Superior VRT2536WS User manual
36" x 24", 36" x 28" & 42" x 28" Universal Vent-Free Fireboxes
P/N 900238-01 REV. A 02/2015
MODELS
UNIVERSAL VENT-FREE FIREBOX
Due to high temperatures, the appliance should be located out
of traffic and away from furniture or draperies.
Do not place clothing or other materials on or near this appli-
ance.
IMPORTANT: READ AND UNDERSTAND THESE INSTRUCTIONS
COMPLETELY BEFORE INSTALLING YOUR VENT-FREE ROOM
HEATERS.
VRT3542WS Shown
FOR YOUR SAFETY: Do not store or use gasoline
or other flammables or liquids in the vicinity of
this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DONOTlightanyappliance.
• DONOTtouchanyelectricalswitches.
• Donotuseanyphoneinyourbuilding.
• Immediatelycallyourgassupplierfroma
neighbor’s phone. Follow your gas suppliers
instructions.
• Ifyourgassuppliercannotbereached,call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
INSTALLATION AND
OPERATION INSTRUCTIONS
VRT2536WS
VRT3536WS
VRT3536WH
VRT3542WS
VRT3542WH
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal injury
or loss of life.
FOR USE ONLY WITH A LISTED GAS-FIRED
UNVENTED DECORATIVE ROOM HEATER NOT TO
EXCEED 40,000 BTU/H.
DO NOT BUILD A WOOD FIRE.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE
INJURY OR PROPERTY DAMAGE. REFER TO THIS MANUAL.
FOR ASSISTANCE OR ADDITIONAL INFORMATION CONSULT
A QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS
SUPPLIER.
CAREFULLY REVIEW THE INSTRUCTIONS SUP-
PLIED WITH THE DECORATIVE TYPE UNVENTED
ROOM HEATER FOR THE MINIMUM FIREPLACE
SIZE REQUIREMENT.
DO NOT INSTALL AN APPLIANCE IN THIS FIREBOX,
UNLESS THIS FIREBOX MEETS THE MINIMUM
DIMENSIONS REQUIREDFORTHEINSTALLATIONS.
THIS IS A VENT-FREE GAS-FIRED HEATER ENCLOSURE. IT
USES AIR (OXYGEN) FROM THE ROOM IN WHICH IT IS IN-
STALLED. PROVISIONS FOR ADEQUATE COMBUSTION AND
VENTILATION AIR MUST BE PROVIDED. REFER TO COMBUS-
TION AND VENTILATION AIR SECTION, PAGES 3 & 4.
In the Commonwealth of Massachusetts:
•Installation must be performed by a licensed plumber or
gas fitter;
• SeeTableofContentsforlocationofadditionalCommon-
wealth of Massachusetts requirements.
INSTALLER: LEAVE THIS MANUAL WITH THE
APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE
REFERENCE.
P900238-01
CU
S
Report No. F14-168
2
IMPORTANT SAFETY
INFORMATION
INSTALLER: PLEASE LEAVE THESE INSTRUC-
TIONS WITH THE OWNER.
OWNER: PLEASE RETAIN THESE INSTRUC-
TIONS FOR FUTURE REFERENCE.
WARNING
If the information in this
manual is not follwed
exactly, a fire or explosion
may result causing prop-
erty damage, personal
injury or loss of life.
IMPORTANT
Before starting your firebox instal-
lation, read these installation
instructions carefully to be sure you
understand them completely and
in entirety. Failure to follow these
instructions could cause a heater
malfunction resulting in serious
injury and/or property damage.
IMPORTANT
The fireplace screens on the appli-
ance must be closed prior to operat-
ing the fireplace.
WARNING
These built-in vent-free fireboxes
have only been tested andapproved
for use with ANSI Z21.11.2 Vent-
free gas logs.
WARNING
Any change to this Vent-Free room
heater can be dangerous. Improper
installation or use of this heater can
cause serious injury or death from
fire, burns, explosion or carbon
monoxide poisoning.
WARNING
Do not attempt to burn solid wood
fuels, other gas log sets or any
other combustible materials in
this vent-free firebox.
WARNING
Carbon Monoxide Poisoning: Early
signs of carbonmonoxide poisoning
are similar to the flu with head-
aches, dizziness and/or nausea. If
you have these signs, obtain fresh
air immediately. Have the Vent-Free
Gas Heater serviced as it may not
be operating correctly.
WARNINGS
• Due to high temperatures, the
firebox should be located out of
traffic and away from furniture
and draperies.
• Do not place clothing or other
flammable material on or near
the heater.
• Any safety screen or guard re-
moved for servicing the firebox
must be replaced and/or closed
prior to operating the heater.
• Installation and repair should
be done by a qualified service
person. The heater should be
inspected before use and at
least annually by a professional
service person. More frequent
cleaning may be required due
to excessive lint from carpet-
ing, bedding material, etc. It is
important that control compart-
ments, burners and circulating
air passageways of the heater
be kept clean.
• Allowtheheatertocoolbefore
servicing. Always shut off any
electricity or gas to the heater
while performing service work.
• Do not install the rebox in a
sleeping room or bathroom.
• Theapplianceanditsindividual
shut-off valve must be discon-
nected from thegas supply piping
system while performing any
tests of the gas supply piping
system at test pressures equal
to or less than 1/2 psig.
WARNING
• Theheatermustbeisolatedfrom
the gas supply piping system by
closing its individual manual
shut-off valve during any pres-
sure testing of the gas supply
piping system at test pressures
equal to or less than 1/2 psig.
• Keepheaterareaclearandfree
from combustible materials,
gasoline and other flammable
vapors and liquids.
• Do not use this heater if any
part has been under water. Im-
mediately call a qualified service
technician to inspect the heater
andto replace any part of the con-
trol system and any gas control
which has been under water.
• Ensurethattheheaterisclean
when operating. Excessive dust
accumulation on the burner and
logs will increase the amount of
carbon monoxide formation and
could lead to carbon monoxide
poisoning and death.
WARNING
Do not install in the vicinity where
gasoline or other flammable liquids
may be stored. The Vent-Free fire-
box must be keptclear and free from
these combustible materials.
WARNING
Maintain minimum clearances.
WARNING
Do not allow fans to blow directly
into the fireplace. Avoid any drafts
that alter burner flame patterns.
3
Misc. Codes / Standards -
The Installation must conform to local codes
or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1/NFPA
54 - latest edition.
The appliance, when installed, must be electri-
cally grounded inaccordance with localcodes or,
in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70 - latest edition.
Check the packaging list to be sure that you
have all the necessary parts in usable condition.
Also check for concealed damage.
Tools and Building Supplies
Normally Required
Tools Should Include:
• Phillipsscrewdriver
• Hammer
• Sawand/orsabersaw
• Level
• Measuringtape
• Electricdrillandbits
• Pliers
• Square
• Pipingcomplyingwithlocalcodes
• Pipewrench
• Teejoint
• Pipecompound
Building Supplies Should Include:
• Framingmaterials
• Wallnishingmaterials
• Caulkingmaterials(noncombustible)
• Fireplacesurroundmaterials
(noncombustible)
• Insulation
(for packing around gas-line penetration holes)
CODES
Adhere to all local codes or in their absence
the latest edition of The National Fuel Gas Code
ANSI Z223.1 or NFPA 54 - latest edition which
can be obtained from The American National
Standards Institute, Inc. (1430 Broadway, New
York, NY, 10018) or National Fire Protection
Association, Inc. (Batterymarch Park, Quincy,
MA,02269).
