Exclusive Heritage MK-10060D User manual

INSTALLATION GUIDE
FOR MK-10060D

60”
INSTALLATION MANUAL
PACKING LIST (Not all components may be included, depending upon your purchase)
RECOMMENDED TOOLS
Main Cabinet
Pen & Ruler Caulk & Caulk Gun Power Drill Phillips Screwdriver Adjustable Wrench Goggles, Gloves & Ear Plugs
Optional: Countertop Optional: Mirror Optional: Square Sink
ENOC
I
L
IS
59.10”
swercSnoitallatsnIrorr
i
M
34.20”
31.50”
Basket
FOR MODELS:
MK-10060D-WMCG
MK-10060D-WMES
MK-10060D-WMTP
MK-10060D-WMWH
MK-10060D-WMCG-NM
MK-10060D-WMES-NM
MK-10060D-WMTP-NM
MK-10060D-WMWH-NM
MK-10060D-CAB-CG
MK-10060D-CAB-ES
MK-10060D-CAB-TP
MK-10060D-CAB-WH
SAFETY & PRECAUTIONS
1. Exclusive Heritage
recommends you to review the
Installation Manual before
starting the vanity installation.
2. Please handle heavy objects
with care and support to avoid
mishaps damages or injuries.
3. After completing the
installation, please wait up to
24-hours before using the vanity.
4. When cleaning the top or
cabinet use mild strength for
scrubbing to avoid scratching the
surface.
5. Professional installation
recommended.
t
i
Kgn
itnuoMkniS
14.96”
20”
22”
59.21”
33.46”

OPTIONAL: HINGES INSTALL & ADJUSTMENT HOW TO CARRY THE TOP
OPTIONAL: SINK INSTALLATION
OPTIONAL: TOP& BACKSPLASH INSTALLATION
1. Attach hinge (A) to door with screws (B). 2. Attach mounting plate (A) to cabinet with screw (B).
12
34
123
Fig. A
CAUTION
Whether you are picking up a small or
large marble countertop, always have
extra support handling the heavy object.
We recommend two adults lifting and
manuevering the countertop around.
3. Attach hinge (A) to mounting plate (B)
and snap into position. 4. Align door to cabinet. Use screw (A) to adjust
door depth, screw (B) to adjust vertically and screw
(C) to adjust horizontally.
• Apply a continuous stream of silicone glue around the
sink top rim. Flip the countertop upside down.
• Carefully align the sink onto countertop back, fasten the
sink rim with the sink mounting screws.
• Apply a continuous silicone glue along the sink edges to
seal any gaps.
1. Measure the screw holes from the backside of mirror (Fig. A) distance.
Then drill the holes into the wall.
2. Insert the anchor screws into the holes and drill the screws into them.
3. Hang up the mirror into position and it’s done.
OPTIONAL: MIRROR INSTALLATION
1 2
2
3
1. Apply a continuous stream of silicone glue
around the top of the cabinet.
2. Carry the countertop and gently place it
onto the cabinet.
3. Install the backsplash by applying silicone
glue near the edge of the countertop. Then
place the backsplash onto the silicone area.
Add additional silicone onto the edges for
sealant if necessary.
Note: Allow up to 24-hours for the silicone
glue to dry before using the vanity.
