Extron electronics NetPA Ultra Series User manual

User Guide
NetPA U 8001 SUB
NetPA Ultra Series
Mono Subwoofer Amplifier with Dante and DSP
68-3414-01 Rev. A
10 22

Safety Instructions
Safety Instructions • English
WARNING: This symbol, , when used on the product, is intended to
alert the user of the presence of uninsulated dangerous voltage within
the product’s enclosure that may present a risk of electric shock.
ATTENTION: This symbol, , when used on the product, is intended
to alert the user of important operating and maintenance (servicing)
instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron website,
www.extron.com.
www.extron.com
I

注意：产品上的这个标志意在提示用户, 设备随附的用户手册中有重
要的操作和维护(维修)说明。

Copyright
© 2022 Extron. All rights reserved. www.extron.com
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or Extron (see the
current list of trademarks on the Terms of Use page at www.extron.com):
Registered Trademarks (®)
Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, eLink, Flat Field, FlexOS, Glitch Free, GlobalConfigurator,
GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink, MediaPort, NAV,
NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch, StudioStation,
SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP, XTPSystems, and ZipClip
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), AVEdge, CableCover, CDRS(ClassD Ripple Suppression),
CodecConnect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator, DSVP(Digital
Sync Validation Processing), EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, Opti-Torque,
PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free,
SpeedNav, Triple-Action Switching, True4K, True8K, Vector™ 4K, WebShare, XTRA, and ZipCaddy

FCC Class B Notice
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part15 of the FCC rules. These limits provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. There is no
guarantee that interference will not occur. If this equipment does cause interference to radio
or television reception, which can be determined by turning the equipment off and on, you
are encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
In order to maintain compliance with FCC regulations, shielded cables must be used with
this equipment. Operation with non-approved equipment or unshielded cables is likely to
result in interference to radio and TV reception. The user is cautioned that changes and
modifications made to the equipment without the approval of the manufacturer could void
the user’s authority to operate this equipment.
NOTE: For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics see the Extron Safety and Regulatory
Compliance Guide on the Extron website.

Regulatory Notifications
WARNING: Potential risk of severe injury or death.
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
• The circuit breaker used for this connection should be rated no lower than
20amps and no greater than 30 amps.
• El disyuntor utilizado para esta conexión no debe tener una capacidad nominal de
entre 20 y 30 amperios.
• This product is intended for indoor use and dry environment only. The device
must not be exposed to dripping or ingress of water and that other objects filled
with liquids, such as glasses, should not be placed on the apparatus.
• Este producto está diseñado únicamente para lugares interiores y entornos
secos. El dispositivo no se debe exponer a goteos ni a entradas de agua, y no se
deben colocar objetos llenos de líquido, como vasos, sobre el aparato.
• XPA Ultra series are Class I products and must be connected to the MAINS outlet
ELECTRICAL with a protective ground connection.
• La serie XPA Ultra son productos de Clase I y deben conectarse a la toma de
corriente ELÉCTRICA con una conexión a tierra de protección.
• Where a mains plug or appliance connector is used as the disconnecting device,
the disconnecting device must remain easily operative.
• Cuando se utilice un enchufe eléctrico o un conector de aparato como el
dispositivo de desconexión, el dispositivo de desconexión debe permanecer
fácilmente operativo.
Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
WARNING: Potential risk of severe injury or death.
ADVERTENCIA: Riesgo potencial de lesiones graves:
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
CAUTION: Risk of minor personal injury.
RECAUCIÓN: Riesgo de lesiones personales leves.
ATTENTION : Risque de blessuremineure.
ATTENTION: Risk of property damage.
ATENCIÓN: Riesgo de daños materiales.
ATTENTION: Risque de dommages matériels.
NOTE: A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.

Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,Op1 scene 1,1 ^B 51 ^W^C
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
EX! *X1&*X2)*X2#*X2! CE}
NOTE: For examples of computer or device responses mentioned in this guide, the
character “0” is used for the number zero and “O” is the capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font
shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are
written in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
A glossary of terms is available at https://www.extron.com/technology/glossary.aspx.

