Fcar F501 EOBD User manual

OperatingGuide for Fcar Code Readers
1
Statement
The publicati on is designed only for the use of FCAR products, and any organizati on or individual shall not
reproduce and back up this Guide in any form (in electronic, mechanical, photocopying, recording forms or
othe r forms) without the wri tten permission of FCAR Company.
The use of the guide is exclusive to professional a uto repairing and maintenance technicians.
The Guide only provides opera ting method of FCAR products , and FCAR s hall not be liable for any possible
cons equence of the use of this method that is applied to other equipment.
FCAR shall not be liable for accidents arising from the use of the purchaser hi mself or the third party,
damages to the equipment due to the purchaser ’s incorrect use, misuse or pri va te modification, repairing
or operations and maintenance requirements that are inconsistent with the Guide, and fees and expense
for the loss.
The Guide is based on the current specifications and functions of the product. If the newspecifi cations and
functions a re added to the product, there will be corresponding changes in the Guide without further
noti ce.
FCAR has been registered its tradema rk throughout the worl d, with the logo as . In countries
where any of the FCAR tradema rks , service marks, domain na mes, logos and company names, etc. are not
registered, FCAR claims that it still has ownership of non-registered tradema rks, service ma rks, domain
names, logos and company names etc. Other products or company names , logos, service marks etc.
referred to in the Guide s till belong to their respecti ve owners . Anyone, without the written permission
from the owners of the applicable trademarks, servi ce marks, domain names, logos or company names etc.,
shall not use any trademarks , service ma rks, domain names, and l ogos of FCAR Company or other
compa nies designated by FCAR Company.
Fcar Series Product Operating Guide
Before using FCAR F3 series product, please read the Guide carefully.
The Guide is based on the current s pecifications and functions of the product. If the new specifications
and functions are added to the product, there will be corresponding changes in the Guide. The new Guide
can be downloaded from the FCAR Company’s website (http://www.fcar.com).
Please carefully read the "Note", ＂Remark＂and “Introductions” of the Guide to ensure that you can use
our products properly and safely.
FCAR F3 Series Main Unit Maintenance and Use Attentions
Do not a llow unauthorized demolition.

OperatingGuide for Fcar Code Readers
2
Avoi d s trong impact to this machine.
Prevent it from closing to the magnetic field.
Do not put this machine in a hot environment for a l ong ti me.
Do not put this machine at a l ow temperature environment for a l ong ti me.
Do not ha ve the screen impacted and keep the keys clean.
Clea n the machine with soft clean cloth and neutral detergent, instead of water or chemical solvents.
Automobile Inspection Notes
Should operate the machine according to safety rules in auto repair i ndustry. Special attentions should be
pa i d in order to prevent the machine from being a ffected or damaged because of the environmental
fa ctors such as the s urrounding pH, poison gas, high pressure, heavy objects, etc.;
Vehi cle battery fl uid contains sulfuric acid, while sulfuric acid is corrosive to the skin. Therefore, in
ope ration you s hould protect your skin from directly contacting with battery fluid. Particularly, ma ke sure
tha t they won’t s plash into your eyes. You should also avoid cl osing to fire;
Engine exhaust emissions contains a variety of toxic compounds, so you should protect yourself from
inhaling them. During operating, the vehicle s hould be parked in a well-ventilated place;
The temperature of the working engine is high, so you should protect yourself from contacting with high
temperature components such as water tank and exhaust pipes;
Before starting the engine, you s hould hold the handbrake and have gear lever placed i n neutral (Guide
trans mission)or P gear position (automatic transmission), so as to avoid the vehicle rushing out and result
in accidents when you start the engine;
Before repairing the vehicles, you should hold parking brake well, shift transmission gear into the neutral
pos ition or P gear, and lower the glass doors and windows on the driver's seat side;
If the engine can be started, you should firstly warm up i t to a normal temperature (water temperature is
at about 80 ℃), a nd cl ose the auxiliary electrical appliances (such as air conditioning, lighting,
loudspeaker, etc.);
Fi nd the diagnostic socket of this car, a nd check, confirm that whether the wires of the diagnostic s ocket
are i n good condition, and then connect the main unit for diagnosis. Otherwise, do not test, a nd a void
da mage to the main unit. If necessary, you can usea multimeter to measure the voltage of diagnostic
socket.
Instrument Use Notes
When you use FCAR series products for testing, you must handle it with care a nd keep them away from
heat source and electromagnetic field, so as to avoid interference with the main unit.
When electrical components are energized, you cannot disconnect the ci rcuit to prevent the
self-inductance, mutual inductance from attacking s ensors and automotive ECU.
When electrical equipment works normally, you should avoid putting magnetic objects close to the
vehi cle control unit, otherwise the vehicle control unit may be damaged.

