Fastrax III User manual

I
Warnings and Cautions
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE. DO NOT INSERTANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instruction in the literature
WARNING
CAUTION
accompanying the product.

II
FCC COMPLIANCE
STATEMENT
FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO
PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE
REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN
THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL
AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE
USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN
EXPENSE.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY
THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME
NMB-003 DU CANADA.
CE COMPLIANCE STATEMENT
WARNING
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER
MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.

III
IMPORTANT SAFEGUARDS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
14. CAUTION - THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE
OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.
15. Use Certified/Listed Class 2 power supply transformer only.

IV
Table of Contents
Chapter 1 —Introduction ........................................................................................................1
1.1 Features...............................................................................................................................................1
Chapter 2 —Installation and Configuration...........................................................................3
2.1 Package Contents................................................................................................................................3
2.2 Basic Configuration of Fastrax III Dome Camera System...................................................................4
2.3 Setting Dome Camera Termination......................................................................................................5
2.4 Fail-safe Network.................................................................................................................................6
2.5 Setting Dome Camera Address (ID) ....................................................................................................7
2.6 Setting Dome Camera Protocol...........................................................................................................8
2.7 Connections.........................................................................................................................................9
Connecting to the RS-485/ 422............................................................................................................9
Connecting Video out connector ..........................................................................................................9
Connecting Alarms ...............................................................................................................................9
Connecting the Power..........................................................................................................................9
2.8 Getting Started...................................................................................................................................10
Chapter 3 —Program and Operation.....................................................................................11
3.1 Dome Camera Selection....................................................................................................................11
3.2 Accessing On-Screen Menu Utility ....................................................................................................11
3.3 How to control On-Screen Menu Utility..............................................................................................12
3.4 Auto Scan...........................................................................................................................................12
3.5 Preset.................................................................................................................................................14
3.6 Shortcut Preset Program ...................................................................................................................16
3.7 Tour ...................................................................................................................................................16
3.8 Pattern ...............................................................................................................................................18
3.9 Alarm..................................................................................................................................................19
3.10 Area Title..........................................................................................................................................21
3.11 Privacy Zone ....................................................................................................................................21
3.12 Camera Menu type 1 .......................................................................................................................23
Focus Control .....................................................................................................................................23
WB (White Balance) Control ..............................................................................................................24
AE Control ..........................................................................................................................................24
Line Lock Control................................................................................................................................25

V
3.13 Camera Menu type 2...........................................................................................................................26
Focus Control.......................................................................................................................................26
WB (White Balance) Control ................................................................................................................27
AE Control............................................................................................................................................27
Line Lock Control .................................................................................................................................28
3.14 Camera Menu type 3...........................................................................................................................29
Focus Control.......................................................................................................................................29
WB (White Balance) Control ................................................................................................................30
AE Control............................................................................................................................................30
Line Lock Control .................................................................................................................................32
3.15 Camera –26X Model...........................................................................................................................32
3.16 Dome Setup.........................................................................................................................................33
Language Setup...................................................................................................................................33
Home Function Setup...........................................................................................................................33
OSD Display.........................................................................................................................................34
View Angle Setup .................................................................................................................................35
Initialize Data....................................................................................................................................... 36
Origin Offset .........................................................................................................................................37
Dome Reset .........................................................................................................................................38
System menu .......................................................................................................................................38
System Information ..............................................................................................................................40
3.17 Function Run.......................................................................................................................................41
3.18 Motion Setup Type 1 (36x model only) ...............................................................................................42
3.19 Motion Setup Type 2 (35x model only) ...............................................................................................43
Appendix A —Specifications................................................................................................ 44
Appendix B —Troubleshooting............................................................................................ 47
Appendix C —Glossary......................................................................................................... 48
Appendix D —Short Cut Key................................................................................................ 51

