Evolution SDS4 User manual

www.evolutionfury.com
SDS4 HAMMER DRILL
Instruction
Manual
Read instructions before operating this tool.
G10100

www.evolutionfury.com
2
FIG 1 FIG 2
FIG 3 FIG 4
www.evolutionfury.com 3
SDS4 HAMMER DRILL
EC - DECLARATION OF CONFORMITY
We, the importer
Evolution Power Tools Ltd.
Venture One
Longacre Close
Sheffield
S20 3FR
Declare that the product
Part numbers: ZIC-SD6A-20
Evolution: SDS4
SDS 4 Function Hammer Drill
Complies with the essential requirements of the following
European Directives:
2006/42/EC – Machine Directive
2006/95/EC – Low Voltage Directive
2004/108/EC – EMC Directive
2002/95/EC – Restriction of the use of Certain Hazardous
Substances in Electrical and Electric Equipment
Standards and Technical specifications referred to:-
EN 55014-1:2006
EN 55014-2/A1:2001
EN 61000-3-2:2006
EN 61000-3-3/A2:2005
EN 60745-1:2009
EN 60745-2-6/A12:2009
All documentation is held on file at the above address and is
available, on request for review.
Authorized Signatory
Date: 29/1/2010
Name: Mr Matthew J Gavins
Position: Managing Director
Year of Manufacture: 2010
IMPORTANT
Please read these operating and safety instructions carefully
and completely. For your own safety, before using this
equipment check that the voltage is correct and that all
handles and parts are firmly secured. If you are uncertain
about any aspect of using this equipment, please contact our
Technical Helpline.
Technical Helpline UK 0870 609 2297
Technical Helpline USA 1-866-EVO-TOOL
SDS HAMMER DRILL
Congratulations on your purchase of an Evolution Power
Tools SDS4 4 Function Hammer Drill. Please complete
your product registration on line to validate your machine’s
warranty period and ensure prompt service if needed. We
sincerely thank you for selecting a product from Evolution
Power Tools.
12 MONTH LIMITED WARRANTY. Evolution power tools
reserves the right to make improvements and modifications
to design without prior notice.
Evolution Power Tools will, within twelve (12) months from
the original date of purchase, repair or replace any goods
found to be defective in materials or workmanship. This
warranty is void if the tool being returned has been used
to drill / chisel materials beyond the recommendations
in the Instruction Manual or if the drill has been damaged
by accident, neglect, or improper service. This warranty
does not apply to machines and / or components which
have been altered, changed, or modified in any way, or
subjected to use beyond recommended capacities and
specifications. Electrical components are subject to
respective manufacturers’ warranties. All goods returned
defective shall be returned prepaid freight to Evolution
Power Tools. Evolution Power Tools reserves the right to
optionally repair or replace it with the same or equivalent
item. There is no warranty – written or verbal – for chisel
/ drill bits. In no event shall Evolution Power Tools be liable
for loss or damage resulting directly or indirectly from the
use of our merchandise or from any other cause. Evolution
Power Tools is not liable for any costs incurred on such
goods or consequential damages. No officer, employee or
agent of Evolution Power Tools is authorized to make oral
representations of fitness or to waive any of the foregoing
terms of sale and none shall be binding on Evolution Power
Tools. Questions relating to this limited warranty should be
directed to the company’s head office, or call the appropriate
Helpline number.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of electric shock, this equipment is fitted
with an approved cord and plug for its intended country of
use. Do not change the cord or plug in any way.
GENERAL SAFETY RULES
Read and understand all instructions before
operating this product. Failure to follow all
instructions listed below, may result in electric
shock, fire and / or serious personal injury.
SAVE THESE INSTRUCTION FOR FUTURE REFERENCE.
WARNING! When using electric tools basic safety
EC - DECLARATION OF CONFORMITY GB
IMPORTANT GB
WARRANTY GB
GENERAL SAFETY RULES GB
IMPORTANT SAFETY INSTRUCTIONS GB

precautions should always be followed to reduce the risk
of fire, electric shock and personal injury including the
following.
Read all these instructions before attempting to operate this
product and save these instructions.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
CAUTION This is a very powerful machine.
When using this drill it is essential that the following rules
are followed.
