Exonic EXONIC EXD 6805 User manual

Model Max Power RMS Power 4 ohms RMS Power 2 ohms RMS Power 1 ohms RMS Power 4 ohms Bridged Variable HPF X-over Variable LPF X-over Bass Boostat 45Hz Remote
EXA 600 600W x 4 50W x 4 70W x 4 - 15 0W x 2 50Hz~5 00Hz, 12dB 50Hz~5 00Hz, 12dB n/a -
EXA 550 550W x 1 16 0W x 1 250W x 1 --50Hz~500Hz, 12dB 50Hz~500Hz, 12dB n/a -
EXA 10 50 10 50W x 1 350W x 1 500W x 1 --n/a 50Hz~250Hz, 12dB 0~12dB Gain
EXA 2000D 2000W x 1 350W x 1 500W x 1 1000W x 1 - n/a 50Hz~250Hz, 12dB 0~12dB Gain
EXONIC Amplifier
VARIABLY VERSATILE
Car audio has come a long way, and so have our
amplifiers. EXONIC amplifiers are variably versatile,
designed to adapt to the many different changes in
automotive design. The ultra compact size allows
installation of amplifiers in more locations. igh
level inputs allow easier factory integration and vari-
able high and low pass filters are designed to elimi-
nate unwanted distortion.
DESIGNED TO DEFINE
A new look, EXONIC amplifiers feature redesigned
a whole new chassis to accommodate our twin
board layout . The heat sink has been designed for
a optimal cooling, allowing a larger mounting sur-
face for the output transistors, but overall smaller in
size. EXONIC’s new amplifiers are designed to
define the new generation of car audio amplifiers
on the market today.
ORE POWER PER SQUARE INCH
The ultra compact design, with double sided PCB
boards, and solid state technology gives EXONIC
amplifiers more power per square inch. Darlington
Transistors enable the amplifier to operate more
efficiently by more than 20% and also produce a full
bodied acoustic sound quality that rivals amplifiers 5
times the size.
2
EXA 1050 1050W
• Monoblock subwoofer amplifier
• 2 ohm Stable
• 350 Watts RMS x 1ch (4ohm)
• 500 Watts RMS x 1ch (2ohm)
• Mosfet Power Supply
• Variable Subsonic Filter 10-60 z, 12dB/Octave
• Lowpass Crossover 50~250 z, 12dB/24dB switchable
• Variable Bass Booster 0-12dB at 45 Z
• Frequency Response : 10 - 250 z
• Remote Gain Control
• Short Protect / DC Protection / Thermal Protection /
Soft Turn On-Mute
• Damping Factor > 350
• 8.8" W x 2.24" x 13" D
EXA 600 600W
• 4ch full-range amplifier
• 2 ohm Stable
• 50 Watts RMS x 4ch (4ohm)
•70 Watts RMS x 4ch (2ohm)
•150 Watts RMS x 2ch (4ohm Bridged)
•Mosfet Power Supply
• Variable igh-pass crossover 50~500 z, 12dB/Octave
• Variable Low-pass crossover 50~500 z, 12dB/Octave
• Frequency Response : 20 - 40K z
•Short Protect / DC Protection / Thermal Protection /
Soft Turn On-Mute
• Damping Factor > 500
• Double Side FR4 PCB
• 6.2" W x 2.0" x 8.9" D
EXA 550 550W
• Monoblock subwoofer amplifier
• 2 ohm Stable
• 160 Watts RMS x 1ch (4ohm)
•250 Watts RMS x 1ch (2ohm)
•Mosfet Power Supply
•Variable igh-pass crossover 50~500 z, 12dB/Octave
• Variable Low-pass crossover 50~500 z, 12dB/Octave
• Frequency Response : 20 - 40K z
• Short Protect / DC Protection / Thermal Protection /
Soft Turn On-Mute
• Damping Factor > 500
• Double Side FR4 PCB
• 6.2" W x 2.0" x 8.9" D
Ultra Compact Size
EXA 2000D 2000W
• Class-D Monoblock subwoofer amplifier
• 1 ohm Stable
• 350 Watts RMS x 1ch (4ohm)
• 500 Watts RMS x 1ch (2ohm)
• 1000 Watts RMS x 1ch (1ohm)
• Mosfet Power Supply
• Variable Subsonic Filter 10-60 z, 24dB/Octave
• Lowpass Crossover 50~250 z, 12dB/24dB switchable
• Variable Bass Booster 0-24dB at 45 Z
• Frequency Response : 10 - 250 z
• Remote Gain Control
• Short Protect / DC Protection / Thermal Protection /
Soft Turn On-Mute
• Damping Factor > 500

Rearview Camera
11
EXM 430 MG
OE Rearview irror with integrated GPS Navigation &
Rearview Camera
• OEM Replacement Rearview Mirror with integrated GPS Navigation
• Samsung S3C244OA-400M Z processor
• 64MB internal memory
•2GB SD card for storing Maps, Pictures, and e-Books
•Built-in GPS reciever with highly sensitive (16 channels)
dual antenna design
•4.3” Touch Screen LCD Monitor (16:9 wide screen)
• Integrated speaker • 2 Video inputs w/rearview camera input