Line/AT Output Processing ............................ 50
Amplifier Output............................................. 53
Amplifier Output Processing........................... 54
Monitoring ..................................................... 55
Open Circuit Detect....................................... 58
Loss of AC..................................................... 58
Dante Controller........................................ 59
Overview ........................................................... 59
Downloading and Installing Dante Controller...... 59
Configuring the Power Amplifier in Dante
Controller.......................................................... 60
Device Name................................................. 60
Receiver and Transmitter Channel Names...... 61
Dante Controller Naming Conventions ........... 61
Renaming the Power Amplifier in Dante
Controller...................................................... 61
Renaming a Receiver or Transmitter
Channel........................................................ 63
Finding a Dante Device IP Address ................ 64
Dante Controller Operation ................................ 65
Dante Devices ............................................... 65
NetPA U 8001 SUB ....................................... 65
Dante Routing Operation ............................... 65
Routing Devices............................................. 65
Disconnecting Inputs from Outputs................ 67
Gain Structure ............................................... 67
Dante Troubleshooting....................................... 67
Simplifying the Network for Troubleshooting... 68
Troubleshooting the Network Interface........... 68
Restarting Dante Controller............................ 69
Configuration Tools ...................................70
Presets.............................................................. 70
Methods for Marking Items ............................ 70
Configuring Presets ....................................... 71
Configuring Groups ...................................... 71
Device Manager ................................................ 73
Contents
Introduction ................................................1
About this Guide.................................................. 1
About the NetPA U 8001 SUB............................. 1
Features .............................................................. 1
Installation ..................................................3
Mounting the NetPA U 8001 SUB........................ 3
Tabletop Use ................................................... 3
Rack Mounting ................................................ 3
SF 10C SUB Mounting with
SAK AMP SF 10C Mounting Kit...................... 8
Flexible Conduit Adapter Kit Installation ............. 12
UL Requirements........................................... 13
Installing the Flexible Conduit Adapter Kit ...... 13
Operation..................................................16
Front Panel Features.......................................... 16
Rear Panel Features .......................................... 17
Operation .......................................................... 21
Default........................................................... 21
AT Port .......................................................... 21
Standby Modes............................................. 22
Monitoring ..................................................... 23
DSP Configurator Software ....................... 25
Software or Firmware Installation ....................... 25
Connecting to DSP Configurator ....................... 26
Accessing the DSP Configurator Help File ......... 27
DSP Configurator Main Workspace ................... 27
Menu Bar ...................................................... 28
DSP Configurator Inputs.................................... 34
Line Inputs..................................................... 34
Line Inputs Processing................................... 36
AT Inputs ....................................................... 44
AT Inputs Processing..................................... 45
Mix-Points ..................................................... 46
DSP Configurator Outputs................................. 48
Line/AT Outputs............................................. 48
vii
NetPA U 8001 SUB • Contents

Managing Devices in Device Manager............ 73
Firmware Loader ............................................... 74
Downloading Firmware Updates.................... 74
Organize Building Blocks................................... 76
Device Settings.................................................. 77
Unit Info......................................................... 77
Serial Settings ............................................... 77
Dante Device ................................................ 77
Remote Communication and Control ......... 79
Connection Options........................................... 79
RS-232 Port .................................................. 80
AT Port .......................................................... 80
USB Config Port............................................ 80
Verbose Modes ............................................. 81
Host-to-Device Communications....................... 81
NetPA Ultra Series-initiated Messages ........... 81
Using the Command and Response Tables ....... 82
Symbol Definitions ......................................... 82
Error Responses............................................ 83
Hardware Reset Modes..................................... 83
Command and Response Table......................... 84
SIS Commands ............................................ 84
Object ID (OID) Number Tables .......................... 94
Input Path OIDs ............................................. 94
Output Path OIDs .......................................... 94
Mix-point OIDs............................................... 95
Troubleshooting................................................. 96
Amplifier Fails to Exit Standby Mode
Promptly....................................................... 96
Amplifier Enters Standby Mode Too Early....... 96
Limiter/Protect LED Warning Indicators.......... 96
Over Temp Indicator LED............................... 97
Status Commands......................................... 97
NetPA U 8001 SUB • Contents viii

