALARMS ....................................................................................................................................... 37
11.1 Table of alarms...................................................................................................................................37
12. PARAMETERS MANAGER........................................................................................................... 38

114EIXKE4.00 ·Syncro series inverter 02/2022
| 4 |
IMPORTANT INFORMATION
Liability and residual risks
EVCO assumes no liability for any damage caused by the following (by way of example; this is not an exhaustive list):
• Installation/useforpurposesotherthanthosespeciedand,inparticular,notadheringtothesafetyprovisionssetout
by current regulations in the country in which the product is installed and/or contained in this manual;
• Useinappliancesthatdonotguaranteesufcientprotectionagainstelectricshocks,wateranddustwithinthe
installation conditions created;
• Useinappliancesthatallowaccesstohazardouspartswithouttheuseofakeyedortooledlockingmechanismwhen
accessing the instrument;
• Tampering and/or modifying the product;
• Installation/use in appliances which do not comply with current regulations in the country in which the product is
installed.
The customer/manufacturer is responsible for ensuring their machine complies with these regulations.
EVCO’s responsibility is limited to the correct and professional use of the product in accordance with regulations and the
instructions contained in this manual and other product support documents.
TocomplywithEMCstandards,observealltheelectricalconnectioninstructions.Asitdependsonthewiringconfigurationas
wellastheloadandtheinstallationtype,compliancemustbeverifiedforthefinalmachineasspecifiedbytherelevantproduct
standard.
Disclaimer
This document is the exclusive property of EVCO. It contains a general description and/or a description of the technical
specifications for the services offered by the products listed herein. This document should not be used to determine the
suitability or reliability of these products in relation to specific user applications. Each user or integration specialist should
conducttheirowncompleteandappropriateriskanalysis,inadditiontocarryingoutaproductevaluationandtestinrelation
to its specific application or use. Users can send us comments and suggestions on how to improve or correct this publication.
Neither EVCO nor any of its associates or subsidiaries shall be held responsible or liable for improper use of the information
contained herein.
EVCOhasapolicyofcontinuousdevelopment.Therefore,EVCOreservestherighttomakechangesandimprovementstoany
product described in this document without prior notice.
The images in this document and other documentation supplied with the product are provided for illustrative purposes only and
may differ from the product itself.
The technical data in this manual is subject to change without prior notice.
Terms and Conditions of use
Permitted use
Thedevicemustbeinstalledandusedinaccordancewiththeinstructionsprovidedand,inparticular,hazardousliveparts
must not be accessible under normal conditions.
The device must be suitably protected from water and dust with regard to its application and must also only be accessible with
the aid of a tool.
Only qualified personnel may install the product or perform technical support procedures on it.
The customer must only use the product as described in the documentation relating to that product.
Prohibited use
Anyuseotherthanthosedescribedinthe"Permitted use"sectionandintheproductsupportdocumentationisprohibited.
The product must be installed outside hazardous ATEX areas.
Disposal
The device must be disposed of in accordance with local regulations regarding the collection of electrical and
electronic appliances.
Consider the environment
Withaviewtorespectingtheenvironment,westrivetoadheretotheenvironmentalperformanceofthecompany,
whiletakingaccountofcustomerrequirements,technologicalinnovationsintermsofmaterialsandtheexpectations
ofthecommunitytowhichwebelong.EVCOplacesgreatimportanceonrespectingtheenvironment,encouragingall
associatestobecomeinvolvedwithcompanyvaluesandguaranteeingsafe,healthyandfunctionalworkingconditions
andworkplaces.
Please consider the environment before printing this document.