• Rearview Camera Included
GPS Navigation
• Navigation Mobile Navigator 6.5
• Millions of points of interest (POIs)
• Voice prompted turn-by-turn directions
• Intuitive menus and stunning 2D and 3D maps
• Spoken street names featuring Text to Speech Technology
•Easy to read map views that adapt to your needs
Bluetooth Function
• Bluetooth hands-free phone • Incoming caller ID display on screen
• Call history Log • Manual/Auto call answering
EX 300
Dual ount Rearview Camera
•Easy to Install Bracket or Flush- ounting
• Low Profile igh Resoulution Camera
•Selectable Display irror / Normal View
• Weather Resistant Moisture Proof Design
• Wide Viewing Angle • 640x480 pixels Resolution
• 1/4” CMOS Color Sensor • 300,000 Pixel Resolution
• Internal Sync System • 380 TVL Resolution
• 2 LUX / F1.2 Minimum Illumination • 45dB + S/N Ratio
• 0.45 Gamma Correction • Automatic Gain Control
• 1.0Vp-p Composite Video Out 75 ohm Load
• -20ºC - 60ºC Operation Temperature
• 12 volt DC Operation • Waterproof IP68
• View Angle : 170º D x128º x 94º V
EX 400
Rearview Camera with Virtual Overlay
Parking Guidelines
• Easy to install Multi-Angle Bracket Mount
• Low Profile igh Resoulution Camera
• Selectable Distortion Corection
• Weather Resistant Moisture Proof design
• Wide Viewing Angle • Super Low Lux Performance
• 720x480 pixels Resolution • 1/4” CMOS Color Sensor
• 350,000 Pixel Resolution • Internal Sync System
• 380 TVL Resolution • 1 LUX Minimum Illumination
• 35dB S/N Ratio • 1.0 Gamma Correction
• Automatic Gain Control
• 1.0Vp-p Composite Video Out 75 ohm Load
• -40ºC - 85ºC Operation • Waterproof IP68
• View Angle : 160º D x 133º x 109º V
•Distortion Correction
•Virtual Overlay Adjustable Parking Guidelines
•Bird’s Eye View ode Compensates for High ount
Low Profile Bracket Type Mount Shown
Selectable Normal or Mirror Image
Distortion Correction compensates for Lens
Distortion to give a true reverse image.
After Correction
Original image
Bird’s Eye View adjusts images from high mounted
cameras to display as if the camera were directly
above parking area.
Corrected Image
Bird’s Eye
Perspective
Virtual Overlay Adjustable Parking Guidelines to enhance parking safety and parking ability.

EXONIC Multimedia Player
EXD 7088
Double DIN 6.2” WVGA Digital TFT ultimedia Disc Player
•6.2" WVGA Digital (800x480 pixels) TFT LCD
• Touch Screen Control
• Rotary Volume Control
• Front SD / USB / AUX Input
• iPod Compatiblel
•Built-in Bluetooth
•Steering Wheel Control Ready
• DVD / VCD / CD / MP3 / WMA / JPEG Playback
• DVD±R / DVD±RW / CD-R / RW Playback
• 4 Channels x 45W MAX Power Output
• 3-Band EQ
• PLL Tuner with 18FM / 12AM Presets
• 4.1 channels Line-Out : Front, Rear and Subwoofer
• PAL / NTSC / SECAM Compatible
• Dual Video Outputs
• Rearview Camera Input
• Telephone Mute
• Multi Function Remote Control
• ISO Cable Connector
• AV Input
First we begin with an OEM quality fit and
finish, and then we add features like iPod
Integration, a high resolution WVGA screen
with stunning picture quality, a full featured
integrated Bluetooth system for hands free
operation, SD card and USB inputs, and even
an auxiliary input to connect more.
EXONIC’s EXD 7088 is an all-in-one multi-
media unit perfect to replace almost any bor-
ing factory double din unit. It’s highly intu-
itive Graphics User Interface makes it simple
to navigate between menus and easy to set
up. Experience video in stunning detail with
its smooth WVGA screen, the internal 45x4
watt amplifier ensure crystal clear sound, and
with several types of media inputs, you are
sure to never run out of music or videos to
watch. Add a rearview camera and connect it
to the EXD 7088’s rearview camera input
and it is automatically selected when the
vehicle is put in reverse. It will even adapt to
most factory steering wheel controls with its
built-in Steering wheel control inputs and
setup–there is no need for additional
adapters or complicated wiring.
