EVEBASE MOVE 2000 User manual
USER MANUAL
POWER STATION MOVE 2000
SAFETY INSTRUCTIONS
Please read this manual carefully. The user of this product takes full responsibility for the operation and usage of
this product. Please check the local regulations in the area of usage of the product. The user of this product is
solely responsible for the usage of this product according to all relevant regulations.
1. In order to ensure the safety of this product during transportation, this product is only charged about 30%
when it is packaged. Please recharge when you get the product. When not using this product, please turn off
the power and unplug the power cord.
2. Only official parts or accessories can be used with this product. If any accessories need to be replaced, please
contact Evebase for more information. Do not charge the product with a charging device that does not meet
the specified parameters and please do not use extension cords and cable taps.
3. Do not disassemble the product and don’t perforate it with sharp objects.
4. A high environmental temperature while using the power station may result in fire or an explosion. Therefore
please follow the maximum operating temperature as specified further in this manual. If the temperature is
too low, the performance of the product will go down or the product will stop working.
5. Only use and store the product in dry and ventilated areas and avoid dust. Please ensure that the air intake
and outlet are unblocked when using.
6. Strictly avoid contact of the product with any liquid. Do not immerse the product into water and make sure it
doesn't get wet. Avoid the usage in rainy or humid places.
7. In case the power station has fallen into water or is wet, place it in an open area and keep a safe distance until
it has dried entirely. As soon as the product is dry again, it can’t be used anymore and has to be disposed
according to the applicable local regulations. In case the power station catches fire, it has to be extinguished
in the next order: water →sand →fire blanket →dry powder →carbon dioxide fire extinguisher.
8. Only use the product on flat surfaces in order to protect the product from falling over. Immediately stop
operating/using the product after falling or other external impact on the power station and avoid strong
vibrations during use. Turn of the power supply immediately after any strong impact and place the battery in
a safe and open area. Finally, dispose the product according to the local regulations.
9. Only use a dry textile to clean the outside of the product.
10. Please keep the product out of reach from children and pets.
11. In case the product is used for the operation of standard medical equipment, please make sure the power
status is monitored carefully, in order to prevent that the power runs out. Please contact Evebase about any
restrictions for the use with medical equipment.
12. Please make sure there is a safe distance between medical implants and the power station, as this product
will generate an electromagnetic field. Please contact Evebase if you need more information about any
restrictions.
13. Avoid usage in a strong static electric/ magnetic field.
14. Avoid usage/ storage near any heat source (fire, car in direct sunlight etc.).
15. Don’t use any wires or metal objects that can result in a short circuit.
16. No items can be stacked on top of the product.
17. If the battery is swollen, leaking or smelly, stop using it immediately.
18. Please make sure the power station is completely discharged before disposal in an official battery recycling
bin. It is prohibited to dispose the product in a standard trash can. Please follow the local regulations.
19. Please contact a professional battery recycling company in case the power station can’t be discharged
completely due to a failure.
20. For long-term storage, please consume power from full power to no power once every 3 months, and then
recharge to about 50%.
21. Please avoid shipping a product with a battery power level higher than 30% and don’t take it on a plane.
AC OUTPUT PARAMETER
Type of AC port AC output
US/JP 100V~120V 50/60Hz
CH 220V 50Hz
UK 230V 50Hz
EU 220V~240V 50Hz
KR 220V 60Hz
PRODUCT INTRODUCTION
This product is a high power portable power station, suitable for family emergency power cuts, outdoor travel,
emergency relief, field work and other scenarios.
The product has a built-in LiFePO4 battery, which supports adapter, car charger, photo-voltaic panel and other
charging methods. The AC output voltage corresponds to different national specifications (see previous page) and
a number of USB ports supply for lighting, ventilator, electric fan, router, notebook and other equipment. Thanks
to the 2000W high power maximum output and pure sine wave AC output this power station can even be used
for most household appliances.
Through the 1100W ultra-fast charging, this model can be full charged within 2 hours. The AC input/output voltage
frequency can be switched automatic or manually between 50Hz/60Hz. This product also supports maximum
5OOW solar charge, allowing you to charge the device, even without access to a power grid.
1
Main power control
6
Air intake/outlet
2
Light control
7
AC on off control (50Hz/60Hz switching control)
3
USB control
8
Anderson input (solar panel)
4
DC control
9
AC input port
5
LCD display
10
Overload protection
1. Main power control
Operate method: Press the main power control button for 3 seconds to turn the system on/off
2. Led light control
Operate method: Shortly press the button to turn it on and to change the light mode (SOS/Flash).
You can turn off the light by pressing the button for 1-2 seconds in any mode.
3. USB button
Operate method: short press to turn on/off
4. DC button
Operate method: short press to turn on/off.
5. LCD display
The display shows the remaining power and different using data.
6. Cooling system
When the fans are working, please do not block the channel.
7. AC button (AC output, total combined 2000W)
Operate method: short press to turn on/off.
Note: 1. Please check the output voltage or frequency before using
2. Press the button for 2 seconds to enter the frequency changing mode. 50Hz and 60Hz will
flash on the display. Press the button again to choose the correct frequency. Wait until the
frequency stops flashing.
8. Solar panel input
Use the Anderson port to connect the solar panel.
1. Solar panels can have a maximum input of 500W and a maximum voltage of 50V
2. Exceeding the maximum voltage will lead to damage on the equipment. This is beyond the
scope of warranty.
