Evve Long Range MK-1900HD Series User manual

Zuid Hollandlaan 7
2596 AL Den Haag
The Netherlands
Phone: [phone] (NL)
E-mail: [email protected]om
Web : www.evvelongrange.com
MK-1900HD Series

EVVE LONG RANGETM
2. INSTALLATION: BUILDING THE CAMERA
SUPPORT SERVICES
RETURNS
SHIPMENT
SAFETY INSTRUCTIONS
1. INTRODUCTION: EQUIPMENT SUPPLIED
FCC COMPLIANCE
ADDITIONAL INFORMATION & RELATED DOCUMENTS

Installation Manual MK1900HD Series 1/11
This manual contains information on the installation and maintenance of
the following Evve Long RangeTM products:
1900HD - High Definition Camera System
The information in this manual is subject to change without notice. Please
refer to our website for the latest information.
NOTE: All graphics contained within this document, including screenshots and
other displays, are for reference use only and are subject to change.
For information on the camera system operation and configuration,
please see Operation manual MK1900HD Series. The manual is available
on the Evve Long Range website at:
www.evvelongrange.com/downloads
17xxHD - High Definition Demonstration Camera Positioning System
Copyright 2019 by Evve Long Range B.V (ELR). ELR has intellectual property rights to
technology embodied in the product described in this manual.
Evve Long RangeTM and Evve International BVTM are trademarkt of BOTHA BV.
17xxHD - High Definition Demonstration Camera Positioning System

Installation Manual 1900HD Series 2/9
This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation. Changes or modifications to this device void the warranty.17xxHD -
High Definition Demonstration Camera Positioning System
At 50km the pixels per meter in
height will be 8. Assuming man
is 2m approx. then 8 pixels is
Detection.
At 5km the pixels per meter in
height will be 40. Assuming
man is 2m approx. then 80
pixels is Identification, i.e. it’s a
man or woman.
This item was thoroughly tested and carefully packed at the factory prior to shipping. Upon
acceptance by the carrier, the carrier assumes responsibility for the item’s safe arrival. If you
receive the item in a damaged condition, apparent or concealed, a claim for damage must be
made to the carrier.
If a visual inspection shows damage upon receipt of this shipment, it must be noted on the freight
bill or express receipt and the notation signed by the carrier’s agent. Failure to do this can result
in the carrier refusing to honor the claim.
When the damage is not apparent until the unit is unpacked, a claim for concealed damage must
be made.
Make a mail or phone request to the carrier for inspection immediately upon discovery of the
concealed damage. Keep all cartons and packing materials.
To return the product to the factory for service, please contact ELR for a Return Material
Authorization (RMA) Number.
Prominently display the RMA number on the outside of the shipping container(s) and on
paperwork contained inside. Give a brief description of why the equipment is being returned and
list the symptoms of any problems being experienced with the equipment.
- High Definition Demonstration Camera Positioning System
Please contact ELR for technical assistance: [e-mail] | [phone] (NL).
- High Definition Demonstration Camera Positioning System

Installation Manual 1900HD Series 3/9
IMPORTANT!
If the camera needs to be shipped, please use the original packaging material which was designed to
protect the product during transportation. If the original packaging is lost or damaged, please order
a replacement at ELR.
17xxHD - High Definition Demonstration Camera Positioning System
WARNING:
Power supplies used with these cameras operate on 115 Vac or 230 Vac. These voltages are
dangerous. Use extreme care working with equipment connected to either 115 Vac or 230 Vac.
WARNING:
Do not remove covers. There are no user-serviceable parts inside.
CAUTION:
Mount the camera system before the power is applied. After the power is applied the camera system
will start a configuration sequence and pan and tilt movement will occur. 17XXHD - HIGH
DEFINITION DEMONSTRATION CAMERA POSITIONING SYSTEM
Installation should be done only by qualified installers and conform to all local codes.
It is the users’ responsibility to ensure that the mounting methods are safe and adequate for
the location.
Use only stainless steel hardware to fasten the mount to an outdoor surface.
All servicing should be performed by qualified service personnel. Procedures in this manual
do not require entry into the housing of the camera positioning system. The unit contains
potential high voltage. It also contains sensitive devices that can be damaged by static
discharge. To reduce the risk of electric shock and damage to the unit by static discharge do
not perform any servicing other that described in these instructions. If the unit is defective,
please contact the Customer Service Department for technical assistance.
Liability: It is the sole responsibility of the installer to provide proper installation in compliance
with all local codes and regulations.
- High Definition Demonstration Camera Positioning System

Installation Manual 1900HD Series 4/9
SAFETY INSTRUCTIONS
The Evve Long Range products are part of the next generation of Long Range camera systems,
ranging from high-definition (HD) to standard-definition (SD) camera positioning systems. The
systems are IP (Internet Protocol) based with a full function built-in operating system. Operator
functions features are controlled from the On Screen Display (OSD).
A drive system positioned within the MK-1900 Series camera permits full 360° continuous pan and
90° tilt movements. The camera systems comply with MIL-STD-18F standards for temperature,
shock, and vibration specifications. For environmental protection the camera systems use an IP67
camera head enclosure and IP66 positioner enclosure.
For more information on specifications and datasheets, please refer to specific product pages at Evve
Long Range website: www.evvelongrange.com/downloads.
- High Definition Demonstration Camera Positioning System

Installation Manual 1900HD Series 5/9
PT UNIT & CONNECTION BOX
CAMERA HOUSING WITH SUNSHIELD
12 BOLTS (M12 STAINLESS STEEL) & ALLEN KEY SET
1.
POWER BOX & CONNECTION CABLES

Installation Manual 1900HD Series 6/9
GRAPHIC DESIGN & PROGRAMMING
WEBSITE TESTING & ONLINE LAUNCHING
2.
This chapter covers the general installation and cable requirements of the MK1900HD series.
- High Definition Demonstration Camera Positioning System
NOTE:
Before starting installation:
Choose a flat surface or bracket.
Have the bolts available.
Do NOT power the systems until all devices are connected.
CAUTION:
The bolts that are used to install the camera must be securely fastened.
After installation and before turning on the camera, check if the camera moves freely and has
enough clearance for pan and tilt movements without any obstructions.

Installation Manual 1900HD Series 7/9
1. Place the camera base in the correct
position to mount the bolts.
2. Check if the bolts are securely fastened.
3. Mount the powerbox at the correct
position.
4. IMPORTANT:
Check the position of the connector and align the camera housing with the drive shaft
following the markers on the camera housing and on the drive shaft.

Installation Manual 1900HD Series 8/9
5. Slide the camera housing on the drive shaft.
6. Secure the bolts on the drive shaft.
BUILDING THE CAMERA
8. Turn on the power.
INFORMATION:
Standard IP-address 192.168.178.150:8080
Analog: 192.168.178.151:80
Log in: admin | Password: 1234
7. Connect the power and data cable from the
power box to the camera.

Installation Manual 1900HD Series 9/9
