FairField PTYUKNDR08 User manual

Models:
PTYUKNDR08 - Yukon River 8’, Northern Dri
PTYUKRVN08 - Yukon River 8’, Weathered Raven
Yukon River
ASSEMBLY INSTRUCTIONS

page 1
Congratulaons on selecng a Yukon River slate pool table - part of the Fairfield Collecon
by Playcra. Please contact us ia email at support@playcra.com should you require any
assistance.
Please carefully read all safety instrucons and direcons before proceeding
1) Your table is designed for use indoors in a climate controled environment only.
Damage can occur if the table is exposed to water, dampness, high humidity,
freezing temperatures, etc.
2) Professional assembly is strongly recommended. This assembly manual is intended to
guide an experienced slate pool table installer with the assembly process of this
specific cabinet. It does not guide on seng the slate or aaching the billiard cloth
for which the process is the same regardless of the cabinet type.
2) The pool table cabinet and slate are extremely heavy. Two or more people are
required for assembly.
3) The table must be assembled in the final locaon where the table will be played.
Aempng to move the table once assembled could result in damage to the table
or serious injury.
5) Only use the table for its intended purpose.
6) Damaged or worn parts may be dangerous for users and the integrity of the table.
Replace worn or damaged components immediately and do not use the table unl any
issues have been resolved. For best results, use only spare parts supplied by Playcra.
7) Unauthorized repairs or alterang the table’s design or funcons may be dangerous and
will void the warranty.
8) Check all screws, bolts, etc. on a regular basis to ensure that they are in good working
condion and have not loosened over me.
9) Over me, pool tables may require releveling. This is considered normal maintenance
as required with owning a slate pool table

HARDWARE LIST
NO. REF. PARTS SPECIFICATION QTY UNIT
A
HANGER BOLT ø10*210 8 PCS
CONNECTION OF PANEL AND LEGS ASSEMBLY
POSITION
B
WASHER ø10*80 12 PCS
CONNECTION OF PANEL AND LEGS ASSEMBLY
POSITION
C
HEX BOLT ø12*220 4 PCS
CONNECTION FOR CROSS BEAMS ASSEMBLY
POSITION
D
SEMICIRCLE SCREW NUT M12 4 PCS
CONNECTION FOR CROSS BEAMS ASSEMBLY
POSITION
E
FLAT HEAD SCREW 4.2*60 8 PCS
CONNECTION FOR MIDDLE BEAMS ASSEMBLY
POSITION
F
HEX BOLT ø10*60 4 PCS
CONNECTION FOR BAEM AND LEGS
G
ADJUSTABLE SCREW ø10*100 12 PCS
TO ADJUST AND LEVELING THE SLATE ASSEMBLY
POSITION
H
ADJUSTABLE SCREW ø10*55 4 PCS
TO ADJUST AND LEVELING THE SLATE ASSEMBLY
POSITION
I
FLAT HEAD SCREW 6*60 12 PCS
TO FIX THE SLATE ASSEMBLY
POSITION
J
HEX BOLT ø8*80 8 PCS
CONNECTION FOR RAILS ASSEMBLY
POSITION
K
SEMICIRCLE WASHER M8 8 PCS
CONNECTION FOR RAILS ASSEMBLY
POSITION
L
NUT M8*30 8 PCS
CONNECTION FOR RAILS ASSEMBLY
POSITION
M
FLAT WASHER M8 20 PCS
CONNECTION FOR PANELS AND RAILS ASSEMBLY
POSITION
NHEX BOLT ø8*30/ø8*40 8+12 PCS
CONNECTION FOR PANELS AND RAILS ASSEMBLY
POSITION
O
HEX BOLT ø10*60 18 PCS
CONNECTION FOR RAILS AND SLATE ASSEMBLY
POSITION

P
DOME WASHER M10 18 PCS
CONNECTION FOR RAILS AND SLATE ASSEMBLY
POSITION
Q
LEATHER POCKET 1 PCS
POCKET ASSEMBLY
POSITION
S
FLAT HEAD SCREW 4.2*20 12 PCS
POCKET ASSEMBLY
POSITION
T
WOODEN PLUG ø10*50 2 PCS
CONNECTED #2 AND #3 TOP RAIL ASSEMBLY
POSITION
HARDWARE LIST

PARTS LIST
NO. DESCRIPTION ITEM SPECIFICATION QTY UNIT
1
LEG 2 PCS
ASSEMBLY POSITION FRAME
2
STEEL DECORATION 1 PC
ASSEMBLY POSITION FRAME
3
CROSS BEAM 2 PCS
ASSEMBLY POSITION FRAME
4
LONG BEAM 2 pcs
ASSEMBLY POSITION FRAME
5
MIDDLE BEAM 2 PCs
ASSEMBLY POSITION FRAME
6
SIDE SLATE 1 1 PC
ASSEMBLY POSITION RAILS
7
MIDDLE SLATE 1 PC
ASSEMBLY POSITION RAILS
8
SIDE SLATE 2 1 PC
ASSEMBLY POSITION RAILS

NO. DESCRIPTION ITEM SPECIFICATION QTY UNIT
9
CLOTH 1 PC
POSITION RAILS
10
SHORT RAIL 2 PCS
ASSEMBLY POSITION RAILS
11
SLATE 2 PCS
ASSEMBLY POSITION RAILS
12
SLATE 2 PCS
ASSEMBLY POSITION RAILS
13
SLATE 4 PCS
ASSEMBLY POSITION RAILS
14 SLATE 2 PCS
ASSEMBLY POSITION RAILS
15
SLATE 2 PCS
ASSEMBLY POSITION RAILS
PARTS LIST

Customer Service
Global Merchants, Inc.
12 Lunar Drive
Woodbridge, CT 06525
