FCC BBQ FCC-GP-201980 Guide

GAS FIREPCE
!
INSTRUCTION MANUAL & MAINTENANCE
Sare  u  cookin!
OUTDOORUSEONLY
READTHEOPERATINGINSTRUCTIONS
BEFOREUSINGTHEAPPLIANCE.
FCC-GP-201980

GAS FIREPCE
Contents
Read Carefully .............................................................................................3
Technical information ...............................................................................4
Warning ..........................................................................................................5
Parts list ............................................................................................................6
Assembly instructions ............................................................................7
Regulator and hose ...............................................................................10
Gas leak test ................................................................................................11
Final Check ................................................................................................12
Lighting instructions................................................................................. 13
Cleaning & Maintenance ...................................................................14
Troubleshooting ..........................................................................................15
Consumer Contact .................................................................................16
2

Read Carefully
Do not use this fireplace indoors, as it may cause personal injury or property damage.
THIS FIREPLACE MUST ONLY BE USED OUTDOORS.
●Do not connect the fireplace to any gas supply until it has been fully assembled.
●This outdoor fireplace is not intended to be installed on recreational vehicles and/or boats.
●Appliance should be located on a solid surface.
●Maintenance and repair should be carried out be a qualified technician.
●Improper installation, adjustment, alteration can cause personal injury or property damage.
●Do not attempt to alter the unit in any manner. Any modifications may be dangerous and are
not permitted.
●Do not store or use petroleum or other flammable vapors or liquids in or near the fireplace
unit.
●The whole gas system, hose, regulator, pilot or burner should be inspected for leaks or damage
before use, and at least annually by a qualified technician.
●All leak tests should be done with a soap solution. Never use an open flame to check for leaks.
●Do not use the fireplace until all connections have been leak tested.
●Turn off the gas valve if smell of gas is detected and immediately shut off any gas supply.
●Do not transport fireplace while it is operation.
●Do not move the fireplace until temperature has fully cooled after it has been turned off.
●Control compartment, burner and circulation air passageways of the fireplace must be kept
clean.
●Frequent cleaning may be required as necessary.
●All gas cylinders should be turned off when the fireplace is not in use.
●Check the fireplace immediately if any of the following occurs:
○The fireplace does not reach temperature.
○The burner makes popping noises during use (a slight noise is normal when the burner is
extinguished).
○Smell of gas in conjunction with extreme yellow tipping of the burner flames.
○The burner does not ignite or continues to go out
●The gas regulator and hose assembly must be located in the cylinder cabinet where gas
cylinder is installed.
●Any guard or other protective device removed for servicing the fireplace must be replaced
before further use.
●Adults and children should stay away from high temperature surfaces to avoid personal injury
or property damage. WARNING: Accessible parts may be very hot.
●Children should be carefully supervised at all time when they are in the area of the fireplace.
●Clothing or other flammable materials should not be hung on the fireplace or placed on or
near the fireplace.
●Do not use the fireplace for any form of cooking.
○Do not throw anything into the fireplace.
●Do not leave the fireplace unattended whilst in operation.
●Do not use fireplace in excessively windy conditions.
●Do not user fireplace in excessively rainy conditions, as this could lead to damage to
components.
●Ensure the gas supply is isolate and shut off when not in use and gas control valve is in the
OFF position.
●Follow all instructions regarding the use of LPG and Butane bottles. Please contact your local
gas supplier for further advice if needed.
●WARNING: Flames from the fireplace are almost invisible in direct sunlight.
3

