Everfit BFK 300 User manual

Ed : 02/17 Rev : 00
INSTRUCTION

2


3
ASSEMBLY INSTRUCTIONS
Step 1
Assembly the rear and front stabilizer
(27&24) with 4 bolts (21), 4 nuts (26) and 4
washers (7).
Step 2
Connect the computer cable up (6) and down
(17), connect the tension control cable up (15)
and down (16) as shown in the right sketch.
Assemble the handlebar post (10) to the main
frame, fix it with four screws (19) and washers
(7).
a
b
c
d
e
Step 3
Assemble the seat (11) to the seat post (14)
with 3 nuts (13) and washers (12).
Insert the seat post into the main frame
through the plastic sleeve. Select the ideal
hole position on the seat post (14). Insert the
knob (18) into the hole. Tighten fully the
knob.

4
ASSEMBLY INSTRUCTIONS
Step 4
Assemble the handlebar (9) to the bracket on
the handlebar post, fix it with two screws (8)
and two washers (7).
Assemble the left hand pedal (22) to the left
hand crank (screw anticlockwise) and the
right hand pedal (23) to right hand crank.
Step 5
Pass the hand pulse cable (5) through the
hole on handlebar post, assemble the plastic
tray (4) on top of the handlebar post, connect
the cables from computer and handlebar post,
slide the computer onto the tray.

5
PARTS LIST
NO. DESCRIPTION Q'TY
1 Computer 1PCS
2 Sensor cable connector 1PCS
3 Hand pulse cable (upper) 1PCS
4 Plastic tray 1PCS
5 Hand pulse cable (lower) 1PCS
6 Sensor cable (upper) 1PCS
7 Semicircle washer 10PCS
8 Umbrella head hex screws 2PCS
9 Handlebar 1PCS
10 Handlebar post 1PCS
11 Saddle 1PCS
12 Flat washer 6PCS
13 Nylon nut 6PCS
14 Seat post 1PCS
15 Tension control cable (upper) 1PCS
16 Tension control cable (lower) 1PCS
17 Sensor cable (lower) 1PCS
18 Seat post knob 1PCS
19 Umbrella head hex screws 4PCS
20 Main frame 1PCS
21 Carriage screw 4PCS
22 Pedal (L) 1PCS
23 Pedal (R) 1PCS
24 Front stabilizer 1PCS
25 Front end cap 2PCS
26 Nut 4PCS
27 Rear stabilizer 1PCS
28 Rear end cap 2PCS
29 Foam grip 2PCS
30 Handlebar pulse 2PCS
31 Umbrella head cross screws 2PCS
32 Handlebar end cap 2PCS
33 Star washer 2PCS
34 Hex. nut 5PCS
35 6000 bearing 1PCS
36 Flywheel 1PCS
37 6900 bearing 1PCS
38 Bushing 1PCS
39 Flywheel spindle 1PCS
40 Sleeve 1PCS
41 Bushing 1PCS

6
NO. DESCRIPTION Q'TY
42 Idle wheel 1PCS
43 Spring 1PCS
44 Idler clamping 1PCS
45 Hex screw 1PCS
46 Crank cover 2PCS
47 Chain cover (R) 1PCS
48 Belt 1PCS
49 Pulley 1PCS
50 Right tooth plug 1PCS
51 Bead nest 2PCS
52 Bottom bracket 2PCS
53 Crank 1PCS
54 Left tooth plug 1PCS
55 Have tooth washer 1PCS
56 Hex. nut 1PCS
57 Chain cover (L) 1PCS
58 Umbrella head hex screw 1PCS
59 Magnetic set 1SETS
60 Hex. nut 2PCS
61 Outer hexagon bolt 1PCS
62 Tension control cable (lower) 1PCS
63 Umbrella head cross screw 5PCS
64 Hex. wrench 1PCS
65 Harpoon wrench 1PCS

7
COMPLETE BIKE ASSEMBLY

8
EXERCISE METER
Monitor Display
KEY FUNCTION:
MODE: This key lets you to select and lock on to a particular function you want.
FUNCTIONS
SCAN Automatically scan through each mode in sequence every 6 seconds. The display loop is
SCAN-TIME-DISTANCE-CALORIE-SCAN on the main screen.
TIME Accumulates total working time from 00:00 up to 99:59.
SPEED Displays current training SPEED, the maximum is 99.9km/ml,it always displays.
DISTANCE Accumulates training distance from 0.00 to the maximum 99.99km/ml with each increment
0.01km/ml.
PULSE Press the MODE key until the pointer advance to PULSE. User’s current heart rate will be
displayed in beats per minutes. Place the palms of your hands on both of the contact pads (or
put ear-clip to ear),and wait for 30 seconds for the most accurate reading.
CALORIE Accumulates calories consumption during training from 0 to the maximum 9999 cal with each
increment 1 cal.
NOTE
1. Without any signal been transmitted into the monitor for 4 minutes, the LCD display will shut off automatically,
and all function values will be kept. You may press mode or start pedaling to have the monitor power on again.
2. If improper display on monitor, please re-install batteries to have a good result.
3. Battery spec: 1.5v um-3 or AAA (2 pcs).

GARLANDO SPA
Via Regione Piemonte, 32 - Zona Industriale D1
15068 - Pozzolo Formigaro (AL) - Italy
www.evert.it - info@evert.it
