F4 TECH FORGE User manual

1
FORGE
HANDHELD USER
MANUAL

2
Table of Contents
Chapter 1....................................................................................................................................................... 6
Getting Started.......................................................................................................................................... 6
Identifying Hardware Components....................................................................................................... 6
Front of Device................................................................................................................................. 6
Keypad.............................................................................................................................................. 8
Top View .......................................................................................................................................... 9
Back of Device.................................................................................................................................. 9
Base................................................................................................................................................. 10
Preparingyour Device ......................................................................................................................... 11
Installing the Battery and SIM Card (select models)..................................................................... 11
Connecting to A/C Power/Charging the Battery............................................................................. 13
Initial Startup .................................................................................................................................. 14
Syncing Device to Your PC................................................................................................................ 14
Installing ActiveSync and WMDC................................................................................................. 15
User Options ....................................................................................................................................... 16
Using the MicroSD card ................................................................................................................. 16
Using the Ultrasonic Ranging Module................................................................................................ 17
Chapter 2..................................................................................................................................................... 17
The Basics............................................................................................................................................... 17
Powering On/Off................................................................................................................................. 17
Power Saving...................................................................................................................................... 17
Turning the backlight on/off ........................................................................................................... 17
Suspend Mode................................................................................................................................. 18
On-Screen Navigation......................................................................................................................... 18
Using the Stylus.............................................................................................................................. 18
Home Screen....................................................................................................................................... 19
Portrait/Landscape View................................................................................................................. 20
Navigation Bar................................................................................................................................ 20
Tool Bar .......................................................................................................................................... 20
Programs............................................................................................................................................. 20
Notifications.................................................................................................................................... 21
Entering Information Into Your Device.............................................................................................. 21

3
Writing on the Screen ..................................................................................................................... 22
Drawing on the Screen.................................................................................................................... 22
Recording a Message...................................................................................................................... 23
Securing Your Device......................................................................................................................... 24
Securing Your Device with a Password.......................................................................................... 24
Chapter 3..................................................................................................................................................... 25
Device Management ............................................................................................................................... 25
Power Management ............................................................................................................................ 25
Low Battery Signals/Actions.......................................................................................................... 25
Power-Saving Tips.............................................................................................................................. 26
Customizing Your Device................................................................................................................... 27
Chapter 4..................................................................................................................................................... 28
Microsoft Pocket Outlook....................................................................................................................... 28
Calendar: Scheduling Appointments and Meetings............................................................................ 28
Creating an Appointment................................................................................................................ 29
Using the Calendar Summary Screen ............................................................................................. 29
Contacts: Tracking Friends and Colleagues........................................................................................ 30
Creating a Contact........................................................................................................................... 30
Tasks: Keeping a To-Do List.............................................................................................................. 30
Creating a Task............................................................................................................................... 30
Notes: Capturing Thoughts and Ideas................................................................................................. 31
Creating a Note............................................................................................................................... 31
Email: Sending and Receiving Email Messages................................................................................. 31
Synchronizing Email Messages...................................................................................................... 31
Connecting Directly to an Email Server......................................................................................... 32
Using the Message List................................................................................................................... 32
Composing /Sending an Email........................................................................................................ 32
Managing Email Messages and Folders.......................................................................................... 33
Chapter 5..................................................................................................................................................... 34
More Programs........................................................................................................................................ 34
ActiveSync/WMDC............................................................................................................................ 34
Synchronizing Data......................................................................................................................... 35
Office Mobile...................................................................................................................................... 35

4
Creating an Office File.................................................................................................................... 36
Opening an Office File.................................................................................................................... 36
Internet Explorer................................................................................................................................. 37
Browsing the Internet...................................................................................................................... 37
Windows Live Messenger................................................................................................................... 38
Setting up Windows Live................................................................................................................ 39
Signing into Messenger................................................................................................................... 39
Windows Media Player....................................................................................................................... 39
Pictures & Videos............................................................................................................................... 40
Viewing Pictures & Videos............................................................................................................. 40
Camera................................................................................................................................................ 41
Taking Pictures ............................................................................................................................... 41
Recording Video Clips.................................................................................................................... 42
Geotagging...................................................................................................................................... 43
Chapter 6..................................................................................................................................................... 45
Getting Connected .................................................................................................................................. 45
Types of Connections ......................................................................................................................... 45
Setting up a Cellular (HSDPA) Connection.................................................................................... 45
Searching and Organizing Information............................................................................................... 47
Remote Desktop.................................................................................................................................. 47
Setting up a Dial-up Connection..................................................................................................... 48
Using a Wireless Network.................................................................................................................. 48
Switching On or Off the Wi-Fi Radio............................................................................................. 48
Using Bluetooth.................................................................................................................................. 50
Switching On or Off the Bluetooth................................................................................................. 51
Sending Files Via Bluetooth........................................................................................................... 52
Receiving Files Via Bluetooth........................................................................................................ 53
Creating a Bluetooth Partnership.................................................................................................... 53
Chapter 7..................................................................................................................................................... 54
GeoAssist Software................................................................................................................................. 54
Starting GeoAssist .............................................................................................................................. 54
GeoAssist Settings.............................................................................................................................. 55
GPS Tab.......................................................................................................................................... 55

