FADE KING FK-S User manual

24h Customer Support
Email:[email protected]
FK-S/FADE KING Hair Clipper
CONTENTS
Components 1
Parameters 2
How to Recharge 2
Fixed-Length Function 3
Cutter Assembly and Disassembly 4
Cutter Cleaning and Maintenance 5
Precautions For Use 6
Warranty Card 7

Components 1 2
Bottom blade
Top blade
Blade lever
LED Display
ON/OFF switch
Combs Brush
Standard 5V/US
charging port
Parameters
How to Recharge
InputUse time 300 minutes 5V 1A
Charge time Charging
method
2.5 hours Type-C/DC
Voltage Material
3.0V Zinc Alloy
Power Blade
10W 440C T-blade
Speed type Battery
6100 RPM
(±200) 2500mAh
1. Insert the charger into the tail of the clipper, connect to the
power to start charging.
2. The liquid crystal indicator lights up, indicating that it start
chargingwhen the red light changes to the green light fully charged.
Note: when the power is switched on after charging, the indicator
lights up to indicate that the charging head is reversed or drawn to
be replaced immediately.

A: Use of Limit Comb: Cropped hair and hair trim
Feature: [1.5, 3, 4.5, 6, 10 & 13mm] six lengths adjustment to
control the hair length.
1. To determine the length of haircut.
2. To select the appropriate limit comb.
3. To fine-tune the cutter
Adjust the cutter by rotating
the adjusting ring from forward
to downward.
Mount the limit comb:
1. Align the limit comb with the blade edge
2. Slightly forward push to mount it.
Disassemble the limit comb: Just pull hard
the limit comb.
Fixed-length Function 3
The sketch shows how the bottom blade holes
are larger than the shanks of the blades
screws.When the blade screws are loosened the
bottom blade can be aligned with tight after the
blade is aligned.
2.Extreme left-hand tooth of the top blade must be covering or be
to the left of the first small tooth of the bottom blade.
3.Extreme right-hand tooth of the top blade must be touching the
big tooth on the bottom blade.
1.End of the top blade teeth should be 1/32" to
1/16,0.79mm to 1.59mm back from the bottom
blade.This is important so that the clipper
doesn’t cut too close or allow the moving cutter
to touch the skin.
Taper Lever
Some clippers are equipped with an adjustable
taper lever that changes the closeness of your
cut.When the lever is in the uppermost position,
the blades will give the closest cut.Pushing the
lever downward gradually increases the cutting
length.
Warm tip: do not disassemble the knife head without any skill.
Cutter Assembly and Disassembly 4
1
3
2

Blade Alignment
Cutter Maintenance
1. Your clippers were carefully examined to ensure that the blades
were oiled and aligned before leaving our factory.
2. Blades must be realigned if they have been removed for cleaning
or replacement.
3. To realign the blades,simply match the upper and bottom blades
teeth up, point for point.(End of top blade teeth should be
approximately 0.5-1.0mm back from the bottom blade.Compare
your clipper blades with the sketch)
4. If blade alignment is incorrect,add a few drops of oil to the
blade,turn the clipper on for a few moments,turn off and
unplug.Loosen screws slightly and adjust.
Tighten screws after the blade is aligned.
To maintain your clipper in peak condition,the
blades should be oiled every few haircuts.
To oil it properly,the unit should be held so the
blades are in a downward position.With the clipper
blade running,dispense 2-3 drops of oil across the
top blade.
Cutter Cleaning and Maintenance 5
1.Please do not disassemble the product.
2.The hair clipper can not be washed.
Please keep it away from wet conditions.
3.The product can only be cleaned by cloth with little water or mild
soap solution.
4.Do not charge the product under environment above 40°C.or
below 0°C.
※The product can produce little heat duringusing or charging,
which is normal.
※Please remove the battery safely and return it to the specified
places when the battery runs out. Never discard it casually.
Precautions For Use 6

Following Guarantees Provided For The Product
1.The product is produced through strict quality management and
inspection.
2.lf malfunction occurred in fair use, the consumer can enjoy free
warranty service according to the warranty card in the purchasing
store or our repair center.
(The battery and blade belong to consumables, not coverd by
warranty but provided with fee)
3.No free services for the following situations:
A.Damages caused by repair or reformation not approved
by our company.
B. Damages caused by false or neglectful use, or by accidents.
C. Damages caused by natural disasters or abnormal voltage.
D. Damages caused by ignoring attentions provided with in the
product specification.
4.The product is only guaranteed when provided the warranty
card instead of the invoice.
Product Name Professional Hair Clipper
Month Date Year
Warranty Period
To Month Date Year
One year from the
purchasing date
Product Model
Purchasing Date
Customer
Address
Address
Name
Name
Name
Phone
Number
Phone
Number
Point of
Sale
Warranty Card 7