1
Chapter 1 —Introduction
1.1 Features
The Fastrax III dome camera and the keyboard controller make up the building blocks for any
surveillance/security system. Using multiple Keyboard Controllers and multiple dome
cameras, no place is too large for monitoring. Extensible and flexible architecture facilitates
remote control functions for a variety of external switching devices such as multiplexers and
DVRs.
Built-in optical power zoom camera with True Night Shot function.
240 Preset positions.
8 Tours consist of Preset, Pattern, Auto-Scan and other Tours can be programmed with
over 300 functions and Preset location. While moving, each Preset scan can be watched in
smooth Vector Scan mode.
16 Auto Scans with the normal, the vector, and the random mode and the Endless Auto-
Pan with 13 speed steps.
8 Patterns (up to 500second) and 8 Privacy zones.
16 Area Titles.
8 Alarm inputs / 4 Aux outs (NC & NO).
Variable speed from 0.1/sec to 380/sec.
Three Variable speed (SLOW, NORMAL, TURBO)
Turbo speed is Max 380/sec with Ctrl key pressed.
Pan / Tilt speed is inversely proportional to the zoom ratio with the option.
Maximum speed is 380/sec when preset command.
Auto Calibration from 0.1to 6(Tilt range is 0to 180).
Programmable user preferences (alarm, preset, title, etc.).
180Digital Flip or 90Auto Flip depended on the model.
Up to 999 selectable camera addresses (3999 by software setting).
Multi-language Menu Display, Password Confirmation.
Function Run menu using DVR without function key (Pattern, SCAN,..)
Built-in RS-485/422 receiver driver.
Optional Clear bubble with black liner (shelter) for concealing the camera.
Optional Tinted Bubble, Indoor & Outdoor pendant housing with heater & blower, Indoor
Flush mount, Parapet mount & Roof Top mount.

2
Figure 1 –Typical System Configuration
push
push
remove camera window
remove window assemble bubble ring ass'y
bubble ring ass'y
screw
Figure 2 –Assemble bubble ring ass’y (Optional)
Note: It is recommended to remove camera window for improving picture quality when you
use bubble ring ass’y.

3
Chapter 2 —Installation and Configuration
2.1 Package Contents
The package contains the following.
Fastrax III (Dome Camera) ………………………1
Bubble Ring ………………………1(Optional)
Instruction Manual (This Document) ………………………1
Assembly Screws for Attaching Fastrax III ………………………3
Plastic Anchor ………………………3
10Pin Connector ………………………1
12Pin Connector ………………………2
CAUTION: Be sure to have caution labels (E version only) on both the body and the
base of the camera. Different version will not support input and output.
The dome camera is for use in surface mounting applications and the mounting surface
should be capable of supporting loads up to 10lb (4.5kg).
The dome camera’s base should be attached to a structural object, such as hard wood,
wall stud or ceiling rafter that supports the weight of the dome camera.
Figure 3 –Installation
Unlock Lock
Lock BODY
BASE
Align extruded tap in the base to
the Keyhole on the pcb in the body
SURFACE(CEILING)
CABLE ENTRY

4
2.2 Basic Configuration of Fastrax III Dome Camera System
Figure 4 –Basic installation diagram
The dome camera must be installed by qualified service personnel in accordance with all
local and federal electrical and building codes. The system should be installed according to
Figures 4 through 9.
AC+ AC- AC+ AC- FGND (Rx+) (Rx-) Rx(Tx)+ Rx(Tx)- GND
Tx+ Tx- GND
RS-485 Controller

5
Figure 5 –Layout of Switches
2.3 Setting Dome Camera Termination
The device which is connected at end of line, whether it be a dome camera or keyboard
controller, must have the cable for communication terminated by setting the appropriate DIP
switch. Without proper termination, there is potential for control signal errors. Total length of
the cable for communication should not exceed 4000ft (1.2km).
Figure 6 –Setting Dome Camera Termination
SW1
1
2
Terminated
ON
ON
Not terminated
OFF
OFF

