Swegon GOLD RX Manual

GOLD RX/PX/CX/SD
Generation F
OPERATING PROCEDURES
MANUAL HAND-HELD MICRO TERMINAL IQNAVIGATOR

GB.GOLDSKFTM.170215
2 www.swegon.com We reserve the right to alter specifications without notice.
Content
1.IQnavigator Hand-held Terminal ............................ 3
1.1 General.......................................................................................... 3
1.2 How to use the micro terminal ....................................................... 4
1.3 Buttons.......................................................................................... 5
1.4 Indicator symbols ........................................................................... 5
1.5 Keyboard ....................................................................................... 6
2. Image Management................................................ 7
2.1 Selection of language..................................................................... 8
2.2 Dashboard ..................................................................................... 8
2.2.1 General....................................................................................................8
2.2.2 To change the operating mode................................................................. 8
2.2.3 Alarm log................................................................................................. 8
2.2.4 Log diagram............................................................................................. 9
2.2.5 Flow chart................................................................................................ 9
The document was originally written in Swedish.

GB.GOLDSKFTM.170215
www.swegon.com 3
We reserve the right to alter specifications without notice.
1.IQnavigator
Hand-held Terminal
1.1 General
The hand-held terminal consists of a 7” capacitive touch screen
with a 3 metre long cable for connection to the air handling
unit's control circuit card by means of a quick-fit connector.
The hand-held terminal is switched on/off with an on/off button
located on the top side of the terminal. If the hand-held terminal
is not used for 45 minutes, it switches over to the sleep mode.
See the illustrations below for particulars of the connections,
buttons and LEDs.
IQnavigator can be used outdoors, but it must be kept at a
weatherproof place.
Data:
Operating temperature: -20 - + 50C
Height from which it can be
dropped without damage: 1 metre
Height from which it can be
dropped without damage: 1 metre
N.B.! When you disconnect the cable
from IQnavigator, squeeze the con-
nector so that you press in the catch
inside the connector (hidden under the
protective rubber covering).
Alarm indicating LED
Flashes red in event of
an alarm
In operation indicating LED
Green steady glow while unit is operating
Light sensor
SD card
for
future
function
USB con-
nection for
future func-
tion
Connection for ex-
ternal power supply
(accessory)
Headphone
connection
For future
function
On/off button:
When the touch screen is at rest or is switched off:
Brief press of the On/Off button = touch screen awakens or starts up
When the touch screen is on:
Brief press of the On/Off button = touch screen at rest
Long press of the On/Off button = Question, "Do you want to power
off IQnavigator?" is displayed, press OK, touch screen switches off
RJ45 connection for power and com-
munication cable for IQnavigator (PoE)
or connection to the network (requires
a TBLZ-1-70 net adapter accessory)
RJ12 contact
for future
function

GB.GOLDSKFTM.170215
4 www.swegon.com We reserve the right to alter specifications without notice.
Airow
Status
Regulation mode
Boost
Unit
Air adjustments
Outdoor air compensation
Booster diffusers
Operation level Supply air
Extract air
Unit
Remaining time
Required time h
min.
FORCING
UNIT
AIRFLOW ADJUSTMENTS
Airow
Supply air
Extract air
Supply air duct
Supply air duct, set point
Extract air duct
Extract air duct, set point
Status
Regulation mode
Boost
Unit
Air adjustment
Outdoor air
compensation
Booster diffusers
Operation level
Dashboard
Stop
Alarm log
Timer, low speed
Flow chart
1.2 How to use the
micro terminal
When a scroll bar is displayed on the touch screen, the screen's
content can be scrolled upward or downward.
Scroll bar
When a light grey surface is displayed to the right and/or to the
left on the touch screen and an image indication is displayed at
the bottom edge, this indicates that it is possible to navigate to
one side or both sides.
Light grey
surface
Image indication
(In this case the screen indicates that it is
possible to navigate to both sides)
Status
When the On/Off button is displayed on the touch screen, drag
or point to it so that it shows the required position.
Press the object you want to open or highlight.
Airow
Status
Regulation mode
Boost
Unit
Air adjustments
Outdoor air
compensation
Booster diffusers
Operation level Supply air
Extract air
Unit
Remaining time
Required time h
min.
FORCING
UNIT
AIRFLOW ADJUSTMENTS

GB.GOLDSKFTM.170215
www.swegon.com 5
We reserve the right to alter specifications without notice.
Dashboard
Stop
Alarm log
Timer, low speed
Flow chart
Dashboard
Stop
Alarm log
Timer, low speed
Flow chart
1.3 Buttons
Buttons along the upper edge of the touch screen have the fol-
lowing functions:
Press this button to log out.
Press this button to go one step upward in the
image tree.
Press this button to close a window and to return
to a previously displayed object.
Press this button to return to the dashboard.
Help texts for the current view.
1.4 Indicator symbols
Hand-held terminal connected.
The hand-held terminal has no connection.
Not logged on
Logged on user (local)
Logged on installation
Indicates that the web page is active
Indicates that some communication protocol is
activated
The current time/date, type of air handling unit and
the name of the plant are displayed along the upper
edge of the touch screen. See also Section 4.10.1 in
the Function Manual, Installation.
Log graph
Log graph