OperatingGuide for Fcar Code Readers
3
Vehi cle control unit or electrical components dismounting should be done only 1 mi nute after the ignition
switch is turned off.
Content
Statement............................................................................................................................. 错误!未定义书签。
1.1 Introduction to Fcar Code Readers........................................................................................................5
1.2 Introduction to Its Appearance and Basic Function ..........................................................................5
1.2.1 F501 Gasoline OBDⅡCode Reader ...................................................................................................6
1.2.2 F502 Diesel OBD Co de Reader ..............................................................................................................7
1.3 Product Parameters..................................................................................................................................7
1.4 Operation Methods ..................................................................................................................................8

OperatingGuide for Fcar Code Readers
4
1.5 Product Configuration List .................................................................................... 错误!未定义书签。
1.6 Warranty Clause ...................................................................................................... 错误!未定义书签。

OperatingGuide for Fcar Code Readers
5
1.1 Introduction to Fcar Code Readers
FCAR F501,F502 OBDⅡ/EOBD code readers are the la test portable vehicle code readers launched by FCAR
Company. Wi th them, the users can fast and efficientl y read out the fault codes in automobile electric
controlling system and then know where the fault codes are and how they happen through such fault codes
read out. The code reader is applicable in all auto repairing factories . They are portable for car owners to at any
time moni tor whether there a re faults in automobile electri c controlling system. LED-guided operation
ins tructions make them easy to understand and practical.
FCAR s eries code reader is a pplicable to the vehicles equipped with standard OBDⅡdiagnostic socket and
can read and erase fault code and read data stream.
1.2 Introduction to Its appearance and Basic Functions
FCAR F501 and F502 series products are sa me in appearance and hardware confi gurations (mode, serial
number that is affi xed to the back of the product). 2.8-inch and 320*240 LED display is adopted. To meet the
operation habit of each indi vidual user, the appearance, menu and functions of the products are well -designed.
It supports all-in-one function, multi -language choosing, and LED-guided operations , which makes i t eas y to
operate a nd understand and quite practical.
Also, the product is a pplicable to vehi cles with 8V ~ 32V working voltage, and is stable in work and can fully
meet customers’different demands for diagnosis.
1、OK di agnosis normal indicator light: The indicator light is on i n communication diagnosis.
2、OK dia gnosis failure indica tor light: The indicator light is on when there is a failure of communication
di a gnosis;

OperatingGuide for Fcar Code Readers
6
3、Voltage indi ca tor light: The indi ca tor light is on when the machine is connected to OBD Ⅱdiagnosti c sockets.
4、Di agnosis communication line, which should be connected to OBD Ⅱdi agnostic sockets on the vehicle;
5、Up a nd down buttons
6、Enter: The button for confirmation;
7、USB da ta line interface: Backup interface for data connecting;
8、Exit: The button for cancellation and back.
1.2.1 F501 Gasoline OBDⅡCode Reader
Features
Support gasoline cars (1996~2013) which have OBDⅡ/EOBD and a re used in a reas like America, Europe
and Asia;
Check fa ult code general(P0、P2、P3、U0) a nd particular cars (P1、P3、U1);
Display definitions of real-ti me data and storage and confirm “check the reasons of Mal functi on Indicator
Lamp (MIL) of the engine;
Clea r malfunction fault code and reset historical storage, and turn off the MIL of the engine;
Di s play freeze frame data; and
Retrieve vehicle i nformation (VIN、CIN、CVN).
Diagnostic Protocol
Generic OBDII and EOBDII
OBDII SAEJ1850 VPW Mode
OBDII SAEJ1850 PWM Mode
OBDII ISO9141-2 ISO Address Mode
OBDII ISO14230-4 KWP Address Mode
OBDII ISO14230-4 KWP Fast Mode
OBDII ISO15765-4 CANBUS 11BI T Mode
OBDII ISO15765-4 CANBUS 29BI T Mode
Functions
Read Stored Codes
Read Pending Codes
Erase Codes
Read Freeze Frame
Current Data
I/M Readiness
O2 Moni tor Test
On-Board Monitor Test
Component Test
Vehi cle Information
DTC Lookup