6
2.4 Fail-safe Network
When you control the dome by the other device not own keyboard, some error may be
existed in the serial communication. The reason is caused by the other device without the
fail-safe network.
At this time, you solve the problem to set this DIP switch to ON of the nearest dome from the
other device only.
Figure 7 –Setting Dome Camera Termination
Figure 8- Termination Diagram
SW2
1
2
ON
PULL-UP
PULL-DOWN
OFF
NONE
NONE

7
2.5 Setting Dome Camera Address (ID)
To prevent damage, each dome camera must have a unique address (ID). When installing
multiple dome cameras using a multiplexer, it is suggested that the dome camera address
match the multiplexer port number.
If you want to set the address more than 999, you should contact the service provider.
Example: Port 1 = Dome 1, Port 2 = Dome 2 … Port 16 = Dome 16. If more than 16 dome
cameras are installed using two or more multiplexers, ID of the dome camera should be ID of
MUX x No. of camera IN. (e.g. multiplexer ID= n, Camera IN= m then ID of Dome =16x
(n-1)+m )
Refer to Figures 4-5 for setting the dome camera address (ID) and protocol selection.
Figure 9 –Setting Dome Camera Address (ID)
1
2
3
4
5
6
7
8
9
0
8
1
1
2
3
4
5
6
7
8
9
0
8
1
1
2
3
4
5
6
7
8
9
0
8
1
S3
S2
S1
DOME ID
S3
S2
S1
1
0
0
1
2
0
0
2
.
.
.
.
999
9
9
9

8
2.6 Setting Dome Camera Protocol
If a dome camera is to be installed with a Fastrax keyboard controller,
select the default protocol.
Consult service personnel if a dome camera is installed with device other than a keyboard
controller.
S/W
On
Off
FUNCTION
D1
S4-1
Enable
Disable
Alarm
D2
S4-2
PAL
NTSC
NTSC/PAL
D3
S4-3
Reserved
D4
S4-4
RS-422
RS-485
RS-422/RS-485
D5
D6
D7
D12
PROTOCOL
S5-1
S5-2
S5-3
S6-4
Off
Off
Off
Off
F2,F2E,Pelco-D,Pelco-P:default
Off
Off
On
Off
F2,F2E
Off
On
Off
Off
Sensormatic RS422
Off
On
On
Off
Pelco-D, Pelco-P
On
Off
Off
Off
Vicon
On
Off
On
Off
Ernitec
On
On
Off
Off
Reserved
On
On
On
Off
F2
Off
Off
Off
On
Philips(Bosch)
Off
Off
On
On
Reserved
Off
On
Off
On
Dynacolor
Off
On
On
On
Reserved
D8
D9
D10
BAUD RATE
S5-4
S6-1
S6-2
Off
Off
Off
2400 bps
Off
Off
On
4800 bps
Off
On
Off
9600 bps (Default)
Off
On
On
19200 bps
On
Off
Off
38400 bps
D11
PARITY BIT
S6-3
Off
None
On
Even
Figure 10 –Protocol Selection Switches
NTSC
PAL
on
on
S4
S4

9
2.7 Connections
•Connecting to the RS485/ 422
The dome camera can be controlled remotely by an external device or control system,
such as a control keyboard, using RS485 half-duplex, RS422 full duplex or simplex serial
communications signals. Connect Marked Tx+, Tx- to Tx+(Rx+) and Tx-(Rx-) of the RS485
control system.
If control system is RS422, connect Rx+(Tx+), Rx+(Tx-) and Rx+, Rx- of the dome camera to
Rx+, Rx- and Tx+, Tx- of the control device respectively.
•Connecting Video out connector
Connect the video out(BNC) connector to the monitor or video input.
•Connecting Alarms
AL1 to 8 (Alarm In)
You can use external devices to signal the dome camera to react on events. Mechanical or
electrical switches can be wired to the AL (Alarm In) and GND (Ground) connectors.. See
Chapter 3 —Program and Operation for configuring alarm input.
GND (Ground)
NOTE: All the connectors marked GND are common.
Connect the ground side of the Alarm input and/or alarm output to the GND connector.
NC(NO)1 TO 4 (Normal Close or Normal Open : Alarm Out)
The dome camera can activate external devices such as buzzers or lights. Connect the
device to the NC(NO) (Alarm Out) and COM (Common) connectors. See Chapter 3 —
Program and Operation for configuring alarm output.
•Connecting the Power
Connect the power of AC 24V 850mA to the dome camera.
Use certified / Listed Class 2 power supply transformer only.