NetPA U 8001 SUB • Introduction 1
Introduction
This section gives an overview of the Extron NetPA U 8001 SUB subwoofer power amplifier.
Topics in this section include:
• About the Guide • Features
• About the NetPA U 8001 SUB
About this Guide
This guide describes the NetPA U 8001 SUB DSP-enabled subwoofer power amplifier, and
discusses how to install, configure, and operate it.
In this guide, the terms “unit”, “amplifier”, and “power amplifier” refer to the
NetPA U 8001 SUB power amplifier.
About the NetPA U 8001 SUB
The Extron NetPA U 8001 SUB is an ENERGY STAR-qualified, Dante®-enabled subwoofer
amplifier with onboard audio DSP, designed specifically for use with the Extron SF 10C SUB
in-ceiling subwoofer speaker, as well as other 8, 4, or 2 ohm subwoofers with similar power
requirements. The NetPA U 8001 SUB can deliver up to 800 watts at 8 ohms, 650 watts at
4 ohms, or 325 watts at 2 ohms.
The NetPA U 8001 SUB is 1U high, half-rack width, and rack-mountable. The amplifier has
mounting holes for 9-inch (22.86 cm) and deeper rack shelves, and is plenum-rated with an
optional flex conduit adapter. The unit is convection-cooled.
Features
• Receives audio from the Dante audio network as well as from analog line level
inputs — Select a channel from any remote Dante-enabled device on the network, or
an analog source, to be brought into the NetPA U 8001 SUB for amplification.
• 800 watts RMS mono output power at 8 ohms — Allows this single amplifier model
to be used in a wide variety of system configurations.
• 650 watts RMS mono output power at 4 ohms
•325 watts RMS mono output power at 2 ohms
•ENERGY STAR qualified amplifier with defeatable auto-standby and fast wake
up — The NetPA U 8001 SUB is an ENERGY STAR qualified amplifier and energy
efficient product that conserves energy and reduces cost. It meets ENERGY STAR
qualification requirements with an auto-standby feature which automatically places the
amplifier into Standby Mode after 25 minutes of inactivity thereby dramatically reducing
power consumption. It quickly returns to full power status in less than 100 ms upon
signal detection, with minimal inrush current. Auto-standby can be disabled if required.
• Mounts in a rack or directly to an SF 10C SUB — Single and dual rack mount
hardware included.
• Onboard DSP with 4x5 mix matrix — Route any input to any output, with or without
processing, crossover supported.