114EIXKE4.00 ·Syncro series inverter 02/2022
| 5 |
IMPORTANT SAFETY INFORMATION
Please read this document carefully before installation; study all the warnings before using the device. Only use the device in
accordance with the methods described in this document. The following safety messages may be repeated several times in
thedocument,toprovideinformationregardingpotentialhazardsortoattractattentiontoinformationwhichmaybeusefulin
explaining or clarifying a procedure.
Thissymbolisusedtoindicateariskofelectricshock.
Itisasafetyindicationandassuch,shouldbeobservedtoavoidpotentialaccidentsorfatalities.
Thissymbolisusedtoindicateariskofseriouspersonalinjury.
Itisasafetyindicationandassuch,shouldbeobservedtoavoidpotentialaccidentsorfatalities.
DANGER
DANGER indicatesasituationofimminentdangerwhich,ifnotavoided,will lead to death or serious injury.
WARNING
WARNING indicatesasituationofimminentdangerwhich,ifnotavoided,may lead to death or serious injury.
CAUTION
CAUTION indicatesapotentiallyhazardoussituationwhich,ifnotavoided,could cause minor or moderate injury.
NOTICE
NOTICE indicates a situation not related to physical injuries but which ,ifnotavoided, could damage the equipment.
NOTE:themaintenance,repair,installationanduseofelectricalequipmentmustonlybeentrustedtoqualifiedpersonnel.
QUALIFIED PERSONNEL
Only suitably trained and experienced personnel capable of understanding the content of this manual and all documentation
regardingtheproductareauthorisedtoworkonandwiththisequipment.Furthermore,thepersonnelmusthavecompleted
coursesinsafetyandmustbeabletorecogniseandpreventtheimplieddangers.Thepersonnelmusthavesuitabletraining,
knowledgeandexperienceatatechnicallevel,andbecapableofanticipatinganddetectingpotentialriskscausedbyusing
theproduct,aswellaschangingthesettingsandmodifyingthemechanical,electricandelectronicequipmentfortheentire
systeminwhichtheproductisused.Allpersonnelworkingonandwiththeproductmustbeentirelyfamiliarwiththerelevant
standardsanddirectives,aswellassafetyregulations.

114EIXKE4.00 ·Syncro series inverter 02/2022
| 6 |
SAFETY INFORMATION RELATING TO THE PRODUCT
Beforecarryingoutanyworkontheequipment,readtheseinstructionscarefully,makingsureyouunderstandeverything.
DANGER
RISK OF ELECTRIC SHOCK, EXPLOSION OR ELECTRIC ARC
• Onlysuitablytrainedpersonnel,familiarwithandcapableofunderstandingthecontentofthemanualandallrelevant
documentation,areauthorisedtoworkonandwiththisinverter.Furthermore,thepersonnelmusthavecompletedcourses
insafetyandmustbeabletorecogniseandpreventtheimplieddangers.Installation,adjustmentandmaintenancemust
only be carried out by qualified personnel.
• Variousproductcomponents,includingtheprintedcircuits,runathazardousvoltagelevels.
• Only use electrically insulated and suitably calibrated measuring devices and equipment.
• Do not handle the equipment while the power supply is connected.
• Do not touch the unshielded components or the terminals while they are live.
• Themotorsmaygeneratevoltageiftheshaftisrotated.Beforecarryingoutanyworkontheinverter,lockthemotorshaft
to prevent it from rotating.
• Beforeworkingontheinverter:
• Disconnect the power supply.
• UseasuitablycalibratedandelectricallyinsulatedVoltmetertomakesurethepowersupplyisdisconnected.
• Waitfor5minutedafterdisconnectingthepowersupplybeforeinstalling/uninstallingaccessories,hardware,cablesor
wires,toallowthecondenserstodischargeanyresidualvoltage.
• Donotopen,disassemble,repairormodifytheproduct.
• Beforehandlingtheproduct,makesureyouarewearingallthenecessarypersonalprotectiveequipment(PPE).
• Do not expose the equipment to liquids or chemicals.
• Before applying voltage to the inverter:
• Makesuretherunningperiodhasbeencompletedandnopartsofthesystemcanbecomehazardous.
• Ifthemainspowersupplyterminalsandthemotoroutputterminalshavebeenearthedandcircuited,removetheearth
and short circuits on these terminals.
• Makesurealltheequipmentisproperlyearthed.
• Makesureallprotectiveelements,suchascovers,hatchesandgrilles,arefittedand/orclosed.
• Checkallwiringconnections.
ForinstallationinaccordancewithstandardEN61800-5-1,adevicecuttingoffthecircuitbetweenthepowersupplyandthe
inverter is required.
DANGER
RISK OF ELECTRIC SHOCK
Usetherequiredsafetyinterlocks(fusesand/ormagnetothermalswitches)ofasuitablesizebetweenthepowersupplyand
the inverter.
DANGER
RISK OF ELECTRIC SHOCK AND FIRE
• Do not use the device with loads greater than those indicated in the technical data section.
• Do not exceed the temperature and humidity ranges indicated in the technical data section.
DANGER
RISK OF ELECTRIC SHOCK OR MALFUNCTIONING OF THE EQUIPMENT
Do not use damaged products or accessories.
Thisdevicewasdesignedtooperateinnon-hazardousenvironments,excludingapplicationsthatgenerate,orcouldpotentially
generate,hazardousatmospheres.Onlyinstallthisdeviceinareasandforapplicationswhicharereliablyfreefromhazardous
atmospheres.
DANGER
RISK OF EXPLOSION
• Onlyinstallandusethisdeviceinsitesthatarenotatrisk.
• Donotinstallorusethisdeviceinapplicationswhicharecapableofgeneratinghazardousatmospheres,suchas
applications that use flammable refrigerants.

