Napoleon GL18NE User manual

INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.37
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
SAFETY INFORMATION
!WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier from
a neighbour’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier,
call the fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
CERTIFIED FOR CANADAAND UNITED STATES USING ANSI/CSAMETHODS.
$10.00
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
CERTIFIED
1
W415-1071 / C / 01.11.12
$10.00
CERTIFIED UNDER: ANSI Z21.60 / CSA 2.26 DECORATIVE GAS APPLIANCES FOR INSTALLATION IN SOLID-FUEL BURNINGAPPLIANCES
GL18
GL24
GL30
GL18NE, GL24NE,
GL30NE
NATURAL GAS
GL18PE, GL24PE,
GL30PE
PROPANE

Andiron, see “ANDIRON
AND GRATE ASSEMBLY”
section.
Logs, see “LOG PLACE-
MENT” section.
Media, see “MEDIA” sec-
tion.
Rating Plate, see “RATING
PLATE INFORMATION”
section.
Batteries, see “BATTERY
INSTALLATION” section.
2
W415-1071 / C / 01.11.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 2
2.0 INTRODUCTION 3
2.1 GENERAL INSTRUCTIONS 4
2.2 GENERAL INFORMATION 5
2.3 MINIMUM APPLIANCE SIZE 5
2.4 RATING PLATE 5
3.0 INSTALLATION 6
3.1 GAS PIPING 6
3.2 DAMPER STOP INSTALLATION 7
4.0 FINISHING 8
4.1 ANDIRON AND GRATE ASSEMBLY 8
4.2 BATTERY INSTALLATION 8
4.3 LOG PLACEMENT 9
4.4 MEDIA 10
4.5 LOGO PLACEMENT 10
4.6 OPTIONAL ROCK PLACEMENT 11
4.7 OPTIONAL REMOTE INSTALLATION (NOT SUPPLIED) 11
5.0 WIRING DIAGRAM 12
6.0 OPERATION 13
6.1 OPERATING AND LIGHTING INSTRUCTIONS 13
7.0 ADJUSTMENTS 14
7.1 PILOT BURNER ADJUSTMENT 14
7.2 VENTURI ADJUSTMENT 14
7.3 FLAME CHARACTERISTICS 15
8.0 MAINTENANCE 15
9.0 REPLACEMENTS 16
10.0 TROUBLE SHOOTING 18
11.0 WARRANTY 20
12.0 SERVICE HISTORY 21
1.0 INSTALLATION OVERVIEW

3
W415-1071 / C / 01.11.12
3.16B
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR IT’S CONTROLS CAN BE
DANGEROUS AND IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate
appliance according to operating instructions could cause fire or injury.
• Risk of fire or asphyxiation do not operate appliance with fixed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal
edges may be sharp.
• Do not burn wood or other materials in this appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away
to avoid burns or clothing ignition. Toddlers, young children and others may be susceptible to accidental
contact burns. Aphysical barrier is recommended if there are at risk individuals in the house. To restrict
access to an appliance or stove, install an adjustable safety gate to keep toddlers, young children and
other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and
draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot
surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children
from hot surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• This appliance is a vented gas-fired appliance. Do not burn wood or other materials in this appliance.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
appliance and venting system are kept clean. The appliance and its venting system should be inspected
before use and at least annually by a qualified service person. More frequent cleaning may be required
due to excessive lint from carpeting, bedding material, etc. The appliance area must be kept clear and
free from combustible materials, gasoline and other flammable vapors and liquids.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe serving a separate solid fuel burning
appliance.
• Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas control
which has been under water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As
with all plastic bags, these are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and
serviced as well as having a Carbon Monoxide Detector installed in the same area to defend you and
your family against Carbon Monoxide.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the
appliance. Elevated temperatures on the wall or in the air above the appliance can cause melting,
discolouration or damage to decorations, a T.V. or other electronic components.
2.0 INTRODUCTION

