Export Import Global AK-3509 User manual

MEGAPIXEL NETWORK IP CAMERA FOR OUTDOOR USE
ART. NO. AK-3509
Thank you for your purchasing our product!
IMPORTER & DISTRIBUTOR:
GLOBAL EXPORT –IMPORT LTD.
H-1151 BUDAPEST SZEKELY E. U. 11.
http://www.global-export-import.eu

Megapixel Full HD IR Network Camera
User Manual
Warning
In case of fire or lightning, pls don’t put product in damp and raining place, operate or maintain
according to the user manual.
Be careful when you see attachment with a Dangerous Voltage which will cause serious
voltage accident.

Notice:
1. Ensure your equity, pls read the user manual carefully before you use the product
2. Pls contact eligible people if you need install and maintain the product
3. Input voltage of this model is DC 12V
4. Working Environment: temperature of -10°C~+60°C, relative humidity
under 85%
5. Pls don’t exceed the user manual’s standard range of temperature, humidity
and voltage.
Product structure illustration
External power supply and camera hardware connection
Connect 12V 1A power supply with power interface, plug network wire, wait for about 2
minutes, machine start-up successful.
Setting instruction when camera connect with PC

Setting instruction when camera connect with PC
IE view: Enter camera’s IP address in IE’s address bar, install control, then you can view image
Preview in IPC client: Install client software, click “settings” in software GUI, choose
megapixels HD camera, click “search” button in “nexwork setting”, software will automatically
search the cameras in Intranet, and show the cameras’ IP address in “searched IP cameras”,
double click the IP address, it will automatically append IP to the form of “connected IP
camera”, without appending cameras, the GUI can’t preview image, click enter, log out preview
UI, camera image will be showed on GUI in 3-5 seconds.
PS: If there is no image, pls disconnect the firewall in system control panel
Camera’s default IP: 192.168.1.88. User name:
admin Password：(No password)
Setting of camera connect with NVR illustration
Camera connect with NVR
Click “parameter setting” button in NVR software GUI, enter IPC setting UI, click “search”
button, system will automatically search cameras in intranet and show the cameras’ IP
address in the form, double click the IP address, it will automatically append IP to the form of
“connected IP camera”, without appending cameras, the GUI can’t preview image, click enter,
camera image will be showed on GUI.

Product Features
720P
Sensor
1.3 megapixel CMOS
Video compression
H.264
IR range
10m - 50m
Dual stream
1280x720(25fps)/432x240(25fps)PAL
1280x720(30fps)/432x240(30fps)PAL
Lens
3.6mm、4.2mm、6mm、8mm、12mm
Min illumination
0.1Lu/F1.2(color)、0 Lux with IR
Day&Night
IR cut filter with auto switch
Frame Rate
1- 25 FPS(FPS); 1-30 FPS ( NTSC)
Bit Rate
500kbit/s~3 Mbit/s
Protocols
TCP、OUP、IP、HTTP、FTP、SMTP、DHCP、DNS、ARP、ICMP、
POP3、NTP
Communication Interface
RJ45 10M/100M self-adaptive Ethemet
Power supply
DC 12V 1A
Record mode
NVR 、IP dient software
Power consumption
Max 6W
Operating Conditions
-20 ~ +60 摄氏度
Operating humidity
10 ~ 85%
Product Size

Client software user manual
1．the introduction
1.1 the introduction
1.2 system requirements
Operating system：over window 2000
CPU：Inter Pentium 4 2.4G or higher
Memory：512M or more
Monitor : support 1024*768 and the higher resolution
Card : support directdraw to accelerate and opening.
1.3 convention
In order to the simplify describe in this manual ,will describe as following .
client software called software
DVR DVS called equipment
"Click" means to click the left mouse button
"double click"means to double click the left mouse button
"Right click" means to click the right mouse button
2. software running
2.1 Running and login
2.11 Double-click The shortcut to run the software。
2.12 Login
Choose the user name ,enter the password clink to enter the program. you can choose
“automatically login,” so it will not appear on the window next time.
2.2 introduction of the Software interface

introduction of the Software interface
1) system and the button bar
Interface can be locked, minimize the window to the taskbar, close program operation。
2 )Tab bar
Contain the function of the different software models
Remote preview ：Real-time preview on the device
Remote playback :Local video playback and remote playback
Remote settings: Configuration setup
Local settings: user management,device management,system setup
3) device tree
Show each equipment and to add management group
4 )Preview Display Window
Real-time preview of the device channel
5 )PTZ control window
For PTZ control, adjust the picture
6 )Preview Control Bar
Preview control to stop, drawings, switching screen modes, full screen, rotation, etc.
3.Equipment Management
Before using the software to operate, need to add and configure the device operation. Click
the tab bar "Configure" tab to enter configuration mode
1
2
3
4
5
6

Click on the left navigation bar set- "Device Manager" item to enter the device management
interface.
4.1 device tree configuration
When the initial run the software, the list defaults to an empty tree, right-click any blank space
can be a list of trees to add area.
Fill in the name of the regional title bar and click OK you can add a tree to the list area, and
because of this added area as the first area, there is no higher in the region area, the higher
the regional name column blank.

Regional add is complete, right-click the regional nodes may choose to sub-region, add the
operation of equipment
Right-click the Add area, pop-up a regional management menu.
Select "Add a sub-regional" sub-regions can be added.
Select "Delete area" will be removed in a selected state area.
Note: If you remove the region which contains other regions under, equipment or channels,
then delete operation will not only delete the selected area, but will remove all of the regions
under this region, equipment or channels; if the region is under the preview channel or Video
will be given a warning.
3.1.1 Manually add the device
Right-click the Add area, pop-up regional management menu, select "Add Device."
Options
Explain
device address
Device IP address or domain name
device port
device port number
http port
http port number
User name
Device’ Registered User name
User password
Device’ Registered User password
Device name
Add the device name it can be customized
channel
Device’ Channel number, please fill in the actual situation
In area
the name of the host region

click“test connection”to check if it could connect to the device
3.1.2 Search the LAN-line equipment
Right click In any regional / sub-regional, click the menu item in the search Device, search the
same LAN-line equipment
Choose one of them，click“add device”