NetPA U 8001 SUB • Introduction 2
• Frequency range optimized for subwoofers — 20 Hz to 1 kHz.
• Convection cooled, fanless operation — Can be stacked without extra rack space
for ventilation. The NetPA U 8001 SUB does not require internal fans or vents for
cooling, ensuring quiet and reliable operation. It generates substantially less heat than
conventional power amplifiers, making it ideal for rack-mount applications where space
is limited (see Rack Mounting Ventilation Recommendations on page 3).
• Extron Patented CDRS - Class D Ripple Suppression — CDRS is an Extron
Patented technology that provides a smooth, clean audio waveform and an
improvement in signal fidelity over conventional Class D amplifier designs. CDRS
eliminates the high frequency switching ripple that is characteristic of Class D amplifiers,
a source of RF emissions which can interfere with sensitive AV equipment such as
wireless microphones.
• Setup and configuration with Extron DSP Configurator Software — Via a Dante
network or USB.
• UL 2043 plenum rated when used with optional Flexible Conduit Adapter Kit —
The NetPA U 8001 SUB meets UL 2043 for smoke and heat release for installation
within a plenum airspace above a drop ceiling when used with the optional Flexible
Conduit Adapter Kit. Above-the-ceiling placement conceals the amplifier to prevent
theft, and is convenient for installing equipment when space inside the room is limited.
• Professional grade signal-to-noise and THD+N performance — The NetPA U
8001 SUB delivers professional grade performance, featuring 100 dB signal-to-noise
ratio and THD+N of less than 0.1%.
• Ultra low inrush current at power up - no need for power sequencing — Allows
multiple NetPA Ultra Series amplifiers to be powered on simultaneously without
overloading power circuits. This eliminates the need for power sequencing.
• Power factor correction - removes harmonic content on AC line — The NetPA
U 8001 SUB features power factor correction technology that smooths out the high
peak currents of the amplifier’s current draw thereby minimizing the presence of high
frequency harmonics on the AC power line and preventing audible artifacts from being
transmitted to other audio equipment in the system.
• Automatic clip limiter — Detects actual onset of clipping. Gain is automatically
reduced without audible artifacts to protect speakers from clipping distortion.
•Multiple protection circuits — Activate during output shorts, thermal overload, or DC
faults to prevent damage to the amplifier and speakers.
•Remote standby port — Enables the NetPA U 8001 SUB to be remotely powered
down when not in use, reducing operating cost.
• 5 mm screw-lock captive screw speaker connectors — Enable simple, secure
connections with 22 to 12 AWG speaker cables.
•Front and rear-mounted signal and protection indication LEDs — Provide
convenient indication of input signal presence and protection circuit activation from both
sides of the equipment rack.
•Front and rear panel over-temperature LEDs — Provides visual indication that the
amplifier temperature has exceeded the optimal value, well in advance of the onset of
thermal protection circuitry.
• Internal Extron Everlast™ power supply — Provides worldwide power compatibility,
with high-demonstrated reliability and low power consumption for reduced operating
cost.
• Extron Everlast Power Supply is covered by a 7-year parts and labor warranty

NetPA U 8001 SUB • Installation 3
Installation
This section describes the installation and setup of the NetPA U 8001 SUB power amplifier. Topics
include:
• Mounting the NetPA U 8001 SUB
• Flexible Conduit Adapter Kit Installation
Mounting the NetPA U 8001 SUB
The NetPA U 8001 SUB amplifier can be:
• Set on a table
•Mounted in a rack
•Mounted to the SF 10C SUB in-ceiling subwoofer in the plenum space
Tabletop Use
Four self-adhesive rubber feet are included. Attach one foot at each corner on the bottom
side of the amplifier and place the unit in a desired location.
Rack Mounting
The NetPA U 8001 SUB amplifier can be mounted in a rack using one of the following
methods:
• Rack ear mounting (see page 5)
• Bridge plate mounting (mounts two amplifiers, see page 6)
• Rack shelf mounting (see page 7)
Rack Mounting Ventilation Recommendations
Excessive heat decreases the optimal
Vent Space
Vent Space
Vent Space
Vent Space
Vent Space
Vent Space
Vent Space
Figure 1. Ventilation
lifetime of the power amplifier. An Over
Temp indicator LED on the front panel of
the amplifier lights red whenever the
recommended operating temperature has
been exceeded.
In a rack environment, the amplifier can
be arranged above or below another non-
NetPA Ultra device, but the environment
around the unit must not reach or go
beyond +122°F (+50°C). To minimize heat,
stack no more than four devices, one-on-
top-of-the-other, without an open space in
between (see figure 1).