114EIXKE4.00 ·Syncro series inverter 02/2022
| 7 |
Theendapplicationutilisesawiderangeofmechanical,electricalandelectroniccomponentsconnectedtooneanotherandthe
inverter is only one part of the application.
Theinverter,asanindividualmachine,isnotcapableofprovidingallthefunctionsnecessarytosatisfyallthesafety
requirementsrelatingtotheendapplication.Dependingontheapplicationandthecorrespondingriskanalysistobeperformed,
a series of additional equipment will be required.
Asamachinedesigner/manufacturer,itisnecessarytobefamiliarwithandobserveallstandardsapplicabletothemachine.
ItisalsoessentialtocarryoutariskassessmentandtodeterminetheappropriatePerformanceLevel(PL)and/orSafety
IntegrityLevel(SIL)inordertodesignandconstructthemachineincompliancewithallapplicablestandards.Theinteraction
betweenallmachinecomponentsmustbeconsidered,anditisessentialtoprovideoperatinginstructionswhichallowtheuser
(qualifiedpersonnel)tosafelycarryoutanytypeofworkonthemachine,suchasoperationandmaintenance.
Thisdocumentassumesfamiliaritywithallstandardsandregulatoryrequirementsrelatingtotheapplication.Astheinverteris
notcapableofprovidingallsafety-relatedfunctionsfortheentireapplication,itisessentialthattherequiredperformancelevel
and/or safety integrity level is guaranteed through the installation of all necessary additional equipment.
WARNING
INSUFFICIENT PERFORMANCE LEVEL AND/OR SAFETY INTEGRITY LEVEL AND/OR MALFUNCTIONING OF THE EQUIPMENT
• Carryoutariskassessmentinaccordancewithallotherstandardsrelatingtoyourapplication.
• Useredundantcomponentsand/orcontrollinesforallcriticalcontrolfunctionsidentifiedintheriskassessment.
• Makesurethattheusefullifeofallcomponentsusedintheapplicationissufficientfortheanticipateddurationoftheentire
application.
• Carryoutin-depthstart-uptestsforallpotentialerrorsituationsinordertochecktheeffectivenessofthesafetyand
monitoringfunctionsimplemented,suchasspeedmonitoringviaencoder,short-circuitmonitoringforallconnected
equipmentandcorrectbrakeandprotectivedeviceoperation.
• Carryoutin-depthstart-uptestsforallpotentialerrorsituationsinordertomakesuretheloadcanbesafelybroughttoa
stop in all conditions.
The Syncro inverter must be installed in a suitably ventilated environment to allow heat to dissipate.
Thetemperatureofthedevicecanexceed80°C(176°F)duringoperation.
WARNING
HOT SURFACES
• Avoidallcontactwithhotsurfaces.
• Donotleaveflammableorheat-sensitivecomponentsonornearhotsurfaces.
• Makesuretheproducthascooledsufficientlybeforehandlingit.
• Makesuresufficientheatdissipationtakesplacebyperformingatestundermaximumloadconditions.
WARNING
MALFUNCTIONING OF THE EQUIPMENT
• Performthewiringcarefully,incompliancewithelectromagneticcompatibilityrequirements.
• Donotoperatetheproductwithunknownorincorrectsettingsordata.
• Carryoutafullstart-uptest.
• Makesurethewiringiscorrectforthesettings.
• Use shielded cables for all I/O signal and communication cables.
• Usedouble-shieldedcablesformotorwiring.
• Minimisethelengthoftheconnectionsasmuchaspossible,toavoidwindingthecablesaroundelectricallyconnectedparts.
• The signal (communication and corresponding power supplies) and power cables for the device must be routed in separate
ducts.
• Use ferrite couplings for the connection cables running to the motor and for the earth connection cable.
• Beforeapplyingthepowersupply,checkallthewiringconnections.
• Donotconnectwirestounusedterminalsand/orterminalsmarkedwiththetext“Noconnection”(N.C.).

