Contents
Introduction...........................................................3
Safety.....................................................................5
SafetyAlertSymbol.........................................5
GeneralSafety.................................................5
SafetyandInstructionalDecals.......................6
Specications........................................................11
Systems..........................................................11
Dimensions....................................................12
TorqueRequirements.....................................12
ProductOverview.................................................13
Operation..............................................................13
Controls.........................................................13
BeforeOperation...........................................15
OperatingInstructions...................................16
DuringOperationSafety.................................16
AfterOperation..............................................20
Transporting..................................................20
Maintenance..........................................................21
MaintenanceSafety.............................................21
RecommendedMaintenanceSchedule(s)............22
PeriodicMaintenance........................................22
EngineMaintenance.......................................22
EngineSafety.................................................22
CheckEngineOilLevel..................................23
CheckMowerBlades......................................23
CheckforLooseHardware.............................24
ServiceAirCleaner.........................................24
ChangeEngineOil.........................................24
CheckHydraulicOilLevel..............................25
CheckTirePressures......................................25
CheckConditionOfBelts...............................25
LubricateGreaseFittings................................25
CheckSparkPlugs..........................................26
CheckSafetyInterlockSystem........................27
ChangeHydraulicSystemFilter......................29
ReplaceEmissionsAirIntakeFilter.................30
ThreadLockingAdhesives..............................30
MobilHTSGrease(OrFood-Grade
Anti-seize)..................................................31
Copper-BasedAnti-seize...............................31
DielectricGrease............................................31
Adjustments......................................................31
AdjustingtheCuttingHeight..........................31
AdjustingtheAxlePosition.............................33
AdjustingtheNumberofSpacersbelow
CasterSupportHub....................................34
AdjustingtheCuttingHeightwithBlade
Spacers.......................................................34
PTOEngagementLinkage
Adjustment................................................34
PTOSafetySwitchAdjustment.......................35
EnginetoMowerDeckBelt
Adjustment................................................35
BladeBrakeAdjustment.................................36
BeltGuideAdjustment...................................37
PumpDriveBeltTension................................37
HydroDriveLinkageAdjustment...................37
TrackingAdjustment......................................39
HydroPumpSpringTensionSetting...............39
ParkBrakeAdjustment...................................40
Cleaning............................................................40
CleaningandStoringSafety.............................40
CleanDebrisFromMachine...........................40
CleanEngineandExhaustSystem
Area...........................................................40
CleanEngineAirCoolingSystem....................41
RemoveEngineShroudsandClean
CoolingFins...............................................41
CleanGrassBuild-UpUnderDeck.................41
WasteDisposal...............................................41
Troubleshooting....................................................42
Schematics............................................................44
CaliforniaProposition65Warning
Information...............................................46
4
