F40C4TMP SNOW28 User manual

Model: SNOW28
USER MANUAL
For 30 Quart Portable Refrigerator

The F40C4TMP portable refrigerator comes with a 2-year warranty from the date of purchase.
If you have any questions during use, please feel free to contact us through:
 Phone No.: 4086887296
Monday to Friday 9:00 am - 5:00 pm ( PST )
Email: [email protected]
 Website: www.f40c4tmp.com
 Amazon: Message us through "Ask a question"in F40C4TMP Amazon shop
AFTER-SALES SERVICE AND WARRANTY

▲Please read this manual carefully before useand keep it properly
① When using for the first time,clean the inside and outside of the portable refrigerator with a damp
cloth.
② Please clean theinside of therefrigerator regularly to prevent odorous bacteria to ensure food safety.
③ If not usedfor a long time, please disconnectthe power and keep the inside of the portable refrigera-
tor dry.
▲Connect the power supply
① The portable refrigerator is dual-use for car and home. It supports 12V / 24V DC and 110V AC.
Tips: The refrigerator can also runwith energy storage power supply.
② For car: Find the DC power cord in the kit. Connect the DC plug to the power outletof the portable
refrigeratorwith another end plugged into cigarette lighter.
③ For home: Find the AC adapter (2 sections) in the kit. Connect one plug to the power outlet of the
portable refrigerator with another end plugged into the household wall outlet.
④ Press the " " button for 3to 5seconds, then the portable refrigerator will be turned on.
Connect to the car
cigarette lighter
12/24V DC power
cord
100-240V AC power
cord
Car refrigerator
power outlet
ATTENTION
1
_ _

▲Safety Attentions
① Always ensure that the power supply voltage connected to the portable refrigerator is correct (the
portable refrigerator verification voltage parameter is on the parameter label).
② Do not pour liquid especially corrosive liquiddirectly into the portable refrigerator.
③ Do notplace the freezer under direct sunlight.
④ The refrigerator couldnot be exposed to rain.
⑤ This product is not designed to be used by children.Do not allow children to crawl around this
product.
2
_ _
PORTABLE REFRIGERATOR ELECTRICAL SCHEMATIC

Voltage
12V DC
24V DC
The Factory Default Voltage Protection Level Is: H
High mode Medium Mode Low mode
11.3V OFF, 12.5V ON 10.1V OFF, 11.4V ON 9.6V OFF, 10.9V ON
24.6V OFF, 26V ON 22.3V OFF, 23.7V ON 21.3V OFF, 22.7V ON
Note: When the portable refrigerator isturnedon, the ON /OFF refers to the ON /OFF of the
compressor.
▲Parts Schematic
▲ Car Battery Protection Function
The built-in electronic control module can automatically monitor the car battery voltage. When the car
battery power drops to a certain level, the portable refrigerator will automatically cut off the power
connectionto ensure that the car battery will notrun out.
PORTABLE REFRIGERATOR OPERATION
3
_ _
①
①
Ventilation port
②
②
12/24V power outlet
③
③
Interior handle
④
④
Control panel & Digital display
⑤
⑤
⑥
⑥
Seal rubber ring
⑦
⑦
Regfrigerator cabinet
⑧
⑧
Removable divider
USB

▲ Digital Display And Control Panel
Battery Protection Mode
Temperature
MAX / ECO Mode
ON / OFF
Unlock / Setting
Increase The Temperature
Decrease The Temperature
Electricity / Voltage
OPERATION INSTRUCTION
4
_ _

▲Operation Method
① Press the " "button for 3 seconds,the refrigerator isturnedon/ standby.
② Press the " " / " "button to adjust the temperature.
③ Long press the " " / " " buttonto increase or decrease the temperature at a rate of 3°Cper second. The
number will not flash during the process of adjustment.
④After setting the temperature, if there is no further operation on the panel within 3 seconds, the temperature display
will stop flashing and save the currently set temperature.
⑤ The temperature display shows the actual temperature inside the box.
⑥Under the standby mode, the control panel will not light up.
⑦ Under the working status, press " "button to switch MAX / ECO mode.
⑧ Temperature can be adjusted between -7.6°F to 50°F(-22°C to +10°C).
⑨ Temperature unit conversion: Press " "and " "for 3 seconds at the same time to switchCelsius(°C) and
Fahrenheit(°F).
⑩ Car battery protection mode: During the working state, press the " "button for 3 seconds to enter the battery
protection setting. Then press the " "buttonto switch H / M / L. After selecting a level, the display panel will flash
for 5 seconds, and then it will automaticallysave and exit the setting.
* Generally speaking, when connectingtothe car power, we recommend using the H level. Whenconnecting to the
portable power station, it is recommend to selectM / L level.
⑪ Note: Please adjust the refrigerator settings when the panel is in the unlocked state. If the panelis locked, please
press the " " button for 3 seconds to unlock it.
▲Temperature Adjustment Settings
Adjust the temperature of the portable refrigerator through the LCD panel.
The portable refrigerator has a power-off memory function. The fridge state(On / Off, ECO/ MAX mode, or H / M / L
level) will be restored automatically before power-off,so there is no need to reset the settings the next time you turn
on the portable refrigerator.
ECO: Energy Saving and Cooling Mode
MAX:FastCooling Mode
5
_ _

