Argos davina mccall 2 in 1 Cross Trainer Exercise... Owner's manual

Assembly & User Instructions - Please keep for future reference
Important – Please read these instructions fully before assembly or using
2 in 1 Cross Trainer Exercise Bike
These instructions contain important information which will help you get the best from your
equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts, call the Customer contact number:
0345 600 1714 www.argos-support.co.uk
487/9141

Contents
SafetyInformation 2
Components-Parts 3
Components-Fixings 4
Assembly Instructions 5-11
Free Area and Training Area 12
Computer Operation 13
Exercising Information 14-17
Before starting 14
Muscle chart 15
Warming up and cooling down 16-17
Care and Maintenance 18
Exploded Parts Diagram 19-20
Parts List 21-22
1

To reduce the risk of serious injury, read the entire manual before you assemble or operate the Davina 2 in 1
Cross Trainer Exercise Bike, In particular, note the following safety precautions.
Assembly
•Check you have all the components and tools listed
on pages 3 and 4, bearing in mind that, for ease of
assembly, some components are pre-assembled.
•Keep children and animals away from the work area,
small parts could choke if swallowed.
• Make sure you have enough space to layout the
parts before starting.
• Assemble the item as close to its final position (in the
same room) as possible.
•Position the equipment on a clear , level surface.
• Dispose ofall packaging carefully and responsibly.
gnisU
• It is the responsibility of the owner to ensure that
all users of this product are properly informed as to
how to use this product safely.
•Thisproduct is intended for domestic use only.
Do not use in any commercial, rental, or institutional
setting.
• Before using the equipment to exercise, always do
stretching exercises to properly warm up.
• If the user experiences dizziness, nausea, chest
pain, or other abnormal symptoms stop the workout
and seek immediate medical attention.
• Only oneperson at a time should use the
equipment.
• Keep hands away from all moving parts.
• Always wear appropriate workout clothing when
exercising. Do not wear loose or baggy clothing,
since it may get caught in the equipment. Wear
athletic shoes to protectyour feet while exercising.
•Do not place any sharp objects around the
equipment.
•Disabled personsshould not use the equipment
without a qualifiedperson or doctor in attendance.
•Thisproduct is suitable for user’s weight of:
100kgs.
•Injuries to health may result from incorrect or
excessive training. The equipment shall be installed
on a stable base and properly leveled.
•The braking system is adjustable.
• This product conforms to: BS EN ISO 20957-1 and
EN 957-9. Class (H) - Home Use - Class (C)
·Warning: Incorrect installation of batteries may
cause battery leakage and corrosion, resulting in
damage tothe computer.
·Do not mix old and new batteries, or
batteries of different types.
·Do not dispose of batteries in a fire.
·Do not dispose of batteries with normal household
waste, take to a local recycling centre.
Important – Please read fully before assembly or using
Safety Information
2
Battery safety
Warning: Before beginning any exercise program, consult your Doctor.This is especially important
for persons over the age of 35 or persons with pre-exisng health problems. You MUST read all
instrucons before using any fitness equipment. Argos and its associates assumes no responsibility for
personal injury or property damage sustained by or through the use of this product. The pedal crank
training equipment is not suitable for therapeuc purposes. Heart rate monitoring systems may be
inaccurate. Over exercise may result in serious injury or death. If you feel faint stop exercising
immediately.