114EIXKE4.00 ·Syncro series inverter 02/2022
|8|
1.1 DESCRIPTION
The series of Syncroinvertersisdesignedtocontrolthree-phasepermanentmagnetsynchronousmotorswithapowerofupto6kW.
Operating environments for the Syncro series of products are:
• Three-phasepermanentmagnetsynchronousmotors(BLDC);
• Three-phaseasynchronousmotors;
• ControllingHVAC-Rcompressors.
Itusesscalarorvectormotorcontrol,dependingonapplicationrequirements.
1.2 PRODUCT OVERVIEW
1
6
7
2
3
4
5
Ref. Description
1Power supply input
2Motor output
3I/O connections
4Digital Output
5Cooler fans
6
PCB fan
7ServiceUSBinput
Fig. 1. Syncro Inverter overview
1.3 FEATURES
The main features of the Syncro series inverter are:
• 3 digital inputs;
• 1safetydigitalinput(forSIL2/SIL3systems);
• 1analogueinput:
• CanbeconguredasanNTC/PTCprobeor0...10Vinput;
• 1digitaloutput;
• 112Vdcoutput;
• 1RS-485Modbusslavecommunicationserialport;
• Availablepowerlevels:
• 4.8kW;
• 6kW.
• Invertercoolingsystemviabuilt-inventilation.
1.4 GENERAL COMPLIANCE
Directive Harmonised standard
LVD Directive 2014/35/EU EN61800-5-1:2007-09:Adjustablespeedelectricalpowerdrivesystems.
Part 5-1:Safetyrequirements–Electrical,thermalandenergysafety.
EMC Directive 2014/30/EU
EN61800-3 (EMC):Adjustablespeedelectricalpowerdrivesystems.ClassC2.
EN61000-3-12 (EMC):Limitsforharmoniccurrentsproducedbyequipmentconnectedto
publiclow-voltagesystemswithinputcurrent>16Aand≤75Aperphase.
Machine Directive 2006/42/EC EN61800-5-2:Adjustablespeedelectricalpowerdrivesystems.Safetyrequirements–
Functionalsafety.
1. INTRODUCTION

114EIXKE4.00 ·Syncro series inverter 02/2022
| 9 |
2. PURCHASING CODES
2.1 PURCHASING CODES TABLE
The table below illustrates the main features of available Syncro series inverters and the corresponding purchasing codes:
Features Syncro
Power supply 230Vac±10% •
Power levels 4.8kW EI4K8M2Y04O0VXX
6kW EI6K0M2Y04O0VXX
Digital inputs NPN(*) 3
Analogueinputs 0...10V 1
Digital outputs
1Arelayat230Vac 1
Powered outputs
12Vdcoutput,100mA
(reinforced insulation)
1
IndicatorLED
YellowLED 1
RedLED 1
GreenLED 1
Installation Panel •
Terminalblocks Quick-disconnectscrew
type •
Communication
ports RS-485MODBUSSLAVE •
NOTE: for further information, consult chapter "Chapter 4. Technical data" on page 11.
(*) = PNP on request; contact the sales ofce for more information.

