Extron electronics S1 26W User manual

Trace template
1
Cutout Template
Determine the speaker location.
Leave at least 1” clearance from the edge of the speaker
to the studs in all directions. Hold or tape template in location,
make sure template is level. Trace along the inside of the template.
4
Insert the speaker into the wall opening.
Loosen the six screws on the front baffle (counter-
clockwise) 1/2 turn. Then tighten the screws (clockwise)
until the dog legs clamp the speaker to the wall.
5
6
Level speaker, position each wall clamp outward, and tighten
each screw until snug.
Install dust shield to protect the speaker during ongoing
construction.
Remove the dust shield,
install the speaker grill.
Dust Shield
Paint Guard
188 mm x 275 mm
(7.4” x 10.8”)
Application diagram:
Specifications:
2
Carefully cut a hole along the inside of the traced line.
3
Attach the speaker wires to the 2-pole captive screw plug.
Use red for the positive (+) wire and black for the negative (-)
wire. Insert the 2-pole captive screw plug into the 2-pole
connector on back of the speaker.
RS-232/MLC/IR
TxRx IR 12V
ABC
PREAMP
100-240V
1.0AMAX.
50-60Hz
AUDIOINPUTS
LINELEVEL
MONO
AUDIO
AUDIO
LINEOUT
AUX/MIX
ADJUST
-42dB
TO
+24dB
L
R
L
RR
12
INPUTS
OUTPUTS
VIDEO HV
B
G
R
12
INPUTS
MONITOROUT
5
6
RIGHT LEFT
AMPLIFIEDOUTPUT
R
Extron
MLS 304SA
MediaLink Switcher
SI 26W
Two-way In-wall
Speaker
Laptop
w/ Audio
Projector
VCR PC
Acoustic & Electrical
General
Speaker type.................................. 2-way in-wall speaker
Frequency range........................... 40 Hz to 20 kHz, -10 dB, half space
Power capacity.............................. 60 W continuous program,
30 W continuous pink noise
Nominal sensitivity...................... 89 dB, 1 W, 1 m, half space
Nominal impedance .................... 8 ohms
Crossover frequency................... 2.5 kHz
Woofer........................................... 6.5" (165 mm) polypropylene cone with
moisture resistant coating
Tweeter.......................................... 0.75" (19 mm) titanium dome
Temperature/humidity............... Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Warranty ....................................... 5 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
SNXXXXXXXX E XXXXX
00/00
Impedance
8Ohms
Engineeredin USA
SI 26W
In-WallSpeaker
At least 1” from the stud.
Print at 100%. - Do Not “Fit to Paper”.
Cut material
Do not over-tighten screws.
CAUTION
SI 26W
In-Wall Speaker
User’s Guide
68-1101-01 Rev A
08 07