COMBUSTION AND VENTILATION AIR
Heaters installed in these appliances shall
notbeinstalledinaconnedspace.Heaters
installed in these appliances may be located
in unusually tight construction provided the
spaceisunconned,orifconned,isprovided
with two permanent openings communicating
directly with an additional room(s) of suf-
cientvolume so that the combinedvolume
of all connected spaces meets the criteria for
anunconnedspace,(NationalFuelGasCode
ANSI Z223.1 - latest edition, Section on Air for
Combustion and Ventilation). Generally 50 ft3
per 1,000 BTU input of all operating appliances
in the space.
TABLE OF CONTENTS
Important Safety Information........... Page 2
PackagingList.................................. Page 3
General Information ......................... Page 3
Burn-in Period.................................. Page 3
Tools/Building Supplies.................... Page 3
Codes............................................... Page 3
Combustion And Ventilation Air ....... Page 3
Cold Climate Insulation .................... Page 4
Requirementsforthe
CommonwealthofMassachusetts Page 5
LocationOfFirebox.......................... Page 6
Clearances ....................................... Page 6
Assembly Steps ............................... Page 8
GasLineInstallation......................... Page 8
FireboxFraming ............................... Page 9
FireboxInstallation........................... Page 9
Specications................................... Page 10
FramingSpecications..................... Page 11
HoodInstallation.............................. Page 11
OptionalEquipment/BlowerKit
Installation .................................. Page 12
FireboxFinishes ............................... Page 15
Accessories/components................. Page 15
ReplacementPartsList .................... Page 17
Warranty .......................................... Page 19
This installation manual will help you obtain
asafe,efcient,dependableinstallationfor
your appliance and vent system.
PLEASE READ AND UNDERSTAND
THESE INSTRUCTIONS BEFORE BEGIN-
NING YOUR INSTALLATION.
Packaging List
Vent-FreeGasFirebox
Hood (optional for models VRT3536WS,
VRT3536WH, VRT3542WS & VRT3542WH)
InstallationandOperatingInstructions
GENERAL INFORMATION
TheseVent-Freereboxenclosuresaredesigned
to accept all ANSI Z21.11.2 approved Decora-
tive Type Vent-Free Gas Log Room Heaters.
For the appropriate Vent-Free Gas Log Room
Heater model, refer to Page 16 (see Vent-Free
Gas Log Sets).Refer to the installation instruc-
tions provided with the log sets for detailed
instructions.
This installation manual along with the vent-free
gas log installation manual will enable you to
obtainasafe,efcientanddependableinstal-
lation of your room heater system.
Do not alter or modify the rebox or its
components under any circumstances. Any
modicationoralterationofthereboxsystem,
includingbutnotlimitedtothereboxandac-
cessories, may void the warranty, listings and
approvals of this system and could result in an
unsafe and potentially dangerous installation.
TheseBuilt-InVent-FreeFireboxeshavebeen
testedandapprovedasVentlessFireboxEnclo-
sures for Gas-Fired Unvented Decorative Room
HeaterstoANSIZ21.91.
Burn-in Period
Duringtherstfewtimesofoperationofthis
appliance there will be some odor due to the
curing of the paint and burning off of lubricants
usedinthemanufacturingprocess.Werecom-
mend that you open windows and ventilate the
house during the initial burns. The paint emits
non-toxicodorsduringthisprocess.
Depending on your use, the burn-in period may
take a few hours or a few days.
KEEP YOUR HOUSE WELL VENTILATED
DURING THE BURN-IN PERIOD. THE ODOR
AND HAZE EMITTED DURING THE BURN-IN
PERIOD CAN BE QUITE NOTICEABLE AND MAY
SETOFFASMOKEDETECTOR.
If an optional blower is installed, Do not turn it
on during the Burn-In period.
CONGRATULATIONS!
InselectingthisSUPERIOR®Vent-FreeGasFireboxyouhavechosenthenestandmost
dependablereplacetobefoundanywhere.Abeautiful,prestigious,alternativetoawood
burningreplace.WelcometoafamilyoftensofthousandsofsatisedSUPERIOR
FireplaceOwners.
Please read and carefully follow all of the instructions found in this manual. Please pay
specialattentiontothesafetyinstructionsprovidedinthismanual.TheHomeowner's
CareandOperationInstructionsincludedherewillassurethatyouhavemanyyearsof
dependableandenjoyableservicefromyourSUPERIORproduct.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
4
Youroptionsare:
a.Reworkequationsaddingthespaceofadjoin-
ingroom(s).Iftheextravolumeprovidesan
unconnedspace,thenremovedoororadd
ventilation grills between rooms. Refer to
National Fuel Gas Code, ANSI Z223.1 - latest
edition, Section on Air for Combustion and
Ventilation.
b. Vent room directly to the outdoors. Refer to
National Fuel Gas Code, ANSI Z223.1 - latest
edition, Section on Air for Combustion and
Ventilation.
c.InstallalowerBTU/Hrheater,suchasa21,000
BTU/Hr, to make the area an unconned
space.
If the actual BTU/Hr used is less than the
maximumBTU/Hrthespacecansupport,then
the space is an unconned space. You will
need no additional fresh air ventilation for an
unconnedspace.
This appliance shall not be installed in a room
orspaceunlesstherequiredvolumeofindoor
combustion air is provided by the method
described in the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, the International Fuel Gas
Code, or applicable local codes.
Maintain adequate clearances around air
openings.
Maintainadequateclearancesforaccessibility
for purposes of servicing and proper operation.
COLD CLIMATE INSULATION
For cold climate installations, seal all cracks
around the appliance with noncombustible
material and wherever cold air could enter
the room. It is especially important to insulate
outside cavities between studs and under floor
on which the appliance rests, if floor is above
ground level. Gas line holes and other openings
should be caulked with high temperature caulk
orstuffedwithunfacedberglassinsulation.If
thereplaceisbeinginstalledonacementslab,
in cold climates, a sheet of plywood or other
raised platform can be placed underneath to
prevent conducting cold up intothe room. It also
helps to
sheetrock inside surfaces and tape for
maximumairtightnessandcaulkrestops.
3.AddtheBTU/Hrofallthefuelburningappli-
ances in the space.
Vent-Free heater ________ BTU/Hr
Gas appliance #1* ________ BTU/Hr
Gas appliance #2 +________ BTU/Hr
Total =________ BTU/Hr
Example:
Vent-freeheater 26,000 BTU/Hr
Gasappliance#1 40,000 BTU/Hr
(water heater)
Total= 66,000 BTU/Hr
* Do not include direct-vent gas appliances.
Direct-vent is sealed combustion and draws
combustion air from the outdoors.
4.ComparethemaximumBTU/Hrthespacecan
supportwiththeactualamountofBTU/Hr
used.
_________ BTU/Hr
(max.thespacecansupport)
_________ BTU/Hr
(actualamountofBTU/Hrused)
Example:
61,440 BTU/Hr
(max.thespacecansupport)
66,000 BTU/Hr
(actualamountofBTU/Hrused)
Thespaceintheaboveexampleisaconned
spacebecausetheactualBTU/Hrusedismore
thanthemaximumBTU/Hrthespacecansup-
port. You must provide additional fresh air.
WARNING
If the area in which the heater may be
operated does not meet the required
volume for indoor combustion air,
combustion and ventilation air shall
be provided by one of the methods
described in the National Fuel gas
Code,ANSIZ223.1/NFPA54,theInter-
national Fuel gas Code, or applicable
local codes.
TheNationalFuelGasCodedenesaconned
space as a space whose volume is less than
50 ft 3per1,000BTU/Hr(4.8m3per kw) of the
aggregate input rating of all appliances installed
inthatspaceandanunconnedspaceasaspace
whose volume is not less than 50 ft 3per 1,000
BTU/Hr(4.8m3per kw) of the aggregate input
rating of all appliances installed in that space.