GB.GOLDSKFTM.170215
6 www.swegon.com We reserve the right to alter specifications without notice.
1.5 Keyboard
The value that can be changed is highlighted in grey. A keyboard
is displayed at the lower edge of the touch screen when you log
on and enter settings.
A value you want to change can be highlighted by pressing it on
the touch screen.
Then enter the required value and save it by pressing on the
Done button.
The function of the buttons:
Decimal point
Deletes previous character
Decreases the highlighted value
Increases the highlighted value
Minus sign.
Used for writing negative values.
Unspecified value.
Used for the time and schedule function.
User selection
Enter PIN code
Cancel Done

GB.GOLDSKFTM.170215
www.swegon.com 7
We reserve the right to alter specifications without notice.
2. Image Management
Start-up image
Select required language (displayed when
starting for first time). See Section 4.2.1.
Dashboard. See Section 2.2.
N.B.! The appearance of the image
varies depending on the type of air han-
dling unit and functions selected.
Select the required authorization level.
local (user). See Function Manual, Users.
No access code is required.
installation. See Function Manual, Installation.
Code (=1111) is required for access to this image group
service.
Code and special training are required for access to this image
group.
Prole selection
Dashboard
Stop
Alarm log
Timer, low speed
Flow chart
Log graph

GB.GOLDSKFTM.170215
8 www.swegon.com We reserve the right to alter specifications without notice.
Dashboard
Stop
Alarm log
Timer, low speed
Flow chart
2.1 Selection of language
When the air handling unit starts up for the first time, a lan-
guage selection image is displayed. Select required language and
press OK.
If you want to change to a different language later on – or
if you’ve selected the wrong language – you can change the
language under Functions in the hand-held terminal. See Section
3.7 in the Function Manual, Users.
2.2 Dashboard
2.2.1 General
The dashboard is normally displayed if no other image has been
selected.
The touch screen switches to the sleep mode after 45 minutes.
To leave the sleep mode, press on the touchscreen's On/Off
button.
The content in the flow chart changes depending on the selected
type of air handling unit and other functions that affect the
relevant operating conditions.
2.2.2 To change the operating mode
You can start and stop the air handling unit or change over to
manual or automatic operation from the dashboard.
The air handling unit should normally be started and
stopped from the hand-held terminal; not by switching
the safety isolating switch on and off.
2.2.3 Alarm log
Active alarms, pending alarms and alarm history (50 latest) can
be viewed under Alarm log. See also Section 5 in the Operating
& Maintenance Instructions.
Shows number of
current alarms
Shows current
operation status
Log graph

GB.GOLDSKFTM.170215
www.swegon.com 9
We reserve the right to alter specifications without notice.
2.2.4 Log diagram
An SD card must be fitted into the air handling unit's control
circuit card (installed from the factory) in order to make this func-
tion possible. Does not apply to the real time log.
Under "Log diagram", a number of signals can be read in dia-
gram form. Up to four signals can be freely selected and read in
the list under the "Signals" button. The log diagram's time inter-
val can be selected as follows: 4 hours, day, week, month or year.
In the list under the "Signals" button, you can also choose to
mark one of the signals to display it with a thicker line in the log
diagram. This is done by tapping the desired coloured square.
The program automatically adjusts the resolution of the signals.
The means that the program adapts the amplitude of the signal
to the height of the diagram within the selected time interval.
The Log diagram can be selected in two types: History or Real
time, under the "Mode" button.
The cursor of the diagram is fixed and the time line can be
moved by scrolling to the right or to the left.
2.2.5 Flow chart
The flow chart can be displayed in full screen by tapping the
Flow chart heading.
Setting the Edit button to ON makes the flow chart editable.
The positions of all the components marked with a green frame
are interchangeable, for example the mutual order between the
air heater and the air cooler. Place your finger on the relevant
component, drag it to the desired position and lift your finger.
The circulation pump of the air heater can be hidden by clicking
on the air heater symbol.
The grey-marked components with green frame are inactive.
These can be activated by tapping the desired component.
Flow chart
Edit
Edit button Component with
green frame
Signals button Time intervals
Example of coloured square
Mode button
Log graph
Cursor
Signals Position 4 hours Day Week Month Year
Summation,
outdoor air
regulation
Outdoor air
Add signal

GB.GOLDSKFTM.170215
10 www.swegon.com We reserve the right to alter specifications without notice.