If you equipped the portable refrigera-
tor with a portable power station, it
could maintain the proper temperature
you set under any circumstances
without any worries.
When placing ice cream, please adjust the
temperature to the lowestand always keep
the portable refrigerator on.
Portable refrigerator let chilled ingredi-
ents(frozen food, expensive seafood, etc.)
accompany the journey.
The ideal storage temperature of red
wine is50°Fto 64°F. The precise
temperature control of the portable
refrigerator canensure the storage
temperature of red wine.
The coating of sunglasses will fall off
under the high temperature in summer,
and the portable refrigerator is the ideal
place to put it.
Cosmetics are easy to deteriorate under
the high temperature in the car. A
portable refrigerator will be a better
choice for you tostore the cosmetics.
Prevent health problems caused by
drinking bottled water that is exposed
to excessive heat.
Tea can be kept fresh in the portable
refrigerator so that you can drink fresh
and delicious tea at any time during
the driving tour.
In summer, the temperature inside the
car is very high, causing the fruits in
the car to be unable to keep fresh for
more than 2 hours. Even if the air
conditioner is open, the storage time is
short. The portable refrigerator can
effectively keep fruits fresh.
OPERATION SUGGESTION
6
_ _

Advice: If there is an abnormal situation that cannot be solved through the guidance, please contact theF40C4TMP
customer serviceteam for assistance.

▲The Portable Refrigerator Does Not Work
①Check whether the power is connected correctly or not (the plug is loose, positive and negative poles are reversed, etc.).
②Check whether the refrigerator is turned on.
③Check whether the cooling ventilation is normal.
④Check whether the fuse is blown.

▲Low Cooling Efficiency
①Check whether the fridge door is closed properly.
②Check whether the door seal is damaged or deformed, resulting in unsealed.
③Check whether the heat dissipation and ventilation are working normally.
④Check whether the temperature setting is proper.

▲Abnormal Noise
①Check whether the refrigerator is placed stably.
②Check whether the refrigerator hit the wall or other items.
③Check whether the internal part in the compressor compartment is loose or fell off.

▲Condensation of the Refrigerator Surface
When the ambient air humidity is >75%, a slight frost will occur on the surface of the cabinet, which is a normal
phenomenon.
TROUBLESHOOTING
7
_ _

① Condition: Plugthe12v DCcord into the car cigarlighter before the
car engine starts.
Solution: Plug the DC cord intothe car cigarlighterafter the car engine
starts.
② Condition: The input voltage of the adapter is too low.
Solution: Adjust the battery protection modeto Middle/Lowlevel. If the
fridge still does not work normally,pleaseuse a new adapter.
Solution: Please replace with a new fan.
The input voltage is too low
Note: For the replacement parts, please contact F40C4TMP customer service team.
① Condition: E3appears when using the DC cord.
Solution: Please use the AC adapter to test it. If the refrigerator can be
used normally without the E3 code, you need to check your external
power supply.
② Condition:E3 appears when using the AC adapter.
Solution: Please power off the refrigerator for 5 minutes. After that,turn
on the refrigerator. If E3 still appears, please replace the compressor
controller.
Compressor starts frequentlyor
input voltage failure
Solution: Please power off the refrigerator for 1 hour, and then restart
the refrigerator to see if E4 still appears. If it is, please replace the
compressor controller.
Compressor turbine speeds too
slow
Solution: Power off the refrigerator for 15 minutes. Then turn on the
refrigeratorto check whether the fan rotates. If the fan does not rotate,
please replace the fan.
Note: Reserve 15cm for the cooling holes for ventilation.
Controller chip overheated
Solution: Disassemblethe control panel to check whether the NTC cord
is loose.
Note: The NTC cord is insidethe control panel.
NTCopen circuit or short
circuit
Fan problem
▲Error Code Definition
Error Code
E1
E2
E3
E4
E5
E6
Error Type Solutions
8
_ _

▲Cleaning
① Disconnect the power supply before cleaning theportable refrigerator.
② Dissolve sodium bicarbonate (baking soda) in warm water to clean the refrigerator. Neveruse abrasive products,
detergents or soaps to clean the refrigerator.
③ After cleaning, wipe the inside of the refrigerator with a clean damp cloth and carefully dry it.
④ If the inside of the device is wet,do not store the device.Always make sure the inside of the refrigerator is dry before
you store it.
⑤ Never clean the equipment in running water or dishwater.
⑥ Clean all vents of the compressor compartment with compressed air or a vacuum cleaner.

▲Defrosting
① The inside of the refrigerator may ice up which will reduce the capacity and cooling efficiency. Defrosting the
refrigerator regularly will keep the portable refrigerator in top operating condition.
② Take out all items.
③ Disconnect the power supply of the portable refrigerator.
④ Open the lid and let the refrigerator temperaturereturn toambient temperature.
⑤ When the ice melts, soak up the water with a clean towel.
⑥ Once all the ice has melted, clean the interior.
CAUTION:DO NOT use hard, sharp or pointed objects to remove the frost or use them to help you
remove the frozen items. This may cause irreparable damage to the cooling system.
9
_ _
CLEANING & MAINTENANCE

www.f40c4tmp.com
Find 40°F, Refresh Your Outdoor Life.