EXD 7084
Double DIN 6.2” WVGA Digital ultimedia Disc Player
•6.2” WVGA Digital (800x480 pixels) TFT LCD
• Touch Screen Control
• DVD / VCD / MP3 / MPEG4 / CD / CD-R / CD-RW Compatible
• Integrated SD / USB / AUX Input
•Built-in Bluetooth
•iPod Compatible (Include iPod Cable)
•Steering Wheel Control Ready
• AM / FM Radio Tuner
• U.S.A. / EUROPEAN Frequency
• Auto Store / Preset Scan
• 30 Station Memory
• NTSC / PAL Compatible
• Graphic OSD On Screen Display
• Title / Time / Chapter / Subtitle / Angle
• Treble / Bass / Balance / Fader / Encoder Volume
• Anti-Shock Mechanism
• ESP Electronic Shock Protection
• Repeat / Intro / Random
• Clock, Mute, Preset EQ
• RCA Line Out
• Subwoofer Output
• Audio / Video Input & Output
• Rearview Camera Input
• Multi Function Remote Control
4
High Res WVGA Digital Panel
•6.2” WVGA DIGITAL TFT Panel
• 800x480 Pixel Resolution
• The BEST in LCD Panel Technology
NEW Graphic Use Interface
• Easy to Navigate New Icons
• Accurate Calibrateable Touch Screen
• ighly Intuitive GUI
Steering Wheel Control Built-in
• Use factory steering wheel control
• Simple connection & on-screen setup
• Eliminates need for extra parts
OE Factory Flush ount Fit
• Slim Front Panel Design Sit Flush
• No need for major fabrication
• Sleeve and OEM Mouting Included
USB and Aux-In on Front Panel
• Plays Music, Videos, Pictures
• Simple Plug, Search, and Play
• Front Panel RCA Aux Input
A / F Tuner
•PLL tuner with 18FM/12AM Presets
•4Ch x 45watt MAX Output
• 4.1 Ch Line Out Front, Rear, Sub
SD Card edia Slot
• Read Music, Videos, Pictures
• Simple Plug, Search, and Play
• MP3, WMA, JPEG, AVI
Bluetooth Function
• Bluetooth hands-free phone
• Incoming caller ID display on screen
• On-Screen Controls
ultimedia Player
• DVD/VCD/CD/MP3/WMA/JPEG
• DVD±R/DVD±RW/CD-R/RW
• Easy Media Search
Wiring and Setup
• 3 Band EQ with LPF Sub Control
• 2 Video Outputs
• RCA Audio / Video Input
RADIO DVD IPOD USB BLUETOOTH AUX SWC SET UP

EXONIC Monitor
9
EXM 704
7" TFT LCD Dual Ch Headrest & Sunvisor
onitor
• Wide Screen 16 : 9 Ratio • igh Resolution
(1440 x 234) TFT LCD • 350 : 1 Contrast Ratio
• 400 cd/m2 Brightness • On Screen Display
• 3 Audio / Video Inputs • Built-in IR Transmitter
• NTSC / PAL Auto Switching • Auto Picture Inverting
• Front Panel AV Input • Multi-Function
• Remote Control • Low Reflection TFT LCD
• Low Power Consumption
•Headrest & Sunvisor Shroud Included
• 12V DC Operation
Don't risk cutting into your factory headrests, replace them with the EXP 900. Designed to
replace most vehicle's headrests, the EXP 900 comes as a complete headrest with a built in
9" monitor. The high resolution screen has built-in on screen adjustments, built-in IR transmit-
ter, and will allow for up to 2 Video & 1 Audio inputs. Spacers are included to accommodate
the two standard sizes of the mounting posts. Unlike many competitors using spring loaded
post width adjustments, our monitors have heavy duty screw adjustments to adjust for mount-
ing post width and headrest mounting rigidity, making a superior headrest mounting system.
