FA5502P/M

FUJI Power Supply Control IC

Power Factor Correction

FA5502P/M

Application Note

June `02

Fuji Electric Co., Ltd.

Matsumoto Factor

y

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

2

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

FA5502P/M

1.This Data Book contains the product specifications, characteristics, data, materials, and

structures as of June 2002. The contents are subject to change without notice for specification

changes or other reasons. When using a product listed in this Data Book, be sure to obtain the

latest specifications.

2. All applications described in this Data Book exemplify the use of Fuji's products for your

reference only. No right or license, either express or implied, under any patent, copyright, trade

secret or other intellectual property right owned by Fuji Electric Co., Ltd. is (or shall be deemed)

granted. Fuji makes no representation or warranty, whether express or implied, relating to the

infringement or alleged infringement of other's intellectual property rights which may arise from

the use of the applications described herein.

3. Although Fuji Electric is enhancing product quality and reliability, a small percentage of

semiconductor products may become faulty. When using Fuji Electric semiconductor products in

your equipment, you are requested to take adequate safety measures to prevent the equipment

from causing a physical injury, fire, or other problem if any of the products become faulty. It is

recommended to make your design fail-safe, flame retardant, and free of malfunction.

4.The products introduced in this Data Book are intended for use in the following electronic and

electrical equipment which has normal reliability requirements.

• Computers • OA equipment • Communications equipment (terminal devices)

• Measurement equipment • Machine tools • Audiovisual equipment

• Electrical home appliances • Personal equipment • Industrial robots, etc.

5.If you need to use a product in this Data Book for equipment requiring higher reliability than

normal, such as for the equipment listed below, it is imperative to contact Fuji Electric to obtain

prior approval. When using these products for such equipment, take adequate measures such

as a backup system to prevent the equipment from malfunctioning even if a Fuji's product

incorporated in the equipment becomes faulty.

• Transportation equipment (mounted on cars and ships) • Trunk communications equipment

• Traffic-signal control equipment • Gas leakage detectors with an auto-shut-off feature

• Emergency equipment for responding to disasters and anti-burglary devices • Safety devices

6. Do not use products in this Data Book for the equipment requiring strict reliability such as

(without limitation)

• Space equipment • Aeronautic equipment • Atomic control equipment

• Submarine repeater equipment • Medical equipment

reproduced in any form or by any means without the express permission of Fuji Electric.

8. If you have any question about any portion in this Data Book, ask Fuji Electric or its sales

agents before using the product. Neither Fuji nor its agents shall be liable for any injury caused

by any use of the products not in accordance with instructions set forth herein.

WARNING

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

3

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

FA5502P/M

CONTENTS

page

1. Description • • • • • • • • • • • • • • • 4

2. Features • • • • • • • • • • • • • • • 4

3. Outline • • • • • • • • • • • • • • • 4

4. Block diagram • • • • • • • • • • • • • • • 5

5. Pin assignment • • • • • • • • • • • • • • • 5

6. Ratings and characteristics • • • • • • • • • • • • • • • 6

7. Characteristic curves • • • • • • • • • • • • • • • 9

8. Description of each circuit • • • • • • • • • • • • • • • 13

9. Design advice • • • • • • • • • • • • • • • 18

10. Example of application circuit • • • • • • • • • • • • • • • 23

Note

• Parts tolerance and characteristics are not defined in all application described in this Data book. When design an

actual circuit for a product, you must determine parts tolerances and characteristics for safe and economical

operation.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

4

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

Q

ualit

y

is our messa

g

e

FA5502P/M

1. Description

FA5502P/M is a control IC for a power factor correction system. This IC uses a CMOS device with high dielectric

strength (30V) to implement low power consumption. This IC uses the average current control system to ensure stable

operation. With this system, a power factor of 99% or better can be achieved.

2. Features

• Low current consumption by CMOS process

• Stand-by : 3µA(max), Start-up : 30µA(max), Operating : 4mA(typ)

• Good regulation of PFC output voltage from no-load to full-load

• Drive circuit for connecting a power MOSFET(IOUT = ±1.5A)

• Pulse-by-pulse overcurrent and overvoltage limiting function

• ±2% accuracy reference voltage for setting DC output and overvoltage protection

• Output ON/OFF control function by external signal

• External synchronizing input pin for synchronous operation with other circuits

• Undervoltage lockout function (ON:16.5V, OFF:8.9V)

• 16-pin package (DIP/SOP)

3. Outline

DIP-16 (FA5502P) SOP-16 (FA5502M)

6.5 ± 0.2

0.3 ± 0.1

7.6 ± 0.2

4.0 ± 0.3

16

1

7.3 ± 0.5

1.5 ± 0.3

2.54 TYP 0.5 ± 0.1

3.4 ± 0.1

19.4 ± 0.3

9

8

17.78 ± 0.3

0º - 15º

0.75 ± 0. 1

1.80 ± 0.05

5.3 ± 0.1

1.27

10º-0º

0.08

0.40 ± 0.05

0.10 ± 0.10 7.8 ± 0.2

10.2 ± 0.1

18

916

0.15 ± 0.05