Note: Some of the smaller components may be pre-fitted to larger components. Please check carefully
before contacting Argos regarding any missing components.
Total mass of the product is 29.0 kg. Foot print of the product is 92 x 51 cm.
The free standing equipment shall be installed on a stable and leveled base.
Com
p
onents - Parts If you have damaged or missing parts, please call
the Customer contact number: 0345 600 1714
Please check you have all parts listing below
48. Saddle Post 14 . Handlebar Post
3
67. Main Frame
49、50. Pedal (R/L)
74 . Saddle
73 . Knob
4. Clamp Cover
2. Handlebar 42. Computer
40/63. Front bottom tube
Rear bottom tube 31. Swing Rod (R/L)
17.Handlebar (R/L)

Note: Some of the fixings are pre-fitted to the larger components. Please check carefully before contacting
Argos regarding any missing fixings.
Components - Fixings
Please check you have all parts listing below
4
Ruler - Use this ruler to help correctly identify the hardware
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
26
8mm Curved Washer x 2
39
M8 x 60 Carriage Bolt x 4
23
8mm Washer x 2
54/55
Allen Bolt x 2 (R/L)
27
M8 Cap Nut x 6
8
8mm Spring Washer x 4
5
8mm Allen Bolt x 2
20
M10 x 45 Bolt x 4
25
8mm x 40 Bolt x 2
21
M8 x 16 Bolt x 2
38
M10 Nylon Nut x 4
Knob x 1
53
10mm Washer x 4
56
1/2" Washer x 2
60/61
1/2" Nylon Nut x 2 (R/L)
59
1/2" Spring Washer x 2
66
M8 x 16 Allen Bolt x 4
73
41
8mm Curved Washer x 8
Wrench S13-14-15
69
Allen Wrench-S6
70
68
Allen Wrench-S8
71
Wrench S17-S19 -S17

Fix the Front Bottom Tube (40) and the Rear Bottom Tube (63) to the Main
Frame (67) with 4 x M8*60 Carriage Bolt (39), 4 x M8 Curved Washer (41)
and 4 x M8 Cap Nut (27).
5
Assembly Instructions
Step 1
39
41
27
39
63
67
40
41
27
41
27

Assembly Instructions
Step 2
1. Connect the Tension Control (13) and Tension Cable (64) together. Connect
the Trunk Wire (15) and Sensor Cable (65) together.
2. Fix the Handle Bar Post (14) tothe Main Frame (67) with 4 x M8*16 Bolt (66)
and 4 x M8 Curved Washer (41).
6
15 13
41
64 65
67
64
13
14
66
65
15

Assembly Instructions
1. Assemble the Swing Rod (31R/L) to the Handle Bar Post (14) with 2 x M8*16
Bolt (21), 2 x M8 Spring Washer (8) and 2 x M8 Washer (23).
2. Connect 2 x Swing Rod (58) to the crank of the Main Frame (67) with
2 x Bolts (54/55) and 2 x 1/2" Washer (56). Then tighten them with 2 x 1/2" Spring
Washer (59) and 2 x 1/2" Nut (60/61).
Note: Please pay attention to the Right and Left of these parts. Do not mix them up.
7
Step 3
23 821
5960
54 56
14
67
8
21
23
59
61
55
56
31L
31R
58
58

Step 4
Assemble the Right (50) and Left Pedal (49) to the Swing Rod (46) with 4 x
M10*45mm Bolt (20), 4 x M10 Washer (53) and 4 x M10 Nylon Nut (38).
Note: Both pedals can be used on either side.
Assembly Instructions
8
20 53
38
53
38
50
46
46
49
20

9
Step 5
1. Unscrew the Knob (73) in anticlockwise direction .
2. Fix the Saddle (74) to the Saddle Post (48) with 4 x M8 Washer (35) and 4 x M8
Washer and 4 x M8 Nut (36).
3. Insert the Saddle Post (48) into the Main Frame (67). Then adjust to the
appropriate height and fasten it with the Knob (73) screwed in a clockwise direction.
Assembly Instructions
35
36
74
48
73
67

Assembly Instructions
Step 6
Fix the Handle Bar (17R/L) tothe Swing Rod (31R/L) with 2 x M8*40 Bolt (25),
2 x M8 Curved Washer (26) and 2 x M8 Cap Nut (27).
Note: Please pay attention tothe Right and Left of these parts. Do not mix them up.
10
25
26
27
25
26 27
17L 17R
31L 31R