114EIXKE4.00 ·Syncro series inverter 02/2022
|10|
NOTICE
MALFUNCTIONING OF THE EQUIPMENT
• Droppagesandshockscandamagetheproductbeyondrepair.
• Tamperingwithorremovingtheidentificationstickersinvalidatesthewarranty.
2.2 CHECKING THE PACKAGING
• Makesurethepackagingisintact;
• Makesuretheinverterisintactupondeliveryandinformthecourierimmediately,inwriting,ofanyproblemscausedby
carelessorimpropertransportation(acceptthepackageconditionally).
2.2.1 Opening the packaging
• Takethepackagetotheinstallationsite;
• Openthecardboardbox,removingthepolystyrenecornerprotectors;
• Slideouttheinverter.
2.2.2 Checking the packaging contents
Thestandardproductpackagecontains:
• Syncro series inverter;
• Instruction sheet for installation and assembly.
3. RECEIVING THE PRODUCT

114EIXKE4.00 ·Syncro series inverter 02/2022
|11|
AllthesystemcomponentsoftheSyncro inverter satisfy European Community (EC) requirements for electrical equipment.
They must be installed in casing or another location designated on the basis of specific environmental conditions and in order
tominimisetheriskofinvoluntarycontactwithhazardousvoltage.UsemetalcasingtoimproveSyncro system immunity to
electromagnetic fields. This equipment satisfies the EC requirements as indicated in the tables below.
WARNING
MALFUNCTIONING OF THE EQUIPMENT
Do not exceed any of the nominal values specified in this section.
4.1 TECHNICAL SPECIFICATIONS
Ambientoperatingconditions: -10...50°C(14...122°F)10…90%RHnon-condensing
Transportationandstorageconditions:-20...60°C(-4...140°F)10…90%RHnon-condensing
Altitude:   Maximum1000m(3.28ft)
Pollution category: 2
Protectiondegree:  IP00conformingtoIEC60529(installationonpanel)
IP44conformingtoIEC60529(installationwithexternalcoolerfan)
Overvoltage category: III in TT/TN systems
Powersupply:   230Vac±10%50/60Hz(single-phase)
Inputcurrent(RMS):  4.8 kW:22A
6 kW:28A
Outputcurrent(RMS):  4.8 kW:12A
6 kW:16A
Dispersioncurrenttoearth: ≥3.5mA
Coolingmethod:   Forcedventilation
4.2 OTHER TECHNICAL INFORMATION
Input properties (SELV)
Digital inputs: 3 multifunctional configurable digital inputs
Analogueinputs:  1inputthatcanbeconfiguredas:
Analogue:0...10V/PTCprobe
Digital: Digital input
STO(SafeTorqueOff)input: 1safetydigitalinput(*)
(*)Powersupply10...24Vac/dc,10mA,canbeintegratedintocontrolsystemsfallingintocategoriesSIL2 and SIL3.
Output properties
Digitaloutputs:   1relayoutput1Aat230Vac(configurable)
Motoroutput:   0...265Vac,3phatVin=230Vac
Carrierfrequency:  4...8kHz
Nominaloverload:  Limitedatmaximumcurrent
Outputfrequency:  0...400Hz
Serial communication port properties (SELV)
RS-485serialport:  
1opto-isolatedRS-485MODBUSRTUSlaveserialport,reinforcedforremoteconnection
Baudrate:9600/19200baud-Maximumcablelength(shielded):1000m(3280ft.)
Cable properties
Minimumoperatingtemperature:85°C(185°F)
Compliance
CE in accordance with standards:
• EN61800-3incategoryC2;
• EN61800-5-1;
• EN61800-5-2.
4. TECHNICAL DATA