EXP 900B / 900T / 900G
9” TFT LED Headrest onitor with Pillow
• Universal eadrest Mounting • Wide Screen 16 : 9 Ratio • igh Resolution TFT LED
•350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio • On Screen Display
•NTSC / PAL • Dual Video Input • Single Audio Input • Built-in IR Transmitter
•Aspect Control Mode • Screen Rotation • Dimmer Control
• Sleep Timer • Multi Function Remote Control • 12V DC Operation
Black EXP 900B
Tan EXP 900T
Grey EXP 900G
Heavy Duty Width Adjustment
EX2312LT
• 23" igh Definition Ready LCD TV • Wide-screen 16:9 Aspect Ratio
• igh Resolution W-XGA (1366 x 768) LCD • 550 : 1 Contrast Ratio
• 500 cd/m2 Brightness • 5 Audio & Video Inputs • DVI Input & PC Input
•12V DC Operation •Built-in IR Output
•Direct Speaker Output •Custom ounting Bracket
• PIP (Picture-in-Picture) & Split Screen •176 Degree Viewing Angle •181 ch TV
• DVI Input • PC Input (RGB) • S-Video with Composit AV Inputs
• Dual Component Video with Composit AV Inputs • Cable Ready Input
• AV Output • 25Watts x 2 Audio Output • Graphic OSD • SRS WOW Surround
For any application EXONIC has the solution …
EXF 2030
Wireless F Transmitter
• i-Gain Output for Cleanest
Reception Possible
• Selectable 7 Channel Transmission
• RCA Type Inputs
• Easy Installation
• Low Power Consumption
EXH 12
Wireless IR Headphones
EXH 44
Dual Channel Wireless IR
Headphones
• Variable Volume Control
• On / Off Switch
• Built-in Auto Mute with Auto
Level Control
• Fully Adjustable Fit
• Extremely Lightweight
• Excellent Sound Quality
EXV 40
ulti-Channel Video Amplifier
• Single Video Input with Four Video
Outputs
• Individual Video Output Gain Controls
• Eliminates Video Signal Loss
• Clarifies Weak or Distorted Video Signals
• Low Power Consumption
EXHP 950B / 950T / 950G
9” TFT LCD Headrest Pillow onitor and DVD Player Combo Package
• Universal Replacement eadrest Mounting • Wide Screen 16:9 Ratio
•igh Resolution TFT LCD • 350 : 1 Contrast Ratio
• 400 cd/m2 Brightness Ratio • On Screen Display • NTSC / PAL
• Integrated USB / SD Card Slot • Dual Video Input • Single Audio Input
• Built-in IR Transmitter • Built-in FM Transmitter • Aspect Control Mode
• Screen Rotation • Dimmer Control • Sleep Timer
• Multi-Function Remote Control • 12V DC Operation
•Included 2pcs of Joystick & Game Disc
2pcs of Joystic & Game CD Included

EXONIC Multimedia Player
6
EXD 8090
ultimedia Disc Player with USB, SD / C
• DVD / VCD / MPEG4 / MP3 / WMA / CD / CD-R /
CD-RW Compatible
• Front USB / SD / MMC / AUX Input
• NTSC / PAL AUTO Compatible
• Anti-Shock Mechanism
• ESP Electronic Shock Protection
• On Screen Display
• Audio & Video Output
• Multi Angle Mounting Capability
• Clock / Mute / Zoom / Loud Function
• Volume / Bass / Treble / Balance / Fader control
• DSP Sound Effect (Pop / Flat / Classic / Rock)
• Extension Remote IR
• Multi Function Remote Control
Experience EXONIC’s EXD 7092, an all-in-one multimedia power house
all designed into a single din motorized touch screen unit. Watch as the dis-
play motorizes out, a stunningly clear 7inch WVGA monitor, intuitive touch
screen menus allow you to navigate through the limitless functions.
Multimedia functions allow playback of DVD, VCD, and CD playback as well
as a USB and SD card inputs, and even an auxiliary input so that you will
never run out of music or videos to watch. Crystal clear sound is produced
with its internal 45watt x 4 amplifier and Multiband EQ. Operate your cell
phone hands free with the integrated full featured Bluetooth system which
allows dialing, address book, search, and even voice recognition and dis-
plays right on the screen. Best of all never get lost with the built-in touch
screen navigation system , with millions of points of interest, you can get
where you want to go, when you want to go. Add a rear view camera to the
EXD 7092 and when the vehicle is shifted into reverse it will automatical-
ly display the video. It will even adapt to most factory steering wheel con-
trols with its built-in Steering wheel control inputs and setup-there is no
need for additional adapters or complicated wiring.