Assembly Instructions
Step 7
Lock the Middle Handlebar (2) to the Handle Bar Post (14) with 2 x M8*30 Bolt (5)
and 2 x M8 Spring Washer (8), then cover it with the Clamp Cover (4).
Step 8
1. Connect the Trunk Wire (15) with the cable of the Computer (42).
2. Install the Computer (42) onto the Handle Bar Post (14). Connect the cable of
the Handle Pulse (10) to the back of the Computer (42).
Assembly completed.
11
2
5
10
8
4
14
22
14
15
10
42
42
15

Free area and training area.
The free area shall be not less than 0.6m greater than the training area in the directions from which
the equipment is accessed. The free area must also include the area for emergency dismount.
Where equipment is positioned adjacent to each other the value of the free area may be shared.
0.6m
(Free area)
0.6m
(Free area)
0.6m
(Free area)
0.6m
(Free area)
Training
12
Workout Area
area
3.7m

FUNCTIONAL BUTTON:
MODE/RESET – Push down to select functions.
– Push down to reset Speed, Distance, Time, Odometer, Calories and Pulse for 4 seconds each.
FUNCTIONS AND OPERATION
1. SCAN: Press MODE button until “▼” appears at SCAN position, the monitor will rotate through
the following functions: Speed, Distance, Time, Odometer, Calories and Pulse. Each display will be held
for 4 seconds.
2. TIME : Count the total time from exercise start to end.
3. SPEED: Display current speed.
4. DISTANCE: Count the distance from exercise start to end.
5. CALORIE: Count the total calories from exercise start to end.
6. ODOMETER: The monitor will display the total accumulated distance.
7. PULSE RATE: Press MODE button until “▼” appears at PULSE position.
Before measuring your pulse rate, please place your palms of your hands on both of your pulse
sensors pads and the monitor will show your current heart beat rate in beats per minute (BPM) on
the LCD after 6~7 seconds.
Remark: During the process of pulse measurement, because of the contact jamming, the measurement
value may be higher than the virtual pulse rate during the first 2~3 seconds, then will return to normal level.
The measurement value can not be regarded as the basis of medical treatment.
NOTE：
1. If the display is faint or shows no figures, please replace the batteries.
2. The monitor will automatically shut off if there is no signal received after 4 minutes .
3. The monitor will be auto-powered on when starting to exercise push button with signal in.
4. The monitor will automatically start calculating when you start to exercise and will stop calculating when
you stop exercising for 4 seconds .
SPECIFICATIONS:
FUNCTION
AUTO SCAN Every 4 seconds
TIME 00:00’~99:59’ (Minute:Second)
CURRENT SPEED The maximum signal can be pickup is 99.9KM/H
TRIP DISTANCE 0.00~999.9KM
CALORIES 0.1~999.9kCAL
ODO 0.1~9999KM
PULSE RATE 40~206BPM
BATTERY TYPE 2pcs of SIZE –AAA (not included)
OPERATING TEMPERATURE 0°C ~+40°C
STORAGE TEMPERATURE -10°C ~+60°C
Computer Operation
13
Functions and Operations
Mode
Display
Functions:
Scan / Speed / Distance / Time
Odometer / Calories / Pulse