OperatingGuide for Fcar Code Readers
7
1.2.2 F502 Heavy truck Code Reader
Features
Support ve hicles that compatible wi th standard protocol of heavy-duty trucks (J1939 a nd J1708).
Read DTC
Support ECU of vehicles like CUMMINS、Bosch、DELPHI
Be connected to OBD16 via diesel 6PINand diesel 9PIN
Diagnostic Protocol
J1587 Test
J1939 Test
Functions
Engine #1
Turbocharger
Trans mission
Axle, Power Unit
Axle, Trailer
Brakes, Power Unit
Brakes, Trailer #1
Ins trument Cl uster
Trip Recorder
…………
1.3 Product Parameters
Screen size
2.8 inch 320*240 LCD
Work voltage
8V ~ 32V
Work current
Typi cal value <100mA
Connection method
Standard 16-PIN OBD diagnosti c
connector
Working temperature
0℃~ 50℃
Storage environment temperature
-20℃~70℃
Relative humidity
60%
Product s ize（mm）
123*88*27
We i ght of the main unit
280g

OperatingGuide for Fcar Code Readers
8
1.4 Operation Methods
1、When the MIL of the engine of the vehi cle wi th standard OBDⅡdiagnos tic socketis lightened up, you must
stop the vehicle as well as hold the brake, turn the key ignition to ON and then insert the FCAR code readerinto
16pi n diagnostic socket of the vehicle; standa rd OBDⅡdiagnos ti c socket generally is set below the s teering
wheel at the driver side.
2、Take F501 for example (the opera tions for F502 diesel code reader is similar). After being connected to
diagnos ti c socket, FCAR reader will sta rt automati call y and displa y the l ogo of FCAR. A few seconds later, you
will enter diagnosis interfa ce and choose the function you want. If you want to do diagnosis, please choose
“Di a gnostics”a nd e nter i t by cl icking the key “Enter”.
3、Vehicle diagnosis：Here, you can see the communication protocol available for s tanda rd OBDⅡdiagnosis of
gasoline vehicle, and choose the i tem a ccording to the a ctualconditions of the vehicle.
===========Select Menu============1/3
Diagnostics
DTC Lookup
Tool Information
===========Select Menu============1/8
Generic OBDII and EOBDII
OBDII SAEJ1850 VPW Mode
OBDII SAEJ1850 PWM Mode
OBDII ISO9141-2 ISO Address Mode
OBDII ISO14230-4 KWP Address Mode
OBDII ISO14230-4 KWP Fast Mode
OBDII ISO15765-4 CANBUS 11BIT Mode
OBDII ISO15765-4 CANBUS 29BIT Mode

OperatingGuide for Fcar Code Readers
9
4、After you enter the s ystem, you can read fault code, erase fault code and read data stream and others (When
the content of the menu exceeds the la rges t part that the interfa ce is able to displa y, you choose the item by
cli cking up and down buttons). If there is communication failure prompted during the diagnosis, please check
whether key swi tch is turned on or not, the diagnosti c protocol selected is ri ght or wrong a nd diagnos tic s ocket
on the vehicle has signal voltage or not, etc.
5、Read Stored Codes，e.g.：
6、Erase Codes，e.g.：
==========Select Menu===========1/10
Read Stored Codes
Read Pending Codes
Erase Codes
Read Freeze Frame
Current Data
I/M Readiness
O2 Monitor Test
On-Board Monitor Test
========Read Freeze Frame=========1/1
P0130 O2 Sensor Circuit (Bank 1 Sensor 1)
==========Select Menu===========1/10
Read Stored Codes
Read Pending Codes
Erase Codes
Read Freeze Frame
Current Data
I/M Readiness
O2 Monitor Test
On-Board Monitor Test

OperatingGuide for Fcar Code Readers
10
7、Erase Codes succeeds：
8、Current Data：Read the status of all current data s tream in a ti mely manner
9、Current Data is displayed as follows，and you can browse them by clickingup and down buttons
============Message Box============
Message: Successful
Press any key to continue
==========Current Data===========1/21
Number of fault codes stored
1
Fuel system 1 status
OL
Fuel System 2 status
Reserved
Calculated Load Value
0.0%
==========Select Menu===========1/10
Read Stored Codes
Read Pending Codes
Erase Codes
Read Freeze Frame
Current Data
I/M Readiness
O2 Monitor Test
On-Board Monitor Test