4
W415-1071 / C / 01.11.12
2.1 GENERAL INSTRUCTIONS
Thoroughly clean the chimney, flue and existing
appliance before installing the new appliance into
it. Do not burn solid fuels in any appliance that is
equipped with this gas log set.
The installation of this appliance must conform with
local codes or in the absence of local codes, it must
conform to ANSI Z.223.1 or the CAN/CGAB149.
Do not operate appliance in the presence of gasoline
or other flammable liquids and vapours. Keep area
clear of other combustible materials. The appliance
and its shut off must be disconnected from the gas supply piping system before any pressure testing of the
system is done.
Installation practices vary from region to region and it is important to know the specifics that apply to your
area,
For example: in Massachusetts State:
• This product must be installed by a licensed plumber or gas fitter when installed within the
commonwealth of Massachusetts.
• The appliance damper must be removed or welded in the open position prior to installation of a
appliance
• insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or bathroom unless the appliance is a
direct vent sealed combustion product.
• Acarbon monoxide detector is required in all rooms containing gas fired appliances.
No external electricity (110 volts or 24 volts) is required for the gas system operation.
ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT,
WITH THE GLASS DOOR OPENED OR REMOVED.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” FROM THE
FRONT FACE OF THE UNIT.
SURFACES AROUND AND ESPECIALLY ABOVE THE APPLIANCE CAN BECOME HOT. AVOID CONTACT
WHEN THE APPLIANCE IS OPERATING.
FIRE RISK. EXPLOSION HAZARD.
HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE PRESSURE TESTING GAS
LINE AT TEST PRESSURES ABOVE 1/2 PSIG. CLOSE THE MANUAL SHUT-OFF VALVE BEFORE PRESSURE
TESTING GAS LINE AT TEST PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG.
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE.
USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING
COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.
DO NOT USE A BLOWER INSERT, HEAT EXCHANGER INSERT OR ANY OTHER ACCESSORY NOT APPROVED FOR USE
WITH THIS APPLIANCE
!
WARNING
We suggest that our gas
hearth products be installed
and serviced by professionals
who are certied in the U.S.
by the National Fireplace
Institute
® (NFI) as NFI Gas
Specialists
www.ncertied.org

5
W415-1071 / C / 01.11.12
2.2 GENERAL INFORMATION
THIS APPLIANCE MUST NOT BE INSTALLED IN A BEDROOM OR BATHROOM.
!
WARNING
2.3 MINIMUM APPLIANCE SIZE Do not install the gas log set into a cavity smaller than that
referenced in the table.
LOG SET HEIGHT WIDTH DEPTH
GL18 18” 22” 14”
GL24 20” 28” 14”
GL30 22” 34” 14”
GL18 GL24 GL30
NG LP NG LP NG LP
Altitude (FT) 0-4,500 0-4,500 0-4,500 0-4,500 0-4,500 0-4,500
Max input (BTU/HR) 55,000 55,000 60,000 60,000 65,000 65,000
Min Inlet Gas Supply Pressure 4.5“ Water
Column 11“ Water Column 4.5“ Water Column 11“ Water Column 4.5“ Water Column 11“ Water Column
Max Inlet Gas Supply Pressure 7“ Water
Column 13“ Water Column 7“ Water Column 13“ Water Column 7“ Water Column 13“ Water Column
Manifold Pressure (Under Flow
Conditions) 3.5“ Water Column 10“ Water Column 3.5“ Water Column 10“ Water Column 3.5“ Water Column 10“ Water Column
2.4 RATING PLATE
THE RATING PLATE IS CHAINED TO THE LEG OF THE BURNER BASE AND SHOULD BE TUCKED
UNDER THE ENTIRE ASSEMBLY
SAMPLE
This rating plate illustration is for reference only. Refer to the rating plate on the appliance for accurate
information.
W385-1870
SERIAL NUMBER/NO. DE SERIE: GLE
REFERENCE#W/N15987
CERTIFIED UNDER / HOMOLOGUE SELON LES NORMES: ANSI Z21.60b-2004 CGA 2.26b-2004, DECORATIVEAPPLIANCE FOR INSTALLATION IN SOLID-FUEL BURNING APPLIANCES
WOLF STEEL LTD.
24NAPOLEONROAD. BARRIE,ONTARIO L4M0G8CANADA
WOLF STEEL USA
103MillerDrive, Crittenden,Kentucky, USA,41030
18”
20”
22”
GL18 PE GL24 PE GL30 PE GL18 NE GL24 NE GL30 NE
CERTIFIED
CERTIFIED FOR CANADA/ USA
CERTIFIEE POUR CANADA/ USA
55,000BTU/h 60,000BTU/h 65,000BTU/h
34,000BTU/h 35,000BTU/h 36,000BTU/h 55,000BTU/h 60,000BTU/h 65,000BTU/h 45,000BTU/h 50,000BTU/h 50,000BTU/h

