F40C4TMP FLOW35 User manual

Model: FLOW35 / FLOW45 / FLOW55
USER MANUAL
For 37/47/58 Quart Portable Refrigerator

ATTENTION
12/24V
12/24V
▲Please read this manual carefully before useand keep it properly
① When using for the first time,clean the inside and outside of the car refrigerator with a damp cloth.
② Please clean the inside of therefrigerator regularly to prevent odorous bacteria to ensure food
safety.
③ If not usedfor a long time, please disconnectthe power and keep the inside of the portable
refrigerator dry.
▲Connect the power supply
Connect the refrigerator to a
100-240V AC power supply with the
AC adapter (When used at home or
hotel).
Connect the refrigerator to a
12V/24V power supply with the DC
cord (When used in a car, truck,
Camper, Van, Jeep, SUV, boat).
Connect the refrigerator to a
portable power stationand solar
panel with the 100V-240V AC
adapter.
Connect the refrigerator to a
portable power stationand solar
panel with the 12/24V DC cord.
1
_ _

1 Door latch
2Lid
3 Sealing Rubber Ring
4 Digital Screen & ControlPanel
5 Handle
6 Wheel
7 Power Outlet
8 12/24V DC Cord
9 100V-240V AC Adapter
The Factory Default Voltage Protection Level Is: H
12V
H high level N medium l evel L low level
11.3V OFF, 12.5V ON 10.1V OFF, 11.4V ON 9.6V OFF, 10.9V ON
24.6V OFF, 26V ON 22.3V OFF, 23.7V ON 21.3V OFF, 22.7V ON
24V
PORTABLE REFRIGERATOR OPERATION
PARTS SCHEMATIC
TROUBLESHOOTING
Voltage
▲Portable Battery Protection Function
The built-in electronic control module can automatically monitor the car battery voltage. When the car
battery power drops to a certain level, the portable refrigerator will automatically cut off the power
connectionto ensure that the car battery will notrun out.
Note: When the portable refrigerator is turnedon, the ON /OFF refers to the ON /OFF of the
compressor.
Advice: If there is an abnormal situation that cannot be solved through the guidance, please
contact theF40C4TMP customer serviceteam for assistance.
▲The Portable Refrigerator Does Not Work
① Check whether the power is connected correctly or not (the plug is loose, positive and negative
poles are reversed, etc.).
② Check whether the refrigerator is turned on.
③ Check whether the cooling ventilation is normal.
④ Check whether the fuse is blown.
▲ Low Cooling Efficiency
① Check whether the fridge door is closed properly.
② Check whether the door seal is damaged or deformed, resulting in unsealed.
③ Check whether the heat dissipation and ventilation are working normally.
④ Check whether the temperature setting is proper.
▲Abnormal Noise
① Check whether the refrigerator is placed stably.
② Check whether the refrigerator hit the wall or other items.
③ Check whether the internal part in the compressor compartment is loose or fell off.
2
_ _

▲Condensation of the Refrigerator Surface
When the ambient air humidity is >75%, a slight frost will occur on the surface of the cabinet, which is
a normal phenomenon.
Note: For the replacement parts, please contact F40C4TMP customer service team.
ErrorCode
E1
E2
E3
Error Type
The input voltage is too low
Fan problem
Compressor starts frequentlyor
input voltage failure