9. AC input
Use a wall socket in order to get to 1100W fast charging. This fully charges the device from 0-100% in 2
hours.
-The product can be charged directly by the wall socked, but please avoid the use of extension cords and
cable taps. When the product is charging, please do not plug other devices in the same socket.
-Do not plug several devices together in an extension socket at once. The current will be to high and
bring damage to the cable, which may result in fire.
-Do not use the same socket to connect other devices when charging this product. When the same
wiring in a general household exceeds 1500W, the safety circuit breaker will be activated.
10. Overload protector
An overload protector is added in order to protect this product. This prevents damage to the product due to
excessive AC input current, cause by lightning and power grid fluctuations. When such a situation occurs,
the overload protector will start to cut off the AC input to protect the product.
Restore the AC input function of the product with the following steps:
1. Turn of the power and unplug all ports.
2. After confirming that all parts are normal, turn on the power button.
3. Press the overload protection button to switch on the AC line to restore AC input.
LCD DISPLAY
1
Charging/ using time
6
Total output power
11
AC charging
2
Fan state
7
LED light
12
Anderson charging
3
High/low temperature protection
8
AC output
13
DC output
4
Power percentage
9
Type-C output
14
Car port output
5
Total input power
10
USB output
15
XT-60 output
When this icon lights up, please keep the air intake/ outlet unobstructed.
When this icon lights up, please note that the operating temperature of the device is too high
or too low. The device will possibly stop working until the temperature is back to the normal
standard.
When this icon is flashing, it shows that the AC input is wrong. Please check the power cable.
When this icon is flashing, it means the output is wrong.
UPS MODE
This power station has a build in ‘’bypass mode’’ functionality, meaning that in case of a power grid shut down,
the power station automatically switches (within 10ms) from the power grid to the internal battery capacity to
supply power.
As demonstrated in the picture below, you can connect the power station between the wall socket and your
electrical appliances. When you turn on the electrical appliances, they will directly use the AC power from the
wall socket (power grid) and don’t use any of the battery capacity.
When the power grid is cut off, it will immediately switch to the internal battery capacity, in order for you to
keep on working. Evebase is not responsible for any abnormal operation or data loss caused by careless use.
-In case the power station jumps into UPS mode in Europe or the United Kingdom and the AC output
exceeds the maximum power of 2000W, the AC output icon will start to flash, indicating overload.
SOLAR PANEL CHARGING
The product can be charged through solar panels. Maximum solar panel input is 500W (maximum 50V voltage).
-The solar panel charging power may fluctuate according to the weather conditions.
-Solar panel voltage exceeding 50V will damage the equipment and isn’t covered by warranty.
CAR CHARGING
This power station can be charged by the cigarette lighter in the car, with an ACC cable. Turn on the power of this
power station, connect the ACC charging cable to the cigarette lighter in the car and to the Anderson interface on
the side of the power station. After starting the engine of the car, the LCD screen of the power station will show
the input power.
-On-board charging should be carried out with the car engine turned on. If the engine of the car is not
turned on, the battery of the car might run out.
-The charging time while charging by car is long, due to the low power output of 90-120W.
PRODUCT SPECIFICATIONS
Product
EveBase Power Station Move 2000W
Product dimensions
L*W*H = 392*279*323mm
Product net weight
22 kg
Rated capacity
1997Wh
AC Charging
50/60Hz 1100W max
MPPT input
11.5-50V 20A 500W max
AC Output
50/60Hz (frequency switch available), rated 2000W, peak 4000W,
pure sine wave. Built-in overload and short circuit protection.
USB QC 3.0
18W x2
USB
USB-A (5V 2.4A) x2
Type-C
5-20V/5.0A, PD3.0 100W x2
DC5521
12V/3A x2
XT-60 output
12V/25A
Car port output
12V/10A
Power off current
<500uA
Operating temperature
-10°C ~ 40°C
Charging temperature
0°C ~ 40°C
Working environment humidity
<90%RH
BATTERY SPECIFICATIONS
Type of battery
32130 LiFePO4
Single cell rated voltage
3.2V
Single cell rated capacity
13Ah
Battery pack rated voltage
51.2V
Battery pack output voltage range
43.2-57.6V
Battery pack rated capacity
1997Wh
Battery pack maintenance
If not used for 3 months, product should be recharged
PROBLEMS AND RESOLUTIONS
Status
Possible cause
Resolution
Above icons flash and buzzing
alarm.
Exceeding standard output,
short circuit.
1. Remove the load.
2. Check if the overload protector is up. If it
is up, press the overload protection button
and press the AC button.
3. If the overload protector doesn't jump
up, directly press AC output restore output
function.
Above icon flashes and buzzing
alarm.
The equipment temperature is
too high or too low.
1. Remove the equipment and turn off the
power of this product.
2. Restart the machine when it is cooled
down.
3. Place the equipment in a -10°C ~ 40°C
environment.
4. Please check if the fan is running
normally and is ventilated.
Charging unavailable
The adapter has a poor
connection.
Confirm the connection status of the cable
and the power supply status.
Overload protection function
activated.
1. Turn off the power button and remove
cables from all ports.
2. After checking if all components are
normal, turn on the power button.
3. Press the overload protection button to
connect the AC cable to recover AC input.
EveBase Tech B.V.
Oostwal 2
1747 EZ
Tuitjenhorn
The Netherlands
www.evebase.com
Designed in NL. Made in PRC.