5
Satellite Detail Tab ......................................................................................................................... 56
Use Mode Tab................................................................................................................................. 57
Log Tab........................................................................................................................................... 59
About Tab ....................................................................................................................................... 59
Chapter 8..................................................................................................................................................... 60
Recommended Settings........................................................................................................................... 60
GPS Settings and Best Practices......................................................................................................... 60
Handheld and Best Practices............................................................................................................... 60
Chapter 9..................................................................................................................................................... 61
Troubleshooting & Maintenance ............................................................................................................ 61
Resetting Your Device........................................................................................................................ 61
Restoring Device to Factory Settings.................................................................................................. 62
Troubleshooting.................................................................................................................................. 63
Caring for Your Device....................................................................................................................... 65
Chapter 10................................................................................................................................................... 66
Safety Precautions................................................................................................................................... 66
About Charging................................................................................................................................... 66
About the Charger............................................................................................................................... 66
About the Battery................................................................................................................................ 67
FCC Warning...................................................................................................................................... 67

6
Chapter 1 Getting Started
Identifying Hardware Components
Front of Device
1
2
3
6
5
4

7
Ref Component Description
1.
LED1 Indicator LED1: System Notification and Battery Status Indication
Blinking Green displays charging battery
Solid Green displays full battery
Blinking Red displays low battery
Solid Red displays faulty battery
Alternating Green and Amber displays charging battery with
Windowsnotifications
Alternating Red and Amber displays low battery with Windows
notifications
Alternating Amber and Green displays full battery with Windows
notifications
Alternating Amber and Red displays faulty battery with Windows
notifications
2.
LED2 Indicator LED2: Status Indication for Integrated Module
3.
Touch Screen Video display that responds to finger taps and gestures
4.
Microphone
Voice recorder
5.
Reset Resets the device
6.
Keypad See “Keypad” section for details

8
Keypad
Ref Component Description
1.
Navigation
Button
Navigates options in 4 directions, center button selects option
2.
Function Keys
F1 ~ F7 Function keys are multi-purpose keys that perform functions
definedbyindividual API
3.
Back Tab Key Backspace key
4.
Front Tab Key Forward delete key
5.
Power Button
Turns device on and o ff
6.
Start Menu
OpensStart Menu
7.
Numeric Keys 12 key numeric keys is embedded in the typewriter keys
8.
Camera Button Press totake a photo
9.
NumLock
Pressing this key toggles the Num Lock on and o
ff
. When on, the NumLock
activatesthe numeric keys
1
2
3
5
6
4
7
8
9

9
Top View
1
2
3
4
5
6
7
8
2
9
Back of Device

10
Top View/Back of Device
Base
Component Description
1.
UltrasonicCover Covers andprotects ultrasonic
2.
Hand Strap hole Install hand strap
3.
LED flash light Flashlight
4.
Camera Takes pictures and records video
5.
Stylus
Used to input information and select options on the
touch screen
6.
ExternalGPS
Antenna
Allows for use of optional external antenna. Antenna
may be placed on top of a vehicle/building to gain
greater reception
7.
Speaker Plays music, sounds and voices
8.
Battery Cover
Screw
Locks the battery cover
9.
Battery Cover Covers and protects battery
Ref Component Description
1.
Power Connector
Allows for battery charging through an A/C adapter
2.
USB OTG (Host & Client)
C
onnector
Allows for USB connection
3.
UART(RS232) Connector
Connects to a RS232 device

11
Preparing your Device
Installing the Battery and SIM Card (select models)
1. Detach the battery cover from device.
2. If your model has the 3.5G capability, you will need to
install the SIM card provided by your mobile provider and
insert the SIM card into the slot, then push to lock.

12
3. To remove the SIM card, slide to open, then remove card.
4. To install the battery, insert the connector side of the
battery first, then secure the connection.
5. Attach the battery cover to the device.

