EXPLON EDC-LM2 User manual

EXPLON Dash Camera
7” Touch screen Full HD 1080P
Rear View Mirror
[EDC-LM2]
INTRODUCTION AND NOTICE
•Thank you for purchasing our Explon Dash Camera- 7” Touch screen Rearview Mirror
with Rear support
•This user manual will contain complete instructions on how to operate your Dash Cam
and is highly recommended to read it prior to use
•This product is intended for use in motor vehicle solely. When mounting the product,
ensure the device is not installed where it might interfere with the driver's field of vision
or disturb deployment of the airbag
•The product requires a memory card to operate, suggested type is a high-speed class
10, 32GB max micro SDHC card
•Do not leave the product in direct sunlight for a long time or if the temperature goes
above 170°F (75°C)
BOX INCLUDES
Front- touch screen mirror
Dash Cam
Rear camera
Car charger and
cable
18 ft Rear cam cable
2 mounting rubber straps and
screws
User manual
INSTALLATION GUIDE

•Before installation, please insert the Memory card in TF slot and format the memory card
prior to use
•Install the front camera over the rearview mirror and attach it with the rubber bands,
adjust its position and lens angle in accordance with your needs and to ensure clear
vision
•Connect the power adapter to the 12V cigarette lighter socket and route the cable in the
interior/ hide the excess cable into the interior panel and gaps to obtain visual aesthetics
•It is recommended to connect rearview camera above the license plate; this might
require drilling 2 holes and attaching with the screws from the kit
•Connect RED cable to the positive lead of the reverse light wires (cords that connect
your car’s tail lights to the dashboard) IMPORTANT NOTE: This might require a little
knowledge of car electronics, in case you are not sure how to properly set it up, it is
highly recommended to seek professional help, such as car electrician.
•Route the rear cam cable to the front of the car and connect it to the main unit
•After the installation is completed, please turn the unit ON by pressing the Power button
located on the bottom of the Front- mirror Dash Cam and start the engine
KEY BUTTONS/ TOUCH SCREEN FUNCTIONS DESCRIPTION
1. USB port
2. AVIN
3. SD card slot
4. GPS port
5. Reset
6. Power button

MAIN MENU
1. Car DVR
2. Photograph
3. Playback
4. Settings
CAR DVR
Once the Dash Cam is installed and the car is in the ignition, the device will power on and you
will be able to start video recording.
Once the recording is started, the red indicator will be flashing next to this icon. If the
recording is stopped, there will be no red flashing indicator.
Use this icon to STOP/START recording
Return to the main menu
Turn ON/OFF audio recording
Manually lock the current video file
Switch between Front and Rearview cam

PHOTOGRAPH
Use this icon to take a picture
Return to the main menu
PLAYBACK
Return to the main menu
Tap this button to delete/erase video or photo
•Previous video
•Rewind
•Play/pause •Forward
•Next video
SETTINGS
Tap this button to enter the settings menu.
•Video Resolution: tap this button to select your preferable video resolution
(default:1080FHD)
Options:1080FHD/ 1080P/ 720P /VGA
•Photo Resolution: tap this button to select your preferable photographic resolution

(default:12MP)
Options:12M/ 10M/ 8M /5M
•Motion Detect: ON/OFF
(default: OFF)
•G-setting: OFF/ High/ Medium/ Low
(default: OFF)
•Video sound: ON/OFF
(default: ON)
•Screen saver OFF/1 Minute/ 2 Minutes/ 3 Minutes
(default: OFF)
•Language ENG/RS/CH/JP/
•Date/Time: ON/OFF
NOTE: Scroll up to see the second page of the settings menu
•Loop video: 1 Minute/ 2 Minutes/ 3 Minutes/ 5 Minutes
(default: 2 Minutes)
•Auto Power Off: OFF/1 Minute/ 3 Minutes/ 5 Minutes
(default: OFF)
•Park Guard: ON/OFF
(default: OFF)
•Frequency 50/60Hz
•Default Setting: OK/Cancel
•Format: OK/Cancel
•Version: GT911-SC2363-WT-20181109 (may vary!)
FEATURED FUNCTIONS
Loop recording
Once the memory card gets full, the device will keep recording in a loop, erasing and overwriting
earlier recordings in a continuous looping fashion. You can set it to record in small, manageable
size clips 1 Minute/ 2 Minutes/ 3 Minutes/ 5 Minutes long.
Park guard
With this function set to ON, after you stop the car, the device goes to standby mode and starts
recording when it detects a significant shock. After the recording is finished, it will automatically
turn off and keep the recording “locked” until you erase it manually.

G-setting
When an impact occurs, it will automatically save the video event. High selection will make the
system more sensitive, and low setting ensures the system will react only to greater shocks.
Screen saver
It refers to the time after which the unit will automatically turn the screen off while the device is
still recording. It is highly recommended to use this feature to save power and reduce distraction
while driving.
Product specifications
Screen size
7 inch
Video resolution
1080FHD/ 1080P/ 720P /VGA
File format
MOV
Photo format
JPEG
Microphone
Support
Speaker
Built-in
Storage
Support Micro SD 32GB class 10
Battery
Built-in 450mAh
Operating temperature
-20°C to 60°C
Front+ Rear Dual Recording
Front: 1080FHD WDR + Rear: VGA
Wide angle lens
Front 170°/ Rear 140°
Support
Loop Recording
Support
Auto Power off
Support
Parking monitoring
Support
G- sensor
Support
Auto-reversing view
Support
Touch screen
Support
Sound recording
Support