1. When drilling it is common that the drill bit jams in the
material being drilled. This will result in the drill trying to
rotate around the drill bit and potentially to come out of
your grip. This SDS drill has a safety clutch mechanism. This
safety clutch mechanism will be activated and stop the drive
to the drill, BUT only if you resist the initial forces caused by
the jamming, by securely holding the drill with BOTH hands.
As this is a powerful machine, these forces are significant.
2. ALWAYS ensure that the front handle is firmly fixed in
place and secure.
3. The front and rear handles must be firmly held to resist
any movement of the drill when the drill or drill bit becomes
jammed.
4. ALWAYS use the drill when standing on a firm and secure
platform or on the ground. (DO NOT USE ON LADDERS OR
STEPS)
5. NEVER start the drill with the drill bit jammed in position.
6. DO NOT stretch to hold the drill. Do not drill above
shoulder height or below knee height, as the drill cannot be
securely held.
7. This machine is not suitable for use with TCT core drill bits,
diamond core drill bits, and diamond drill bits.
1) Work Area Safety
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) Electrical Safety
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric shock if your body is earthed
or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of
an RCD reduces the risk of electric shock.
3) Personal Safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power tool
while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source and / or
battery pack, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving parts.
Loose clothes, jewelry or long hair can be caught in moving
parts.
g) If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
4) Power Tool Use & Care
a) Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and / or
the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting
www.evolutionfury.com
4
the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of
the power tool for operations different from those intended
could result in a hazardous situation.
5) Service
a) Have your tool repaired by a qualified person. This electric
tool complies with the relevant safety rules. Repairs should
only be carried out by qualified persons using original spare
parts, otherwise this may result in considerable danger to
the user.
b) When servicing a tool, use only genuine Evolution
replacement parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or failure to
follow Maintenance Instructions may create a risk of electric
shock or injury.
SPECIFIC SAFETY RULES & SYMBOLS
WARNING!
Do not operate machine if warning and / or instruction labels
are missing or damaged. Contact Evolution Power Tools for
replacement labels.
Symbole Description
V Volts
A Amperes
Hz Hertz
Min -1
Revolutions, strokes,
surface speed, orbits etc.
per minute
~ Alternating Current
noNo Load Speed
Double Insulated
Wear Safety Goggles
Wear Ear Protection
To obtain an additional copy of your manual, please contact
Evolution Power Tools at :
UK 0870 609 2297
USA 1-866-EVO-TOOL
WEB www.evolutionpowertools.com
ADDITIONAL SPECIFIC SAFETY RULES
Do not let familiarity with this product (gained from repeated
use) replace strict adherence to hammer drill safety rules.
If you use this tool incorrectly you could suffer serious
personal injury.
1.Hold tools by the insulated gripping surfaces when
performing an operation where the cutting tool may contact
hidden wiring or its own cord. Contact with a ‘live’ wire will
make exposed metal parts of the tool ‘live’ and shock the
operator.
2.Always be sure you have a firm footing. Be sure no one is
below you when using the tool in high locations.
3.Hold the tool firmly with both hands. Always use the side
grip.
4.Keep hands away from rotating parts.
5.Do not leave the tool running. Operate the tool only when
hand-held.
6.Do not touch the bit or the workpiece immediately after
operation; they may be extremely hot and could burn your
skin.
7.Some materials contain chemicals which may be toxic.
Take caution to prevent dust inhalation and skin contact.
Follow material supplier safety data.
Caution!
Always unplug drill from the mains supply before changing
the drill bit, servicing, cleaning or adjusting the drill.
SPECIFICATIONS
Evolution SDS4
Motor (110v/230v – 50Hz/60Hz): 650W
Impact Energy: 1.6J
Speed Range: 0-1100 min -1
Machine Weight: 2.8 kg
Product Dimensions (HxWxD): 210mm x 320mm x 85mm
Recommended Maximum Duty Cycle: 30 mins
Max. Drill Diameter (Steel): 13mm
Max. Drill Diameter (Concrete): 20mm
Max. Drill Diameter (Wood): 30mm
Sound Pressure Level (Under Load): Lpa = 88.6dB (A)
Lwa = 99.6dB (A)
K = 3dB (A)
Vibration: ah 14.015 m/s2
K 1.5 m/s2
Packaging
Gross Weight : 4.9kg
www.evolutionfury.com 5
SDS4 HAMMER DRILL
SPECIFIC SAFETY RULES & SYMBOLS GB
ADDITIONAL SPECIFIC SAFETY RULES GB
SPECIFICATIONS GB

www.evolutionfury.com
8
PARTS DIAGRAM
www.evolutionfury.com
SDS4 HAMMER DRILL
9

www.evolutionfury.com 7
of your bit, decrease the tool performance and shorten the
service life of the tool.