13
Connecting to A/C Power/Charging the Battery
• Fully charge battery before initial use of your device
• Connect the converter to the A/C charger.
• The LED indicator will blink green when the battery is
charging. Do not disconnect your device from A/C power
until the battery is fully charged. This may take a couple of
hours.
For Optimal Performance:
•Only use the included A/C charger.
•The lithium battery does NOT need to be fully discharged
before next charging.
•Do NOT charge the battery in high temperatures (i.e. direct
sunlight).
•The battery MUST be fully charged at least once every two
weeks even if the device is not in use. Over-discharge of the
battery creates negative battery performance.
•The battery will also charge if the device is connected via
USB to a computer.

14
Initial Startup
•Connect the device to A/C power or make sure the battery
has been fully charged.
•Turn on device by pressing the Power button.
•Select the language you prefer to use.
•Follow the Setup Wizard’s on screen instructions.
oIf a SIM card has been inserted and the 3.5G network
provider has set the PIN, you will be prompted to
enter PIN.
oOnce Setup is complete, the Home screen will appear.
The device is now ready for use.
Syncing Device to Your PC
Your device can connect and synchronize data with a Windows-
based computer through ActiveSync and Windows Mobile
Device Center (WMDC). ActiveSync is compatible with
Windows XP. WMDC is only compatible with Windows Vista
or Windows.
ActiveSync and WMDC act as gateways between your device and
your computer. They allow for transferring Outlook email,
appointments, contacts, and tasks as well as media (i.e. pictures,
music, and videos).

15
Installing ActiveSync and WMDC
•Before installation, make sure Microsoft Outlook is installed
on your computer.
•Be sure to install ActiveSync or Windows Mobile Device
Center before connecting to your device.
•For Windows XP, download and install ActiveSync.
•For Windows Vista or Windows 7, download and install
Windows Mobile Device Center. Visit the Microsoft website
to download the program and to obtain operating
instructions: http://www.microsoft.com.
•ActiveSync connection problems may occur in some cases.
Likely causes include:
oInteroperability with firewall applications
oNetwork management applications
oFor troubleshooting information, visit the
Microsoft website: http://www.microsoft.com.
• After software installation is complete, connect your device
to your computer via the USB cable. The device is now
ready to be synchronized.

16
User Options
Using the MicroSD card
The device supports micro Secure Digital (microSD). Use the
following steps to insert a microSD card:
• Detach the battery cover from device.
• Remove the battery.
• Insert the card into the slot.
• Re-insert the battery.
• Re-attach the battery cover to device.
Make sure the microSD card slot is free of debris and always store
microSD card in a protective case to avoid heat, dust, & humidity.

17
Using the Ultrasonic Ranging Module
This device supports the Ultrasonic Ranging Module. For
additional product information, please contact your reseller or an
authorized service provider.
Chapter 2 The Basics
Powering On/Off
To turn off the device, hold down the power button; the device
will display a 3 second countdown notification, then power off.
Power Saving
Turning the backlight on/off
• The touchscreen’s backlight dims after inactivity. By
default, the touchscreen will dim after 30 seconds of activity
on battery power.
• While connected to A/C charger, the touchscreen will dim
after 1 minute of activity.
• To restore the backlight, either double tap the touchscreen or
press any button.

18
Suspend Mode
• The device sets itself into suspend mode after inactivity. By
default, the device will set itself into suspend mode after 3
minutes of inactivity on battery power.
• The device will set itself into suspend mode after 5 minutes
of inactivity while connected to A/C power.
• To manually set the device into suspend mode, briefly press
the power button.
• To resume operation, press the power button.
On-Screen Navigation
Using the Stylus
This tool is used to navigate the device’s touchscreen. The stylus
is located at the device’s left side; remove from slot for use.
Tap
To open items and select options, touch the screen once with the
stylus.
Drag
To drag text and images across the screen, tap, hold, and drag text
or image. Lists and multiple items can also be selected and
moved.
Tap and Hold
Tap and hold the stylus on an item to view a shortcut menu of
available options. From the shortcut menu, select preferred
option.

19
Home Screen
• When the device is turned on, the default screen is the Home
screen.
• The Home screen can be accessed by tapping:and then
Home.
• The Home screen displays upcoming appointments, active
tasks, email messages and notifications, and more. If a
section of the Home screen is tapped, the associated program
will open.

20
Portrait/Landscape View
To change the view preference, tap: Settings/System/Screen/
General/then select “Landscape” or “Portrait”.
Navigation Bar
The navigation bar is located at the top of the screen. It displays
active programs and tools, such as: volume, battery, time,
connectivity, and more. Tap the navigation bar to setup related
items.
Navigation Bar:
Tool Bar
The toolbar is located at the bottom of the screen, including
options such as an onscreen keyboard and the Menu button.
Tool Bar:
Programs
To switch from one program to another without closing other
programs, tap: to open the Start menu.
All available programs can be accessed through the Start menu.