Rooms communicating directly with the space
in which the appliances are installed, through
openings not furnished with doors, are consid-
eredapartoftheunconnedspace.
Unusually tight construction is dened as
constructionwhere:
a.Wallsandceilingsexposedtotheoutside
atmosphere have a continuous water vapor
retarder with a rating of one permor less with
openings gasketed or sealed, and
b.Weatherstrippinghasbeenaddedonoper-
able windows and doors, and
c. Caulking orsealants are applied to areassuch
asjointsaroundwindowanddoorframes,
between sole plates and floors, between
wall-ceilingjoints,betweenwallpanels,at
penetrations for plumbing, electrical, and
gas lines, and at other openings.
Usethefollowingequationstodetermineifyou
haveaconnedorunconnedspace.
1. Determine the volume of space — ft
3.
LengthxWidthxHeight= _____ ft
3
(Include adjoining rooms with doorless
passageways or ventilation grills between
rooms).
Example:24'(L)x16'(W)x8'(H)=3072
ft
3
2. Divide the volume of space by 50 ft
3to
determinethemaximumBTU/Hrthespace
can support.
(volume of space – ft 3)/ 50 ft 3=(Maximum
BTU/Hrthespacecansupport)
Example: 3072 ft
3/ 50 ft
3=61.44
or61,440BTU/Hrthespacecansupport.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
5
NOTE: The following requirements reference various Massachusetts
and national codes not contained in this document.
Requirements for the Commonwealth of Massachusetts
TheseappliancesareapprovedforinstallationintheUSstateofMas-
sachusettsifthefollowingadditionalrequirementsaremet:
• Un-ventedRoomHeatersshallbeinstalledinaccordancewith527
CMR30.
• Installationandrepairmustbedonebyaplumberorgastterlicensed
intheCommonwealthofMassachusetts.
• Theexiblegaslineconnectorusedshallnotexceed36inches(92
centimeters) in length.
• The individual manual shut-off must be a T-handle type valve.
• UnventedappliancesmayNOTbeinstalledinbedroomsorbathrooms.
• A working smoke detector must be installed in the area where vent-
free appliances are installed.
Sellerofunventedpropaneornaturalgas-redsupplementalroomheaters
shallprovidetoeachpurchaseracopyof527CMR30uponsaleoftheunit.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
40"
16"
Optional
Hearth
Extension
6
Fireplace
Opening
Top Stand-
Off Spacer
(on appliance)
Top of Appliance
Finished Wall
Header
Shown with Canopy
Installed (required on
UVF-36 only)
Non-Combustible
Material
3" Min.
(shaded area)
Shown with hood
Installed (required
on VRT2536WS)
Ceiling clearance: The ceiling must be at
least40"fromthetopofthereboxopening
(Figure 2).
Noncombustible material: Noncombustible
materials, such as slate and marble, must be
at least 1/2" thick and may be used without
restriction above the rebox opening, to the
sides or as a hearth extension, so long as
they do not obstruct vent openings for heat
circulating models.
RECOMMENDATION: Use high temperature
finish material for the mantels and/or use
the hood (for VRT3536WS, VRT3536WH,
VRT3542WS & VRT3542WH).
Clearances
Ensure the minimum clearances shown in
Figures 2 through 6 aremaintained.Leftand
right clearances are determined when facing
thefrontoftherebox.
Follow these instructionscarefully to ensure safe
installation.Failuretofollowtheserequirements
maycreatearehazard.
Sidewall clearances:Thesidesoftherebox
openingmustbeatleast16"fromanycom-
bustible wall (Figure 2).
Figure 2
Not to Scale
Figure 1
Combustible Wall Clearance
Above Appliance (all models)
Figure 3
CAUTION
Do not install in the vicinity where
gasoline or other flammable liquids
may be stored. The Vent-Free fire-
box must be keptclear and free from
these combustible materials.
WARNING
Do not use a blower insert, heat
exchanger insert or other acces-
sory not approved for use with this
fireplace.
WARNING
Do not install these built-in Vent-
Free fireboxes in sleeping quarters,
or in recreational vehicles.
WARNINGS
Do not install these appliances:
•Wherecurtains,furniture,cloth-
ing or other flammable objects
are less than 42" from the front of
the Vent-Free room heater.
•Inhightrafcareas.
•Inwindyordraftyareas.
LOCATION OF FIREBOX
Carefully select the best location for installation
ofyourbuilt-inVent-Freerebox.Thefollowing
factorsshouldbetakenintoconsideration:
•Clearance to side wall, ceiling, woodwork
and windows.
• Location must not be affected by drafts
causedbykitchenexhaustfans,returnair
registers for forced air furnaces/air condi-
tioners, windows or doors.
• Installationmustprovideadequateventila-
tion and combustion air.
• Donotinstallthisreboxinasleepingroom
or bathroom.
• Locationshouldbeoutofhightrafcareas
and away from furniture and draperies due
toheatfromrebox.
• Never obstruct the front opening of the
Vent-Free rebox or restrict the ow of
combustion and ventilation air.
• Minimizemodicationstoexistingconstruc-
tion. See Figure 1 for location suggestions.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
7
Noncombustible material (minimum requirements) with wood mantel or
other combustible projections: Toinstallthereboxwithawoodmantel,
shelf or other combustible projection above rebox opening. Refer to
Figures 4, 5 & 6.
Minimum clearence requirementsinclude any projections suchas shelves,
window sills, mantels, etc., above the appliance.
If your mantel profile is unsafe, you may either:
• Raisethemanteltoanacceptable
height, or
• Removethemantel.
Floor clearance:Thesereplacesmaysitdirectlyonacombustiblesurface.
Theapplianceshouldbemountedonafullysupportedbaseextendingthe
full width and depth of the unit. The appliance may be located on or near
conventionalconstructionmaterials.However,
if installed on combustible materials, such as carpeting, vinyl tile, etc., a metal
or wood barrier covering the entire bottom surface must be used.
Figure 5
Combustible Mantel and Trim Clearance
Model VRT2536WS WITH Hood Installed
Hood is required on all installations for this model only.
sEXAMPLE: If you choose to install a mantel that projects 5", you will need to
install it so that the bottom of the mantel and trim is approximately 13" or more
above Firebox opening (see coordinate in shaded area above).
sEXAMPLE: If you choose to install a mantel that projects 4", you will need to install it
so that the bottom of the mantel and trim is approximately 13" or more above Firebox
opening (see coordinate in shaded area above).
Models VRT3536WS and VRT3542WS WITH Hood Installed
Hood is optional on these models
16”
9-1/2”
2”
3”
4”
5”
6”
10”
11”
12”
13”
14”
15”
Top of Firebox Opening Screen
Top of Appliance
Combustible Mantel
and Trim
Header
Top Spacer
on Appliance
Safe Zone
Hood
Non-Combustible
Material 3” Min.
Example
Example
Coordinate
in ()Example
Combustible
Material (wall)
Figure 4
16”
17”
18”
9”
3”
4”
5”
6”
7“
8”
10”
11”
12”
13”
14”
15”
Top of Firebox Opening Screen
Top of Appliance
Combustible
Material (wall)
Combustible Mantel
and Trim
Header
Top Spacer
on Appliance
Safe Zone
Non-Combustible
Material 3” Min.
