Excelsior Balcony Barbie EBB 001 User manual
Balcony Barbie
Instruction Manual
Model
EBB 001
1
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the
appliance.
WARNING:
Charcoal or similar combustible fuels must not be used with this appliance.
The appliance should be supplied through a residual current device (RCD)
having a rated residual operation current not exceeding 30mA.
The supply cord should be regularly examined for signs of damage and the
appliance is not to be used if the cord is damaged.
2
Safety Tips
•
Position on a flat, stable surface.
•
A service agent/qualified technician should carry out installation and any repairs if
required. Do not remove any components on this product.
•
Consult Local and National Standards to comply with the following:
•
Health and Safety at Work Legislation
•
Building Regulations
•
DO NOT immerse the appliance in water.
•
Some surfaces become hot during operation - take care when using the appliance.
•
Always switch off and disconnect the power supply to the appliance when not in use.
•
This appliance must only be used in accordance with these instructions and by persons
competent to do so.
•
This appliance is not suitable for use by children.
•
Keep all packaging away from children. Dispose of the packaging in accordance to the
regulationsof local authorities.
•
If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Product Description
•
EBB 001 - Outdoor Electric BBQ (Mild Steel plate. Cooking Area: 520mm x 330mm)
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and
operation of this machine will provide the best possible performance from your Excelsior
product.
Pack Contents
The following is included:
•
Excelsior BBQ
•
Waste Tray
•
Instruction Manual
GBI Sales prides itself on quality and service, ensuring that at the time of packaging the
contents are supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Excelsior dealer immediately.
3
Note: 200°C to 220°C is suitable for general cooking.
Operation
Cooking plate
Grease tray
Power
indicator light
Thermostat
Seasoning the Cooking Plate
Before using for the first time the cooking surface needs to seasoned.
1.
Ensure the cooking surface is clean, with Eucalyptus oil or similar.
2.
Brush the surface with cooking oil.
3.
Set the thermostat to 110°C and turn the appliance On. The power indicator light turns on.
4.
Once the appliance reaches temperature the power indicator light turns off.
5.
Turn the appliance Off and allow to cool before wiping away any excess oil.
6.
The appliance is now ready to use.
Cooking
1.
Connect the appliance to the mains power supply.
2.
Set the thermostat to the desired temperature (60°C-300°C). The power indicator light comes on and
the appliance begins to heat up.
3.
The power indicator light turns off when the appliance has reached the set temperature.
4.
Place the foodstuffs on the cooking plate and cook as required.
Note: Excelsior recommend the cooking surface is lightly oiled before cooking.
4
NOTE: IT IS VITAL THAT THE COOKING SURFACE IS RE-SEASONED AFTER SCOURING.
WARNING: DO NOT remove the tray during or immediately after use as the contents
will be hot.
Cleaning, Care & Maintenance
If grease is permitted to accumulate, it will begin to carbonise into a hard substance that is extremely
difficult to remove. To prevent this follow the cleaning steps below:
•
Always turn Off the appliance and disconnect from the power supply before cleaning.
•
Allow the appliance to cool before cleaning.
•
Use warm, soapy water and a damp cloth to clean the exterior of the appliance.
•
Take care when using scrapers to remove cooking residues as they can damage the cooking surface.
•
Dry thoroughly after cleaning.
•
A qualified electrician should carry out repairs if required.
•
After every use, clean the cooking surface thoroughly and leave coating of oil on surface to
protect from surface rust.
Scraping
After each use, scrape the appliance with a scraper/grill stone/copper brush or flexible spatula to remove
excess fat and food. A waste tray is provided for the scrapings if necessary.
If there is an accumulation of burned fat or food, the cooking surface should be thoroughly scoured and
re-seasoned. .
Waste Tray
These appliances feature a waste tray to collect any liquid or fats that run off during cooking.
After every use, remove and empty the grease tray before washing with warm soapy water. Do not allow the
tray to overfill or excess grease will run out of the overflow hole at the front of the tray.
WARNING: DO NOT USE STEEL WOOL AS IT MAY LEAVE SHARDS THAT COULD
CONTAMINATE FOOD.
5
Troubleshooting
If your Excelsior appliance develops a fault, please check the following table before making a call to
the Helpline.
Fault
Probable Cause
Action
The appliance is not working
The appliance is not switched on
Check the appliance is plugged in correctly
and switched on
Plug and lead are damaged
If within Warranty period, return to place
of purchase for replacement
Fuse has blown
If within Warranty period, return to place
of purchase for replacement
Power supply
Check power supply
Internal wiring fault
Call agent or qualified electrician
Appliance does not reach set
temperature
Faulty thermostat
Call agent or qualified electrician
Faulty element
Call agent or qualified electrician
Appliance heats up but indicator light
does not come on
Bulb has expired
Call agent or qualified electrician
Power indicator light comes on but
appliance does not heat up
Faulty element
Call agent or qualified electrician
Faulty thermostat
Call agent or qualified electrician
Thermostat set incorrectly
Check thermostat
Appliance slow to heat up
Cooking surface not clean
Clean cooking surface
Faulty element
Call agent or qualified electrician
Technical Specifications
Model
Voltage
Power
Current
Cooking Surface
Dimensions
w x d (mm)
Dimensions
h x w x d (mm)
Weight
(kg)
EBB 001
220-240V
2200W
9.6A
520 x 330
185 x 523 x 439
21.5
6
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
•
Live wire (coloured brown) to terminal marked L
•
Neutral wire (coloured blue) to terminal marked N
•
Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible
for waste disposal in your area.
Parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal
authorities.
Excelsior products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of GBI Sales.
Every effort is made to ensure all details are correct at the time of going to press, however, GBI Sales reserve the right to change
specifications without notice.
7
DECLARATION OF CONFORMITY
Equipment Type Outdoor Electrical BBQ
Model EBB 001
AS/NZ 3820 Essential Safety Requirements for Low
Voltage Electrical Equipment
Standards EN 55014-1:2006 + A1:2009+A2:2011
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55014-2:2015
AS/NZS 60335-1:2011+A1 to A4
AS/NZS 60335-2-78:2005 +A1 & A2
Producer Name Excelsior
Producer Address 78 Mallard Way
Cannington
WA 6107
Producer Telephone (08) 9478 0466
I, the undersigned, hereby declare that the equipment specified above conforms
to the above Legislation and Standard(s).
Date 26/09/11
Signature
Full Name Richard Cromwell
Position Marketing Director