How you begin your exercise program depends on your physical condition. If you have been inactive for
severalyears, or are severely overweight, you must start slowly and increase your time on the equipment;
a few minutes per workout.
Initially, you may be able to exerciseonly for a few minutes in your targetzone,however, your aerobicfitness
will improve over the next six to eightweeks.Don’t be discouraged if it takes longer. It’s important to work
at yourown pace. Ultimately, you’ll be able to exercisecontinuously for 30 minutes. The better your aerobic
fitness, the harderyouwill have to work to stay in your target zone.
Please remember these essentials:
• Have your doctor review your training anddiet programs to adviseyou of a workout routineyoushouldadopt.
• Beginyourtraining programslowlywithrealisticgoalsthathave been set by youandyourdoctor.
•Monitor yourpulse frequently. Establishyour target heart rate based on your ageandcondition.
•Set up your equipment on a flateven surface at least 3 feet fromwalls and furniture.
Exercise intensity
To maximize the benefits of exercising, it is important to exercise with the properintensity. The properintensity
level can be found by using your heart rate as a guide. For effective aerobic exercise, your heart rate should
be maintained at a level between 65% and 85% of your maximum heart rate as you exercise. This is known as
your targetzone. You canfindyour targetzone in the table below.
80
100
120
140
160
180
200
Beats per minute (bpm)
25
Age
30 35 40 45 50 55 60 70
Cardiovascular
performance
Intermediate aerobic
Effective fat burning
Up to 55%
55% to 65%
65% to 85%
85% to Max
During the first few months of your exercise program, keepyourheart ratenear the lowend of your targetzone
as you exercise. After a few months,your heart rate can be increased gradually until it is near the middle of
your targetzone as youexercise.
To measure your heart rate, stop exercising but continue moving your legs or
walking around andplace two fingers on your wrist. Take a six-second heartbeat
countandmultiply the results by 10 to findyour heartrate. For example, if your
six-second heartbeat count is 14, your head rate is 140 beats per minute.
(A six-seconds count is used because your heart rate will drop rapidly when you
stop exercising.) Adjust the intensity of your exercise until your heart rate is at the
proper level.
Exercisin
g
Information
Before starting
14

Aerobic Exercise
Aerobic exerciseimproves the fitness of your lungsand heart - your body’s most important muscle. Aerobic
exercise fitness is promoted by any activity thatusesyour large muscles(arms, legs, or buttock, for example).
Your heart beats quickly and you breathe deeply. An aerobic exercise should be part of your entire exercise
routine.
Weight Training
Along with aerobic exercising which helps get rid of and keep off the excess fat that our bodies can store,
weight training is an essential part of the exercise routine process. Weight training helps tone, build and
strengthen muscle. If you areworking aboveyour target zone,youmaywant to do a lesseramount of reps.
As always, consult yourdoctor before beginningany exercise program.
Targeted Muscle Groups
The exercise routine that is performed on the Treadmill will develop the upper and lower body muscle
groups. These muscle groups are highlighted onthe muscle chart below.
A: Trapezius
B: Anterior
C: Pectoralis Major
D: Serratus Anterior
E: Biceps
F: Abdominal
G: Sartorius
H: Quadriceps
I: Tibialis
J: Trapezius
K: Posterior
L: Triceps
M: Latissimus Dorsi
N: Gluteals
O: Hamstrings
P: Gastrocnemius
A
B
C
E
F
G
H
I
J
K
L
M
N
O
P
D
kcaBtnorF
Exercising Information
Muscle Chart
15

Eachworkout should include the following three parts:
1. A warm-up, consistingof 5to 10 minutes of stretchingand light exercise. Such asjogging on the
spot,star jumpsandlunges.A proper warm up increases your bodytemperature,heart rate and
circulation in preparation for exercise.
2. Training zoneexercise consisting of 20 to 30 minutes of exercisingwith your heart rate in yourtraining
zone. (Note:During the first few weeks of yourexerciseprogrammer, do not keep your heart rate in your
training zone for longer than 20 minutes.)
3. Acool-down, with 5 to 10 minutes of stretching. Thiswillincrease the flexibility of your musclesandwillhelp
to prevent post-exercise problems.
Exercise Frequency
To maintainor improve your condition, plan three workouts each week with at least one day of rest
betweenworkouts. After a few months of regularexercise, you may complete up to five workouts each
week, if desired. Remember, the key to success is to make exercise a regular and enjoyable partof your
everyday life.
Suggested Stretches
See thefollowingbasic stretching exercises.Move slowly as you stretch,never bounce.
Hamstring stretch
Sit with one leg extended. Bring the sole of the
opposite foot toward you and rest it against the
inner thigh of your extended leg. Reach toward
yourtoes as far as possible.
Hold for 15 counts, then relax.
Repeat 3 times for each leg.
Stretches:Hamstrings, lower back and groin.
Toe touchstretch
Stand with your knees bent slightly and slowly
bend forward from your hips. Allow your back
and shoulders to relax as you reach down
toward yourtoes as far as possible.
Hold for 15 counts, then relax .
Repeat 3 times.
Stretches:Hamstrings, back of knees and back.
Exercising Information
16
Warming up and Cooling down

