Evve Long Range MK-1900HD Series User manual

Operation Manual MK1900HD Series 1/13
Zuid Hollandlaan 7
2596 AL Den Haag
The Netherlands
Phone: [phone] (NL)
E-mail: [email protected]om
Web : www.evvelongrange.com
MK-1900HD Series

EVVE LONG RANGETM
7. OPERATING COMMANDS FOR THE CAMERA
5. HOW TE SET OR CHANGE END STOPS
6. ABSOLUTE CONTROLS
SUPPORT SERVICES
FCC COMPLIANCE
ADDITIONAL INFORMATION & RELATED DOCUMENTS
2. OPERATING IN GOOGLE BROWSER
SAFETY INSTRUCTIONS
3. OPERATING IN VLC
4. HOW TO USE DIFFERENT SPEEDS
9. OPERATING COMMANDS FOR THE LASER
8. OPERATING COMMANDS FOR THE LENS

This manual contains information on the operation and the different
interfaces of the following Evve Long RangeTM products:
1900HD - High Definition Camera System
The information in this manual is subject to change without notice. Please
refer to our website for the latest information.
NOTE: All graphics contained within this document, including screenshots and
other displays, are for reference use only and are subject to change.
For information on the camera installation, please see Installation Manual
MK-1900HD. This manual is available from the Evve Long Range website
at: www.evvelongrange.com/downloads
17xxHD - High Definition Demonstration Camera Positioning System
Copyright 2019 by Evve Long Range B.V. (ELR). ELR has intellectual property rights to
technology embodied in the product described in this manual.
Evve Long RangeTM and Evve International BVTM are trademarkt of BOTHA BV.
17xxHD - High Definition Demonstration Camera Positioning System

Operation Manual MK1900HD Series 2/12
This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation. Changes or modifications to this device void the warranty.17xxHD -
High Definition Demonstration Camera Positioning System
At 50km the pixels per meter in
height will be 8. Assuming man
is 2m approx. then 8 pixels is
Detection.
At 5km the pixels per meter in
height will be 40. Assuming
man is 2m approx. then 80
pixels is Identification, i.e. it’s a
man or woman.
Please contact ELR for technical assistance: [e-mail] | [phone] (NL).
- High Definition Demonstration Camera Positioning System
WARNING:
Power supplies used with these Cameras operate on 115 Vac or 230 Vac. These voltages are
dangerous. Use extreme care working with equipment connected to either 115 Vac or 230 Vac.
WARNING:
Do not remove covers. There are no user-serviceable parts inside.
CAUTION:
Mount the camera system before the power is applied. After the power is applied the camera system
will start a configuration sequence and pan and tilt movement will occur. 17XXHD - HIGH
DEFINITION DEMONSTRATION CAMERA POSITIONING SYSTEM

Operation Manual MK1900HD Series 3/12
SAFETY INSTRUCTIONS
Installation should be done only by qualified installers and conform to all local codes.
It is the users’ responsibility to ensure that the mounting methods are safe and adequate for
the location.
Use only stainless steel hardware to fasten the mount to an outdoor surface.
All servicing should be performed by qualified service personnel. Procedures in this manual
do not require entry into the housing of the camera positioning system. The unit contains
potential high voltage. It also contains sensitive devices that can be damaged by static
discharge. To reduce the risk of electric shock and damage to the unit by static discharge do
not perform any servicing other that described in these instructions. If the unit is defective,
please contact the Customer Service Department for technical assistance.
Liability: It is the sole responsibility of the installer to provide proper installation in compliance
with all local codes and regulations.
- High Definition Demonstration Camera Positioning System
The Evve Long Range products are the part of the next generation of Long Range camera systems
ranging from high-definition (HD) to standard-definition (SD) camera positioning systems. The
systems are IP (Internet Protocol) based with a full function built-in operating system. Operator
functions features are controlled from the On Screen Display (OSD).
A drive system positioned within the MK1900 Series camera permits full 360° continuous pan and
90° tilt movements. The camera systems comply with MIL-STD-18F standards for temperature,
shock, and vibration specifications. For environmental protection the camera systems use an IP67
camera head enclosure and IP66 positioner enclosure.
Definition Demonstration Camera Positioning System