114EIXKE4.00 ·Syncro series inverter 02/2022
|12|
5. MECHANICAL ASSEMBLY
5.1 INTRODUCTION TO INSTALLATION
Syncro inverter installation anticipates application to a panel by means of M5 screws (not supplied).
Inparticular,thesafetyinstructions,electricalrequirementsandcurrentregulationsforthemachineortheprocessinwhich
this device is involved must be observed.
Thepresenceofdust,liquidsorconductiveforeignobjects,ordamagedparts,maycauseparasiticvoltagedraw.
DANGER
RISK OF ELECTRIC SHOCK, EXPLOSION OR ELECTRIC ARC
• Do not use damaged products.
• Beforehandlingtheproduct,makesureyouarewearingallthenecessarypersonalprotectiveequipment(PPE).
• Do not handle the equipment while the power supply is connected.
• Themotorsmaygeneratevoltageiftheshaftisrotated.Beforecarryingoutanyworkontheinverter,lockthemotorshaft
to prevent it from rotating.
• Do not expose the equipment to liquids or chemicals.
• Before applying voltage to the inverter:
• Makesuretherunningperiodhasbeencompletedandnopartsofthesystemcanbecomehazardous.
• Ifthemainspowersupplyterminalsandthemotoroutputterminalshavebeenearthedandcircuited,removetheearth
and short circuits on these terminals.
• Makesurealltheequipmentisproperlyearthed.
• Makesureallprotectiveelements,suchascovers,hatchesandgrilles,arefittedand/orclosed.
• Checkallwiringconnections.
Thisdevicewasdesignedtooperateinnon-hazardousenvironments,excludingapplicationsthatgenerate,orcouldpotentially
generate,hazardousatmospheres.Onlyinstallthisdeviceinareasandforapplicationswhicharereliablyfreefromhazardous
atmospheres.
DANGER
RISK OF EXPLOSION
• Onlyinstallandusethisdeviceinsitesthatarenotatrisk.
• Donotinstallorusethisdeviceinapplicationswhicharecapableofgeneratinghazardousatmospheres,suchas
applications that use flammable refrigerants.
WARNING
HOT SURFACES
• Avoidallcontactwithhotsurfaces.
• Donotleaveflammableorheat-sensitivecomponentsonornearhotsurfaces.
• Makesuretheproducthascooledsufficientlybeforehandlingit.
• Makesuresufficientheatdissipationtakesplacebyperformingatestundermaximumloadconditions.
Inverters can generate strong localised electrical and magnetic fields. They may cause electromagnetic interference in
sensitive devices.
WARNING
ELECTROMAGNETIC FIELDS
• Donotallowwearersofmedicaldevicessuchaspacemakerstoapproachtheequipment.
• Do not place devices which are sensitive to electromagnetic interference near the equipment.

114EIXKE4.00 ·Syncro series inverter 02/2022
|13|
5.2 PERMITTED INSTALLATION POSITIONING
CAUTION
OVERHEATING CAUSED BY POSITIONING WHICH IS NOT PERMITTED
• Install the inverter in accordance with the permitt
ed positioning.
• If you apply positioning which is not
permitted,thepowerdrivesystemsmayoverheatandbecomedamaged.
Fig. 2. Syncro installation positioning
5.3 MINIMUM INSTALLATION DISTANCES
Install the Syncro inverterobservingtheminimumdistanceof40mm(1.57in.)oneachside,soastoguaranteeadequate
ventilationandaerationofthesystem.Makesurethereisadistanceofatleast10mm(0.39in.)betweenthesupportbaseand
the cooler.
WARNING
HOT SURFACES
• Avoidallcontactwithhotsurfaces.
• Donotleaveflammableorheat-sensitivecomponentsonornearhotsurfaces.
• Makesuretheproducthascooledsufficientlybeforehandlingit.
• Makesuresufficientheatdissipationtakesplacebyperformingatestundermaximumloadconditions.
40 (1.57)
40 (1.57)
10 (0.39)
40 (1.57)
mm (in.)
Fig. 3. Minimum installation distances - side view

114EIXKE4.00 ·Syncro series inverter 02/2022
|14|
40 (1.57)
mm (in.)
40 (1.57)
40 (1.57) 40 (1.57)
Fig. 4. Minimum installation distances - front view

114EIXKE4.00 ·Syncro series inverter 02/2022
|15|
5.4 INSTALLATION METHOD
Syncro inverter installation anticipates application to a panel by means of M5 screws (not supplied).
142,25 (5.60)
94,25 (3.71)
6 x M5
Fig. 5. Syncro inverter installation method
Panel thickness
Thispanelthicknessvariesdependingonthematerialusedtomakeit:
Material Thickness (X) [mm (in.)]
Metal 1...2(0.04...0.08)

114EIXKE4.00 ·Syncro series inverter 02/2022
|16|
5.5 DIMENSIONS AND WEIGHT
190 (7.48)
176 (6.93)
130 (5.12)
285 (11.22)
130 (5.12)
mm (in.)
15 (0.59) 19.1 (0.75)
6 (0.24)
78.6 (3.09)
78.6 (3.09)
130 (5.12)
Fig. 6. Syncro Inverter dimensions
Weight
Reference Weight in kg (lb)
Syncro ~6kg(13.22)

