FAT TIRE GOLF SCOOTER Cruiser 3.0 User manual

Cruiser 3.0 Owner’s Manual
www.FatTireGolfScooter.com
[e-mail]
Phone: [phone]
Fax: [phone]

2
Table of Contents
Page 3- Specifications
Page 4- General Operation
Page 5- Safety Information
Page 6- Warranty

3
Rebel 3-Wheel Specifications
• 3000 Watt, High Torque Waterproof Motor
• 63v Lithium Ion Battery Pack
• Approx. 15 mph speed (locked for golf course safety), 25mph
Max.
• Weight Capacity 300 lbs.
• Scooter Weight– 190 lbs.
• 225/55-8 Tubeless Tires
• Front and Rear Hydraulic Disc Brakes
• 63 volt, 3amp Charger
• LED Headlight
• One Year Parts Warranty
• Cooler
• Sand Bottle
• Scorecard Holder

4
Operation of Fat Tire Cruiser 3.0
1. Insert key and turn clockwise. Display will light up showing the battery status. Turn key one more
position to activate front headlight
2. When ready to ride, slowly twist the throttle toward you while keeping your left fingers on the brake
handle, ready to brake. Drive a very short distance and apply the left brake. Do this 2-3 times until
you get familiar with the throttle and braking. Once comfortable, build up a little speed and get your
feet up on the floorboard.
3. The red button near the throttle will control the available top speeds, 3 being the fastest.
Charging the battery:
The Rebel Fat Tire Cruiser is equipped with a 63 volt 20ah lithium ion battery. The battery can be charged on
-board or the battery can be removed from under the seat and charged remotely. It takes approximately 6
hours to fully charge the battery. The charger has a red light to indicate the battery is being charged, and a
green light when fully charged. Remove the charger from the battery after charging.

5
Safety Tips
Safety tips for the Fat Tire Golf Scooter (FTGS) include:
1. Pay attention to your surroundings at all times. Make sure you are comfortable with the throttle and
hand brakes before going out on the course.
2. Be careful with your speed. Avoid obstacles or sharp turns. Use your brakes when going downhill
to avoid excessive speed.
3. The FTGS should be kept at least 10 feet from the tees and greens.
4. Do not ever put multiple people on the same FTGS.
5. Be careful and always pay attention.
6. Stay clear of mud, sand, loose dirt or gravel, and water.
7. The FTGS is not a toy and is not to be ridden by children under the age of 18.
8. Do not enter areas that are identified as not safe for the FTGS
.
9. Never ride down hills that put your safety and the FTGS at risk. Walk your FTGS down steep
slopes and areas where advised by the course.
10. Do not take the FTGS over curbs as this can cause serious damage.
11. Do not operate FTGS under the influence of alcohol or drugs.

6
Warranty
The Fat Tire Golf Scooter warranties all parts against manufacturers defects for a period of
ONE year.
FTGS will, at their discretion, replace or repair any item found to be defective, including:
• Frame
• Motor
• Controller
• Battery
• Throttle
• Brake Calipers and Master Cylinders
NOTE:Wear items such as tires, brake pads, rubber parts, seat fabric and cushions, cooler, sand
bottle etc. are NOT included.
Labor costs are NOT covered by warranty
ANY DAMAGE OR DEFECT OCCURRING FROM THE MISUSE OF THE SCOOTER IS
NOT COVERED.
Warranty starts from the time scooter is delivered to your home or facility.
Fat Tire Golf Scooter
13232 N. Cave Creek Rd.
Phoenix, AZ 85022
www.fattiregolfscooter.com