Example
Example
Coordinate
in ()Example
Hood
23”
24”
16”
6”
7”
8”
10” 9”
17”
18”
19”
20”
21”
22”
Top of Firebox OpeningScreen
Top of Appliance
Combustible Mantel
and Trim
Header
Top Spacer
on Appliance
Safe Zone
Non-Combustible
Material 3” Min.
sExample
s
Example
Combustible
Material (wall)
s
Coordinate
in (s)Example
Models VRT3536WS and VRT3542WS WITHOUT Hood Installed
Hood is optional on these models
Combustible Mantel and Trim Clearance
sEXAMPLE: If you choose to install a mantel that projects 7", you will need to install it
so that the bottom of the mantel and trim is approximately 18" or more above Firebox
opening (see coordinate in shaded area above).
Figure 6
Combustible Mantel and Trim Clearance
WARNING
The hood must be in place to be in compliance with the
clearances specified in Figures 4 & 5. Do not remove or
replace hood, only use hood supplied or offered for these
fireboxes (see Pages 16 & 17). Do not use any hood which
may be provided with the decorative type Vent-Free room
heater.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
8
Consult all local codes.
Properly size and route the gas supply line
from the supply regulator to the area where the
applianceistobeinstalled perrequirements
outlined in the National Fuel Gas Code, NFPA
54-latestedition(USA)orB149-latestedition
(Canada).Neverusegalvanizedorplasticpipe.
Gas lines must be routed,constructed and made
of materials that are in strict accordance with
localcodesandregulations.Werecommend
thataqualiedindividualsuchasaplumber
orgastterbehiredtocorrectlysizeandroute
the gas supply line to the appliance. Installing
a gas supply line from the fuel supply to the
appliance involves numerous considerations of
materials,protection,sizing,locations,controls,
pressure, sediment, and more. Certainly no one
unfamiliarandunqualiedshouldattemptsizing
or installing gas piping.
Remove the gas line access cover plateon either
theleftorrightsideofthereplace(seeFigure
8showing locations).
Install1/2"min.to1-1/2"max.insidediameter
approvedgaslinethroughthereboxwallfor
connection to the Vent-Free room heater inside
the rebox. Connect the gas line before the
reboxisenclosedinthenishedwall.Gasline
holes and other openingsshould be caulkedwith
high temperature caulk or stuffed with unfaced
berglassinsulation.
Ensure that a sediment trap is installed in the
existinggasline,ifnot,installasedimenttrap
upstream of the heater to prevent moisture
and contaminants from passing through trap
to the heater controls and burners. Failure to
do so could prevent the heater from operating
reliably.
Anexternalregulatormustbeusedonallpro-
pane(L.P.G).heaters,inadditiontotheregulator
ttedtotheheater,toreducethesupplytank
pressureto13"W.C.(maximum).Anycopper
tubingusedtosupplypropane(L.P.G).from
the tank must be internally tinned.
INSTALLATION
Gas Line Installation
ASSEMBLY STEPS
Notes:
• Illustrations shown in this manual reect
“typical” installations with nominal dimen-
sions and are for design and framing refer-
ence only. Actual installations may vary due
toindividualdesignpreferences.However,
always maintain minimum clearances to
combustible materials and do not violate any
specicinstallationrequirements.Referto
theFramingSpecicationsFigure
s
on Page
11.
• Thefollowingstepsrepresentthenormal
sequenceofinstallation.Eachinstallation
is unique, however, and might require a
differentsequence.
Step 1.Position rebox prior toframing or
into prepared framing.
Step 2. Field wire the main power supply to
the appliance if a blower kit is to be installed
(at the time of installation or a later date).
Anoptionaljunctionboxkitandblowerkitisre-
quired(seePage 15
for ordering information).
Follow the installation andwiring instructions on
Pages 12 through 14). Electrical connections
shouldonlybeperformedbyanexperienced,
licensed/certiedtradesman.
Step 3. Plumb gas line. (Gas connections
shouldonlybeperformedbyanexperienced,
licensed/certiedtradesman).
Step 4. Install decorative type Vent-Free room
heater per the instructions provided with the
Vent-Free room heater.
Step 5. Complete nish wall material, sur-
roundandoptionalhearthextensiontoyour
individual taste.
TESTALLCONNECTIONSFORGASLEAKS
(FACTORY AND FIELD)
Test allgas jointsfrom thegas meterto the
gas heater regulator for leaks using a gas leak
test solution (also referred to as bubble leak
solution).
Note: Using a soapy water solution as a leak
detection solution is not recommended because
thesoapresiduethatisleftonthepipes/ttings
can result in a false-positive leak detection reading
if a gas leak sniffer is used. Soap residue can also
result in corrosion over time.
DO NOT USE AN OPEN FLAME TO CHECK
FORLEAKS.
Leak Test Procedure:
Turn on gas supply and test for gas leaks using
a gas leak test solution.
A.Light the appliance (refer to the lighting
instructions label provided with gas logs).
B. Brushalljointsandconnectionswiththegas
leak detection solution. If bubbles are formed,
or gas odor is detected, turn the gas control
knob(off/pilot/on)tothe“OFF”position.Either
tighten or refasten the leaking connection, then
retest as described above.
C.Whenthegaslinesaretestedandfoundto
be leak free, rinse off the leak testing solution
fromgaslinettings.
WARNING
Connecting directly to an unregu-
lated propane (L.P.G.) tank can
cause an explosion.
CAUTION
Plumbing connections should
only be performed by a qualified,
licensed plumber. Main gas supply
must be off when plumbing gas
line to fireplace or performing
service.
IMPORTANT
Hold heater regulator with a wrench
toprevent movementwhen connect-
ing to inlet piping.
WARNING
Check Gas Type: The gas supply
must be the same as stated on the
heater’s rating plate. If the gas
supply is different, DONOT INSTALL
the heater. Contact your dealer for
the correct model.
IMPORTANT
Pack unfaced fiberglass insulation
material (not provided) around the
gas line access hole on appliance
and all exterior gas line penetra-
tion holes.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
Figure 7
8d Nail or equivalent
nail or screw
Top Spacer
9
The rebox may be positioned and then the
framing built around it, or the framing may
beconstructedandthereboxpositionedinto
the opening.
Usually, no special floor support is needed for
therebox,however,tobecertain:
1.Estimate the total weight of the rebox
system and surround materials such as
marble, brick, stone, etc., to be installed
(see Product Referance Table on Page 10
for appliance weight).
2.Measure the square footage of the oor
space to be occupied by the system and
surrounds.
3.Notetheoorconstruction,i.e.2"x6",2"x
8"or2"x10",singleordoublejoists,type
and thickness of floor boards.
4. Use this information and consult your lo-
cal building code to determine if you need
additional support.
Ifyouplantoraisetherebox,buildtheplat-
formassemblythenpositionreboxontop.
Secure the platform to the floor to prevent
possible shifting.
Firebox Installation
Step 1. Frame these appliances as illustrated in
Figures 9 through 11. All framing details must
allow for a minimum clearance to combustible
framing members as shown in Figures 2
through6. Also refertoappliancespecications
on Page 10 . Headersmaybeindirectcontact
with the appliance top spacers but must not
besupportedbythemornotchedtotaround
them. All construction abovethe appliance must
be self supporting, DO NOT USE THE APPLI-
ANCE FOR STRUCTURAL SUPPORT.
Note: The framed depth from a framed wall,
must always be measured from a finished
surface. If a wall covering such as drywall is
to be attached to the rear wall, then the depth
must be measured from the drywall surface. It
is important that this dimension be exact.
Step 2.Levelthereboxbycheckingthetop
edgeoftherebox.Shimifnecessary.
Step 3. Fireplace should be secured to side
framing members using the full length nailing
tabsatthetopandbottomofthereplacefront
face. Use 8d nails (see Figure 7).