114EIXKE4.00 ·Syncro series inverter 02/2022
|17|
6. ELECTRICAL CONNECTIONS
WithintheEuropeanUnion,allmachinesincorporatinganinvertermustconformtothemachinesdirective2006/42/EC.The
machinemanufactureris,inparticular,responsibleforinstallingageneralswitchandensuringcompliancewithstandardEN
60204-1.
6.1 CONNECTION BEST PRACTICE
The following information describes the wiring guidelines and best practices which should be observed when using the inverter.
DANGER
RISK OF ELECTRIC SHOCK, EXPLOSION OR ELECTRIC ARC
• Onlysuitablytrainedpersonnel,familiarwithandcapableofunderstandingthecontentofthemanualandallrelevant
documentation,areauthorisedtoworkonandwiththisinverter.Furthermore,thepersonnelmusthavecompletedcourses
insafetyandmustbeabletorecogniseandpreventtheimplieddangers.Installation,adjustmentandmaintenancemust
only be carried out by qualified personnel.
• Variousproductcomponents,includingtheprintedcircuits,runathazardousvoltagelevels.
• Only use electrically insulated and suitably calibrated measuring devices and equipment.
• Do not handle the equipment while the power supply is connected.
• Do not touch the unshielded components or the terminals while they are live.
• Themotorsmaygeneratevoltageiftheshaftisrotated.Beforecarryingoutanyworkontheinverter,lockthemotorshaft
to prevent it from rotating.
• Beforeworkingontheinverter:
• Disconnect the power supply.
• UseasuitablycalibratedandelectricallyinsulatedVoltmetertomakesurethepowersupplyisdisconnected.
• Waitfor5minutedafterdisconnectingthepowersupplybeforeinstalling/uninstallingaccessories,hardware,cablesor
wires,toallowthecondenserstodischargeanyresidualvoltage.
• Donotopen,disassemble,repairormodifytheproduct.
• Beforehandlingtheproduct,makesureyouarewearingallthenecessarypersonalprotectiveequipment(PPE).
• Do not expose the equipment to liquids or chemicals.
• Before applying voltage to the inverter:
• Makesuretherunningperiodhasbeencompletedandnopartsofthesystemcanbecomehazardous.
• Ifthemainspowersupplyterminalsandthemotoroutputterminalshavebeenearthedandcircuited,removetheearth
and short circuits on these terminals.
• Makesurealltheequipmentisproperlyearthed.
• Makesureallprotectiveelements,suchascovers,hatchesandgrilles,arefittedand/orclosed.
• Checkallwiringconnections.
DANGER
RISK OF ELECTRIC SHOCK, EXPLOSION OR ELECTRIC ARC
Makesurealltheequipmentisproperlyearthed.
DANGER
RISK OF ELECTRIC SHOCK AND FIRE
• Do not use the device with loads greater than those indicated in the technical data section.
• Do not exceed the temperature and humidity ranges indicated in the technical data section.
• Onlyusecableswithasuitablecross-sectionasindicatedinthesection“Wiringbestpractices”.
ForinstallationinaccordancewithstandardEN61800-5-1,adevicecuttingoffthecircuitbetweenthepowersupplyandthe
inverter is required.
DANGER
RISK OF ELECTRIC SHOCK
Usetherequiredsafetyinterlocks(fusesand/ormagnetothermalswitches)ofasuitablesizebetweenthepowersupplyand
the inverter.
Whentheinverterisinstandbyandthemotorisnotrunning,thelatterremainslive.
DANGER
RISK OF ELECTRIC SHOCK
Do not handle the motor when the inverter is in standby.