• Thereisforceexertedonthetool/bitatthetimeofhole
break-through. Hold the tool firmly and take care when the
bit begins to break through the workpiece.
• Always secure small workpieces in a vice or other hold
down device.
Drilling Wood
When drilling wood the best results will be obtained by
using dedicated wood bits equipped with a guide screw. The
guide screw makes drilling easier by pulling the bit into the
workpiece.
Drilling Metal
To prevent the bit from slipping when starting a hole, make
an indentation with a centre-punch and hammer at the point
to be drilled. Place the point of the bit into the indentation
and begin drilling.
Use an appropriate lubricant for the material being drilled
with the exception of iron and brass which should be drilled
dry.
Hammer Drilling Operation
Select the hammer drill function on the mode selection
switch.
CAUTION
There is a sudden twisting force exerted on the tool / bit
at the time of hole break-through, when the hole becomes
clogged with chips and particles, or when striking reinforcing
rods embedded in concrete. Always use the side grip handle
and firmly hold the tool by both the side handle and the
switch handle during hammer drilling operations. Failure to
do so could result in loss of control of the tool and potential
injury to the operator.
Be sure to use a dedicated tungsten-carbide tipped drill bit.
Position the bit at the desired location for the hole, then pull
the switch trigger. Do not force the tool. Consistent light
pressure gives the best results. Keep the tool in position and
prevent it from slipping away from the hole.
Do not apply extra pressure if the hole becomes clogged
with chips or particles. Instead allow the tool to run at idle
and then partially remove the bit from the hole. By repeating
this several times the hole will be cleaned out and normal
drilling may be resumed.
Chiselling Operations
Set the mode selection switch to the preferred operator
position, either chisel (locked) or chisel (unlocked).
CAUTION
When using the tool for chiselling operations it is very
important that the operator wears all the appropriate safety
equipment. Safety glasses and dust masks are essential and
other apparel such as gloves, safety shoes, ear protectors
etc should be worn as necessary.
Ensure that all marking out is completed before any
chiselling is attempted. Insert the required chisel into the
SDS chuck and ensure positive location. Offer the chisel
up to the worksurface and holding the tool firmly with both
hands begin the chiselling operation. Switch on the tool and
begin to cut.
Do not force the tool. Gentle consistent pressure works
best. Do not try to remove too much material in one pass.
Several repeat passes may be needed to achieve the
required results.
MAINTENANCE
Maintenance & Troubleshooting
Keep tool, cord, and carry case clean and free from chips.
Avoid using cleaning products, which include benzene,
trichloroethylene, chloride, or ammonia as these can damage
plastic parts. In case of electrical or mechanical malfunction,
immediately switch off the tool and disconnect the plug.
Excessive sparking may indicate the presence of dirt in
the motor or worn out carbon brushes. Check for wear and
replace when they reach 6mm (1/4”). For all other service
take machine to your local dealer, or to Evolution Power
Tools USA, Iowa, if bought in the USA.
Lubrication
Your machine gearbox is lubricated at the factory. To check
and / or add lubricant, it is necessary to dismantle the tool.
This operation should always be handled by the nearest
SERVICE CENTER or Evolution Power Tools USA, Iowa,
if in the USA. All repairs and servicing made by these
centres are fully guaranteed against defective materials and
workmanship.
Notice:
Fair wear and tear and damage caused by misuse is not
covered under the 12-Month guarantee.
ENVIRONMENTAL PROTECTION
Recycle unwanted materials instead of disposing of them
as waste. All tools, hoses and packaging should be sorted,
taken to the local recycling centre and disposed of in an
environmentally safe way.