NetPA U 8001 SUB • Installation 4
UL rack mounting guidelines
The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the
equipment in a rack.
CAUTION: Risk of minor personal injury:
• Elevated operating ambient temperature — If the equipment is installed in a
closed or multi-unit rack assembly, the operating ambient temperature of the rack
environment may be greater than room ambient. Therefore, consider installing the
equipment in an environment compatible with the maximum ambient temperature
(Tma) specified by Extron.
• Reduced air flow — Install the equipment in the rack so that the amount of air
flow required for safe operation of the equipment is not compromised.
• Mechanical loading — Mount the equipment in the rack so that uneven
mechanical loading does not create a hazardous condition.
• Circuit overloading — When connecting the equipment to the supply circuit,
consider the connection of the equipment to the supply circuit and the effect
that circuit overloading might have on overcurrent protection and supply wiring.
Consider equipment nameplate ratings when addressing this concern.
• Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to supply connections other than direct
connections to the branch circuit (such as the use of power strips).
Consignes UL pour le montage en rack
Les consignes UL (« Underwriters Laboratories ») suivantes concernent l’installation en
rack :
ATTENTION : Risque de blessuremineure :
• Température ambiante élevée — En cas d’installation de l’équipement dans
un rack fermé ou composé de plusieurs unités, la température du rack peut être
supérieure à la température ambiante. Par conséquent, il est préférable d’installer
l’équipement dans un environnement qui respecte la température ambiante
maximale (Tma) spécifiée par Extron.
• Réduction du flux d’air — Si l’équipement est installé dans un rack, veillez à ce
que le flux d’air nécessaire pour un fonctionnement sécurisé de l’équipement soit
respecté.
• Charge mécanique — Installez l’équipement en rack de manière à éviter toute
situation dangereuse causée par le déséquilibre de la charge mécanique.
• Surcharge électrique — Lorsque vous connectez l’équipement au circuit
d’alimentation, observez la connexion de l’équipement et étudiez les effets
possibles d’une surcharge du circuit sur les protections contre les surintensités et
les conducteurs d’alimentation. Consultez à cet égard les indications de la plaque
d’identification de l’équipement.
• Mise à la terre — Assurez-vous que l’équipement est correctement mis à la
terre. Accordez une attention particulière aux connexions électriques autres que
les connexions directes au circuit de dérivation (ex. : les multiprises).

NetPA U 8001 SUB • Installation 5
Rack ear mounting
The NetPA U 8001 SUB amplifier ships with a set of rack ears, so that the half rack-width
amplifiers can be installed in a full rack-width space.
Mount the amplifier with the rack ears as follows:
1. Remove the rubber feet from the bottom of the amplifier if previously installed.
2. Attach the included rack ears (one long and one short) to the sides of the amplifier with the four
provided #6 machine screws (see figure 2, 1).
e
NetPAU 800 1 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIFIER S
1
1
1
1
1
1
e
Net PA U 8001 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIFI ERS
Figure 2. Installing Rack Ears onto the NetPA U 8001 SUB
3. Insert the amplifier into the rack and align the holes in the rack ear with the holes on the
rack.
4. Secure the amplifier to the rack using the four provided 10-32 x 3/4” screws (see
figure 3, 1).
e
NetPAU 800 1 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIFIERS
1
1
1
1
1
1
e
Net PA U 8001 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIFI ERS
Figure 3. Securing Rack to NetPA U 8001 SUB
1
2

NetPA U 8001 SUB • Installation 6
Bridge plate rack mounting
The NetPA U 8001 SUB amplifier ships with a bridge plate connector that allows two
amplifiers to be connected together and form a full rack-width unit.
Mount two NetPA U 8001 SUB amplifiers by doing the following:
1. If the rubber feet are installed on the bottom of the amplifier, remove them.
2. Position two amplifiers upside down and next to each other.
3. Use the bridge plate connector and the four provided #4 machine screws to connect
the two amplifiers together (see figure 4, 1).
4. Attach the two short rack ears to the amplifiers with the four provided #6 machine
screws (2).
Mounting
screws (4)
11
2
2
e
NetPA U 8 001 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPL IFIERS
e
NetPA U800 1 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLI FIERS
1
1
1
1
1
1
e
NetPA U 8001 S UB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPL IFIERS
2
2
2
e
e
NetPA U 8 001 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIF IERS
Figure 4. Installing NetPA U 8001 SUB Bridge Plate
5. Insert the amplifiers into the rack and align the holes in the rack ears with the holes in
the rack.
6. Secure the amplifiers to the rack using the four provided 10-32 3/4” screws
(see figure 5, 1).
Mounting
screws (4)
11
2
2
e
NetPA U 8 001 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPL IFIERS
e
NetPA U800 1 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLI FIERS
1
1
1
1
1
1
e
NetPA U 8001 SU B
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPL IFIERS
2
2
2
e
e
NetPA U 8 001 SUB
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIF IERS
Figure 5. Secure Connected NetPA U 8001 SUB Amplifiers to Rack
3
4