EXD 7092
otorized 7” WVGA Digital In-Dash ultimedia Disc Player
•7” WVGA Digital (800x480 pixels) Display
• Touch Screen TFT LCD
•Detachable Face
• Fully Motorized View Angle
•DVD / VCD / MP3 / MPEG4 / CD / CD-R / CD-RW Compatible
•iPod Compatible & iPod Cable include
•Built-in BLUETOOTH
•Integrated SD / USB / AUX Input
•SWC Steering Wheel Control ready
• NTSC / PAL Compatible
• Graphic OSD On Screen Display
• Anti-Shock Mechanism
• ESP Electronic Shock Protection
• AM / FM Radio Tuner
• U.S.A. / EUROPEAN Frequency Spacing
• Auto Store / Preset Scan / 30 Station Memory
• Title / Time / Chapter / Subtitle / Angle
• Treble / Bass / Balance / Fader / Encoder Volume
• Clock / Mute / Preset EQ / Repeat / Intro / Random
• RCA Line Out
• Subwoofer Output
• Audio / Video Input & Output
• Digital Audio Output
• Rearview Camera Input
• Multi Function Remote Control

EXONIC Headunit
7
EXONIC 150
W A / P3, CD Receiver
•CD / MP3 / WMA / CD-R / CD-RW Compatible • Front AUX Input • Detachable Face
• MP3 File and Folder Search by Name • MP3 Track and MP3 Character Search
• MP3 ID3 TAG (Song / Album / Artist Title) Display • Multi-Color LCD Display
•DSP Sound Effect (Pop, Rock, Classic, Flat) • Volume / Bass / Treble / Balance / Fader control
•AM / FM Radio Tuner • 30 Preset Stations (18 FM / 12 AM) • Auto Memory Store
• MOSFET 45W x 4 Audio Output • 2 Channels x 2V Line-Out • Intro Scan
• Optional Multi Function Remote Control
EXONIC 250
W A / P3, CD Receiver with USB, SD / C
• CD / MP3 / WMA / CD-R / CD-RW Compatible • Integrated USB Port • Integrated SD / MMC Card Slot
• Front AUX Input • Detachable Face • iPod Ready • MP3 File and Folder Search by Name
• MP3 Track and MP3 Character Search • MP3 ID3 TAG (Song / Album / Artist Title) Display
• Volume / Bass / Treble / Balance / Fader control • DSP Sound Effect (Pop / Flat / Classic / Rock)
• Auto Memory Store • Repeat / Program / Random Play • AM / FM Radio Tuner
• 30 Preset Stations (18 FM / 12 AM) • MOSFET 45W x 4 Audio Output
• 4 channels x 4V Line-Out • 4V Subwoofer Output • Multi Function Remote Control
EXONIC 500
Flip-Down W A / P3, CD Receiver with USB, SD / C
• CD / MP3 / WMA / CD-R / CD-RW Compatible • Integrated USB Port • Integrated SD / MMC Card Slot
• Front AUX Input • Flip-Down and Detachable Face • iPod Ready • MP3 File and Folder Search by Name
• MP3 Track and MP3 Character Search • MP3 ID3 TAG (Song / Album / Artist Title) Display
• Volume / Bass / Treble / Balance / Fader control • DSP Sound Effect (Pop / Flat / Classic / Rock)
• Auto Memory Store • AM / FM Radio Tuner • 30 Preset Stations (18 FM / 12 AM)
• MOSFET 50W x 4 Audio Output • 4 channels x 4V Line-Out
• 4V Subwoofer Output • Multi Function Remote Control

EXONIC Monitor
8
EXM 930HP
9” TFT LCD Ceiling ount onitor
with Built-in DVD Player and Headphones
• DVD, DiVX, MP4, MP3, VCD, SVCD, CD, CD-R, CD-RW, WMA Playback
• Wide Screen 16:9 Ratio • USB & SD Card Slot
• Low Reflection, igh Resolution TFT LCD • Swivel Display
• 350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio • On Screen Display
• NTSC / PAL Auto Switching • Dual Audio & Video Input • Audio & Video Output
• Built-in FM Transmitter • Built-in IR Transmitter • Built-in Dome Lighting
• Multi-Function Remote Control • 12V DC Operation
•Interchangeable Color Cover (Black, Grey, Tan) Included
EXM 1100
11” TFT LCD Ceiling ount onitor
•Wide Screen 16 : 9 Ratio • Low Reflection, igh Resolution TFT LCD
• Swivel Display • 350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio
•On Screen Display • NTSC / PAL Auto Switching • Dual Audio & Video Input
• Built-in FM Transmitter • Built-in IR Transmitter • Built-in Dome Lighting
• Multi Function Remote Control • Audio & Video Output • 12V DC Operation
•Interchangeable Color Cover (Black, Grey, Tan) Included
EXM 110HP
11” TFT LCD Ceiling ount onitor