Calf/achilles stretch
With one leg in front of the other , reach forward
and place your hands against a wall. Keep your
back leg straight and your back foot flat on the
floor. Bend your front leg, lean forward and move
your hips toward the wall.
Hold for 15 counts, then relax.
Repeat 3 times for each leg. To cause further
stretching of the achilles tendons, bend your
back leg as well.
Stretches:Calves, achilles tendons and ankles .
Quadriceps stretch
With one hand against the wall for balance,
reach back and grasp one foot with your other
hand. Keeping your bent knee pointing directly
downward towards the floor, gentle pull your
heel towards your buttock until you feel a gentle
stretch in the target area.
Hold for 15 counts, then relax.
Repeat 3 times for each leg.
Stretches: Quadriceps and hip muscles .
Innerthigh stretch
Sit with the soles of your feet together and your
knees outward. Pull your feet toward your groin
area as far as possible.
Hold for 15 counts, then relax.
Repeat 3 times.
Stretches: Quadriceps and hip muscles .
Exercising Information
17

1. Examine the equipment
periodically in order to detect
any damage or wear which may
have been produced.
2.The safety level of the
equipment can be maintained
only if it is examined regularly
for damage and wear, e.g.
connection points.
3. Lubricate moving parts with
light oil periodically to prevent
premature wear.
4. Inspect and tighten all parts
before using the equipment,
replace any defective parts
immediately, and do notuse
the equipment again until it is in
perfect working order.
5. Replace defective
components immediately and/or
keep the equipment out of use
until repair.
6. Special attention to
components most susceptible to
wear.
7. The equipment can be
cleaned using a damp cloth and
mild non-abrasive detergent.
Do notuse solvents.
8. Do not attempt to repair this
equipment yourself. Should
you have any difficulty with
assembly, operation or use
of your exercise product or if
you think that you may have
parts missing, contact the
manufacturer, their approved
service agent or the Customer
contact number: 0345 600 1714
www.argos-support.co.uk
Guarantee:
For guarantee purposes, please
retain your purchase receipt.
Information for Users on Disposal of old Equipmentand Batteries (European Union only)
These symbols indicate that equipment with these
symbols should not be disposed of as general household
waste. If you want to dispose of the product or battery ,
please consider the collection systems or facilities for
appropriate recycling.
Products Battery
Notice: The sign Pb below
the symbol for batteries
indicates that this battery
contains lead.
Care and Maintenance
18

Exploded Parts Diagram
19
1
2
56
9
41
66
10
12
8
21
25
34 35 36
34
33
53
38 52
53 38
45
52
51
17L
11
28
39
37
43
44
45
47
38
1
3
78
16 4
14
15
31L
16
17R
23
24
26
27
24
30
30
13
24
25
26 27
24
23 821
33
34
34
35
36
40
39
37
27
20
43
44
45
47
38
46
67
51
52
59
60
52
53
38
45
57
58
54
62
39 39
63
27
41
55
57
58
57
59
61
64 65
56
29
29
28
50
46
S13
S15
S14
#68 S8 1PC #69 S6 1PC #70 S13-14-15 1PC #71 S17-19(内17）1PC
S19 S17
S17
18
18
19
19
31R
32
32
53
38
56
22
62
57
49
20
73
72
42
35
36
41
74
48