OperatingGuide for Fcar Code Readers
11
5、DTC query：Select DTC Lookup. This DTC query function is applicable to general standard DBD DTC. Therefore,
if you ca nnot fi nd the one you want on the screen, i t suggests that the DTC i s the one set by the manufacturers.
6、Here, you can find all standa rd OBDⅡDTC. According to the tips below, you can query DTC by changing DTC
number. This interface means tha t when you press up or down button, the DTC number will increase or reduce
1000 (“Step” for short) for once. If there is a need to change the step, please press Enter,and step will undergo
cycl ic cha nge (like 1000→100→10→1→1000).
7、The interface is as follows when the step is s witched to 10
===========Select Menu============1/3
Diagnostics
DTC Lookup
Tool Information
============ DTC Lookup===========1/1
P0001 Fuel Volume Regulator Control
Circuit/Open
[Enter ] Scaling =0100
[Up ] Value +1000
[Down] Value -1000
[Exit ] Exit to menu
============ DTC Lookup===========1/1
P0001 Fuel Volume Regulator Control
Circuit/Open
[Enter ] Scaling =0001
[Up ] Value +0010
[Down] Value -0010
[Exit ] Exit to menu

OperatingGuide for Fcar Code Readers
12
===========Select Menu============1/3
Diagnostics
DTC Lookup
Tool Information
7、Product system information：Incl uding the information l ike serial number of the product
8、Seri al Number, Release Date, Software Version, Hardware Version, Database Version, and so on
1.5 Product Configuration List
Number
Physical Map
Name
Description
1
Outer package
==========Tool Information==========1/5
Serial Number ：A13010101
Release Date ：2013-03-18
Software Version ：V1.0
Hardware Version：V8.5
Database Version：V5.8

OperatingGuide for Fcar Code Readers
13
2
Mai n uni t of
code reader
3
Di e se l -6
Note：This
connector is
onl y l imited to
F502
4
Di e se l -9
Note：This
connector is
onl y l imited to
F502
5
Opera ting guide
Production
introducti on,
operati on
methods ,
warrant claus e,
etc.

OperatingGuide for Fcar Code Readers
14
1.6 Warranty Clause
Dear Fcar users, wel come to choose Fca r F3-W products . In order to enjoy better use of the product, you
are suggested to take good care of your products , and operate the products in accordance wi th the operating
guide whenever you use i t. If you can use the products pursuant to this requirement, you will enjoy long-term
qua lity s ervice provided by your products.
1．After you are sure that the following terms and conditions are met and you ha ve carefull y read the wa rranty
clause of this product, you can enjoy the free maintenance servi ce provided by FCAR Technology if there
are s ome defects related to materials or workmanship on your products.
2．Your product must be purchased from product dealer that is authorized by Shenzhen Fca r Technology Co.,
Ltd (hereinafter referred to Fca r Technology). You have to bear the maintenance cost for your product if
you buy the product through non-normal channels.
3．The following objects of the product is out of the warranty range: Operati ng guide, items that are eas y to
wea r and tear such as inner a nd outer package box
4．Si nce the date when the products are purchased, if the products suffer performance failure caused by
non-human fa ctors, you can choose our maintenance services or repla ce the product with the same model
within 15 days. You can enjoy one year warrantyservice for the main unit
5. You ma y not enjoy free warranty s ervice if the products a re in any of the following cases:
1）Failure, defect or flaw that do not belong to the quality of Fcar Technology products: including youruse
of the product not a ccording to the product instruction, improper opera tion of the produ ct, crash, fall,
disassembly by yourself, connection of improper accessories, damage owing to crash because of
improper transport or s torage of the product, the erosion and corrosion,etc. that caused by infiltration
of liquid or food.
2）The na tural wear and tear of product: Including but not limited to cover, keypad, a ccessories etc.
3）Product main unit serial number and wa rranty ca rd product serial number do not ma tch, and product
qua lity inspection tag or bar code is removed, altered or damaged.
4）Mai ntenance a nd modification without the approval of Fcar Technology or FCAR distributor
6. In case of product quality problem or failure occurring during the wa rranty period, you can take the
fol lowing measures:
1）You can dial customer service hot-line number of FCAR Technology: （[phone], a nd get right
service information.
2）After you get the valid response of our company, you have to post your products to the address (see the
details following the wa rranty clause) designated by our company for repairing and maintenance,
otherwise, you will not get timely repairing and maintenance. You will be responsible for the loss of your
products.
7. In the process of product wa rranty, you should bear relevant cost arising before post your prod ucts to the
places designated by Fca r Technology: including costs for package, transportation, delivery and insura nce,
etc.
8. If enjoying your free wa rranty service under this warranty clause is the only measure for the losses due to

OperatingGuide for Fcar Code Readers
15
product defect within the product wa rranty peri od, Fca r technology shall not be liable for your direct or
indirect loss.
9. All product warranty information, product fea tures and speci fi cation changes will be posted on Fcar
Technology latest promotionalmaterials and Web site without further notice.