114EIXKE4.00 ·Syncro series inverter 02/2022
|18|
6.1.1 Wiring best practices
Whenwiringthecontrollers,observethefollowinginstructions:
• TheI/Oandcommunicationwiringmustbekeptseparatefromthepowersupplywiring.Thesetwotypesofwiringmust
be routed in separate ducts.
• Makesuretheoperatingenvironmentandconditionsfallwithinthespeciedvalues.
• Usewireswiththecorrectdiameter,suitedtothevoltageandcurrentrequirements.
• Use copper conductors (compulsory).
• Use shielded twisted pair cables for analogue I/O connections.
• UseshieldedtwistedpaircablesfornetworkandRS-485serialconnections.
Usecorrectlyearthedshieldedcablesforallinputsoranalogueoutputs,forcommunicationconnectionsandformotorwiring.
WARNING
MALFUNCTIONING OF THE EQUIPMENT
• Performthewiringcarefully,incompliancewithelectromagneticcompatibilityrequirements.
• Carryoutafullstart-uptest.
• Makesurethewiringiscorrectforthesettings.
• Use shielded cables for all I/O signal and communication cables.
• Usedouble-shieldedcablesformotorwiring.
• Minimisethelengthoftheconnectionsasmuchaspossible,toavoidwindingthecablesaroundelectricallyconnectedparts.
• The signal (communication and corresponding power supplies) and power cables for the device must be routed separately.
• Beforeapplyingthepowersupply,checkallthewiringconnections.
• Donotconnectwirestounusedterminalsand/orterminalsmarkedwiththetext“Noconnection”(N.C.).
Suitable wiring for the power supply
Passo 10,16 mm (0.399 in.)
Ø 4 mm (0.157 in.)
mm2
AWG
0.5…16 0.5…16
20…6 20…6
0.5…16 0.5…16
20…6 20…6
2 x 0.5…4
2 x 20…12
2 x 0.5…6
2 x 20…10
2 x 0.5…6
2 x 20…10
2 x 0.5…6
2 x 20…10
mm
in.
10
0.39 M4
1.2...1.5
10.62...13.6
N•m
lb-in
Fig. 7. Suitable wiring for the power supply
Suitable wiring for I/O SELV
Step 5.08 mm (0.199 in.)
Ø 3.5 mm (0.14 in.)
mm2
AWG
0.2…2.5
24…14
0.2…2.5
24…14
0.25…2.5
22...14
2 x 0.25…1
2 x 22…18
2 x 0.2…1.5
2 x 24…16
2 x 0.2…1
2 x 24…18
2 x 0.5...1.5
2 x 20...16
mm
in.
7
0.28 C0.5...0.6
4.42...5.31
N•m
lb-in.
0.25…2.5
22...14
Fig. 8. Suitable wiring for I/O SELV
Suitable wiring for earthing
Step 5.08 mm (0.199 in.)
Ø 3.5 mm (0.14 in.)
mm2
AWG
2.5
14
2.5
14
2.5
14
2 x 1.5
2 x 16
mm
in.
7
0.28 C0.5...0.6
4.42...5.31
N•m
lb-in.
Fig. 9. Suitable wiring for earthing
6.1.2 Sizing safety interlocks
Current (A)
Syncro
Type
40
Rapid
Current (A)
Syncro
Type
40
Type B
Fig. 10. Sizing safety interlocks

114EIXKE4.00 ·Syncro series inverter 02/2022
|19|
6.2 WIRING DIAGRAM
Power supply
Motor output
I/O
1
Digital
output
USB
USB port
PE
L
N
PE
RS-485+ RS-485-
STO
12 V
GND
ID1 ID2 ID3
WV U
Out1
2
11 12
3 4 5 6 7 8 910
Fig. 11. Syncro inverter wiring diagram
TERMINALS
NNEUTRAL-Powersupplyinput 1-2
RS-485serialinputforremoteconnection
LPHASE-Powersupplyinput 3-6 Digital input ID1 connection
PE EARTH-Powersupplyinput 4-6 Digital input ID2 connection
UMotor control output 5-6 Digital input ID3 connection
VMotor control output 7-8 SafetydigitalinputSTO connection
WMotor control output 9-10 Auxiliary12Vpowersupplyoutput
PE Motor earth connection 11-12 out1 relay output connection (NO)

114EIXKE4.00 ·Syncro series inverter 02/2022
|20|
6.2.1 Safety digital input STO wiring diagram
7 8
10...24 Vac
STO
Fig. 12. Syncro inverter wiring diagram
