Fantech TFC6 User manual

Part No.: TFC6 08/12 Page 1 of 2
FAN CONTROL THERMOSTAT
SPECIFICATIONS
Sensing element : NTC
Temperature set-point range: 5°C to 30°C
Accuracy: ±1.5°C
Maximum current rating: 6 Amps
Power supply: AC240V, 50/60 Hz
Dimensions: 86 × 86 × 33 mm (W × H × D)
Operating rating: 0-40°C, 5-95%RH (non-condensing)
Control performance: 2°C differential
OPERATING MODE
Turn the knob to the desired temperature indicated on the scale.
MODE SELECTION
Configuration jumpers allow your TFC6 to be adapted to COOL or HEAT mode.
COOL: Set jumper configuration as per Diagram 1 to EXTRACT warm air OUT of a room.
When the room temperature is higher than the set-point, the fan will start.
When the room temperature drops to the set-point, the fan will turn off.
HEAT: Set jumper configuration as per Diagram 2 to SUPPLY warm air INTO a room.
When the room temperature is less than the set-point, the fan will start.
When the room temperature reaches the set-point, the fan will turn off.
LED INDICATION
Red = Power on
Orange = in working status
CONTROL LAYOUT WIRING DIAGRAM
MOUNTING
1. To open remove knob &
depress clips at top.
2. Fix the base with screws. 3. Connect as per wiring
diagram.
4. Install the cover and knob.
Temp. scale
Power OFF
Temp. knob
LED light
L
N
N
Fan
AC240V
50/60Hz
H
Diagram 2
Heat Mode
J1
J
2
J3
J1
J2
J3
Diagram 1
Cool Mode

Part No.: TFC6 08/12 Page 2 of 2