Firebox Framing
Construct rebox framing following Figures
9 through 11 and Table 1 on Page 11 for
yourspecicinstallationrequirements.Referto
Figure 8 on Page 10forreboxdimensions.
The rebox may be installed directly on a
combustible floor or raised on a platform of
an appropriate height.Whentheapplianceis
installed directly on carpeting, vinyl tile or other
combustible material,other than wood ἀflooring,
the appliance shall be installed on a metal or
woodpanelextendingthefullwidthanddepth
oftheappliance.Besurereboxrestsonasolid
continuous floor or platform with appropriate
framing for support and so that no cold air can
enterroomfromundertherebox.
Note: The nailing flange and the area directly
behind the nailing flange is exempt from the
clearances described on the firebox clearance
label.
Step 4. To safely operate the heater with con-
sideration of the mantel clearances the hood
mustbeinstalled(ModelVRT2536WSOnly).
CAUTION
Do not block the heat-circulating
air inlets and outlets on these
fireboxes. Doing so may create a
potential fire hazard.
IMPORTANT
Under no circumstances shall the
firebox top spacers be removed or
modified(see Figure 8). The header
may be in direct contact with the top
spacers but must not be supported
by them, notched or altered to fit
around them.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
10
Figure 8
SPECIFICATIONS
Gas Line
Access -
Both Sides Access Opening for Junction
Box - Right Side Only
(remove the knock-out
before installing J-Box).
J-Box / Electrical Kit is not
provided with appliance.
Junction Box
Top View
A
E
C
D
P *Q
F
H
J
M
N
1 (25)
7-1/16
(179)
Front View
B
G
Right Side View
L
K
Top Stand-Off
Spacers (4
places)
6-3/16
(157) 5-3/4
(146)
3-9/16
(90)
Top of Bottom
Refractory
Bottom of
Firebox
Opening
Top of Firebox
Opening
* Hood
Product Reference Information
Cat. No. Model Ship. Weight (lbs) Shipping Volume
F0322 VRT2536WS 150 lbs 20 Cu. Ft.
F0298 VRT3536WS 200 lbs 22 Cu. Ft.
F0299 VRT3536WH 200 lbs 22 Cu. Ft.
F0300 VRT3542WS 230 lbs 26 Cu. Ft.
F0301 VRT3542WH 230 lbs 26 Cu. Ft.
* A hood comes standard and is required for model VRT2536WS. The
factory-supplied hood must be installed on the firebox for safe opera-
tion for model VRT2536WS in all installations. This part is optional for
models VRT3536WS, VRT3536WH, VRT3542WS & VRT3542WH.
Dimensions - Inches (millimeters)
Model No. A B C D E F G H J KL M N P *Q
VRT2536WS 36
(914)
24
(610)
41-3/4
(1061)
37-1/4
(946)
23-1/2
(597)
20
(508)
3
(76)
7-3/8
(187)
15-7/8
(403)
7-1/2
(190)
11-15/16
(303)
1-5/16
(33)
5-1/2
(140)
30-5/16
(770)
29-5/8
(753)
VRT3536WS &
VRT3536WH
36
(914)
28
(711)
41-3/4
(1061)
41-1/4
(1048)
23-1/2
(597)
20
(508)
3
(76)
8-3/8
(213)
15-7/8
(403)
7-1/2
(190)
11-15/16
(303)
1-5/16
(33)
5-1/2
(140)
34-5/16
(872)
33-5/8
(854)
VRT3542WS &
VRT3542WH
42
(1067)
28
(711)
47-3/4
(1213)
41-1/4
(1048)
29-1/2
(749)
20
(508)
3
(76)
8-3/8
(213)
15-7/8
(403)
7-1/2
(190)
11-15/16
(303)
1-5/16
(33)
5-1/2
(140)
34-5/16
(872)
33-5/8
(854)
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
11
FRAMING SPECIFICATIONS
Figure 9
HoodKitInstallation(see ordering information on Page 16)
The firebox canopy (hood) must not be modified or replaced with a
canopy that may be provided with the unvented decorative room
heater.
NOTE: A hood comes standard and is required for model VTR2536WS.
The factory-supplied hood must be installed on the firebox for safe
operation for model VTR2536WS in all installations (this part is optional
for other models). See
Figure 13.
Thesehoodkitsaredesigntobettedtothefaceoftheappliancedirectly
abovethereboxopening.Inadditiontoprovidinganaestheticallypleasing
appearance to your appliance, the hood reduces heat effects to decora-
tivemantelsandnishmaterialslocateddirectlyabovethereplaceand
reducestheMantel/Trimclearances(seeFigures 4, 5 & 6 on Page 7).
Please read this entire manual and understood thoroughly before proceeding
with the installation of these kits.
Step 1.Usinga5/16"nutdriverorsocket,removethescreenandrod
assemblies as shown in Figure 12.
Step 2. Align the hood with the holes in the side frames as shown in
Figure 13. Install three screws as shown in Figure 13.Make
sure hood is level and secure.
Step 3. Reinstall screen and rod assemblies (see Figure 12).
Framing Dimensions
Opening VRT2536WS VRT3536WS &
VRT3536WH
VRT3542WS &
VRT3542WH
A 42-1/4" (1073) 42-1/4" (1073) 48-1/4"(1226)
B 40-1/4" (1022) 44-1/4" (1124) 44-1/4" (1124)
C23-9/16"(599) 23-9/16"(599) 29-9/16"(751)
D11-1/4"(286) 11-1/4"(286) 14-1/4"(362)
E63-1/2"(1613) 63-1/2"(1613) 69-1/2"(1765)
F 31-3/4" (807) 31-3/4" (807) 34-3/4" (883)
G 20-1/2"( 521) 20-1/2"( 521) 20-1/2"( 521)
H 44-3/16"(1122) 44-3/16"(1122) 49-1/8"(1248)
Table 1 - This Table corresponds to Figures 9, 10 & 11
Rough Framing Face
(Unfinished Shown) Back Wall Of Chase/Enclosure
Including Finishing Materials If Any
Rough Framing Face
(Unfinished Shown)
A
C
G
Parallel Installation
Figure 10
Figure 11
This Figure corre-
sponds to Table 1
This Figure corresponds
to Table 1
WARNING: Do not fill
spaces around the
firebox with insulation
or other materials.
A
B
Header
Figure 12
Removing Screens & Rods:
Remove screws (see dotted
lines). Pull out rods from
locatingholesonsideofrebox
opening.
Reinstalling Screens & Rods:
Insert rods into corresponding
locatingholesonsidesofrebox
opening, then reinstall screws
as shown.
A
C
D
HF
G
E
Back Wall Of Chase/Enclosure
Including Finishing Materials If Any
Rough Framing Face
(Unfinished Shown)
Corner Installation
This Figure corresponds to Table 1
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
12
OPTIONAL EQUIPMENT
BlowerKits
The FBK-100 Blower Kits are used when
a wall-mounted ON/OFF blower switch is
desired, and the FBK-200 Blower Kits are
used when a wall-mounted variable speed
blower control (rheostat) is desired. A Junction
Box/ Electrical Kit isalsorequiredtoinstallthese
kits (purchased separately - see Page 15).
The blower is installed beneath the rebox.
Room air is drawn in through the side slots
ofthereplace,heatedasitpassesacrossthe
rebox,anddischargedthroughtheupperarea
ofthereboxopening.
The installation instructions for installing these
blower kits are on Pages 12 through 14. Also
see the installation instructions provided with
theblowerkits(Form#750028M).Forelectrical
requirements,refertoFigures 14, 15 & 16.
