EyeView CMI-220 User manual

IP CAMERA
User’s Manual

About this document
This user manual is intended for administrator and/or user of IP
camera. Operational instructions & network configuration are
elaborated. Prior knowledge about network setup and configuration
will be helpful.
IMPORTANT
9Check PC specification requirements.
9Check OS platform requirements.
9Install NVR2 software before you start working with video server.
9Read special notes and important configuration information.

TABLE OF CONTENTS
1. INTRODUCTION
1.1 PRODUCT OVERVIEW
CMI-220 is a professional IP surveillance application. With embedded
web viewer, streaming video/audio over network can be accessed
like browsing a website. It is also capable of encoding MPEG4
stream, the only digital surveillance product in the market with
proprietary design for "Ease-of-use", "Reliability", and
"Manageability".
1.2 PACKAGE CONTENTS
IPCamera Software CD
Powerconnector Power Adaptor

1.3PHYSICAL DESCRIPTION
1 2
Back Panel
34
5
1. Power Socket
DC12V 1A
2. Video Out
3. Reset Button
4. LAN/WAN RJ45 Port
10/100 Mbps auto sensing, fast Ethernet port for secure
Local Network or WAN for FTTH or xDSL connectivity
5. DI/DO
DO: Logic Level 0:0~0.5V; Logic Level 1: 2.8~3.3V

Side Panel
1. Auto Iris
2. V.D D.D
Video Driver or Digital Driver
3. VR
Variable Resistant adjustment
4. DIP Switches for CCD Functions
Auto Electronic Shutter Speed Mode
AES On 1/50 (60) sec. ~ 1/100,000 sec;
AES Off: 1/50 (60) sec.
Back Light Compensation
ON/OFF (Switchable)
Flickless
ON/OFF (Switchable)

2 Hardware Installation
Make sure network environment
Default IP of IP Camera is 192.168.1.2 Please make sure IP Camera and
your PC are in the same network segment before running the installation.
Please set the number
from 2 to 254.
e.g. 192.168.1.115
Connect necessary cables
The Ethernet cable and power cable are necessary for previewing function.
Make sure all cables are correctly and firmly connected.

1. Connect an analog monitor to IP Camera Video Out (BNC connector)
2. Connect the power adaptor to IP Camera
3. Connect IP Camera LAN/WAN port to an Ethernet hub (RJ45 connectors)
4. Connect a PC to the Ethernet hub (RJ45 connectors)
3. SOFTWARE CD
Software CD in the package contains the following:
9NVR2 IP surveillance management software

9NVR User Manual
9Firmware binary file
9IP Camera Manual
9IP Setting
4. BEFORE YOU INSTALL SOFTWARE
9PC running Microsoft Windows 2000 or above is only capable of
running NVR2 software.
9PLEASE go through NVR users’ manual before installation to
check further PC requirements in order to ensure smooth
software operation.
5. LANGUAGE SUPPORT
ENGLISH
NOTE
NVR setup will auto-run when inserting CD. Pay attention to dialog
box questions before you press OK button.