10
2.8 Getting Started
Once installed apply power to the dome camera. The dome camera will start a configuration
sequence.
OSD Position
The dome can move the OSD position in the OSD position setup.
OSD Position Setup
001 AF AE
EMPTY DATA
DOMEID:0001
ALARM:1 W→360.0,090.0
(AREA TITLE) (AF AE)
(FUNC TITLE )
(CTRL KEY TO MOVE)
SAVE AND EXIT(ESC TO CANCEL)
(ALARM MESSAGE) (DOME ID…)
(ANGLE…)
INFORMATIO
N DISPLAY
FUNCTION
UNDER RUNNING
ALARM DISPLAY
CAMERA TITLE
CAMERA ID
VIEW DIRECTION
PAN & TILT ANGLE
PRESET TITLE
AREA TITLE
STATUS of
FOCUS and AE

11
Chapter 3 —Program and Operation
3.1 Dome Camera Selection
Before you program or operate a dome camera, you must select the dome camera by
pressing the dome camera No. + CAM
Example:Pressing 1, 0and CAM key sequentially will select dome camera 10. The
selected dome camera ID will be displayed on the LCD monitor of the keyboard controller.
3.2 Accessing the On-Screen Menu Utility
You can call up the On-screen menu utility on your monitor by pressing MENU key on the
keyboard controller, the following On-screen menu utility will appear:
DOME MENU
AUTO SCAN
PRESET
TOUR
PATTERN
ALARM
AREA TITLE
PRIVACY ZONE
CAMERA
DOME SETUP
FUNCTION RUN
EXIT(ESC TO EXIT)

12
3.3 How to control the On-Screen Menu Utility
Function
Button
Call the On-screen menu utility
MENU
Navigate through the menu items.
Joystick up or down
Go into the sub-menu items.
Joystick left or right
or IRIS Open
Change value.
Enter the editing title mode.
Joystick left or right or
Zoom handle twist or
Tele , Wide
Change value of angle
CTRL + Joystick
Enter the changing angle mode.
IRIS Open
Exit the changing angle mode.
IRIS Close
Escape (EXIT)
ESC
3.4 Auto Scan (Shortcut: SCAN)
The Auto scan supports up to 17 programmed angles at user-programmable speeds. Follow
these steps to program Auto Scan:
NUMBER :01 -08, 10-17, 09:AUTO PAN mode
TITLE :up to 12 characters.
MODE :NORMAL, VECTOR, RANDOM (AUTO PAN mode :NORMAL, RANDOM
only)
NORMAL: Move from start point to end point in panning only.
VECTOR: Move from start point to end point including tilt and zoom simultaneously and
linearly. In some model, the zoom is fixed at wider angle and the zoom
magnification information is not displayed.
RANDOM: Move randomly between the start point and the end point.
AUTO SCAN SETUP
NUMBER : 01
TITLE : A01
MODE : NORMAL
SPEED : 5 STEP
START ANGLE : ----- ----- ---
END ANGLE : ----- ----- ---
SCAN DIR : CCW
SWAP : OFF
DWELL : 03 SEC
SAVE AND EXIT(ESC TO CANCEL)