If the blower kit is to be installed at the time of
installation or at a later date, the main power
supply must be installed at the time of instal-
lation. This will require that the electrical
connections must be madeBEFORE the firebox
is framed and enclosed in the finished walls.
Routea3-wire,120VAC,60Hz,1phpower
supply and connect toelectrical receptacle wires
and wall switch or rheostat.
Grounded
to Appliance
Blower Motor
Motor Plug
Receptacle
120V
Appliance Junction Box
NOTE: If any of the original wire as supplied
must be replaced, it must be replaced with type
AWM 105°c – 18Ga. wire
120V, 60HZ,
1PH BLOWER
CONTROL CIRCUIT
WIRING
Junction
Box
Factory Wired
Blower
Tab
Intact
Plug blower
into this
receptacle
Ground - Green
* Wall-mounted ON/
OFF Blower Switch
or Variable Speed
Control Switch.
Ground
HOT SIDE OF
RECEPTACLE
*An ON/OFF Wall Switch is used with the FBK-100 kit
(field provided or sold separately - order P/N 85L87); A
VariableSpeedControl(provided)isusedwiththeFBK-
200 kit. The installation of these kits also require a
JunctionBox/ElectricalKit,notincluded.SeePage
15 for ordering information.
Note: If any of the original wire as supplied must be
replaced, it must be replaced with type AWM 105
degree C - 14 gage wire.
Neutral - White
120 VAC Black
Green
Ground
Screw
NEUTRAL
SIDE OF
RECEPTACLE
Black
Field Wired
Figure 16
Blower
* Junction Box
Bend blower mounting
tabs up to secure
blower in place
* Electrical Outlet
Tie a loose knot in power
cord to take up slack
Top View
Figure 15
Figure 14
Note: If any of the original wire as supplied must be
replaced, it must be replaced with type AWM 105
degree C - 14 gage wire.
*TheJunctionBox/ElectricalKit isnotincluded.
See Page 15 for ordering information.
Figure 13
Hood
Side View
IMPORTANT
TheGroundLead must be connected
to the green screw (located on the
junction box). Failure to do this
could result in an electrical short or
shock injury.
The appliance must be electrically
grounded in accordance with local
codes or, in the absence of local
codes, the national electrical code,
ANSI/NFPA 70-(latest edition). (In
Canada, the current CSA C22-1
Canadian Electrical Code).
CAUTION
Electrical connections should
only be performed by a qualified,
licensed electrician. Main power
must be off when connecting to
main electrical power supply or
performing service.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
13
Step 1.Followtheinstructionsbelowforthemodelyouareinstalling:
Model VRT2536WS:
Using a screwdriver remove the screw from the blower access panel
as shown in Figure 18. Slide the panel to the right until the flange
clears the opening. Remove the panel and set aside.
Models VRT3536WS, VRT3536WH, VRT3542WS & VRT3542WH:
Liftoutthebottomrefractorypanel(seeFigure 17).
Step 2.Removetherectangularknock-out(forJ-Box)ontherightside
of unit (see Figure 8 for location). InstalltheJunctionBox&Electrical
outletbelowthereboxoorintotherectangularopeningontheright
side cabinet panel where you removed the knock-out (see Figures 20 &
21). The Junction Box / Electrical Kit is sold separately (see Page 15 for
ordering information).
• Squeeze the J-Box anges together to t into the opening shown in
Figures 20 and 21.
• Wires will need to be passed through the hole shown in Figure 19.
• An approved strain relief bushing (not supplied with the kit), is required
to restrain the wires (see Figure 19).
Step 3.Looselytieaknotinthepowercordtotakeupslack(seeFigure 22).
Step 4.LocatethetabsshowninFigure 23. Position the blower assembly
so that the tabs (located on the cabinet base) are seated in the notches of
the blower bracket. Bend the tabs over to secure the blower assembly (see
Figure 24).
Step 5. Plug power cord into the electrical outlet as illustrated in Figure 15.
Models: VRT3536WS,
VRT3536WH, VRT3542WS
& VRT3542WH
J-Box Flanges
J-Box &
Electrical
Outlet
Right Outside Cabinet Panel
Wires
Figure 17
Figure 20 - Model VRT3542WS Shown
Figure 18 - Model VRT2536WS Figure 21
Lift Out Bottom Refractory Panel
IMPORTANT
All electrical wiring must be performed by licensed Elec-
tricians. Electrical wiring must comply with the National
Electrical Code ANSI/ NFPA 70 - latest edition
Installation Instructions -
FBK-100orFBK200BlowerKitsandJBKJunctionBoxKit
Firebox
oor
Blower
Access
Panel
Remove screw, then lift out blower access panel.
J-Box Flange
Install into side wall rectanular opening
Firebox
oor
Screw
Figure 19 - Junction Box Kit (all models)
J-Box &
Receptacle
J-Box & Electrical Outlet
Screw
Remove knock-out
(strain relief bush-
ing [not supplied]
presses into this
hole around romex
wires - see Step 8 on
Page 14).
Cover Plate
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
14
Step 8. Ensure that power supply wires are NOT "live" before making
these connections). Install J-Box Cover Plate as follows:
Feed the * Romex wires (or other equivalent plastic insulated
wire-ReferANSI/NFPA70-NationalElectricalCode-Latest
Edition)throughtheJ-BoxCoverretangularopening,thencon-
necttotheJ-boxwires.Thestrainreliefbushing(notsupplied)
shouldbepressedintotheknock-outonJ-boxcoveraroundthe
Romex(thiswillprovideprotectiontothewiresandpreventsstrain
againstconnectionsfromJ-box).SeeWiringDiagram-Figure
16. InstallthecoverplateoverJ-Boxopeningonapplianceas
shown in Figure 25.
Note:Wireconnectionsshouldbepositionedinsideoftheap-
pliance.
*Romexisaplasticinsulatedwirefrompowersupply-sometimescalled
non-metallic sheath.
Cabinet Base
Figure 22
Figure 21 - VRT3542WS Shown
Figure 24 - VRT3542WS Shown
Loose knot in power
cord to take up slack
Firebox
oor
Model VRT3542WS Shown
Model VRT3542WS
Locating Tabs
Bend Locating Tabs Over
(into notches)
Use screw provided and
secure in place as shown
The notched side of
cover plates goes inside
firebox panel
Screw Cover Plate
Right Side Panel of Firebox
Figure 25 - Installing J-box Cover Plate - All Models
Step 9.Followtheinstructionsbelowforthekityouareinstalling:
FBK-100Kits-Installaeld-provided(orP/N85L87)ON/OFFwall
switch in a convenient location on a wall, near the fireplace.
FBK-200Kits-Installthekit-providedvariablespeedcontrol(rheo-
stat) in a convenient location on a wall, near the fireplace.
Step 10.Followtheinstructionsbelowforthemodelyouareinstalling:
Model VRT2536WS:
Reinstall the blower access panel that was removed on Step 1 (see
Figure 18).
Models VRT3536WS, VRT3536WH, VRT3542WS & VRT3542WH:
Reinstall the bottom refractory panel that was removed on Step 1
(see Figure 17).
J-Box opening
on appliance
Step 6. Routea3-wire,120VAC,60Hz,1phpowersupplytotheright
side of appliance.
Step 7.LocatetheJ-Boxcover(providedinJ-BoxKit).Removetheround
knock-out (see Figure 19).
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
15
FIREBOX FINISHES
Thereareawidevarietyof“nishedlooks”foryourbuilt-inVent-Freereboxfromformalwall
decor with elaborate mantels to rustic wood paneling or warm brick facings.
