Register your product and get support at
EN Quick start guide
CED1700

1
a

R-CH
L-CH
R-CH
L-CH
1
2
3
4
567890!"
P
R
N
D
2
L
$%
&
§
/
b

2a
183 mm
53mm
5mm
b

3
c

4

English
Install the car audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Connect wires 1
1Check the car’s wiring carefully, then connect
them to the supplied ISO wires. a
Connector Connect to
1 Yellow wire The +12V car battery which
is live at all times.
2 Blue wire The electric antenna control
lead or power supply lead of
the antenna booster
If there is no electric antenna
or antenna booster, or it is
manually operated telescopic
antenna, it is not necessary
to connect this lead.
3 Black wire A metal surface of the car
First connect the black
ground (earth) lead, then
connect the yellow and red
power supply leads.
4 Red wire The +12V power terminal
which is live in the accessory
(ACC) position of the
ignition switch
If there is no accessory
position, connect to the
+12V car battery terminal
that is always live. Be sure
to connect the black ground
(earth) lead to a metal
surface of the car rst.
5 Green and
green/black
wires
Left speaker (Rear)
6 White and
white/black
wires
Left speaker (Front)
7 Gray and
gray/black
wires
Right speaker (Front)
Connector Connect to
8 Purple and
purple/black
wires
Right speaker (Rear)
2Connect the other end of the supplied
standard connector to the car audio
system. b
Connector/
Obeject
Connect to/with
1 Pink wire Extension wire
2 2.5m extension
wire (Not included)
Parking brake (-)
3 Brake switch
4Ground
5 ISO wires Connected in step 1
above.
6 Grey wire Rear line out Left/
Right
7 Black wire Front line out Left/
Right
8 Blue cable Subwoofer
9 Red cable Aux Right
10 White cable Aux Left
11 Yellow cable Video in
12 Yellow cable Camera in
13 Yellow cable Video out 1
14 Yellow cable Video out 2
15 Purple wire Reverse camera (B+)
16 Gearbox switch
17 Reverse gear signal Back lamp lead +
Mount in the dashboard 2
1If the car does not have an on-board drive
or navigation computer, disconnect the
negative terminal of the car battery.
2Ensure that car dashboard opening is within
these measurements: a
3Slide the unit into the dashboard until a
click sound is heard. b
4Attach the trim plate. c
5Reconnect the negative terminal of the car
battery.

Turn on
1Press to turn on the unit.
2Touch a language to select.
To adjust screen brightness, press•DIMMER
on the remote control, then press or .
To turn off the unit, press and hold•for
3 seconds.
Set date and time
1Touch to display main menu.
2Touch [Settings].
3Touch to access 2nd page.
4Touch [Date].
5Touch year digit to highlight this digit.
6Touch / to set year.
7Repeat step 5 and 6 to set month and day.
Set Time
1Touch [Set time].
2Touch hour/minute digit to highlight the digit.
3Touch / to set hour/minute.
Set time format
1Touch [Clock Mode] repeatedly to toggle
between [12Hr] and [24Hr] options.
Listen to Radio
1Touch to display home menu.
2Touch [Radio].
3Touch on FM or AM repeatedly on the left
of the screen to select band:
4 Briey touch or to tune to a radio
station by step.
Touch•or for over 1 seconds to
tune to a radio station automatically.
Play disc 3
You can play video, audio or images stored on the
following discs:
DVD video, DVD-R, DVD-RW•
VCD•
Audio CD, CD-R, CD-RW•
1Insert the disc into the disc slot with label
side facing up.
Countries where you
bought the unit
Supported DVD
region code
China
Asia Pacic, Taiwan,
Korea
Latin America
Russia, India

Play USB device 4
Note
Ensure that the device contains playable•
content.
1Open the lid of USB socket.
2Insert the USB to the USB socket.
Play with Bluetooth device
Pair the Bluetooth-enabled devices
1Turn on the Bluetooth function on your
device.
2Search for other Bluetooth device with
your device.
3Select “CED1700” in the pairing list.
4Enter default password “0000”.
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
CED1700_51_QSG_V1.0
Make a call
1Touch on top of the screen.
2Touch number icons directly to input phone
number.
3After the phone number entered, touch .
Receive call
By default, all incoming calls are received
automatically.
1If there is incoming call, [Incoming call...]
ashes on the screen. Speak into the
Bluetooth microphone.
2When conversation ends, tap (red) to
terminate the call.