GAS FIREPCE
0063-19
DESTINATIONOF
COUNTRIESTOUSE VALVESIZE GASTYPE GASCATEGORY
BE, BG, CY, DK, EE, FI,
FR, HR, HU, IS, IT, LT, LU,
MT, NL, NO, RO, SK, SI,
SE and TR
Dia. 1,32 mm
(Pilot: 0,25 mm)
G (butane), G(propane) and
their mixtures I3B/P(30)
I3B/P(30): G30(Butane), G31(propane)
and mixtures of these.
Technical information
Total Heat input: 7,3 kW
Gas consumption: 531 gram/hour
Gasbottle (not included): Use standard
bottle approved for use in the Nordic
Region.
Even though butane and propane gas can
be used, we recommend propane for use in
the Nordic Region.
Approved hoses and regulators are
available om most outlets selling gas
equipment.
NB! Gas hoses used for this product must
not exceed 120 cm in length.
ONLY THE GAS TYPE AND GAS CATEGORY LISTED IN THE
RATING LABEL CAN BE USED WITH THIS GAS FIREPLACE
This product is produced according to
EUROPEANGASAPPLIANCE
STANDARDEN-
and is CE certified.
THEAPPLIANCEISSETTOOPERATE
D: 50 cm
H: 134 cm
W: 50 cm
4

1. The regulator shall comply with the standard EN16129;
●For category I3+, the appliance shall use the butane 30mbar regulator (reduced
pressure:28-30mbar) or the propane 37mbar regulator (reduced pressure: 37mbar).
●For category I3B/P(30), the appliance shall use the LPG 30mbar regulator(reduced
pressure:28-30mbar).
●For category I3B/P(50), the appliance shall use the LPG 50mbar regulator (reduced
pressure:50mbar).
2. The hose shall comply with the standard EN 16436 and the length of the
hose should not exceed 1.5m.
3. The minimum distance from non protected combustible materials shall be
2m.
4. To change the gas cylinder in a amply ventilated area, away from any ignition
source (candle, cigarettes, other ame producing appliances, ...).
5. Check that the regulator seal is correctly tted and able to full its function.
6. Do not obstruct the ventilation holes of the cylinder housing.
7. Close the gas supply at the valve of the gas cylinder or the regulator after
use.
8. In the event of gas leakage, the appliance shall not be used or if alight, the
gas supply shall be shut off and the appliance shall be investigated and
rectied before it is used again.
9. Check the tubing or the exible hose (at least once per month and each
time the cylinder is changed). If it shows signs of cracking, splitting or other
deterioration it shall be exchanged for new hose of the same length and of
the equivalent quality.
10. Read the instructions before installation and use.
11. This appliance must be installed and the gas cylinder stored in accordance
with the regulations in force.
12. Do not move the appliance when in operation.
13. Shut off the valve at the gas cylinder or the regulator before moving the
appliance.
14. The tubing or the exible hose must be changed within the prescribed
intervals.
15. Use only the type of gas and the type of cylinder specied by the
manufacturer.
16. In case of violent wind particular attention must be taken against tilting of
the appliance,
17. Keep the instructions for future reference.
18. Do not connect the gas cylinder directly to the appliance without regulator.
19. The tubing or the exible hose must be changed within the prescribed
intervals.
20. Use only the type of gas and the type of cylinder specied in these
instructions.
21. The injector is assembled by manufacturer only.
5
WARNING

GAS FIREPCE
name picture QTY
FIREPCE 
CASTORWHEELS 
Mx SCREWS, M
WASHERSANDM LOCK
WASHERS

STAINLESSSTEELHANDLE 
DOORKNOB + M SCREW,
WASHERANDLOCK
WASHER

VAROCKS 
WARNING! EXERCISECAUTIONWHENUSINGELECTRICTOOLS
 THEIRSTRENGTHCANDAMAGETHESCREWS.
Please follow these instructions step by step.
APhillips screwdriver and a 10 mm wrench or a adjustable wrench is necessary.
We recommend being two persons when assembling the fireplace.
2 x LOCKABLE
WHEELS
2 x WHEELS
6
Parts List