Onlynoncombustible materials likemarble, stone, tile,brick, etc. mayoverlap the blackfront
facing.Sealalljointsbetweentheblackfacingandwallsurroundstopreventairintrusion.Use
noncombustible caulking material only to seal the black metal facing to the surround material on
thenishedwall.SeeFigures 3 & 26.
Raised Hearth Extension
Ahearthextensionmaybeusedbutisnotrequiredfortheseappliances.Araisedhearthextension
may be used as shown in Figure 26.
Raised Hearth Extension
(combustibles allowed.
No carpet or vinyl)
Combustible Platform
SIDE VIEW
Firebox Floor
Combustible Wall
Figure 26 - Raised Hearth Extension
Non-Combustible Wall
(see Figure 4)
Fireplace Opening
* From Base to
Bottom of Firebox
Opening (floor)
5-3/4" Max.*
Base
APPROVED ACCESSORIES AND
COMPONENTS
Decorative Volcanic Stone
The decorative volcanic stone, Model FDVS,
can be used to enhance the look of your ap-
pliance.OrdermodelFDVSforreplacement
of stone when needed. Spread the decorative
volcanic stone evenly around the bottom of
therebox.
JunctionBox/RecepticalKit
TheJunctionBox(J-Box)Kitisdesignedtobe
used when an optional FBK-100 or FBK-200
BlowerKitistobeinstalled.
(ref. Form #750010M)
Decorative Volcanic Stone
Cat. No. Model No. Description
80L42 FDVS Bag of Volcanic Stone
JunctionBox/RecepticalKit
Cat. No. Model No. Description
H1958 JBK JunctionBox/ElectricalKit
(ref. Form #750203M)
DecorativeScreenDoorPanelKit
Cat. No. Model Where Used
H1959 ASD3624-TI VRT2536WS
H1960 ASD3628-TI VRT3536WS & VRT3536WH
H1961 ASD4228-TI VRT3542WS & VRT3542WH
DecorativeArchScreenPanelKit
This attractive screen door is easy to install and
enhances the appearance of the appliance.
(ref.Form#750209M)
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
16
OutsideAirGate&DuctKit
Cat. No. Model No. Description
H3991 OAK-UVFRC OutsideAirGate&DuctKit
OutsideAirGate&DuctKit
These kits have an air gate assembly, 4" diam-
eter duct and a termination hood. The air gate
allowsadjustmentoftheamountofoutsideair
deliveredtothereforcombustion.Onlyone
kit,locatedontherightsideofthereplace,
isrequired.
(ref. Form #750206M)
BlowerKit
TheFBK-100blowerprovidesforaconstantvelocityforcedaircirculationfeatureforyourap-
pliance.TheFBK-200assemblywithvariablespeedwallswitchprovidesaforcedaircirculation
feature for your appliance.
Black Hood
Cat. # Model Models Where Used
H1989 FC36 VRT3536WS, VRT3536WH
(VRT2536WS standard part)
H1990 FC42 VRT3542WS & VRT3542WH
*ForcedAirBlowerKits
Cat.
No.
Model No. Description
80L84 FBK-100 Blower, Standard
(single speed)
80L85 FBK-200 Blower, Variable Speed
(w/wall-mounted switch)
Touch-UpPaintKit
Repair of minor scratches and
discoloration of the appliance
black painted surfaces may be
accomplished with the touch-up
paint kit.
Touch-UpPaintKits
Cat. No. Model No. Description
90L73 FTPK-B Touch-Up Paint (Black)
(ref. Form # 504216M)
P
A
I
N
T
The variable speed control
rheostat is included with
FBK-200 models only
An ON/OFFwall switch canbe used
with the FBK-100 models (eld
supplied or order P/N 85L87 Wall
Switch Kit, shown below)
ON/OFFWallSwitchKit
TheON/OFFwallswitchkit
may be used to control the
bloweroperation,ifFBK-
100 blower kit is installed.
InstalltheON/OFFwall
switch in a convenient
locationnearthereplace.
WhiteWallSwitchKit
Cat. No. Model No. Description
85L87 FWSK ON/OFFWallSwitchKit
* The installation of these kits also require a Junction Box / Receptical
Kit, not included. See ordering information on page 15.
(ref. Form #750195M)
APPROVED ACCESSORIES AND
COMPONENTS
For more information on available log sets for this and other Superior products, visit SuperiorFireplaces.US.com.
NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
17
3
4
5
2
1
6
3
4
5
No. Description
VRT2536WS VRT3536WS VRT3536WH VRT3542WS VRT3542WH
Part No. Qty. Part No. Qty. Part No. Qty. Part No. Qty. Part No. Qty.
Gas Fireplace Assembly - - - - - - - -
1. Firescreen H2325 2H2694 2H2694 2H2699 2H2699 2
2. Rod, Screen H3919 2H3919 2H3919 2H2700 2H2700 2
3a. Refractory,Left H7758 1H7762 1H7766 1H7762 1H7771 1
3b. Refractory, Right H7759 1H7761 1H7765 1H7761 1H7770 1
4. Refractory, Rear H7770 1H7764 1H7767 1H7768 1H7772 1
5. Refractory, Bottom - - H7763 1H7763 1H7769 1H7769 1
6. Hood H1989 1H1989 1H1989 1H1990 1H1990 1
3
4
5
2
1
6
3
4
5
Anexplodedviewofthereboxwithnumberedpartsandareplacement
parts list can be found on the Page. Normally, all parts should be ordered
through your distributor or dealer. Parts will be shipped at prevailing
prices at time of order.
Whenorderingrepairparts,alwaysgivethefollowinginformation:
1.The*modelnumberoftherebox.
2.The*serialnumberoftherebox.
3. The part number.
4. The description of the part.
5.Thequantityrequired.
6.Theinstallationdateoftherebox.
REPLACEMENT PARTS
3
4
5
2
1
6
3
4
5
* NOTE: The model and serial number can be found on the rating label
located on the bottom left front corner of the appliance.
Ifyouencounteranyproblemsorhaveanyquestionsconcerningthe
installation of a Vent-Free heater in this system, please contact your dis-
tributor or dealer or visit our website at www.SuperiorFireplaces.us.com.
WARNING
Failure to position the parts in accordance with these
diagrams or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.
18
NOTES
19
12/02/2013
Printed in U.S.A. © 2013 Innovative Hearth Products LLC
P/N 900223-00, Rev. NC 12/2013
Innovative Hearth Products
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
Innovative Hearth Products
Superior™ Brand Gas Fireplaces, Stoves and Inserts
20 Year Limited Warranty
THE WARRANTY
Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior™ Brand gas fireplace, Stove or Insert ("Product") to be free from defects in materials
and workmanship at the time of manufacture. The Product body and firebox carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against
thermal breakage only. After installation, if covered components manufactured by IHP are found to be defective in materials or workmanship during the 20 Year Limited
Warranty period and while the Product remains at the site of the original installation, IHP will, at its option, repair or replace the covered components. If repair or replacement
is not commercially practical, IHP will, at its option, refund the purchase price or wholesale price of the IHP product, whichever is applicable. IHP will also pay IHP prevail-
ing labor rates, as determined in its sole discretion, incurred in repairing or replacing such components for up to five years. THERE ARE EXCLUSIONS AND LIMITATIONS
to this 20 Year Limited Warranty as described herein.
COVERAGE COMMENCEMENT DATE
Warranty coverage begins on the date of installation. In the case of new home construction, warranty coverage begins on the date of first occupancy of the dwelling or six
months after the sale of the Product by an independent IHP dealer/distributor, whichever occurs earlier. The warranty shall commence no later than 24 months following
the date of product shipment from IHP, regardless of the installation or occupancy date.
