Exmark VANTAGE 48 Manual

VANTAGE®
48/52/60InchModels
SetupInstructions
ForSerialNos.313,000,000&Higher
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer
extranet.
DealerPack
Part#DescriptionQty.Use
103-2106Key,ExmarkLogo1
1-603511Key,Standard1
Fillouttheonlinewarrantyregistration
formandplacekeysintoliterature
pack.
LiteraturePack
Manual,Operator's
DVD,ExmarkTrainingMaterial
CheckingTirePressure
1.Checkthetirepressureinthedrivetires.Proper
inationfordrivetiresis12–16psi(83–110kPa).
2.Adjustifnecessary.
ServicingtheBattery
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Important:Themachineisshippedwithalled
leadacidbattery.
DANGER
Chargingorjumpstartingthebatterymayproduce
explosivegases.Batterygasescanexplodecausing
seriousinjury.
•Keepsparks,ames,orcigarettesawayfrom
battery.
•Ventilatewhenchargingorusingbatteryinan
enclosedspace.
•Makesureventingpathofbatteryisalwaysopen
oncebatteryislledwithacid.
•Alwaysshieldeyesandfacefrombattery.
DANGER
Batteryelectrolytecontainssulfuricacid,whichis
poisonousandcancausesevereburns.Swallowing
electrolytecanbefatalorifittouchesskincan
causesevereburns.
•Wearsafetyglassestoshieldeyes,andrubber
glovestoprotectskinandclothingwhen
handlingelectrolyte.
•DoNotswallowelectrolyte.
•Intheeventofanaccident,ushwithwaterand
calladoctorimmediately.
1.Checkthevoltageofthebatterywithadigital
voltmeter.Locatethevoltagereadingofthebattery
©2012—ExmarkMfg.Co.,Inc.
P .O.Box808
Beatrice,NE68310
PartNo.4501-444Rev.A
PrintedintheUSA
AllRightsReserved

inthetablebelowandchargethebatteryforthe
recommendedtimeintervaltobringthechargeup
toafullchargeof12.6voltsorgreater.
Important:Makesurethenegativebattery
cableisdisconnectedandthebatterycharger
usedforchargingthebatteryshouldhave
anoutputof16voltsand7ampsorlessto
avoiddamagingthebattery(seechartfor
recommendedchargersettings).Thisis
especiallyimportantonKohlerEFI(Electronic
FuelInjection)units.Failuretodosomay
damagetheECU(ElectronicControlUnit).
Voltage
Reading
Percent
Charge
Maximum
Charger
Settings
Charging
Interval
12.6or
greater
100%16volts/7
amps
NoCharging
Required
12.4–12.675–100%16volts/7
amps
30Minutes
12.2–12.450–75%16volts/7
amps
1Hour
12.0–12.225–50%14.4volts/4
amps
2Hours
11.7–12.00–25%14.4volts/4
amps
3Hours
11.7orless0%14.4volts/2
amps
6Hoursor
More
CAUTION
Iftheignitionisinthe“ON”positionthere
ispotentialforsparksandengagementof
components.Sparkscouldcauseanexplosionor
movingpartscouldaccidentallyengagecausing
personalinjury.
Besureignitionswitchisinthe“OFF”position
beforechargingthebattery.
2.Connectthenegativebatterycable.
Note:Ifthepositivecableisalsodisconnected,
connectthepositive(red)cabletothepositive
batteryterminalrst,thenthenegative(black)cable
tothenegativebatteryterminal.Slipinsulatorboot
overthepositiveterminal.
Note:Iftimedoesnotpermitchargingthebattery,
orifchargingequipmentisnotavailable,connect
thenegativebatterycableandrunthevehicle
continuouslyfor20to30minutestosufciently
chargethebattery.
PositioningtheDischargeChute
Loosenthetwo3/8inchnylocnutsattachingthe
dischargechute.Lowerthedischargechuteinto
position.Retightenthenylocnutsuntilthechuteissnug
butcanpivotfreely.
ServicingtheEngine
Theengineisshippedwithoil;checkoillevelandif
necessarylltotheappropriatelevel.Exmark4-Cycle
PremiumEngineOilisrecommended.Refertothe
EngineOwner’sManualforanacceptablealternative.
ServicingtheHydraulicOil
Themachineisshippedwithhydraulicoilinthe
reservoir.
1.Runthemachineforapproximately15minutesto
allowanyextraairtopurgeoutofthehydraulic
system.
2.Checkhydraulicreservoirandifnecessaryllthe
reservoirtotheappropriatelevelwithExmark
PremiumHydrooil.
3.Replacehydraulicreservoircapandtightenuntil
snug.DoNotovertighten.
Note:Thebafeislabeled“HOT”and“COLD”.
Theoillevelvarieswiththetemperatureoftheoil.
The“HOT”levelshowsthelevelofoilwhenitisat
225°F(107°C).The“COLD”levelshowsthelevelof
theoilwhenitisat75°F(24°C).Filltotheappropriate
leveldependinguponthetemperatureoftheoil.For
example:Iftheoilisabout150°F(65°C).Filltohalfway
betweenthe“HOT”and“COLD”levels.Iftheoilisat
roomtemperature(about75°F(24°C)),llonlytothe
“COLD”level.
FillingOuttheProduct
Registration
Fillouttheonlinewarrantyregistrationformandplace
keysintoliteraturepack.
2