●Please read instruction thoroughly before using the appliance.
The gas heater will arrive in one box containing the appliance with burner already
installed, castor wheels and lava rock fuel beds . Remove the appliance from
packaging. Carefully place it down on the floor, keeping it upright for ease of assembly.
●Extreme care should be taken when handling the heater, to ensure the gas pipes,
thermocouple lead, gas valve or burner are not damaged or loosened in anyway.
●Please note: ALL heaters have been burn tested and leak tested prior to leaving the
factory. Although each unit is cleaned, there may be the odd scorch mark around the
pilot and main burner gas jets.
1. Mount the stainless steel handle on the
top rear of the fireplace using 2 pcs. M6x16
screws, washers and lock washers.
2. Mount the castor wheels under the
fireplace using 16 pcs. M6x16 screws,
washers and lock washers. Put the locable
castors on the same side as the handle
(rear).
1
2
Remove the fireplace body and all of the parts from carton, then do the following steps:
7
Assembly

GAS FIREPCE
4. Using the safety latch at the top of
the rear safety glass, unclip the glass and
slowly pull down with the hinges.
3. Attach the door knob on the door using
1 pcs M4 screw, washer and lock washer.
3
4
8
Assembly

5. This should be done outside.
Cover the burner with either glass or lava rock fuel beds. DO NOT tip the bag of lava rock
onto the burner as the bags usually contain some fine dust which could clog the burner jets.
It is better to empty the bags into a suitable container and then place the glass or rock by
hand around the burner.
Make sure the area around the pilot light is kept clear to allow air to reach.
5Positioning Lava Rock on the Burner – Keep Pilot Area Clear
TIPS!
●THE LAVA ROCKS WILL GO AROUND THE PILOT AREA AGAIN EVERY
TIME THE FIREPLACE IS MOVED AROUND.
●ALWAYS CHECK IF THE LAVA ROCKS ARE BLOCKING THE PILOT AREA
BEFORE EVERY USE.
Make sure the area around the pilot housing is kept clear to allow air to reach.
Caution: blocking pilot area may delay lighting and lead to abnormal burning.
9
Assembly

GAS FIREPCE
HOSE
●Connect the gas hose to the gas rail inlet inside the cabinete. Do not overtighten.
●Do not use any sealing tape, paste or liquid on the connection.
●Connect the regulator to the gas bottle according to your regulator and bottle
dealer’s instructions.
●Gas hoses used for this product must not exceed 120 cm in length
●Check the gas hose regularly for cracks, damage and decay. Never use a damaged
gas hose.
●Check that the movable plastic collar on the regulator is intact and that it has not
been damaged by hot Fireplace parts.
●Use an approved gas bottle that fits the regulator supplied.
REGULATOR
●Confirm that the control knobs are in the OFF position.
●We recommend propane gas for use in the Nordic Region, but butane can also be
used.Butane is not very suitable for low temperatures.
●Fit the regulator and the hose. New hoses can be quite stiff and hard to push onto
the inlet pipe, so soften the end of the hose by running it under a hot tap for a
few seconds. Try not to get water inside the hose.
●Follow the assembly instructions supplied with the regulator set.
10
Regulator and gas hose
WARNING
●It’s extremely important that you DO NOT route the gas hose directly
under the burner. Do not allow the hose to touch any part of the burner
or heater. The hose should be located so that it is not subjected to undue
strain or placed where is could be damaged.
●Disconnect the regulator when fireplace is not in use.
●Never move the FIREPLACE while it is in use, or connected to the gas
bottle.

11
Gas Leak Testing
WARNING
ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED
BEFORE USING THE FIREPLACE.
LEAK TEST SHOULD BE PERFORMED ANNUALLY, AND WHENEVER THE GAS BOTTLE IS
REMOVED OR REPLACED.
ALWAYS PERFORM A LEAK TEST IN A WELL-VENTILATED AREA.
 IFTHEREARESTILLGASLEAKSAFTERREPEATEDATTEMPTS CONTACTYOURDEALER.
 IFBUBBLESAPPEAR SWITCHOFFTHEGASSUPPLYANDREPAIRTHE
PROBLEM. PERFORMANEWLEAKTEST. DONOTUSETHEBBQBEFOREYOU
ARESURETHATTHEREARENOLEAKS.
OPENTHEGASTAPONTHEREGUTORANDCAREFULLYCHECKFORBUBBLES
APPEARINGANYWHERETHELIQUIDHASBEENAPPLIED.
MAKEAMIXEDSOLUTION  WATERANDLIQUID
DETERGENT / SOAP.
 ENSURETHATTHEREARENONAKEDFMES HEAT
SOURCESANDCIGARETTESINTHEVICINITY WHEN
PERFORMINGALEAKTEST.
 CHECKTHATTHECONTROLKNOBONTHEFIREPCE
AREINTHE ”OFF” POSITION.