Operation Manual MK1900HD Series 4/12
CLASS 3 (EYE & SPECULAR REFLECTION HAZARD):
Never aim the laser at a person’s eye or stare at the laser from within the beam.
Keep the beam path above or below eye level for one seated or standing.
Laser safety eyewear is needed if MPE (Maximum Permissible Exposure) is exceeded.
Don’t view beam directly with optical instruments unless a protective filter is used.
Only experienced and authorized individuals are permitted to operate the laser.
Secure the laser from operation by unauthorized personnel. A key switch should be
used if unauthorized personnel may gain access to the laser.
Always strive to enclose as much of the beam path as practical and to operate the
laser in a controlled access area.
During alignment, avoid placing one’s eye near the axis of the beam path, where
specular reflections are most likely to occur. Alignment eyewear should be
considered.
Unnecessary specular (i.e., mirror-like) reflecting objects should be removed from
the beam path.
Mount the laser on a firm support to ensure the beam travels along its intended
path.
Post laser hazard warning signs at entrances to laser use areas.
SAFETY INSTRUCTIONS
For more information on specifications and datasheets, please refer to specific product pages at Evve
Long Range website: www.evvelongrange.com/downloads.
finition Demonstration Camera Positioning System

Operation Manual MK1900HD Series 5/12
1.
Open the Google browser.
Use the following address to log in to the interface of the encoder:
192.168.178.150:8080 (HD encoder)
192.168.178.151:80 (Analog encoder)
Log in screen appears.
Log in to the TVMS program:
Login: admin
Password: 1234
Screenshot ANT-3500
There will be a small delay due to the browser of approc. 300ms.

Operation Manual MK1900HD Series 6/12
2.
Open VLC Player.
Log in screen appears.
Select File and then select Open
Network.
Type the following address:
rtsp://192.168.178.150:8080/video1
Press Open: the video will be
displayed.

Operation Manual MK1900HD Series 7/12
3.
For all directions the same.
When you joggle the joystick one time
to the direction, it’s ultra slow.
You can speed this up by joggling the
joystick into the same direction as
before. The speed will go from > to >>,
>>> and >>>>.

Operation Manual MK1900HD Series 8/12
HOW TO REMOVE END STOPS
Command:
Release Left
95 PRESET
Release Right
96 PRESET
Release Up
97 PRESET
Release Down
98 PRESET
The operator/user is able to set end stops.
4.
HOW TO SET END STOPS
Command:
Set Left
91 PRESET
Set Right
92 PRESET
Set Up
93 PRESET
Set Down
94 PRESET

Operation Manual MK1900HD Series 9/12
Level elevation and north position for absolute control.
5.
Command:
Absolute Control
99 PRESET

Operation Manual MK1900HD Series 10/12
6.
STARTING UP
To enter the camera menu, press
5 AUX ON
When you enter the camera
settings, the camera movement
will be blocked. Getting out of the
camera menu will unblock the
camera movement again.
OPERATING COMMANDS
Command:
Enter camera menu
88 PRESET
Save menu
89 PRESET
Exit menu
90 PRESET
Use the joystick to move through the menu.
To exit the camera settings, press
5 AUX OFF

Operation Manual MK1900HD Series 11/12
7.
LENS FUNCTIONS
Press selected numbers and PRESET
Command:
Function:
70 PRESET
active_filter = 0xcf; // 4 different filter states
71 PRESET
active_filter = 0xdf;
72 PRESET
active_filter = 0xef;
73 PRESET
active_filter = 0xff;
74 PRESET
x2 on
75 PRESET
x2 off
76 PRESET
autofocus one shot, cleared after sending command
79 PRESET
enable autoiris on
80 PRESET
autoiris off, ie never cuts in

Operation Manual MK1900HD Series 12/12
8.
STARTING UP
To start the laser, press
6 AUX ON
The laser is on and there is no
power coming out.
OPERATING COMMANDS
Command:
Start laser
6 AUX ON
Less power
OPEN
Power up by 10% each step
CLOSE
Switch laser off
6 AUX OFF
To operate the lens, you can give direct commands. The laser is standard off and with no power.
The laser light is steerable in the image. You can use the joystick to move the light through
the image.
When you enter the laser settings, the camera movement will be blocked. Getting out of the
laser menu will unblock the camera movement again.
After switching off the laser, the moving block of the camera is disabled. The operator can
move the camera again. For the demo this safety is built in!

Operation Manual MK1900HD Series 13/12