with Built-In DVD Player
• DVD, DiVX, MP4, MP3, VCD, SVCD, CD, CD-R, CD-RW, WMA Playback
•Wide Screen 16 : 9 Ratio • Low Reflection, igh Resolution TFT LCD
•Swivel Display • 350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio
• On Screen Display • NTSC / PAL Auto Switching • Dual Audio & Video Input
•Audio & Video Output • Built-in FM Transmitter • Built-in IR Transmitter
•Built-in Dome Lighting • Multi Function Remote Control• 12V DC Operation
•Interchangeable Color Cover (Black, Grey, Tan) Included
Interchangeable Color Cover (Black, Grey, Tan)
Interchangeable Color Cover (Black, Grey, Tan)
EXM 900DVD
9” WVGA Digital TFT LCD Ceiling ount onitor with Built-in DVD Player
•9” WVGA Digital (800x480pixels) TFT LCD
• DVD, MP4, MP3, VCD, SVCD, CD, CD-R, CD-RW, JPEG, Kodark Playback
• Wide Screen 16:9 Ratio • USB & SD Card Slot (8~16GB) • Touch Button Control
• Low Reflection, igh Resolution TFT LCD • 350 : 1 Contrast Ratio
• 400 cd/m2 Brightness Ratio • On Screen Display
• OSD Languages : English, Spanish, French, German, Chinese
• Audio / Video Input & Output • Built-in FM Transmitter • Built-in IR Transmitter
• Built-in Dome Lighting & Door Light • Built-in Speakers
•Included Joystic & Game CD
• Multi-Function Remote Control • 12V DC Operation
Wireless IR eadphones Included
Joystic & Game CD Included
Interchangeable Color Cover (Black, Grey, Tan)

EXONIC Multimedia Player
5
EXD 6805
7” Touch Screen In-Dash ultimedia Disc Player
• 7” Wide TFT LCD Touch Screen
•Fully otorized View Angle • Detachable Face
• DVD / MPEG4 / VCD / CD / MP3 Compatible
• Graphic OSD On Screen Display
• NTSC / PAL Compatible
• AM / FM Radio Tuner
• U.S.A. / European Frequency
• Built-in BLUETOOT A2DP & AVRCP
• Integrated USB Port
• Integrated SD / MMC Card Slot
• Anti-Shock Mechanism
• ESP Electronic Shock Protection
• Rearview Camera Input
• Front AUX Input • RCA Line Out
• Dual Video Output • Subwoofer Output
• TA Traffic Announcement
• Multi Language Setup : OSD, Subtitle, Audio, Menu
Language (English / Spanish / French / Portuguese /
German / Italian / Russian)
• Auto Store / Preset Scan
• Clock, Title, Chapter, Subtitle & Angle
• Treble / Bass / Balance / Fader / Volume /
LO / DX & ST / MO
• Preset EQ – POP / ROCK / JAZZ / CLASSIC / FLAT
• Multi Function Remote Control
EXD 7082
otorized 7” Touch Screen 2-DIN ultimedia Disc Player
• 7” TFT LCD Touch Screen
•Fully otorized View Angle
• DVD / VCD / MP3 / MPEG4 / CD / CD-R / CD-RW Compatible
•Integrated SD / USB / AUX Input
•AM / FM Radio Tuner
•U.S.A. / EUROPEAN Frequency
•Auto Store / Preset Scan
• 30 Station Memory
• NTSC / PAL Compatible
• Graphic OSD On Screen Display
• Title / Time / Chapter / Subtitle / Angle
•Treble / Bass / Balance / Fader / Volume Control
•Anti-Shock Mechanism
•ESP Electronic Shock Protection
• LO / DX & ST / MO Selector
• Repeat / Intro / Random
•Clock, Mute, Preset EQ
•RCA Line Out
• Subwoofer Output
• Audio / Video Input & Output
• Rearview Camera Input
• Multi Function Remote Control

RearView Camera
10
Compatible
Combine any of our rearview cameras with our OEM
Navigation Interfaces for a factory worthy setup. Clearly
display what is behind your vehicle direct to your factory
screen. Designed with safety in mind our cameras give
you a wide angle view to see what you normally may not
when using your rear view mirror.
Waterproof
Completely water proof design. No need to worry
about rain or dust, the camera is sealed from the ele-
ments inside its own case. Our extremely durable alu-
minum case housing with stands all water conditions
without corrosion or rust.
Night View
Our cameras are designed to adapt to low light situa-
tions. This can be extremely useful when parking at
night or in dark parking spaces. Our EXR 200 even
has built-in Night Vision for very low or no light sce-
narios.
