Exclusive Heritage CL-10160D-WMTP User manual

INSTALLATION GUIDE
FOR CL-10160D-WMTP

INSTALLATION MANUAL
PACKING LIST
RECOMMENDED TOOLS
Main Cabinet
Pen & Ruler Caulk & Caulk Gun Power Drill Phillips Screwdriver Adjustable Wrench Goggles, Gloves & Ear Plugs
swercSnoitallatsnIrorriM
rorriM
potretnuoC
t
i
Kgn
itnuoMkni
S
ENOC
I
L
IS
MODEL: CL-10060D-WMTP
1. Exclusive Heritage
recommends you to review
the Installation Manual
before starting the vanity
installation.
2. Please handle heavy objects
with care and support to
avoid mishaps damages or
injuries.
3. After completing the
installation, please wait up
to 24-hours before using the
vanity.
4. When cleaning the top or
cabinet use mild strength
for scrubbing to avoid
scratching the surface.
5. Professional installation
recommended.
Width: 60”
Depth: 22.05”
Height: 34.46”
SAFETY & PRECAUTIONS
OVERALL DIMENSIONS
ksniSe
rauqS
34.46”
31.5”
60”
59.05”

HINGES INSTALL & ADJUSTMENT HOW TO CARRY THE TOP
SINK INSTALLATION
TOP& BACKSPLASH INSTALLATION
1. Attach hinge (A) to door with screws (B). 2. Attach mounting plate (A) to cabinet with screw (B).
12
34
1
1
3
23
Fig. A
CAUTION
Whether you are picking up a small or
large marble countertop, always have
extra support handling the heavy object.
We recommend two adults lifting and
manuevering the countertop around.
1.Apply a continuous stream of silicone glue around the
top of the cabinet.
2.Carry the countertop and gently place it onto the
cabinet.
3.Install the backsplash by applying silicone glue near
the edge of the countertop. Then place the backsplash
onto the silicone area. Add additional silicone onto the
edges for sealant if necessary.
Note: Allow up to 24-hours for the silicone glue to dry
before using the vanity.
3. Attach hinge (A) to mounting plate (B)
and snap into position. 4. Align door to cabinet. Use screw (A) to adjust door depth, screw (B) to adjust vertically and screw
(C) to adjust horizontally.
• Apply a continuous stream of silicone glue around the
sink top rim. Flip the countertop upside down.
• Carefully align the sink onto countertop back, fasten the
sink rim with the sink mounting screws.
• Apply a continuous silicone glue along the sink edges to
seal any gaps.
1. Measure the screw holes from the backside of mirror (Fig. A) distance.
Then drill the holes into the wall.
2. Insert the anchor screws into the holes and drill the screws into them.
3. Hang up the mirror into position and it’s done.
2
MIRROR INSTALLATION

LEGAL DISCLAIMER
TO OBTAIN SERVICE UNDER WARRANTY
LIFETIME LIMITED WARRANTY
Send E-mail To: [email protected]
Subject: Customer Support - Warranty
Please include the following information:
A. Date of purchase and installation
B. Proof of Purchase (copy of original dated invoice)
C. Description of nature of defect
D. Model number
Exclusive Heritage LLC provides all product information
and data in a “AS IS”, “WHERE IS”, and “WHERE
AVAILABLE” format. The product prices and
specifications are subject to changes without notice.
Exclusive Heritage is not responsible for, nor have any
liability for mistakes or typographical errors, including
liability of incidental, consequential, and special damages.
You agree to indemnify, defend, and hold harmless with
Exclusive Heritage LLC, its affiliates, agents, managers,
employees, and licensors from and against any and all
claims and expenses, including reasonable attorneys’ fees,
arising out of or related in any way to your use of the
website, product manual, installation guide, care and
maintenance guide, violation of this Agreement, violation
any law or regulation, or violation of any third party
proprietary or privacy right.
VOID OF WARRANTY IF
• The product was purchased from an unauthorized seller.
• The contractor, service installer, or yourself failed to follow installation procedures.
• The installation was performed not in accordance with local electrical, plumbing, and structural codes.
• The product was not cared for per proper maintenance guidelines.
• The product sustained damage as a result of excessive and aggressive use of abrasive chemicals/cleaners.
• The product was subjected to abusive treatment such as placing, dropping, rubbing, or hammering
against heavy objects.
• Unauthorized modifications were made to the product.
• Accidental occurrences as a result of fire, earthquake, flood, natural disaster, or acts of God.
Exclusive Heritage would like to inform you, as the Original Buyer/End-User who files for a new
replacement request, that certain aspects of this warranty does not cover the followings:
• Transportation or shipping cost
• Labor cost
• Travel time
• Lost wages or profits
• Home damages
• Professional service fees (attorney, experts, etc.)
• Investigation, analyses, report costs
• Other Contingent Liabilities
This warranty gives you specific legal rights, some States do not allow limitations on how long an implied
warranty lasts. So the above limitation may not apply to you and you may also have other rights which
vary from state to state.
The Exclusive Heritage bathroom vanities you (herein also defined as the Original Buyer/End-User) have purchased from one of its authorized distributors is covered under
the 2 Years Limited Warranty policy. The warranty protects your purchase against material defects. In the event a new vanity replacement is warranted, Exclusive Heritage
reserved the right to perform a complete and thorough investigation, including but not limited to material defects and causes. If one of the defective causes which falls within
the list identified below, the warranty will be voided. In the event an exact replacement is not available, Exclusive Heritage reserved the right to replace the product with a
similar model but comparable in value. THIS WARRANTY IS NOT TRANSFERABLE.