Solutions
① Condition: Plug the 12V DC cord into the car cigar
lighter before the car engine starts.
Solution: Plug the DC cord intothe car cigarlighterafter
the car engine starts.
② Condition: The input voltage of the adapter is too low.
Solution: Adjust the battery protection modeto
Middle/Lowlevel. If the fridge still does not work
normally,pleaseuse a new adapter.
Solution: Please replace with a new fan.
① Condition: E3appears when using the DC cord.
Solution: Please use the AC adapter to test it. If the
refrigerator can work normally without the E3 code, you
need to check your external power supply.
② Condition:E3 appears when using the AC adapter.
Solution: Please power off the refrigerator for 5 minutes.
After that,turn on the refrigerator. If E3 still appears,
please replace the compressor controller.
Solution: Please power off the refrigerator for 1 hour,
and then restart it to see if E4 still appears. If it is, please
replace the compressor controller.
Solution: Power off the refrigerator for 15 minutes. Then
turn it on to check whether the fan rotates. If it doesn't,
please replace the fan.
Note: Reserve 15cm for the cooling holes for ventilation.
Solution: Disassemble the control panel to check
whether the NTC cord is loose.
Note: The NTC cord is inside the control panel.
E4
E5
E6
Compressor turbine speeds is
too slow
Controller chip overheated
NTC open circuit or short circuit
TROUBLES AND TROUBLESHOOTING
3
_ _

▲Function Introduction
After power on, the digital control panel will light up for 1 second, and then display normally. The
default settings remain as the last time set. In the standby mode, the ECO/MAX light flashes.
▲ON/OFF
1. Long press the " " button, the refrigerator will be in the turn on/standby mode.
Turn on mode: Display the whole screen for 1 second, and then display the current inner box tempera-
ture.
Standby mode: The ECO/MAX light flashes.
▲Temperature Adjustment Setting
① Short press the " " button to increase the temperature by 1 °C, the maximum temperature can
reach up to +10 °C; short press the "-"to reduce the temperatureby 1 °C, the minimum temperature
can be turned down to -20 °C; long-press the " "/" " button, it would increase/decrease by 3 °C
per second.
②After setting the temperature, if there is no further operation on the panel within 3 seconds, the
temperature display will stop flashing and save the currently set temperature.And then the display
panel will show the current temperature of the inside box.
③ The initial startup default Fahrenheit is 32°F, and the default Celsius is 0°C.
▲Celsius/Fahrenheit Switch
①After turning on the refrigerator, press the " " and " " buttons at the same time to switch
Fahrenheit / Celsius.
②When switching between Fahrenheit and Celsius, the displayed value is related to the set tempera-
ture. For example, when the temperature is set to 0 °C, the panel will display as 32°F when switching
to Fahrenheit.
▲ECO/MAX Mode Switch
Press the" "button to switch between ECO (energy-saving) mode and MAX (fast cooling) mode.
The indicator light is red in ECO mode while it is blue in MAX mode.
▲Battery Protection Voltage Setting
Note: The factory default battery protection level is H (high level).
Long press the " "button to enter the battery protection voltage setting. When the current level
icon flashes, short press the " "button to switch between H1/N2/L3 level (according to your
needs). If there is no operation on the panel for 3 seconds, it would automatically save andexit the
level setting mode.
The portable refrigerator has a power-off memory function. The fridge state (On / Off, ECO / MAX mode, or H / M
/ L
level) will be restored automatically before power-off, so there is no need to reset the settings the next time
you turn on the freezer.
ECO: Energy Saving and Cooling Mode
MAX: Fast Cooling Mode
ON/OFF
Switch/Setting
Temperature UP
Temperature Down
OPERATION INSTRUCTION
4
_ _

PORTABLE REFRIGERATOR ELECTRICAL SCHEMATIC
The F40C4TMP portable refrigerator comes with a 2-year warranty from the date of purchase.
If you have any questions during use, please feel free to contact us through:

 Phone No.: 4086887296
Monday to Friday 9:00 am - 5:00 pm ( PST )
 Email: [email protected]
 Website: www.f40c4tmp.com
 Amazon: Message us through "Ask a question"in F40C4TMP Amazon shop
Tip: It is recommended to use this refrigerator in a car.
▲Safety Attention
① Always ensure that the power supply voltage connected to the portable refrigerator is correct (the
portable refrigerator verification voltage parameter is on the parameter label).
② Do not pour liquid especially corrosive liquiddirectly into the portable refrigerator.
③ To avoid danger, it is forbidden to transform the refrigerator privately.
④ The refrigerator couldnot be exposed to rain.
AFTER-SALES SERVICE AND WARRANTY
5
_ _