Introducing OEM License Plate earview Camera
EXR 909NB
EX 909NC / Chrome
EX 909NB / Black
License Plate Rearview Camera Built-in Night Vision
•igh Sensitive 1/3” Sony CCD • 250,000 Pixels
• 420 TV Line orizontal Resolution
•Moisture Free Waterproof • Reverse Image
•150 degree Wide Angle of View
• Remarkable True Color Reproduction
•Excellent Auto White Balance
• Super Sensitive Low Lux Image Capture
•Aluminum Die-Casting Frame • Waterproof (IP67)
• 12V DC Operation • Remarkable Low Lux Performance of 0.8 Lux at F2.0
EX 100
Bullet Type earview Camera
• Moisture Free Waterproof
• 1 Lux low Light Color Camera
• Wide Angle of View • Reverse Image
• 12 volt DC operation
EXR 909NC
Take A look Back
EX 900C / Chrome
EX 900B / Black
License Plate Rearview Camera
• igh Sensitive 1/3” Sony CCD • 250,000 Pixels
• 420 TV Line orizontal Resolution • Moisture Free Waterproof
• Reverse Image • 150 degree Wide Angle of View
• Remarkable True Color Reproduction • Excellent Auto White Balance
• Super Sensitive Low Lux Image Capture • Aluminum Die-Casting Frame
• 12V DC Operation • Remarkable Low Lux Performance of 0.8 Lux at F2.0
•Waterproof (IP67)
EXR 900B
EXR 900C
EXM 352
3.5” Digital TFT LCD Rearview onitor
• Adapts to any Rearview Camera • On Screen Display
• Dual Video Inputs • 300 cd/m2 Brightness
• Brightness, Contrast, Color & Tint Control
• Reverse Trigger Delay Time • Seperate Volume Up/Down
• Screen Mode : Mirror Image / orizontal Flip / Vertical Flip
• Adjustable Suction Cup Mount included • 12V DC operation
US Patent Pending
Night Vision
EX 200
Bullet Type earview Camera
• CCD built-in Night Vision
• Moisture Free Waterproof
• 1 Lux low Light Color Camera
• 150 degree Wide Angle of View
• 250,000 Pixels
• Reverse Image
• 12 volt DC operation
EX 359B (Black)
EX 359C (Chrome)
• EXR 900B / EXR 900C License Plate Rearview Camera
• EXM 352R 3.5” Digital TFT LCD Rearview Monitor
EA VIEW CAME A PACKAGE
US Patent Pending
Night Vision
EX 150
Bullet Type earview Camera
• CMOS built-in Night Vision
• Moisture Free Waterproof
• 1 Lux low Light Color Camera
• Wide Angle of View • Reverse Image
• 12 volt DC operation
Night Vision

EXONIC Speaker
The punishment that is delivered to car audio sub-
woofers is far greater than any other component in
an audio system. It is very easy to make a speaker
look good but it is a very tedious and time-consum-
ing task to make them perform well. We take
tremendous pride in each of our three subwoofer
series and quality from top to bottom is never com-
promised. The new EXONIC®Series Subwoofer with
flat progressive spider, flat tinsel woven wire and 2-
1/2” 4ohm dual voice coils will be able to get the
maximum power from your amplifiers
Model Size Power (RMS/Pea ) Cone Voice Coil Impedance Freq. Response SPL
EXW 100 10” 200 / 400 Non-pressed kraft pulp 2’ 4-layer D C DUAL 4 ohms 32 - 1KHz 85 dB
EXW 120 12” 250 / 500 Non-pressed kraft pulp 2’ 4-layer D C DUAL 4 ohms 28 - 1KHz 88 dB
EXW 101 10” 200 / 400 Non-pressed kraft pulp 2’ 4-layer SINGLE C SINGLE 4 ohms 32 - 1KHz 85 dB
EXW 121 12” 250 / 500 Non-pressed kraft pulp 2’ 4-layer SINGLE C SINGLE 4 ohms 28 - 1KHz 88 dB
The EXONIC EXS Series Speakers are designed
to give you the same great sound quality experience
you are used to. Superior engineering and con-
struction, these speakers are built from the ground
up. They feature a new stamped steel basket design,
mounted magnet structures, and tweeters that are
designed for optimal efficiency. The new IMPP
Chrome Cone design allows structural rigidity pro-
ducing smooth bottom end, rich mid-ranges and
metal dome tweeters for that brilliantly crisp high.
EXONIC - Sound that you will enjoy for hours.