Accessories – Genuine Evolution Supplied
HTA 155 SDS to Chuck Adaptor
HTA 153 13mm Chuck and Key
SDS4 HAMMER DRILL
ENVIRONMENTAL PROTECTION GB
Packaging Weight: 0.3kg
Packaging Dimensions (HxWxL):310mm x 125mm x380mm
ASSEMBLY
Your Evolution Power Tools saw is shipped complete.
Remove all contents from the box and inspect to ensure no
damage was incurred during shipping, and that the items
listed below are included.
Description Qty
Instruction Manual 1
Side Handle 1
Depth Gauge 1
SDS Drills 3
SDS Chisels 2
Carry Case 1
GETTING STARTED
CAUTION! ALWAYS DISCONNECT THE DRILL FROM
POWER SOURCE BEFORE MAKING ADJUSTMENTS.
Refer to the “Service Parts List Drawing”.
FUNCTIONAL DESCRIPTION
CAUTION
Always be sure that the tool is switched off and unplugged
before adjusting or checking a function on the tool.
Switch action (FIG1)
CAUTION
• Beforepluggingin thetool,alwayschecktosee thatthe
switch trigger actuates properly and returns to the ‘OFF’
position when released.
• Theswitchcanbelockedinthe‘ON’positionforeaseof
operator comfort during extended use. Apply caution when
locking the tool in the ‘ON’ position and maintain a firm grip
on the tool.
To start the tool, simply pull the switch trigger. Tool speed
is increased by increasing pressure on the switch trigger.
Release the switch trigger to stop the drill.
For continuous operation, pull the switch trigger and then
push in the lock button.
To stop the tool from the locked position, pull the switch
trigger fully, then release it.
A speed control screw is provided so that the maximum tool
speed can be limited (variable). Turn the speed control screw
clockwise for higher speed, and counterclockwise for lower
speed.
Reversing switch action
This drill has a reversing switch to change the direction of
rotation. Move the reversing switch lever to the required
position (clockwise or counterclockwise rotation) as indicated
by the arrows on the drill body.
CAUTION
• Alwayscheckthedirectionofrotationbeforeoperation.
• Use the reversing switch only after the tool comes to a
complete stop. Changing the direction of rotation before the
tool stops may damage the tool.
Selecting the action mode (FIG2)
This tool has a 4 position action mode selecting switch.
Push in the locking button on the switch lever and rotate the
switch to the desired position. Release the locking button
and ensure that the button has locked the switch in the
required position.
The 4 positions are:
• Drill•HammerDrill•Chisel(unlocked)•Chisel(locked)
Installing the side handle (FIG3)
CAUTION
Always be sure that the tool is switched off and unplugged
before carrying out any work on the tool.
Always use the side grip handle to ensure operating safety.
Install the side grip handle onto the drill collar and secure in
place by tightening the handle. Note that the handle may be
swung through 360º. Ensure that the side handle is pushed
fully home against the drill body before tightening.
Depth Gauge
The depth gauge is convenient for drilling holes of uniform
depth. To install, loosen the side grip handle and insert the
depth gauge into the hexagonal hole. Adjust to suit and
tighten the side grip handle to lock both the handle and depth
gauge into the desired position.
Installing or removing a drill bit or chisel (FIG4)
CAUTION
Always be sure that the tool is switched off and unplugged
before carrying out any work on the tool.
Carefully insert the SDS chisel or bit into the SDS chuck.
Gently pull the bit into the chuck whilst rotating the bit
slowly. Pull back on the chuck collar and continue pulling the
bit gently until positive location is felt and the bit slides fully
home into the chuck.
Only remove the bit when operations have finished and the
bit has completely cooled down.
To remove the bit, slide the chuck collar rearward and
carefully pull the bit out of the chuck
OPERATION
Standard Drilling Operation
Ensure that the action mode selecting switch is set on the
standard drill mode.
CAUTION
• Using excessive force on the tool will not speed up the
drilling. Excessive pressure will only serve to damage the tip
www.evolutionfury.com
6
FUNCTIONAL DESCRIPTION GB

www.evolutionfury.com
10
NOTES
www.evolutionfury.com
SDS4 HAMMER DRILL
11
NOTES