13
SPEED : 1 - 13 step, the lower number means the slower speed.
SCAN DIR : Set the scan direction, CCW(Counter Clock Wise), CW(Clock Wise)
SWAP : Swap the start point for the end point.
DWELL : Set the dwell time at the both end, 01 –99 seconds
1. Press the SCAN key to enter the auto scan menu directly. Or press the MENU key to
display the main menu on the monitor. Scroll to Auto Scan and push the Joystick to the
right.
2. Select the‖NUMBER‖and set the desired number by pushing the Joystick left or right.
3. Select the ―TITLE‖and twist the Joystick to enter the title edit mode.
4. Twist the Joystick by changing the alphanumeric characters and move the next position.
Or move down to the character table and press CTRL or IRIS OPEN at the desired
character then the cursor position moves to the next position automatically. Push the
Joystick left or right at the ―ALL DELETE‖field to delete all characters. Push the
Joystick left or right at the ―EXIT‖field to finish title edit menu.
5. Select ―MODE‖ and ―SPEED‖.
6. Select ―START ANGLE‖. Hold down the CTRL key while selecting the start position using
the Joystick. Current panning position will be displayed. Release CTRL key to complete
the selection of the start position. Or Press IRIS Open then the ―CTRL‖displays. Move
the desired position and the zoom position. Press IRIS Close then the ―CTRL‖
disappears. To adjust at the 0.1 degree interval, twist the Joystick at the pan field and the
tilt field. To adjust at the one zoom interval, twist the Joystick at the zoom field.
7. Select ―END ANGLE.‖ Hold down the CTRL key while moving the Joystick to select the
end position. The end position angle should be larger than start position. Release the
CTRL key to complete the selection of the end position. Or Press IRIS Open then the
―CTRL‖displays. Move the desired position and the zoom position. Press IRIS Close
then the ―CTRL‖disappears. To adjust at the 0.1 degree interval, twist the Joystick at the
pan field and the tilt field. To adjust at the one zoom interval, twist the Joystick at the
zoom field.
8. Set ―SCAN DIR‖to CCW or CW.
9. Select ―SWAP‖. Set to ON, to exchange the start angle and the end angle.
TITLE EDIT MENU
A01
*
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z 0 1 2 3
4 5 6 7 8 9 ( )
ALL DELETE
EXIT (ESC TO EXIT)

14
10. Set ―DWELL TIME‖.
11. Select Save and Exit and push the Joystick to the right or press IRIS Open. Press
ESC or IRIS Close to exit the program without saving.
Pressing the HOME key delete stored data at the angle field.
To set the position using the preset position:
a. Before entering the Auto Scan menu, select a preset position as a starting point for
Auto Scan.
Example:2+ PRST and do step 1 to 4. In step 5, just press the Ctrl key at the start angle
position, the current position will be displayed as a start position.
b. Save and exit from the menu.
c. In normal mode, call a preset to be the end point of scan. Press 3+ PRST then press
Scan key to enter the Auto Scan menu. Move the cursor position to END ANGLE. Just
press CTRL key at the end angle position. Save and exit from the menu.
Press SCAN key on the angle field to display with the small OSD. Then the screen will show
as below.
The setting procedure is the same as above.
NOTE: 09:AUTO-PAN mode(Endless panning)
3.5 Preset (Shortcut: PRST)
If you need to view specific places routinely, you should program presets. A preset is a
programmed video scene with automatic pan, tilt, zoom, focus, and AE settings. Once
programmed, placing the number position and pressing a PRST button on your controller
calls up that preset automatically. In addition, presets may be assigned to alarm actions or
as the ―home‖position for the dome camera. As many as 240 presets, whose positions are
saved in the dome’s firmware, may be programmed.
There are three pages of preset menu. Each page has 80 presets. Pages can be scrolled
by pushing the Joystick to the Left or Right on the first or last No. of Preset.
AUTO SCAN AREA SETUP
(CTRL KEY)
NUMBER01
START: ----- ----- ---
END : ----- ----- ---
EXIT(ESC TO EXIT)