NetPA U 8001 SUB • Installation 7
Rack shelf mounting
The NetPA U 8001 SUB can be mounted on a shelf using the optional RSU 129 1U
Universal Rack Shelf Kit.
Mount the amplifier with the shelf as follows:
1. If the rubber feet are installed on the bottom of the amplifier, remove them.
2. Place the amplifier on one half of the rack shelf.
3. Align the front of the amplifier with the front of the shelf, and align the threaded holes on
the bottom of the amplifier with the holes in the rack shelf (see figure 6).
4. Attach the amplifier to the rack shelf with the two provided 4-40 x 3/16” machine
screws. Insert the screws from the underside of the shelf and fasten them into
diagonally-opposite corners.
ATTENTION: Using screws longer than 3/16” damages the unit and voids the
warranty.
ATTENTION : L’utilisation de vis plus longues que 3/16” endommagera l’unité et
annulera la garantie.
(2) 4-40 x 3/16"
Screws
RSU 129
1U Universal Rack Shelf
False faceplate
uses 2 screws.
Use 2 mounting holes
on opposite corners.
e
OVER
TEMPLIMITER/PROTECT
SIGNAL
NetPAU 8001 SUB
POWERAMPLIFIERS
NetP
Figure 6. Mounting the Amplifier onto a Rack Shelf
5. Attach either the false front panel, which is provided with the rack shelf, or a second half
rack-width device to the unoccupied side of the rack.
6. Attach the rack to the shelf by using the four 10-32 x 3/4” screws provided with the
shelf. Insert the screws through #10 beveled washers, then through the holes in the
rack.
5

NetPA U 8001 SUB • Installation 8
SF 10C SUB Mounting with SAK AMP SF 10C Mounting Kit
The SAK AMP SF 10C mounting kit attaches an Extron NetPA U 8001 SUB power amplifier
to the back of an SF 10C SUB subwoofer speaker. This kit enables the amplifier to be
mounted as close as possible to the subwoofer, thereby allowing for the shortest possible
speaker wiring.
Use the SAK AMP SF 10C kit to mount an Extron NetPA U 8001 SUB to the SF 10C as
follows:
NOTE: If the SF 10C SUB is being installed into a plenum airspace, the AC input of
the power amplifier must be replaced with the Flexible Conduit Adapter Kit. See
Installing the Flexible Conduit Adapter Kit (see page 13) for detailed installation
instructions.
1. On the SF 10C, loosen the cable conduit access plate screw and remove the plate (see
figure 7).
Alternate
Knockout
Cable Conduit
A
ccess Plate
Screw
1
1
1
Figure 7. Removing the Cable Conduit Access Plate
2. Remove the 4-pole captive screw connector that is attached to the speaker (1).
3. Feed the unterminated end of the provided short cable through the back of the cable
clamp (see figure 8, 1on the next page).
6

NetPA U 8001 SUB • Installation 9
Cable
Clamp
Remove the jackets from the ends of the wires and
attach them to the captive-screw output connector
of the amplier.
1
1
12
2
2
A
ccess Plate
Scr
ew
Figure 8. Feeding the Cable through the Back of the Cable Clamp
4. Plug the 4-pole captive screw connector of the pre-terminated cable into the captive
screw connector on the speaker (see figure 8, 2).
5. Reattach the cable conduit access plate to the speaker.
6. Tighten the cable clamp.
7. Attach the NetPA U 8001 SUB to the SAK AMP SF 10C brackets using the provided
screws in the holes indicated in figure 9.
e
Net PAU 80 01 SU B
OVER
TEMP LIMITER/PROTECT
SIGNAL
POWER AMPLIFIERS
Figure 9. Attaching the Amplifier to the SAK AMP SF 10C Brackets
8. Attach the brackets (with the amplifier attached) to the screw holes on the end of the
SF 10C SUB speaker containing the cable conduit access plate, using the provided
screws (see figure 10 on the next page).
7
8