SETTHEREGUTORTOTHE ”OFF” POSITIONANDCONNECTITTOTHEGASBOTTLE.
APPLYTHELIQUIDTOALLJOINTSANDCONNECTIONSONTHEGASBOTTLE REGUTOR
THEENTIREHOSEANDALLVALVESONTHEBBQ.
!WARNING!
NEVER USE AN OPEN
FLAME TO PERFORM
A GAS LEAK TEST

GAS FIREPCE
LOCATION
●The heater is for outdoor use only. Always ensure that adequate ventilation is provided.
○Always maintain proper clearance to combustible materials of at least 2 metres.
○Do not place near to your house.
○Do not place near to shed, garage or fences.
○Do not place under roof covering or low overhanging trees
○Do not place near to power sources or under overhanging power cables.
●Heater must be placed on level firm ground. Ensure that castor wheels are locked into place.
FINAL CHECK
●Check that the control knobs work
normally.
●Check that the gas hose is free of
cracks and damage (it should always
be done before using the BBQ)
●Check that the gas bottle and hose
do not come into contact with hot
objects.
NOTE!
●This fireplace has an overturn
switch. It will shut off gas supply
to pilot if the the heater should
tip over.
●Pay attention to the product
stability when in use.
12
Final Check

Lighting Instruction
LIGHTING THE FIREPLACE
1. Open the cabinet door and put the gas
cylinder into the cabinet.
2. Make sure to turn the control knob
clockwise to “OFF” position.
3. Connect the regulator to the gas
bottle.
4. Turn the gas supply “ON” at the
cylinder. Check with the use of soapy
water for any gas leakage between the
cylinder and the regulator
5. Push down the control knob and keep
pressing whilst turning anti-clockwise
to the “Ignition” position (a click will be
heard), this will light the pilot.
6. If the click is not heard repeat
this process. Note that when first
connecting fireplace to the gas
cylinder there will be air in the gas
hose or the rest of the system. Keep
pressing the control valve knob for
about 1 minute to purge the air and
allow gas into system.
7. Once the pilot burner is lit, keep
the control knob pressed for 5
seconds then release it.
8. If the burner does not stay alight,
repeat the above steps again.
9. Adjust the heat setting by turning
the control knob to the ‘High’ or
‘Low’ position.
EXTINGUISH THE FIREPLACE
●To shut down the fireplace turn
the gas cylinder valve or regulator
switch to the ‘OFF’ position and
then turn the control valve knob
on the appliance clockwise to the
‘OFF’ position.
WARNING!
●IF THE BURNER FAILS TO IGNITE, TURN THE CONTROL
VALVE KNOB ‘OFF’ (CLOCKWISE) AND TURN THE GAS
CYLINDER VALVE ‘OFF’. WAIT FOR FIVE MINUTES BEFORE
ATTEMPTING TO RELIGHT WITH IGNITION SEQUENCE.
●IF THE FIREPLACE STILL FAIL TO LIGHT, PLEASE READ THE
TROUBLESHOOTING SECTION OR CONTACT YOUR DEALER.
13