EXCLUSIONS AND LIMITATIONS
This 20 Year Limited Warranty applies only if the Product is installed in the United States or Canada and only if operated and maintained in accordance with the printed
instructions accompanying the Product and in compliance with all applicable installation and building codes and good trade practices.
This warranty is non-transferable and extends to the original owner only. The Product must be purchased through a listed supplier of IHP and proof of purchase must be
provided. The Product body and firebox carry the 20 Year Limited Warranty from the date of installation. Vent components, trim components and paint are excluded from
this 20 Year Limited Warranty. The following do not carry the 20 Year Limited Warranty but are warranted as follows:
Burner – Repair or replacement for one year from the date of installation
Gas components – Repair or replacement for one year from the date of installation
Gaskets – Repair or replacement for one year from the date of installation
Logs – Replacement for one year from the date of installation against thermal breakage only
Optional blowers & remote controls – Repair or replacement for one year from the date of installation
Optional glass doors – Repair or replacement for 90 days from the date of installation
Tempered glass - Replacement for one year from the date of installation
Labor coverage – Prevailing IHP labor rates apply for the warranty period of the component
Parts not otherwise listed carry a 90 day warranty from the date of installation.
Whenever practicable, IHP will provide replacement parts, if available, for a period of 10 years from the last date of manufacture of the Product.
IHP will not be responsible for: (a) damages caused by normal wear and tear, accident, riot, fire, flood or acts of God; (b) damages caused by abuse, negligence, misuse, or
unauthorized alteration or repair of the Product affecting its stability or performance (The Product must be subjected to normal use. The Product is designed to burn either
natural or propane gas only. Burning conventional fuels such as wood, coal or any other solid fuel will cause damage to the Product, will produce excessive temperatures
and could result in a fire hazard.); (c) damages caused by failing to provide proper maintenance and service in accordance with the instructions provided with the Product;
(d) damages, repairs or inefficiency resulting from faulty installation or application of the Product.
IHP is not responsible for inadequate fireplace system draft caused by air conditioning and heating systems, mechanical ventilation systems, or general construction condi-
tions which may generate negative pressure in the room in which the appliance is installed. Additionally IHP assumes no responsibility for drafting conditions caused by
venting configurations, adjoining trees or buildings, adverse wind conditions or unusual environmental factors and conditions that affect the operation of the unit.
This 20 Year Limited Warranty covers only parts and labor as provided herein. In no case shall IHP be responsible for materials, components or construction, which are not
manufactured or supplied by IHP or for the labor necessary to install, repair or remove such materials, components or construction. Additional utility bills incurred due to
any malfunction or defect in equipment are not covered by this warranty. All replacement or repair components will be shipped F.O.B. from the nearest stocking IHP factory.
LIMITATION ON LIABILITY
It is expressly agreed and understood that IHP’s sole obligation and the purchaser’s exclusive remedy under this warranty, under any other warranty, expressed or implied,
or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified herein.
In no event shall IHP be liable for any incidental or consequential damages caused by defects in the Product, whether such damage occurs or is discovered before or
after repair or replacement, and whether such damage is caused by IHP’s negligence. IHP has not made and does not make any representation or warranty of fitness for a
particular use or purpose, and there is no implied condition of fitness for a particular use or purpose.
IHP makes no expressed warranties except as stated in this 20 Year Limited Warranty. The duration of any implied warranty is limited to the duration of this expressed warranty.
No one is authorized to change this 20 Year Limited Warranty or to create for IHP any other obligation or liability in connection with the Product. Some states and provinces
do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. The provisions of this 20 Year
Limited Warranty are in addition to and not a modification of or subtraction from any statutory warranties and other rights and remedies provided by law.
INVESTIGATION OF CLAIMS AGAINST WARRANTY
IHP reserves the right to investigate any and all claims against this 20 Year Limited Warranty and to decide, in its sole discretion, upon the method of settlement.
To receive the benefits and advantages described in this 20 Year Limited Warranty, the appliance must be installed and repaired by a licensed contractor approved by IHP.
Contact IHP at the address provided herein to obtain a listing of approved dealers/distributors. IHP shall in no event be responsible for any warranty work done by a
contractor that is not approved without first obtaining IHP's prior written consent.
HOW TO REGISTER A CLAIM AGAINST WARRANTY
In order for any claim under this warranty to be valid, you must contact the IHP dealer/distributor from which you purchased the product. If you cannot locate the dealer/
distributor, then you must notify IHP in writing. IHP must be notified of the claimed defect in writing within 90 days of the date of failure. Notices should be directed to the
IHP Warranty Department at 1508 Elm Hill Pike, Suite 108; Nashville, TN 37210 or visit our website at WWW.SUPERIORFIREPLACES.US.COM.
Printed in U.S.A. © 2013 InnovativeHearthProducts
P/N 900238-01 REV. A 02/2015
IHPreservestherighttomakechangesatanytime,withoutnotice,indesign,materials,specica-
tions, prices and the discontinuance of colors, styles and products. Consult your local distributor
forreplacecodeinformation.
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
1508ElmHillPike,Suite108•Nashville,TN37210
P900238-01
Other manuals for VRT2536WS
1
This manual suits for next models
4
Table of contents
Other Superior Indoor Fireplace manuals
Superior
Superior VRT6036RS User manual
Superior
Superior GRD-5000N User manual
Superior
Superior DRL6542TEN User manual
Superior
Superior BRT4036TEN User manual
Superior
Superior DRC6340TEN Owner's manual
Superior
Superior STANDARD Series User manual
Superior
Superior BR-42 User manual
Superior
Superior CF5500-CMN User manual
Superior
Superior BRT40STTMN User manual
Superior
Superior WRT6036RS User manual
Superior
Superior VRE3036ZMN User manual
Superior
Superior SSDVPF-CNE-B User manual
Superior
Superior VFST-CMN User manual
Superior
Superior GHC-6500 SERIES User manual
Superior
Superior DRT3033 User manual
Superior
Superior VF4000-CMP-2 and User manual
Superior
Superior VRT4032ZMN User manual
Superior
Superior SDVI and operation Operating instructions
Superior
Superior Merit WRT2036WS User manual
Superior
Superior VRT3032 Series User manual
Popular Indoor Fireplace manuals by other brands
Enviro
Enviro G39G owner's manual
Lennox
Lennox SLDVT-40 Care and operation instructions
Monessen Hearth
Monessen Hearth DFX24C Installation and operating instructions
Regency
Regency GEM54-NG Owners & installation manual
ORTAL
ORTAL Lyric Front Facing Series Installation and operation manual
GHP Group
GHP Group Pleasant Hearth PHZCI28LP manual
Sunjoy
Sunjoy Sunnest A304001006 manual
Muskoka
Muskoka Harmony Assembly instructions
bemodern
bemodern 800CF instructions
baltur
baltur TBG 45 P instruction manual
Nordica
Nordica FOCOLARE 80 IDRO CRYSTAL DSA Instructions for installation, use and maintenance
Regency
Regency Plateau PTO30-NG Owners & installation manual
Kohlangaz
Kohlangaz Desire HLBL SN Series Installation, maintenance & user instructions
Security Chimneys International
Security Chimneys International BIS Tradition BISTRAD Installation and operation instructions
Astria Fireplaces
Astria Fireplaces Sentinel Series Operation instructions
Empire
Empire DVX36FP31L(N Installation instructions and owner's manual
baltur
baltur TBG 50 LX PN Instruction manual for installation, use and maintenance
Napoleon
Napoleon BL36NTE Installation and operating instructions