NetPA U 8001 SUB • Installation 10
Mounting Sc
rews
(4 places)
LIMITTER/PROTECT
SIGNAL
R
OVER
TEMP
1212
RS-232
STANDBY
Tx Rx GG
AT CONFIG LINEOU T
LINEIN
REMOTE
CLASS2 WIRING
OUTPUTS
8Ω/4Ω
OUTPUTS
8Ω/4Ω
100-240V
--1.7A,50-60 Hz
NetPAU 8001 SUB
Figure 10. Attaching the Brackets and Amplifier to the SF 10C SUB Subwoofer
9. Remove the jackets from the ends of the wires of the short cable that was attached to
the speaker in Installing the flexible conduit kit, step 10 (see page 15).
10. Wire the green captive screw connector provided with your amplifier to the unterminated
ends of the cable wires (see figure 11 on the next page).
The NetPA U 8001 SUB has a 2-pole connector.
• The red wire connects to the +pin.
• The black wire connects to the Ground pin.
9

NetPA U 8001 SUB • Installation 11
LIMITTER/PROTECT
SIGNAL
R
OVER
TEMP
1212
RS-232
STANDBY
Tx Rx GG
AT CONFIG LINEOU T
LINEIN
REMOTE
CLASS2 WIRING
OUTPUTS
8Ω/4Ω
OUTPUTS
8Ω/4Ω
100-240V
--1.7A,50-60 Hz
NetPAU 8001 SUB
MITER/PROTECT
SIGNAL
8Ω/4Ω OUTPUT
CLASS 2 WIRING
NetPA U 8001 SUB
Figure 11. Connecting the Amplifier to the Subwoofer
10

NetPA U 8001 SUB • Installation 12
Flexible Conduit Adapter Kit Installation
The kit provides a way to replace the IEC power cord with a conduit, where required by local
codes.
WARNING:
AVERTISSEMENT :
• The circuit breaker used for this connection should be rated no lower than 20 amps and
no greater than 30 amps.
• Le disjoncteur utilisé pour cette connexion devrait avoir une cote comprise entre
20 et 30 amps.
• This unit must be installed in accordance with the National Electrical Code and
with all local codes.
• Cet appareil doit être installé conformément au National Electrical Code et à tous
les codes locaux.
• Installation and service must be performed by a qualified electrician only.
• L’installation et l’entretien doivent être effectués uniquement par un électricien
qualifié.
• An ALL-POLE MAINS SWITCH with a contact separation of at least 3 mm in
each pole shall be incorporated in the electrical installation of the building, The
installation shall be carried out in accordance with all applicable installation rules.
• Un interrupteur omnipolaire avec une séparation contact d’au moins 3
mm dans chaque pôle, devra être incorporée dans l’installation électrique du
bâtiment. L’installation doit être réalisée conformément à toutes les règles
d’installation applicables.
• Make sure the source device and the NetPA Ultra are turned off and
disconnected from the power source before you begin.
• Vérifiez que l’appareil source et le périphérique source sont éteints et
déconnectés de la source d’alimentation avant de commencer.
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
• Afin de réduire les risques d’incendie ou de choc électrique, protégez cet appareil
de la pluie ou de l’humidité.
• The product is a Class I product, which must be connected only to a mains
socket outlet with a protective earthing (grounding) connection.
• Ce produit est un produit de Classe I, qui doit être connecté seulement à une
prise femelle secteur équipée d’une connexion de mise à la terre.
• The mains plug/appliance coupler is used as the disconnect device and shall
remain readily operable.
• La fiche secteur / le coupleur d’appareil est utilisé comme dispositif de
déconnexion et doit rester facilement utilisable.
• A UL-Listed electrical distribution box is recommended for the termination of the
conduit opposite the PS 124 power supply or the NetPA Ultra amplifier (see UL
Requirements on page13).
• Un boîtier de distribution électrique certifié UL est recommandé pour la terminaison du
conduit à l’opposé de l’alimentation PS 124 ou de l’amplificateur NetPA Ultra (voir UL
Requirements à la page 13).