GAS FIREPCE 14
CLEANING & MAINTENANCE
●Ensure all cleaning is done whilst fireplace is turned off and fully cooled down.
●Wipe surfaces with a soft, damp cloth.
●Do not use any corrosive or combustible cleaning solutions.
●Keep the outdoor fire covered when not in use to stop rain from blocking the
burner jets.
●Make sure burner is kept clean and clear of combustible materials and dirt.
●Soot can build up on the glass beads, lava rocks and ceramics logs. This could
block burner jets so remove the fuel bed and wipe with damp cloth to clean soot.
●Soot can build up on the surrounding safety glass. Carefully remove the glass
from glass bracket with rel ative screwdriver, wipe soot with a soft, damp cloth,
then carefully replace. Two people maybe required disassembly and reassembly
of the surrounding safety glass.
●Ensure the condition of gas hose is suitable and shows no signs of cracking or
general wear & tear.
●It is advised to get the appliance check by a qualified technician every 3 years.
●If the burner jets do get blocked by soot or other dirt then remove the fuel bed
and use a pin or paperclip. Ensure the burner is switched
●Follow the above maintenance steps on a regular basis.
AFTER USE & STORAGE
1. Turn the control knob on the appliance clockwise to the ‘OFF’ position.
2. Turn the gas supply off at the cylinder.
3. Do not leave the area until flames have fully extinguished.
4. Children must not be left unattended straight after use as the appliance will still
be hot for some time.
5. Check gas valve for tightness and damage. If damage is suspected this must be
changed by a qualified technician.
6. Always store gas cylinders in well ventilated areas.
7. Once fireplace has cooled down it can be moved to alternative location such as
garage of shed.
8. Once fireplace has cooled down it is safe to use rain cover for protection.
Maintenance

PILOT WILL NOT LIGHT OR STAY ON
●Ensure gas supply is turned on and cylinder is not empty.
●Press ignition button several times. Ensure to keep the main gas lever pressed
in for at least 10 seconds.
●If the ignition button stays stuck in then lubricate with WD40 whilst the
fireplace is not lit.
●Keep trying as air can get trapped in pipes and can take some time to purge all
the air out of the system.
●Check that glass or lava rocks or other debris are not covering the pilot.
●Check to see if any connections are loose and tighten if required.
●Check to see if there is a leak in the gas hose. Replace if required.
●Try lighting the pilot with a match or lighter if the spark electrode is wet or
damaged.
●Ensure that the appliance is on level ground and completely vertical as the
‘Overturn Shut Off Device’ may have been triggered.
BURNER WILL NOT LIGHT
When the pilot is lit, there should be no reason the main burner would not light.
●If the pilot is lit but the burner does not light check if too much glass or lava
rock is around pilot assembly. This could block the pilot light from igniting the
main burner.
●If the pilot is lit but the burner does not light there could be damage to the
control valve. This would need replacing by a qualified technician.
●If the pilot is not lit the flame failure device has cut off the gas supply. Wait 2
minutes, then try relighting the pilot.
●Ensure that the appliance is on level ground and completely vertical as the
‘Overturn Shut Off Device’ may have been triggered.
MAIN BURNER SUDDENLY GOES OUT
●If the pilot is extinguished for any reason (sudden gust of wind or it started
raining) then the main gas supply would automatically cut off.
●Turn the control lever to the ‘OFF’ position, and leave for 2 minutes before
relighting the pilot.
●Once the pilot is lit the main burner will work.
●The gas cylinder maybe empty. If so, replace the cylinder with a full one.
●Ensure that the appliance is on level ground and completely vertical as the
‘Overturn Shut Off Device’ may have been triggered.
15
Trouble Shooting

Consumer contact
Always attach your receipt and product serial number when making a warranty claim.
Serial number is located on the side of the BBQ.
Produced in China for FCCProducts Co., Ltd.
This product is covered by a warranty in accordance with consumer legislation. It has
undergone strict quality controls and testing at the factory.
If there are any parts missing or the product has been damaged, please contact your
dealer or the consumer contact below for help.
Faults due to misuse, lack of maintenance or modification of the product will
invalidate the warranty. Damaged parts not due to a fault with the product will be
invoiced according to our price list + carriage and administration fee.
If new parts are needed or in the event of a warranty claim, please contact your
dealer or consumer contact:
FCCPRODUCTSAS
KJELLERVEST   KJELLER NORWAY
[phone]
[e-mail]
www.fccproducts.no
We are always looking for ways we can improve our products. Therefore, we reserve the right to change
technical specifications at any time. You will always find the latest manual on www.fccproducts.no.
