Falcon 4G CPE Router User manual

1
FALCON 4G
CPE Router
User Manual
Benutzerhandbuch


2
WHAT’S IN THE BOX? 3
QUICK SETUP GUIDE 3
ROUTER OVERVIEW 4
ROUTER DESCRIPTION 5
SIMCARD 5
WIRED CONNECTION STEPS 6
WIRELESS CONNECTION STEPS 7
ADMIN LOGIN 8
GENERAL UK APN SETTINGS 9
TECHNICAL SPECIFICATION 9
RESETTING PASSWORD 10
RESET ADMIN PASSWORD 10
FACTORY RESET 11
TROUBLESHOOTING 12
WAS IST IN DER BOX? 13
KURZANLEITUNG ZUR EINRICHTUNG 13
ROUTERÜBERSICHT 14
ROUTER DESCRIPTION 15
SIM KARTE 15
KABELGEBUNDENE VERBINDUNGSSCHRITTE 16
SCHRITTE ZUR DRAHTLOSEN VERBINDUNG 17
ADMIN LOGIN 18
GENERAL UK APN SETTINGS 19
TECHNISCHE SPEZIFIKATION 19
RESETTING PASSWORD 20
ADMINPASSWORT ZURÜCKSETZEN 20
WERKSEINSTELLUNGEN ZURÜCKGESETZT 21
TROUBLESHOOTING 22
RANGE BOOSTER SOLUTIONS 23
Congratulations on the purchase of your new
FALCON 4G CPE Router
Please read the manual carefully.
If further support is required please contact us
United Kingdom Enquiries:
UK Website: https://falcontechnology.co.uk
European Website: https://falcontechnology.eu
Email: [e-mail]
Telephone: [phone]
German Enquiries:
Email: info@easynd24.de
Hotline: [phone]
CONTENTS

3
WHAT’S IN THE BOX?
• Check for any accessories hidden behind or in the packing materials
when opening the box.
• The item colours and shapes may vary depending on the models.
User Manual
4G Router
Antenna’s
Ethernet Cable (1m)
Local Power Supply
QUICK SETUP GUIDE
Step 1: insert your SIM-card (it will require preloaded data from your ISP).
Step 2: Plug in the device.
Step 3: Use your mobile phone or computer to search and connect to the
network “FALCON-300-4G”:
Step 4: Enter Password: F@LCON@300a
Step 5: Conrm signal by checking the solid light on the front of the
router.
Step 6: Scroll down to P9 for APN settings.
Step 7: Enjoy your browsing experience.
12v cigarette power
cable (2m)

4
ROUTER OVERVIEW

5
ROUTER DESCRIPTION
SIM-CARD
white

6
Wired Connection:
1. Insert activated SIM-Card
2. Conrm the CPE is in normal start-up state
3. Connect the PC or other equipment terminals with the network port on
the back of the CPE through the network cable (1m cable included)
4. Figure below shows wired connections:
WIRED CONNECTION STEPS
SIM

7
WIRELESS CONNECTION STEPS
Wireless Connection:
1. Insert activated SIM-Card
2. Conrm the CPE is in normal start-up state. Search available networks
and click on “FALCON-300-4G”
3. Key in the wi password:“F@LCON@300a”
4. Figure below shows connections and sticker on base of router:
SIM

8
ADMIN LOGIN
1. Login details are found on the base of the router (and below).
2. Open your browser and type in the IP followed by username and
password.
1. Login page will appear as below.
2. Conrm APN settings are correct.

9
GENERAL UK APN SETTINGS
Name Username Password Access Point Name
(APN)
EE eesecure secure everywhere
giga gg p giga.com
O2 o2web password mobile.o2.co.uk
Sky Mobile mobile.sky
Three three.co.uk
Vodafone PAYG wap wap pp.vodafone.co.uk
Vodafone wap wap wap.vodafone.co.uk
Talkmobile wap wap talkmobile.co.uk
Virgin Mobile goto.virginmobile.uk
Tesco Mobile tescowap password prepay.tesco-mobile.
com
*At the time of printing all details were correct but for any discrepancies
please check with your provider.
TECHNICAL SPECIFICATION
Power: 12v 1A
Ethernet Speed: 300Mbps
Wireless LTE: 150 Mbps
Max users: 32
Signal Strength: -112dBm
RSSI: -85.3dBm
SINR: 1.1
Languages: 46

10
RESETTING PASSWORD
3. Click“Apply”to save changes
1. Now signed in, click on Settings > WLAN > WLAN Basic Setup
1.1 Change SSID
1.2 Change password (click display password to conrm).
2. Sign back in when prompted to with your new details.
2.1 Please save your new credentials
2. Click“Apply”to save changes
RESET ADMIN PASSWORD
1. Now signed in, click on Settings > System > Modify Password
1.1 Enter old password and stronger new password.