6
W415-1071 / C / 01.11.12
3.0 INSTALLATION
The appliance and gas logs function as a system. If the appliance is not drafting properly and spilling into the
room (check with a match or a smoke stick), reposition the damper clamp until a positive draft is obtained
by opening the damper. If negative pressure in home prevents having a positive draft, consult an air quality
specialist.
!
WARNING
DO NOT CONNECT EITHER THE WALL SWITCH, THERMOSTAT OR GAS VALVE TO ELECTRICITY
(110 VOLTS).
This appliance must be isolated from the gas supply piping system by closing the individual manual shut off
valve during any pressure testing of the gas supply piping system at test pressure equal to or less than ½ psi
(3.5 kPa)
A. Centre the appliance in the fireplace opening, making
sure the appliance has enough room behind it for the
gas line to run behind the log set under the log support.
B. Route the gas line and sizing using piping ½” diameter
or greater to allow the full volume of gas to the
appliance. The routing of the gas line has to be done to
local and / or national codes.
C. When rigid pipe is used an ANSI approved manual shut
off and a union must be installed upstream within the
appliance cavity.
D. To ensure the appliance operates reliably install a
sediment trap upstream of the appliance within the
structures of the piping system.
E. When using propane, a regulator must be used between the tank and the outside wall of the house to
ensure the line pressure does not exceed 14” w.c.
F. Check gas connections with a gas detection device to test for leaks in the system. Soapy water
mixture can also be used to check for leaks.
G. Once all the gas connections are tested for leaks, start the appliance. Follow the lighting instructions
to ensure the appliance is working properly before finishing.
Regulator Union Manual
Shut-Off
Valve
Wall
Shut-Off
Key
Sediment
Trap
Appliance
Appliance
3"
3.1 GAS PIPING
!
WARNING
THIS APPLIANCE MUST BE INSTALLED IN A SOLID-FUEL BURNING FIREPLACE WITH A WORKING
FLUE AND CONSTRUCTED OF NON-COMBUSTIBLE MATERIAL.

7
W415-1071 / C / 01.11.12
3.2 DAMPER STOP INSTALLATION
DAMPER STOP
DAMPER
The damper must be permanently locked in
position to prevent full closure and to provide
a minimum flue opening. Various methods
for locking the damper may be used but may
be restricted from region to region and it is
important to know the specifics that apply to
your area. For your convenience a damper
stop is provided with the appliance and may
be used where not prohibited by state or local
codes.
Use the 3” adjustable bolt to adjust the damper to the correct opening, based on the enclosed chart.
Should the damper stop not fit, or provide the required permanent opening from the Minimum Damper Opening
table, have the damper cut to provide a minimum permanent opening or install an alternate stop.
Creosote, ashes and loose paint must be cleaned from the
chimney flue and firebox by a qualified chimney cleaner,
before installing in a solid fuel burning appliance.
Any outside air ducts and/or ash dumps in the fireplace shall
be permanently closed at time of appliance installation.
If the damper stop (supplied) is not applicable the damper
may be fixed open by the following method:
• Drill a hole in either end of the damper.
• Using a bolt of sufficient length and adjustment, with 2
nuts, secure to damper through the hole.
• Adjust to correct opening.
MINIMUM DAMPER OPENING
(SQUARE INCHES)
CHIMNEY
HEIGHT MASONRY APPLIANCE FACTORY BUILT APPLIANCE
633.8”
831.2”
10 28.7” 22.1”
15 26.1” 17.3”
20 23.7” 14.5”
25 22.7” 12.6”
30 21.6” 11.3”
35 10.8”
40 10.2”