EXS 252 200W
•5" 2-way • IMPP Chrome Cone
•4ohm • 80-22K z
EXS 265 240W
• 6.5" 2-way • IMPP Chrome Cone
•4ohm • 60-22K z
EXS 268 240W
• 6x8" 2-way • IMPP Chrome Cone
• 4ohm • 60-22K z
EXS 369 400W
• 6x9" 3-way • IMPP Chrome Cone
•4ohm • 60-22K z
Model Size Component Power (RMS / Pea ) Cone Impedance Freq. Response Depth (inch) Depth (mm)
EXS 252 5” 2-Way 50 w / 200 w IMPP Chrome 4 ohm 80 - 22 KHz 1-7/8” 48 mm
EXS 265 6.5” 2-Way 60 w / 240 w IMPP Chrome 4 ohm 60 - 22 KHz 2-1/8” 53 mm
EXS 268 6” x 8” 2-Way 60 w / 240 w IMPP Chrome 4 ohm 60 - 22 KHz 2-1/8” 53 mm
EXS 369 6” x 9” 3-Way 100 w / 400 w IMPP Chrome 4 ohm 60 - 24 KHz 2-7/8” 72 mm
3
EXW 100 400W
Dual 4 ohms
EXW 120 500W
Dual 4 ohms
EXW 101 400W
Single 4 ohms
EXW 121 500W
Single 4 ohms

EXONIC
Mobile Entertainment
®
Ample Audio, Inc. • 6293 Burnham Ave. Buena Park, CA 90621 • www.exonicmobile.com
EXONIC Digital TV
EXDTV 100
ATSC Digital TV Tuner with Antenna
•igh quality ATSC / QAM Demodulator • Antenna Power Output
• Extension Remote Eye • OSD On Screen Display • Closed Captioning
• Favorite Channels • Selectable A/V Input • Compact Size (1” x 5” x 3”)
•igh Gain Mini Magnet Mount Antenna Included • 12 VDC Operation
Upgrade your existing setup to receive digital TV channels with EXONIC’s EXDTV 100 Digital TV tuner. The pack-
age comes complete to upgrade your soon to be obsolete analog TV tuner. Measuring only 1” x 5” x 3” this com-
pact TV tuner will fit just about anywhere in most vehicles and comes equipped with an extension IR, power cables,
a remote control, and all necessary wiring. The unit features a high quality ATSC / Qam demodulator, built-in anten-
na power supply for amplified TV antennas, a complete OSD menu with favorite channels menu and support for
closed captioning. The EXDTV 100 also has an A/V input to use with a game system or DVD player and is selec-
table through the remote. Included is a high gain mini magnet mount antenna, measuring only 5.5” tall, that can eas-
ily be mounted and removed for security purposes.
EXM 1100DTV
11” TFT LCD Ceiling ount Digital TV
• Wide Screen 16:9 Ratio • Low Reflection, igh Resolution TFT LCD
• Swivel Display • 350:1 Contrast Ratio • 400 cd/m2 Brightness Ratio
• On Screen Display • NTSC / PAL Auto Switching
• Dual Audio & Video Input • Built-in FM and IR transmitter
• Built-in Dome Lighting • Multi Function Remote Control
•Interchangeable Color Covers Included • 12 VDC Operation
The first 11” Ceilling Mount Monitor with built-in ATSC Digital TV tuner. This unit not
only is the first to have a built-in Digital TV Tuner but also it includes three color inter-
changeable covers to match most vehicles factory color. Each color does not have
to be special ordered, instead it is included in the box. These colors include Black,
Grey, and Tan. The screen features a 16:9 ratio wide screen, high contrast LCD dis-
play, which also swivels 180 degrees for easy viewing. Built-right into the screen is
an IR transmitter, FM transmitter, dome lighting, and Digital TV Tuner, The EXM
1100DTV includes a high quality ATSC / QAM demodulator, built-in antenna power
supply for amplified TV antennas, a complete OSD menu with favorite channels
menu and support for closed captioning Also included is a high gain mini magnet
mount antenna, measuring only 5.5” tall, that can easily be mounted and removed for
security purposes
Interchangeable Color Cover (Black, Grey, Tan)
Matching your OEM interior color is just a snap away. Select the color that best matches your interior
and just snap it for a factory finish look. Best of all these snap on color covers are included with each unit
so there are no additional parts to buy or order.
DTV Tuner and ATSC M/H Tuner
11” Ceilling Mount Digital TV
EXDTV 200MH
ATSC and STSC H DTV Receiver Combo
•Easy installation & Operation • User friendly GUI(user interface)
• igh-Performance ATSC & M/ module built-in
• Electronic Program Guide • Closed Caption available
• Noise cancellation high-quality Digital picture
• igh-sensitivity Pole antenna（Magnet type)
• All functions by Compact Remote Controller
• Aspec Ratio Setting(4:3, 16:9) • Compact size and light weight
• A/V IN 1C (optional). • A/V OUT 1C for TV monitor and etc.
• Auto Time Setting & Time Zone Setting
• Selected ATSC D and ATSC M (Mobile)
Welcome to enjoy high-quality crystal-clear ATSC Digital TV and ATSC M Mobile
Digital TV in which an enhanced ATSC & M/ combo module is built, wherever
you drive or stay as long as you are with FOVU SDMK-110CB ATSC(Terretorial
D Digital TV) Plus ATSC M (Digital Mobile TV) Combo Digital TV Receiver.