8
W415-1071 / C / 01.11.12
4.0 FINISHING
4.1 ANDIRON AND GRATE ASSEMBLY
A. With the 2 andirons laying face
down, secure the grate overtop
using two ¼-20 bolts (supplied in
the manual baggie).
B. Install the grate/andiron assembly
to the burner base using four 1 ¼”
self tapping screws (supplied in the
manual baggie).
1
2
USE ONLY ACCESSORIES
DESIGNED FOR AND
LISTED WITH YOUR
SPECIFIC LOG SET.
4.2 BATTERY INSTALLATION
A. Remove all the logs.
B. The battery pack is located at the rear right corner
of the burner behind the pilot. If there is room, slide
the battery pack out to the right, otherwise lift up
carefully, making sure that the wires connected to
the battery pack do not become entangled.
C. Unfasten the Velcro and replace the 4 AA batteries.
D. Replace battery pack and log set (see “LOG
PLACEMENT” section).

9
W415-1071 / C / 01.11.12
4.3 LOG PLACEMENT
PhazerTM logs, exclusive to Napoleon Appliances, provide a unique and realistic glowing effect that is different
in every installation. Failure to follow these log placement instructions may cause sooting.
A. Place the rear log #1 onto
the locating studs on the
rear log support.
B. Position the holes on the
bottom of log #2 onto the
fibre embosses shown.
C. Position the bottom cavity
of log #3 onto the bracket
located in the front right
corner.
D. Position the pins on the
bottom of log #4 into the
holes on the left end of
log #1 and the left end of
log #2.
E. Place the end of log #5
on the right end of log
#1. The fork in the log
should straddle the knot
on top of the log #2.
Log colours may vary. During the initial use of the appliance, the colours will become more uniform as colour
pigments burn in during the heat activated curing process.
Positioning the logs improperly will cause flame impingement and carboning.
Blocked burner ports can cause an incorrect flame pattern, carbon deposits and delayed ignition. Use only
certified PhazerTM logs available from your authorized dealer/distributor.
!
WARNING
FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE
ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY
DAMAGE OR PERSONAL INJURY.
LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE
PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED
IGNITION MAY OCCUR.
THE LOGS ARE FRAGILE AND SHOULD BE HANDLED WITH CARE.
76.1A

10
W415-1071 / C / 01.11.12
4.4 MEDIA
A. Place lava or ember rock around the base of the appliance, making sure not to block any burner ports
or valve access. Retain a small amount of lava rock for step 3 and if applicable step 4.
B. Place formed charcoal lumps around the front and sides of the appliance.
C. Use remaining lava or ember rock to blend with the charcoal lumps.
D. GL30 ONLY: Sprinkle remaining lava rock onto the outer fibre ember beds to hide the seam.
IMPORTANT: DO NOT COVER FRONT SLOTS BENEATH THE ANDIRONS WITH MEDIA.
GL 18 GL 24 GL 30
LOGO
½"
LOGO
½"
Remove the backing of the logo supplied. Centre the logo
on the front of the appliance, ½” in from the left side, as
shown.
4.5 LOGO PLACEMENT
